Manufacturer
International Comfort Products
Model Number
PHD436000K000C1
Description
Performance 14 Packaged Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1173714 | ACCUMULATOR |
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1173702 | CAPACITOR RUN RD 370V 45+10MFD |
| 1178001 | CIRCUIT BOARD |
| 1177777 | COIL ASSEMBLY OUTDOOR 36 AL LF |
| 1177778 | COIL ASSEMBLY OUTDOOR 36 AL RT |
| 1177771 | COIL EVAPORATOR AL/CU |
| 1172619 | COIL REV VALVE 24V |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1176139 | COVER |
| 1176062 | COVER ASSEMBLY DUCT |
| 1176158 | DISTRIBUTOR 2 CKT |
| 1174361 | DISTRIBUTOR COND |
| 1185849 | ECM X-13 MTR CONTROL 3/4 HP |
| 1171219 | FAN PROP |
| 1172311 | FILTER DRIER |
| 1178502 | GRILLE ASSEMBLY 14-INCH |
| 1178501 | GRILLE ASSEMBLY 14-INCH |
| 1178435 | GRILLE ASSEMBLY 14-INCH |
| 1171267 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1178464 | INSUL ASSEMBLY BLOWER PANEL |
| 1178612 | INSUL ASSEMBLY ELEC PANEL LG |
| 1176083 | INSUL ASSEMBLY TOP EVAP |
| 1176140 | INSUL CONTROL PLATE |
| 1176146 | INSUL PANEL POWER ENTRY |
| 1176087 | INSUL PANEL RET DUCT |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1173634 | METERING DEVICE .042 |
| 1177596 | MOTOR BLOWER 1/230 3/4 VS 600-1200 |
| 1185076 | MOTOR CONDENSER 1/230/220 1/4 1100/900 |
| 1171357 | PAINT HAZ -HAZ- |
| 1178462 | PANEL COIL ACCESS LG |
| 1178463 | PANEL COMP ACCESS LG |
| 1176022 | PANEL CORNER 14-INCH COND |
| 1176082 | PANEL CRN 14-INCH |
| 1176025 | PANEL CRN 14-INCH HDR |
| 1176066 | PANEL DUCT |
| 1176145 | PANEL SIDE |
| 1177021 | PLATE ASY |
| 1178548 | PLATE COMP MTG |
| 1176143 | PLATE CONTROL |
| 1176076 | PLATE FAN TOP |
| 1177318 | PLUG COMP |
| 1178457 | RACEWAY OFM 11-INCH |
| 1176074 | SCROLL |
| 1178677 | SWITCH TEMP |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1176063 | TOP CONDENSER |
| 1171496 | TRANSFORMER |
| 1173708 | VALVE REVERSING |
| 1176869 | VALVE TXV 3.0 TON R410A |
| 1177025 | WHEEL 11-10DD CCW |
