Model Image
Manufacturer

HP

Model Number

C4112A

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
C7843-67901 C7843-67901 16MB, 100-PIN SDRAM DIMM MEMORY MODULE
C7843A C7843A 16MB, 100-PIN SDRAM DIMM MEMORY MODULE
C4137-67901 C4137-67901 16MB, 100-PIN, 32-BIT, 60NS, EDO DRAM DIMM MEMORY MODULE
C4137A C4137A 16MB, 100-PIN, 32-BIT, 60NS, EDO DRAM DIMM MEMORY MODULE
C4286A C4286A 2MB FLASH DIMM MEMORY - FONT STORAGE DEVICE
C2985-69031 C2985-69031 3.5GB EIO HARD DRIVE - LASERJET EIO FONT/PRINT JOB STORAGE
Q7707-67951 Q7707-67951 32MB, 100-PIN SDRAM DIMM MEMORY MODULE
C4135-67901 C4135-67901 4MB, 100-PIN, 32-BIT, 60NS, EDO DRAM DIMM MEMORY MODULE
Q1866-69001 Q1866-69001 500-SHEET FEEDER AND PAPER TRAY - PRINTER SITS ON TOP OF THIS UNIT - INCLUDES 50
C4293A C4293A 8MB SIMPLIFIED CHINESE MROM DIMM - FOR LASERJET PRINTERS
C4292A C4292A 8MB TRADITIONAL CHINESE MROM DIMM - FOR LASERJET PRINTERS
C7842-67901 C7842-67901 8MB, 100-PIN SDRAM DIMM MEMORY MODULE
C4136-67901 C4136-67901 8MB, 100-PIN, 32-BIT, 60NS, EDO DRAM DIMM MEMORY MODULE
C4136A C4136A 8MB, 100-PIN, 32-BIT, 60NS, EDO DRAM DIMM MEMORY MODULE
C7842AX C7842AX 8MB, 100MHZ SDRAM DIMM MEMORY MODULE
RB2-1980-000 RB2-1980-000 BIN FULL LEVER - FACE DOWN OUTPUT TRAY SENSOR LEVER
5184-5224 5184-5224 BLACK TONER CARTRIDGE - WITH 'ULTRA-PRECISE' TONER - HAS MAXIMUM CAPACITY TONER
C4129X C4129X BLACK TONER CARTRIDGE - WITH 'ULTRA-PRECISE' TONER - HAS MAXIMUM CAPACITY TONER
RG5-3523-000 RG5-3523-000 CABLE ASSEMBLY
RG5-7073-000 RG5-7073-000 CABLE ASSEMBLY - A 20-PIN (F) CONNECTOR TO TWO 14CM (5.5IN) CABLES WITH 7-PIN (F
RG5-3562-000 RG5-3562-000 CABLE ASSEMBLY - A 22-PIN (F) CONNECTOR TO MANY CABLES: 32.4CM (12.8IN) WITH 8-P
RH7-5195-000 RH7-5195-000 CASSETE PAPER PICKUP SOLENOID
RB2-1906-000 RB2-1906-000 CLEANING BRUSH
RG5-5438-030 RG5-5438-030 CONTROL PANEL - DOES NOT INCLUDE OVERLAY
RB2-1759-000 RB2-1759-000 CONTROL PANEL LEAF SPRING
RB2-1978-000 RB2-1978-000 DEFLECTION PAWL - DIVERTS PAPER OUTPUT TO REAR TRAY OR TOP
RS6-0357-000 RS6-0357-000 DELIVERY ROLLER SHAFT GEAR
RB2-1758-000 RB2-1758-000 DISPLAY COVER - CONTROL PANEL DISPLAY COVER
RB2-1732-000 RB2-1732-000 DOOR SWITCH - INDICATES WHEN TONER DOOR IS AJAR
RB2-1739-000 RB2-1739-000 DOOR SWITCH SPRING - PROVIDES TENSION FOR TONER DOOR SWITCH
J3111A J3111A ETHERNET 10BASE-T/10BASE2 AND LOCALTALK (RJ-45, BNC, LOCALTALK) EIO NETWORK PCA
RB2-2042-000 RB2-2042-000 EXTENSION LOCK - PAPER LENGTH EXTENSION LOCK
RB2-1747-030 RB2-1747-030 FACE DOWN AUXILIARY COVER
RG5-3554-000 RG5-3554-000 FACE DOWN BIN FULL CABLE
RG9-1337-000 RG9-1337-000 FACE DOWN GUIDE ROLLER
RS5-2225-020 RS5-2225-020 FACE DOWN GUIDE ROLLER TORSION SPRING
RG5-3552-060 RG5-3552-060 FACE UP TRAY ASSEMBLY - DROP DOWN OUTPUT TRAY WITH EXTENSION
RB2-1740-020 RB2-1740-020 FAN GROUNDING PLATE AND FAN HOUSING
RF5-2634-000 RF5-2634-000 FEED ROLLER - MOVES PAPER AFTER PICKUP ROLLER
RB2-3232-000 RB2-3232-000 FEED ROLLER - SHAFT WITH ROUND ROLLERS THAT MOVES PAPER AFTER PICKUP ROLLER ON 5
RG5-4211-000 RG5-4211-000 FEEDER CONTROLLER PCA ASSEMBLY
RB3-0435-000 RB3-0435-000 FRONT COVER - TOP FRONT COVER BETEERN THE FRAME SIDES
RG5-3561-000 RG5-3561-000 FUSER CABLE
C4110-69018 C4110-69018 FUSING ASSEMBLY - 110 VOLTS
RG5-4183-110 RG5-4183-110 GEAR DRIVE ASSEMBLY FOR 500-SHEET PAPER PICKUP
RB2-1736-000 RB2-1736-000 GROUNDING PLATE
RB2-1990-000 RB2-1990-000 GROUNDING PLATE
RB2-1735-000 RB2-1735-000 GROUNDING PLATE
RB2-1734-000 RB2-1734-000 GROUNDING PLATE
RB1-6141-000 RB1-6141-000 GROUNDING PLATE
J7934G J7934G HP JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BO
C6072-60306 C6072-60306 HP-GL/2 DRIVER SOFTWARE FOR AUTOCAD - FOR DOS AND WINDOWS 3.1/95/NT 4.0 - ON 3.5
C6072-60307 C6072-60307 HP-GL/2 DRIVER SOFTWARE FOR AUTOCAD - FOR DOS AND WINDOWS 3.1/95/NT 4.0 - ON 3.5
C6072-60304 C6072-60304 HP-GL/2 DRIVER SOFTWARE FOR AUTOCAD - FOR DOS AND WINDOWS 3.1/95/NT 4.0 - ON 3.5
C6072-60305 C6072-60305 HP-GL/2 DRIVER SOFTWARE FOR AUTOCAD - FOR DOS AND WINDOWS 3.1/95/NT 4.0 - ON 3.5
C6072-60301 C6072-60301 HP-GL/2 DRIVER SOFTWARE FOR AUTOCAD - FOR DOS AND WINDOWS 3.1/95/NT 4.0 - ON 3.5
RB3-0426-000 RB3-0426-000 INNER COVER - TRAY SIZE SENSOR COVER
C4110-90035 C4110-90035 INSTALLATION GUIDE - INSTRUCTION SHEET FOR INSTALLING THE USER GUIDE CD-ROM ON A
92215N 92215N INTERFACE CABLE KIT - FOR HP PERIPHERALS DESIGNED FOR USE IN AN APPLETALK/PHONEN
J3113A J3113A JETDIRECT 600N INTERNAL PRINT SERVER (10BASE-T AND 100BASE-TX) LAN INTERFACE BOA
J4167-61001 J4167-61001 JETDIRECT 600N TOKEN RING LAN INTERFACE BOARD - DB-9 AND RJ-45 CONNECTORS
J7934-69011 J7934-69011 JETDIRECT 610N INTERNAL PRINT SERVER (10BASE-T AND 100BASE-TX) LAN INTERFACE BOA
J4167-69001 J4167-69001 JETDIRECT 610N TOKEN RING LAN INTERFACE BOARD - DB-9 AND RJ-45 CONNECTORS
J6057AR J6057AR JETDIRECT 615N INTERNAL PRINT SERVER (10BASE-T AND 100BASE-TX) LAN INTERFACE BOA
J4135-61001 J4135-61001 JETDIRECT CONNECTIVITY CARD - HAS ONE USB PORT, ONE SERIAL (DB9) PORT, AND ONE L
RB2-1887-000 RB2-1887-000 LARGE FEED BELT - WIDE BELT IN MIDDLE OF ASSEMBLY
C4110-67927 C4110-67927 LASERJET 5000 SERIES MAINTENANCE KIT (120V) - INCLUDES FUSER ASSEMBLY, SEPARATIO
C4110-91041 C4110-91041 LASERJET 5000 SERIES SERVICE MANUAL
C4110-40004 C4110-40004 LASERJET 5100 CONTROL PANEL OVERLAY (ENGLISH)
5851-1890 5851-1890 LASERJET PART LIST BOOKLET - COVERS LASERJET 1005, 1010, 1012, 1015, 1200, 2300,
5851-1891 5851-1891 LASERJET QUICK REFERENCE SERVICE GUIDE (MONOCHROME) - VOLUME IV
RS5-2952-000 RS5-2952-000 LATCH PLATE SPRING - HOLDS TENSION ON REAR TRAY LATCHES
RB2-3284-000 RB2-3284-000 LEAF SPRING - PROVIDES TENSION ON TRAY FOR PROPER ALIGNMENT
RB2-1825-000 RB2-1825-000 LEAF SPRING - TRAY SIZE SENSOR FINGERS
RB2-3286-000 RB2-3286-000 LEAF SPRING - TRAY SIZE SENSOR SPRING
RB2-1772-000 RB2-1772-000 LEAF SPRING FOR TRAY 1
RB3-0437-000 RB3-0437-000 LEFT AUXILIARY COVER - TOP OF THE LEFT SIDE COVER
RB2-1756-020 RB2-1756-020 LEFT CORNER COVER - LOCATED BELOW THE FRONT DROP DOOR TRAY
RB3-0439-000 RB3-0439-000 LEFT COVER - LEFT FRONT FRAME COVER
RB2-1992-020 RB2-1992-020 LEFT LATCH BLOCK - HOUSING FOR LEFT SIDE TRAY LATCH
RB1-6149-000 RB1-6149-000 LEFT PICKUP ROLLER BUSHING
RB2-1815-000 RB2-1815-000 LEFT PICKUP ROLLER COLLAR - HOUSES SHAFT BUSHING
RB2-1989-000 RB2-1989-000 LEFT SIDE BUSHING FOR LOWER DELIVERY ROLLER
RG5-3550-040 RG5-3550-040 LEFT SIDE COVER ASSEMBLY
RB2-1976-020 RB2-1976-020 LEFT SIDE REAR FACE UP TRAY LATCH
RB2-1904-000 RB2-1904-000 LEFT SIDE TRANSFER ROLLER BUSHING
RB2-1796-000 RB2-1796-000 LEFT SIDE TRAY 1 PICKUP ROLLER SHAFT CAM
RB2-1808-000 RB2-1808-000 LEVER SPRING - PROVIDES TENSION FOR PAPER SENSOR FLAG
RB1-6251-000 RB1-6251-000 LOWER DELIVERY ROLLER - PRESSES AGAINST THE LOWER DELIVERY ROLLER SHAFT ASSEMBLY
RB2-1985-000 RB2-1985-000 LOWER OUTPUT DELIVERY ROLLER - SHAFT WITH FOUR ROLLERS
RB2-1782-000 RB2-1782-000 LOWER TRAY PAPER SENSOR LEVER
C4110-69035 C4110-69035 MAINTENANCE KIT - FOR 120 VAC - INCLUDES FUSER ASSEMBLY, SEPARATION ROLLERS, TRA
C4110-99028 C4110-99028 MANUAL BUNDLE - INCLUDES 'GETTING STARTED' GUIDE AND POCKET QUICK REFERENCE GUID
RB2-1781-000 RB2-1781-000 MULTI PURPOSE TRAY PAPER SENSOR LEVER
RB2-1744-000 RB2-1744-000 ON/OFF SWITCH
RF5-4117-000 RF5-4117-000 PAD ASSEMBLY
RF5-2635-000 RF5-2635-000 PAPER ARM
RS6-0351-000 RS6-0351-000 PAPER FEED GEAR
RS6-0352-000 RS6-0352-000 PAPER FEED GEAR
RB1-6195-000 RB1-6195-000 PAPER FEED PULLEY - IDLER PULLEY FOR SMALL BELTS
RB1-6192-000 RB1-6192-000 PAPER FEED SHAFT
RB2-1886-000 RB2-1886-000 PAPER FEED SHAFT - DRIVES ALL THREE BELTS
RB2-1780-000 RB2-1780-000 PAPER GUIDE - GUIDES PAPER FROM PICKUP ROLLER TO FEED ROLLER
RG5-6197-000 RG5-6197-000 PAPER GUIDE - TRAY 1 PAPER GUIDE PLATE ASSEMBLY
RG5-3544-000 RG5-3544-000 PAPER PICKUP DRIVE ASSEMBLY
RB1-8865-000 RB1-8865-000 PAPER PICKUP ROLLER (D-SHAPED) - SOLD INDIVIDUALLY
RB2-1821-030 RB2-1821-030 PAPER PICKUP ROLLER ASSEMBLY (D-SHAPED) - RUBBER ROLLER ON A PLASTIC FRAME - LOC
RB2-1783-000 RB2-1783-000 PAPER SENSOR LEVER SPRING
RB2-1784-000 RB2-1784-000 PAPER SENSOR LEVER SPRING - HOLDS TENSION ON SENSOR ARM
RB2-1820-040 RB2-1820-040 PICKUP ROLLER - TRAY 1 PICKUP ROLLER
RF5-2636-000 RF5-2636-000 PICKUP ROLLER ASSEMBLY - PICKS PAPER OUT OF TRAY
RB2-3314-000 RB2-3314-000 PICKUP ROLLER COUPLER
RB2-1800-000 RB2-1800-000 PICKUP ROLLER SHAFT - TRAY 2
RB1-2190-000 RB1-2190-000 PICKUP ROLLER SPRING HOOK
WS6-5092-000 WS6-5092-000 POWER CONNECTOR - SUPPLIES POWER TO OPTIONAL PAPER TRAYS
8120-6802 8120-6802 POWER CORD (FLINT GRAY) - 2.3M (7.5FT) LONG - HAS 90 DEGREE (F) RECEPTACLE (FOR
RG5-3545-000 RG5-3545-000 POWER INLET ASSEMBLY - A/C INPUT AND POWER SWITCH
C4110-67917 C4110-67917 POWER SUPPLY ASSEMBLY WITH RIBBON CABLE - 100-120VAC INPUT
C4110-67918 C4110-67918 POWER SUPPLY ASSEMBLY WITH RIBBON CABLE - 220/240VAC INPUT
RG5-3551-100 RG5-3551-100 REAR COVER ASSEMBLY
RG5-3553-000 RG5-3553-000 REAR DOOR SENSOR ASSEMBLY - ARM AND MOUNT ASSEMBLY
RB3-0404-000 RB3-0404-000 RETURN COVER - ACCESS TO PAPER PICKUP ROLLER
RG5-3624-100 RG5-3624-100 REVERSING ASSEMBLY FOR DUPLEXER ASSEMBLY
RH2-5338-000 RH2-5338-000 RIBBON CABLE - FROM PAPER PCA TO CONTROLLER PCA
RH2-5337-000 RH2-5337-000 RIBBON CABLE - HAS TWO 40-PIN (M) EDGE CONNECTORS - 1.4CM (0.6IN) LONG
RB3-0436-000 RB3-0436-000 RIGHT AUXILIARY COVER - TOP OF THE RIGHT SIDE FRAME
RB2-1755-020 RB2-1755-020 RIGHT CORNER COVER - LOCATED BELOW THE FRONT DROP DOWN TRAY
RB3-0438-000 RB3-0438-000 RIGHT COVER - RIGHT FRONT FRAME COVER
RB2-1991-020 RB2-1991-020 RIGHT LATCH BLOCK - HOUSING FOR RIGHT SIDE TRAY LATCH
RB3-0425-000 RB3-0425-000 RIGHT MOUNT
RB2-1804-000 RB2-1804-000 RIGHT PICKUP ROLLER BUSHING
RB2-1803-000 RB2-1803-000 RIGHT PICKUP ROLLER COLLAR - HOUSES SHAFT BUSHING
RB2-1988-020 RB2-1988-020 RIGHT SIDE BUSHING FOR LOWER DELIVERY ROLLER
RB2-1749-040 RB2-1749-040 RIGHT SIDE COVER ASSEMBLY
RB2-1903-000 RB2-1903-000 RIGHT SIDE TRANSFER ROLLER BUSHING
RB2-1797-000 RB2-1797-000 RIGHT SIDE TRAY 1 PICKUP ROLLER SHAFT CAM
RB2-1998-000 RB2-1998-000 ROLLER - UPPER ROLLER OF FACE-DOWN ROLLER GUIDE - 4 USED
RB2-1802-000 RB2-1802-000 ROLLER CAM - LEFT SIDE PICKUP ROLLER CAM
RB2-1805-000 RB2-1805-000 ROLLER CAM - RIGHT SIDE PICKUP ROLLER CAM
RB2-1997-000 RB2-1997-000 ROLLER HOLDER - FACE DOWN GUIDE ROLLER HOLDER
C2933A C2933A RS-232C SERIAL CABLE - 9-PIN (M) TO 25-PIN (F) - 3.0M (9.8FT) LONG
RB2-1807-000 RB2-1807-000 SENSOR FLAG LEVER - PAPER FEED SENSOR ARM
RB2-1791-000 RB2-1791-000 SENSOR LEVER - TRAY 2 PAPER OUT SENSOR
RB2-1790-000 RB2-1790-000 SENSOR MOUNT
RG5-4212-020 RG5-4212-020 SENSOR PCA - TRAY SIZE SENSOR PCA - HAS FOUR MICRO SWITCHS ACUATED BY THE TRAY S
C2809A C2809A SERIAL CABLE ADAPTER - 9-PIN (M) TO 25-PIN (F)
RF5-2421-000 RF5-2421-000 SHUTTER LEVER - CONNECTS TO LASER SHUTTER
RB2-1888-000 RB2-1888-000 SMALL PAPER FEED BELT - ONE ON EACH SIDE OF WIDE BELT
RB2-1731-000 RB2-1731-000 SWITCH ROD - MECHANICAL LINK BETWEEN ON/OFF SWITCH LEVER AND ELECTRICAL ON/OFF S
RB2-1856-040 RB2-1856-040 TONER CARTRIDGE ENGAGEMNET ARM
RB2-1774-000 RB2-1774-000 TONER CARTRIDGE GUIDE - LEFT SIDE
RB2-1775-000 RB2-1775-000 TONER CARTRIDGE GUIDE - RIGHT SIDE
5090-3379 5090-3379 TONER CLEANING CLOTH - SPECIALLY TREATED CLOTH FOR ABSORBING TONER (1 PER PACKAG
RB2-1748-000 RB2-1748-000 TOP COVER - REAR PORTION OF THE TOP COVER
RG5-3558-000 RG5-3558-000 TOP OF PAGE SENSOR CABLE
RG5-3525-040 RG5-3525-040 TRANSFER GUIDE ASSEMBLY - GUIDES PAPER INTO TRANSFER ROLLER
RB2-1905-000 RB2-1905-000 TRANSFER ROLLER BUSHING COVER - RIGHT SIDE
C4110-67910 C4110-67910 TRANSFER ROLLER KIT - TRANSFER ROLLER WITH TOOLS AND REPAIR INSTRUCTION GUIDE
RS5-2431-000 RS5-2431-000 TRANSFER ROLLER SPRING - PROVIDES TENSION FOR ROLLER BUSHING
RS5-1392-000 RS5-1392-000 TRAY 1 AND 2 LEFT SIDE PICKUP ROLLER SHAFT BUSHING
RB1-6177-000 RB1-6177-000 TRAY 1 AND 2 PICKUP SHAFT BUSHING - RIGHT SIDE
RB1-6179-000 RB1-6179-000 TRAY 1 AND 2 PICKUP SHAFT BUSHING - RIGHT SIDE
RH7-5194-000 RH7-5194-000 TRAY 1 PAPER PICKUP SOLENOID - SL404
RG5-3519-070 RG5-3519-070 TRAY 1 PICKUP ROLLER ASSEMBLY - SHAFT/ROLLER ASSEMBLY THAT FEEDS PAPER FROM PAPE
RB1-6130-000 RB1-6130-000 TRAY 1 PICKUP ROLLER GEAR
RB1-6134-040 RB1-6134-040 TRAY 1 SENSOR ARM
RB1-6136-000 RB1-6136-000 TRAY 1 SENSOR ARM SPRING - HOLDS TENSION ON SENSOR ARM
RF5-2397-000 RF5-2397-000 TRAY 2 LEFT RAIL - LEFT SIDE TRAY SUPPORT
RG5-3521-040 RG5-3521-040 TRAY 2 PAPER PICKUP ROLLER ASSEMBLY
RS5-0695-000 RS5-0695-000 TRAY 2 PICKUP ROLLER SHAFT DRIVE GEAR
RF5-2398-030 RF5-2398-030 TRAY 2 RIGHT RAIL - RIGHT SIDE TRAY SUPPORT
RG9-1485-000 RG9-1485-000 TRAY 2 SEPARATION PAD WITH SPRING
RS5-2434-000 RS5-2434-000 TRAY 2 SHAFT GEAR SPRING - HOLDS TENSION ON SHAFT HOOK
RB3-0441-000 RB3-0441-000 TRAY COVER - REAR TRAY COVER FOR 500 SHEET UNIVERSAL PAPER TRAY
RB2-1975-020 RB2-1975-020 TRAY LATCH - FOR RIGHT SIDE, REAR FACE UP
RF5-4151-000 RF5-4151-000 TRAY SENSOR ASSEMBLY
RB2-1977-000 RB2-1977-000 TRAY SUPPORT STRAP - SUPPORTS REAR DROP DOWN OUTPUT TRAY
RH7-1431-000 RH7-1431-000 TUBEAXIAL FAN
RG5-3542-090 RG5-3542-090 UPPER DELIVERY ROLLER ASSEMBLY - PAPER OUTPUT ROLLER ASSEMBLY - INCLUDES RIGHT A
C4110-60117 C4110-60117 WORLDWIDE MULTI-LINGUAL USER MANUAL - ON CD-ROM
Main Menu x
