Manufacturer
Hestan
Model Number
KRG485GDNGPP
Description
Range, 5 Burner With Griddle, All Gas, 48-inch - N
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACCESS PANEL, MEAT PROBE, 36-INCH RANGE |
|
|
ADAPTER, STRAIGHT, 1/2 NPT X 3/8-INCH CC |
|
|
ANTI-TIP BRACKET, INDOOR RANGE |
|
|
ASSEMBLY, PANEL, SIDE, LEFT, 36-INCH RANGE |
|
|
ASSEMBLY, PANEL, SIDE, RIGHT, 36-INCH RANGE |
|
|
ASSEMBLY, PORCELAIN, WELDMENT, DOOR LINER, LARGE OVEN, 48-INCH RANGE, BLACK |
|
|
ASSEMBLY, PORCELAIN, WELDMENT, DOOR LINER, SMALL OVEN, 48-INCH RANGE, BLACK |
|
|
ASSEMBLY, WELDMENT, HOLDER, HINGE, LEFT, 36-INCH RANGE |
|
|
ASSEMBLY, WELDMENT, HOLDER, HINGE, RIGHT, 36-INCH RANGE |
|
|
BAFFLE, CONVECTION, PORCELAINED, LARGE OVEN, 48-INCH RANGE |
|
|
BAFFLE, CONVECTION, PORCELAINED, SMALL OVEN, 48-INCH RANGE |
|
|
BLADE, CONV FAN, 152MM |
|
|
BOTTOM, COVER, FLAME SPREADER, 18-INCH GAS OVEN - BLACK |
|
|
BOTTOM, COVER, FLAME SPREADER, 30 GAS OVEN - BLACK |
|
|
BRACKET, HIS, 18-INCH OVEN, ALL GAS |
|
|
BRACKET, MOUNTING, BROIL BURNER, 36 GAS OVEN |
|
|
BRACKET, MOUNTING, HSI, BROIL |
|
|
BRACKET, MOUNTING, RISER, REAR ACCESS, RANGETOP |
|
|
BRACKET, REGULATOR, RANGES |
|
|
BRACKET, SUPPORT, KICK PANEL, 48-INCH RANGE GAS |
|
|
BULLNOSE, RANGETOP, WA - 48 |
|
|
BURNER BASE ASSEMBLY, DUAL FLOW, 15.5K - LP |
|
|
BURNER BASE ASSEMBLY, DUAL FLOW, 15.5K - NG |
|
|
BURNER BASE ASSEMBLY, DUAL FLOW, 23K - LP |
|
|
BURNER BASE ASSEMBLY, DUAL FLOW, 23K - NG |
|
|
BURNER BASE ASSEMBLY, SINGLE FLOW, SEALED BURNER - LP |
|
|
BURNER BASE ASSEMBLY, SINGLE FLOW, SEALED BURNER - NG |
|
|
BURNER BASE, SEALED BURNER, SF |
|
|
BURNER RING, SEALED BURNER, SF |
|
|
BURNER, INFRARED, GRIDDLE, RESIDENTIAL INDOOR |
|
|
BURNER, IR, BROILER, RESIDENTIAL INDOOR |
|
|
BURNER, TUBE, 18K BTU |
|
|
BURNER, U STYLE |
|
|
CLAMP, GAS VALVE, RESIDENTIAL INDOOR |
|
|
COMPRESSION TUBE FITTING, 1/2-INCH CC X 1/2-INCH MNPT |
|
|
CONTROL PANEL, CHIN ASSEMBLY - 485GD RANGE |
|
|
CORD, POWER, 6 FT, 15A, 3/14 AWG, SJTW |
|
|
COVER, ACCESS, COOLING FAN, 18-INCH OVEN, GAS RANGE |
|
|
COVER, BROILER TUBE, GAS RANGE |
|
|
COVER, CONV FAN, 18-INCH OVEN, GAS RANGE |
|
|
COVER, DISPLAY CONN, SMALL, 48-INCH RANGE |
|
|
COVER, ELEC. CONNECTOR, OVEN DOOR, LARGE, 48-INCH RANGE |
|
|
COVER, EXHAUST, COOLING FAN - GAS OVEN |
|
|
COVER, FLUE, GAS RANGE, 36 |
|
|
COVER, GRIDDLE, ASSEMBLY, RESIDENTIAL INDOOR - 12 GAS |
|
|
COVER, INLET, BROIL BURNER, 36 GAS RANGE |
|
|
COVER, LH, ACCESS, COOLING FAN, GAS RANGE |
|
|
COVER, OVEN ACCESS, RANGETOP |
|
|
COVER, REAR, CASE LOWER, 18-INCH OVEN - GAS |
|
|
COVER, REAR, CASE LOWER, 30-INCH OVEN - GAS |
|
|
COVER, RH, ACCESS, COOLING FAN, GAS RANGE |
|
|
COVER, RISER, ISLAND, RESIDENTIAL INDOOR - 48 |
|
|
COVER, RTD PROBE - 30-INCH GAS |
|
|
COVER, SIDE, CONV FAN, 18-INCH OVEN, GAS RANGE |
|
|
COVER, TRAY, BURNER, INDOOR RESIDENTIAL |
|
|
CROSSMEMBER, FRONT, FRAME, RANGETOP - 48 |
|
|
D-BEAUTY RING, DUAL FLOW, RESIDENTIAL INDOOR |
|
|
D-CROSS RING, DUAL FLOW, RESIDENTIAL INDOOR |
|
|
D-DUAL BURNER HEAD, DUAL FLOW, RESIDENTIAL INDOOR |
|
|
D-INNER BURNER HEAD, DUAL FLOW, RESIDENTIAL INDOOR |
|
|
DEFLECTOR, AIR, MATTE BLACK, BOTTOM, DOOR, LARGE, 48-INCH RANGE |
|
|
DIFFUSER LENS, PRESS FIT |
|
|
DRIP PAN, 365 RANGETOP |
|
|
ELBOW, 1/2 NPT |
|
|
ELBOW, ORIFICE, IR BURNER |
|
|
ELBOW, SINGLE FLOW, FRONT, ASSEMBLY |
|
|
ENCLOSURE, COOLING FAN, 18-INCH OVEN, GAS RANGE |
|
|
ENCLOSURE, COOLING FAN, GAS RANGE |
|
|
ENDCAP, HANDLE, LH, OVEN DOOR, INDOOR |
|
|
ENDCAP, HANDLE, RH, OVEN DOOR, INDOOR |
|
|
FAN, CONVECTION, 36-INCH RANGE |
|
|
FAN, COOLING, RANGE, SMALL |
|
|
FLUE COVER, 18-INCH OVEN, GAS |
|
|
FLUE COVER, COMBINED, 36 GAS OVEN |
|
|
FRONT, FIREBOX, GRIDDLE, WA |
|
|
GAS ASSEMBLY, DOUBLE, ALL-GAS OVEN |
|
|
GAS ASSEMBLY, GRIDDLE, 12 |
|
|
GAS ASSEMBLY, SINGLE, ALL-GAS OVEN |
|
|
GASKET ASSEMBLY, CELL, OVEN, LARGE OVEN, 48-INCH RANGE |
|
|
GASKET ASSEMBLY, SMALL OVEN, 48-INCH RANGE |
|
|
GASKET, MAIN, SEALED BURNER, SF |
|
|
GASKET, WINDOW PACK, 36-INCH RANGE |
|
|
GASKET, WINDOW PACK, SMALL OVEN, 48-INCH RANGE |
|
|
GRATE ASSEMBLY, DUAL, RESIDENTIAL INDOOR |
|
|
GRATE ASSEMBLY, SINGLE, RESIDENTIAL INDOOR |
|
|
GREASE TRAY, GRIDDLE, RESIDENTIAL INDOOR, TEFLON COATED |
|
|
GRIDDLE PLATE, RESIDENTIAL INDOOR, WA - 12 |
|
|
GRILL, FRONT, RANGETOP, 48-INCH |
|
|
HANDLE, DOOR, OVEN, LARGE, 48-INCH GAS RANGE |
|
|
HANDLE, DOOR, SMALL OVEN, 48-INCH GAS RANGE |
|
|
HARNESS, WIRE, MAIN, 48-INCH ALL GAS RANGE |
|
|
HARNESS, WIRE, OVEN TO RANGETOP, 48-INCH RANGE (VW-1/FT1) |
|
|
HARNESS, WIRE, RANGETOP/RANGE, 485GD (VW-1/FT1) |
|
|
HEAD, BURNER, SEALED BURNER, SF |
|
|
HEAT SHIELD, LEFT, INDOOR OVEN |
|
|
HINGE, 18-INCH OVEN |
|
|
HINGE, 30-INCH OVEN |
|
|
HOLDER, ORIFICE, BULKHEAD, SMALL |
|
|
HOSE KIT, DUAL FLOW, RESIDENTIAL INDOOR - FRONT |
|
|
HOSE KIT, DUAL FLOW, RESIDENTIAL INDOOR - REAR |
|
|
HOSE, FLEX, 3/8 OD, 9-INCH , F-F, NUT/FERRULE(874 RASYWIP 8/16/22) |
|
|
HOSE, FLEX, 5/8OD X 1/2MIP X 1/2MIP, 8-INCH |
|
|
IGNITER, HOT SURFACE, 3.2 TO 3.6 AMP |
|
|
INSERT, BROILER PAN, INDOOR RANGE |
|
|
INSERT, CONTROL PANEL, 48 RANGE |
|
|
INSERT, PAN, BROILER, SMALL, INDOOR |
|
|
INSULATION, REAR, CONV. FAN, 1/2-INCH THK, 36-INCH RANGE |
|
|
JET HOLDER, MAIN, SEALED BURNER, SF/DF |
|
|
JOINER, FRONT, 48-INCH RANGE |
|
|
KIT, ORIFICE, VALVE, INDOOR - 062 |
|
|
KIT, ORIFICE, VALVE, INDOOR - 065 |
|
|
KIT, ORIFICE, VALVE, INDOOR - 073 |
|
|
KIT, ORIFICE, VALVE, INDOOR - 080 |
|
|
KIT, ORIFICE, VALVE, INDOOR - 087 |
|
|
KNOB ASSEMBLY, GRIDDLE TEMP, GAS, RESIDENTIAL INDOOR |
|
|
KNOB ASSEMBLY, MAIN BURNER, RESIDENTIAL INDOOR (2500-PCS AT GEETON WH 8/20) |
|
|
KNOB ASSEMBLY, OVEN FUNCTION, 18, GAS, RESIDENTIAL INDOOR |
|
|
KNOB ASSEMBLY, OVEN FUNCTION, GAS, RESIDENTIAL INDOOR |
|
|
KNOB ASSEMBLY, OVEN TEMP, 18, GAS, RESIDENTIAL INDOOR |
|
|
KNOB ASSEMBLY, OVEN TEMP, NON SC, RESIDENTIAL INDOOR |
|
|
KNOB ASSEMBLY, SINGLE FLOW, RESIDENTIAL INDOOR |
|
|
LED DRIVER / ISOLATOR BOARD |
|
|
LED LIGHT, PANEL MOUNT, 8MM |
|
|
LED MODULE, KNOB LIGHTING |
|
|
MANIFOLD, INDOOR, 485 RANGE |
|
|
MODULE, RE-IGNITER, SINGLE POINT, RI 120F-1, 120V, 3MA |
|
|
NUT, HEX, 1/4-28, CONV. FAN, RANGE |
|
|
NUT, PANEL, 3/8-INCH NPS |
|
|
ORIFICE HOLDER, OVEN |
|
|
ORIFICE, #42, MAIN, SEALED BURNER, SF-NG |
|
|
ORIFICE, #54, MAIN, SEALED BURNER-LP |
|
|
ORIFICE, HOOD, 37 DMS |
|
|
ORIFICE, HOOD, 48 DMS |
|
|
ORIFICE, HOOD, 52 DMS |
|
|
ORIFICE, HOOD, 56 DMS |
|
|
ORIFICE, MAIN, DUAL FLOW BURNER, INDOOR, #46 |
|
|
ORIFICE, MAIN, DUAL FLOW BURNER, INDOOR, #52 |
|
|
ORIFICE, MAIN, DUAL FLOW BURNER, INDOOR, #55 |
|
|
ORIFICE, MAIN, DUAL FLOW BURNER, INDOOR, #58 |
|
|
ORIFICE, SIMMER, DUAL FLOW BURNER, INDOOR, #73 |
|
|
ORIFICE, SIMMER, DUAL FLOW BURNER, INDOOR, #78 |
|
|
ORIFICE, SPUD, DMS 47 |
|
|
ORIFICE, SPUD, DMS 50 |
|
|
ORIFICE, SPUD, DMS 55 |
|
|
ORIFICE, SPUD, DMS 56 |
|
|
PAN, BROILER, SMALL, INDOOR |
|
|
PAN, DRIP, ACCESSORY, GRILL |
|
|
PLATE, MOUNTING, CONVECTION FAN MOTOR, 36 GAS RANGE |
|
|
PLATE, MOUNTING, CONVECTION FAN, RANGE, GAS - BLACK |
|
|
PLUG, FOR 1/4-20 SHCS, CHROME |
|
|
POP RIVET, 1/8DIAX .275L, SS |
|
|
RACK, INDOOR OVEN, 18-INCH |
|
|
RACK, LADDER, LH & RH, RANGE |
|
|
RACK, NO SLIDES, INDOOR OVEN, 30-INCH |
|
|
REAR COVER, 48-INCH RANGETOP |
|
|
REAR COVER, LH, 36-INCH RANGE |
|
|
RECEIVER, STANDARD, 36-INCH RANGE |
|
|
RECEPTACLE, BALL STUD,18LB PULL, C1663-028-3B |
|
|
REGULATOR, STRAIGHT-THRU, 1/2-INCH NPT, CONVERTIBLE, DD-RV48 (5-INCH /10-INCH W.C.) |
|
|
REGULATOR, STRAIGHT-THRU, 1/2-INCH NPT, CONVERTIBLE, DD-RV48, 5/10, CONVERTED TO LP |
|
|
RELAY BOARD, ELAN, EOC-U DEPOP |
|
|
RISER ASSEMBLY, LOW, INNER SIDE MOUNT, RESIDENTIAL INDOOR - 48 |
|
|
RISER ASSEMBLY, TALL, INNER SIDE MOUNT, RESIDENTIAL INDOOR - 48 |
|
|
RISER, ISLAND, INNER SIDE MOUNT, RESIDENTIAL INDOOR - 48 |
|
|
RTD PROBE, W/FLANGE, AMP CONNECTOR |
|
|
SELECTOR, 2 POSITION, RESIDENTIAL INDOOR |
|
|
SELECTOR, 8 POSITION, RESIDENTIAL INDOOR |
|
|
SERVICE NUT, KEPS, 1/4-20, ZN, PKG 4 |
|
|
SERVICE, ASSEMBLY, CONTROL PANEL INSERT, KRG484GD, KRG485GD |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - BLACK |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - BLUE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - BURGUNDY |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - DARK GRAY |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - GREEN |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - ORANGE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - PURPLE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - RED |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - SS |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - TURQUOISE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - WHITE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, LARGE OVEN, 48-INCH RANGE - YELLOW |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - BLACK |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - BLUE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - BURGUNDY |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - DARK GRAY |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - GREEN |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - ORANGE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - PURPLE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - RED |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - SS |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - TURQUOISE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - WHITE |
|
|
SERVICE, ASSEMBLY, DOOR SKIN, SMALL OVEN, 48-INCH GAS RANGE - YELLOW |
|
|
SERVICE, BULB, HALOGEN, G4 BI-PIN, 20W, PKG 2 |
|
|
SERVICE, BUMPER, RUBBER, .50 DIAM. X .156 H, PKG 4 |
|
|
SERVICE, CABLE HOLDER, PUSH IN, 3/8-INCH DIAMETER, PKG. 6 |
|
|
SERVICE, GASKET, VALVE, SADDLE MOUNT, PKG 6 |
|
|
SERVICE, GRATE, FOOTPAD, PKG 4 |
|
|
SERVICE, HOSE, FLEX, 1/2 OD, F-F, NUT/FERRULE - 024 |
|
|
SERVICE, HOSE, FLEX, 3/8 OD, F-M, NUT/FERRULE TO LOXIT - 015 |
|
|
SERVICE, HOSE, FLEX, 3/8 OD, F-M, NUT/FERRULE TO LOXIT - 024 |
|
|
SERVICE, HOSE, FLEX, 3/8 OD, F-M, NUT/FERRULE TO LOXIT - 030 |
|
|
SERVICE, HOSE, FLEX, 3/8 OD, F-M, NUT/FERRULE TO LOXIT - 048 |
|
|
SERVICE, HOSE, FLEX, 3/8 OD, F-M, NUT/FERRULE TO LOXIT - 065 |
|
|
SERVICE, IGNITOR KIT, DUAL FLOW BURNER |
|
|
SERVICE, IGNITOR KIT, SEALED BURNER, SINGLE FLOW |
|
|
SERVICE, LARGE HESTAN LOGO W/ RETAINING RINGS & TAPE |
|
|
SERVICE, LENS, LAMP, HALOGEN, 12V 20W, 65MM X 80MM |
|
|
SERVICE, MS, 10-24 X 1/2, HEX HD W/ LOCK WASHER, ZN, PKG 10 |
|
|
SERVICE, MS, 10-32 X 1/2, PH, PAN, BLK-OXIDE, SS, PKG 4 |
|
|
SERVICE, MS, 10-32 X 3/4-INCH , HEX, ZINC PLATED, STEEL, PKG 4 |
|
|
SERVICE, MS, 8-32 X .375, PH, PAN, SS, PKG 6 |
|
|
SERVICE, MS, 8-32 X .375, PH, ROUND HD, ZN, PKG 6 |
|
|
SERVICE, MS, M4 X 12, SEALED BURNER, PKG 4 |
|
|
SERVICE, MS, M5 X 0.8 X 18, HEXHD, SS, PKG 5 |
|
|
SERVICE, PANEL, KICK, 48-INCH RANGE |
|
|
SERVICE, PLUG, SNAP-IN, 5/16 HOLE, .047 - .078 PANEL THK., STEEL, NICKEL PLATED, PKG 4 |
|
|
SERVICE, SB, #8-32 X 3/16 DIA X 1/4L, SS, PKG 2 |
|
|
SERVICE, SCREW, MOUNTING, M5X12, SEALED BURNER, PKG 4 |
|
|
SERVICE, SMS, #10-24 X .50, HEXWSH, TYPE F, SS, PKG 10 |
|
|
SERVICE, SMS, #10-24 X 1/2, PH, PAN, TYPE F, SS, PKG 10 |
|
|
SERVICE, SMS, #8 X 1/2, PH, ROUND, BLK-OXIDE, SS, PKG 4 |
|
|
SERVICE, SMS, #8 X 3/8, PH, PAN, SS, PKG 10 |
|
|
SERVICE, SMS, #8 X 3/8, SLOT, HEXWSH, SS, PKG 6 |
|
|
SERVICE, SMS, #8-32 X 3/8, PH, PAN, TYPE F, SS, PKG 4 |
|
|
SERVICE, STANDOFF, MALE-FEMALE, 1/2-INCH L, #8-32, PKG 4 |
|
|
SERVICE, THERMOSTAT ASSEMBLY, GRIDDLE, RESIDENTIAL INDOOR |
|
|
SERVICE, WSH, FLAT, #10 (.203 X .375 X .020), BLK-OXIDE, 18-8 SS, PKG 6 |
|
|
SERVICE, WSH, FLAT, #10 (.218 X .437 X .032) BLK-OXIDE, 18-8 SS, PKG 2 |
|
|
SHELF, RESIDENTIAL INDOOR - 48 |
|
|
SHIELD, EXHAUST, 18-INCH GAS OVEN |
|
|
SHIELD, EXHAUST, 36 GAS OVEN |
|
|
SMS, #8-32 X 1/2, FLT, PAN, TYPE F, SS |
|
|
SNAP BUSHING, .50 MAX ID, BLACK |
|
|
SNAP BUSHING, 1.06-INCH MAX ID, BLACK |
|
|
STRAIN RELIEF, SNAP-IN, 3/4-INCH KNOCKOUT |
|
|
SUPPORT, PANEL, SIDE, LEFT, LOWER, 36-INCH RANGE |
|
|
SUPPORT, PANEL, SIDE, RIGHT, LOWER, 36-INCH RANGE |
|
|
SWITCH, HI-LIMIT, 265F (60TX25 611232) |
|
|
SWITCH, PLUNGER, N.O., OVEN DOOR |
|
|
SWITCH, PUSHBUTTON, 19MM, SPST, 5A, 250VAC |
|
|
TEE, FEMALE, 1/2 X 1/2 X 1/2 NPT |
|
|
TRANSFORMER, 20VA, 120V TO 12V, CLASS 2 |
|
|
TRANSFORMER, 40VA, 120VAC TO 12/24V, CLASS 2 |
|
|
TRIM, SIDE, LH, 48-INCH RANGE |
|
|
TRIM, SIDE, RH, 48-INCH RANGE |
|
|
VALVE, DUAL FLOW, RESIDENTIAL INDOOR -LP |
|
|
VALVE, DUAL FLOW, RESIDENTIAL INDOOR -NG |
|
|
VALVE, SINGLE FLOW, RESIDENTIAL INDOOR -LP |
|
|
VALVE, SINGLE FLOW, RESIDENTIAL INDOOR -NG |
|
|
WASHER, FLAT, M6 |
|
|
WINDOW PACK, 36-INCH RANGE |
|
|
WINDOW PACK, SMALL OVEN, 48-INCH RANGE |
|
|
WSH, C'SUNK, #8, SS |
|
|
WSH, FLAT, #8 (.169 X .304 X .032), SS |
