Manufacturer
HP
Model Number
CH956A
Description
Hp Designjet L25500 60-inch Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
256MB, 184MHZ, SDRAM DIMM MEMORY MODULE |
|
|
60-INCH SPINDLE |
|
|
AEROSOL FILTER AND FAN ASSEMBLY |
|
|
AIR PRESSURE SYSTEM (APS) ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
AIR PRESSURE SYSTEM (APS) ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
BROKEN BAG FIXING TOOLS |
|
|
CABLE PLATE BUNDLE (CABLES) - FOR 60-INCH PLOTTERS |
|
|
CARRIAGE ASSEMBLY - DOES NOT INCLUDE THE CARRIAGE PCA, ENCODER SENSOR, AND COLOR |
|
|
CARRIAGE FLEX CABLES - FOR DESIGNJET PRINTERS |
|
|
CARRIAGE PC BOARD - FOR THE DESIGNJET Z6100 PRINTER SERIES |
|
|
CARRIAGE STOPPER - INCLUDES CARRIAGE STOPPER SCREW AND MEDIA-AXIS MOTOR BRACKET |
|
|
CARTRIDGES TRAYS - LOCATED ON THE LOWER INK SUPPLY STATION (ISS) |
|
|
CENTER GUIDE (MEDIA INPUT) ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
CENTER GUIDE (MEDIA INPUT) ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
CENTER PLATEN ASSEMBLY - INCLUDES THE ATTACHMENT SCREW RETAINER - FOR 60-INCH PL |
|
|
COLOR SENSOR (SOL) SHUTTER PROTECTOR |
|
|
COLOR SENSOR ASSEMBLY - FOR DESIGNJET PRINTERS |
|
|
COMPLETE PINCHWHEEL ASSEMBLY - INCLUDES THE MEDIA SENSOR - FOR 60-INCH PLOTTERS |
|
|
CONTROL PANEL ASSEMBLY - INCLUDES CABLE AND FERRITE CORES |
|
|
CPU FAN ASSEMBLY |
|
|
CROSS-BRACE ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
CURING FAN |
|
|
CURING FAN CABLE - FOR 60-INCH PLOTTERS |
|
|
CURING FANS COVER - DOES NOT INCLUDE FANS - FOR 60-INCH PLOTTERS |
|
|
CURING GRILLE - FOR 60-INCH PLOTTERS |
|
|
CURING HOLDER BRACKET |
|
|
CURING MODULE BASE - DOES NOT INCLUDE THE FANS - FOR 60-INCH PLOTTERS |
|
|
CURING RESISTORS - FOR 60-INCH PLOTTERS |
|
|
CURING THERMAL SWITCH |
|
|
CUTTER ASSEMBLY |
|
|
DRIVE ROLLER ENCODER KIT - FOR 42-INCH PLOTTERS |
|
|
DRIVE ROLLER ENCODER KIT - FOR 60-INCH PLOTTERS |
|
|
DRIVE ROLLER GEAR (OVERDRIVE GEAR) KIT - INCLUDES ROLLER BRAKE ASSEMBLY |
|
|
DROP DETECTOR SENSOR - FOR DESIGNJET PRINTERS |
|
|
DRYER AC INPUT ASSEMBLY |
|
|
DRYER FAN CABLE - FOR 60-INCH PLOTTERS |
|
|
DRYER GRILLE - LOCATED ON THE DRYER MODULE |
|
|
DRYER IR TEMPERATURE SENSOR - FOR 60-INCH PLOTTERS |
|
|
DRYER MODULE - INCLUDES THERMAL SWITCH AND RESISTORS - FOR 60-INCH PLOTTERS |
|
|
ELECTRONICS MODULE CABLE KIT - FOR THE DESIGNJET L25500 PRINTER SERIES |
|
|
ELECTRONICS MODULE EXTENSION - FOR 60-INCH PLOTTERS |
|
|
EMPTY ELECTRONICS MODULE ASSEMBLY |
|
|
ENCODER STRIP AND SENSOR KIT - FOR 42-INCH PLOTTERS |
|
|
FOOT ASSEMBLY - FOR THE DESIGNJET L25500 PRINTER SERIES |
|
|
FOOT BRACE ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
FOOT BRACE ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
FRONT PANEL WINDOW COVER - FOR 60-INCH PLOTTERS |
|
|
HARD DISK DRIVE (HDD) - INCLUDES HOLDER AND SCREWS |
|
|
HARDWARE KIT - INCLUDES SCREWS FOR LEGS ASSEMBLY |
|
|
HEATER CONTROL ASSEMBLY COOLING FAN (PETISA) |
|
|
HEATERS CONTROL ASSEMBLY (PETISA) - INCLUDES COOLING FAN |
|
|
INK SUPPLY STATION TO CARTRIDGE CABLE CONNECTOR |
|
|
INK SUPPLY TUBE CLIPS |
|
|
INPUT FEED ROLLER ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
INPUT FEED ROLLER ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
INPUT FEED ROLLER LEVERS (TWO USED) |
|
|
INTERCONNECT PCA - CONTROLS SEVERAL MOTORS AND IS ALSO USED AS A CONNECTIONS BOA |
|
|
IR CURING SENSOR - FOR 60-INCH PLOTTERS |
|
|
IR CURING SENSOR FAN - FOR 60-INCH PLOTTERS |
|
|
LEFT AND RIGHT SIDE CURING TRIMS |
|
|
LEFT AND RIGHT SIDE STAND SUPPORTS |
|
|
LEFT COVER ASSEMBLY - FOR THE DESIGNJET L25500 PRINTER SERIE |
|
|
LEFT SCAN-AXIS BRACKET |
|
|
LEFT SIDE CURING COVER |
|
|
LEFT SIDE ROLLFEED MODULE ASSEMBLY |
|
|
LEFT SIDE TRIM ASSEMBLY |
|
|
LEG COVER - COVERS BOTH THE LEFT AND RIGHT LEG ASSEMBLIES |
|
|
LEGS ASSEMBLY - FOR THE DESIGNJET Z6100 PRINTER SERIES |
|
|
LINE SENSOR ASSEMBLY - INCLUDES HOLDER AND CABLE |
|
|
LOWER INK SUPPLY STATION (ISS) - INCLUDES THE CARTRIDGE TRAYS |
|
|
MEDIA PRESENCE SENSOR |
|
|
MEDIA-AXIS MOTOR - DRIVES THE DRIVE ROLLER ASSEMBLY - INCLUDES THE MEDIA ADVANCE |
|
|
MEDIA-AXIS MOTOR - DRIVES THE DRIVE ROLLER ASSEMBLY - INCLUDES THE MEDIA ADVANCE |
|
|
MYLAR STRIP - LOCATED ON THE WINDOW - FOR 60-INCH PLOTTERS |
|
|
OPTICAL MEDIA ADVANCE SENSOR (OMAS) CABLE |
|
|
OPTICAL MEDIA ADVANCE SENSOR (OMAS) MODULE |
|
|
OPTICAL MEDIA ADVANCE SENSOR ASSEMBLY |
|
|
OUTPUT PLATEN - FOR 60-INCH PLOTTERS |
|
|
OUTPUT ROLLER SUPPORT - INCLUDES THE PINS |
|
|
PAPER DRIVE ROLLER ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
PAPER DRIVE ROLLER ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
PAPER JAM SENSOR - INCLUDES CARRIAGE REFLECTOR AND CABLE |
|
|
PINCHWHEEL (MEDIA) LEVER ASSEMBLY - FOR DESIGNJET PRINTERS |
|
|
PINCHWHEEL KIT - FOR DESIGNJET PRINTERS |
|
|
POWER SUPPLY UNIT (PSU) - DESIGNJET L25500 PRINTER SERIES |
|
|
PRIMER ASSEMBLY - FOR DESIGNJET PRINTERS |
|
|
PRIMER VALVES AND PRIMER TUBES ASSEMBLY - FOR DESIGNJET PRINTERS |
|
|
PRINTHEAD MAINTENANCE CARTRIDGE DOOR |
|
|
PRINTMECH PCA - CONTROLS MOTORS AND FANS |
|
|
REAR COVER - FOR 60-INCH PLOTTERS |
|
|
REAR DRYER FAN |
|
|
REAR TUBE SHELF - INCLUDES BRACKETS - FOR 42-INCH PLOTTERS |
|
|
REAR TUBE SHELF - INCLUDES BRACKETS - FOR 60-INCH PLOTTERS |
|
|
RESIDUAL CURRENT CIRCUIT BREAKERS (RCCB)/GFIS - INCLUDES TWO UNITS |
|
|
RETURN KIT - FOR RETURNING DEFECTIVE LARGE FORMAT PRINTER INK SYSTEMS - INCLUDES |
|
|
REWINDER MOTOR AND GEARS |
|
|
RIGHT BRACKET ASSEMBLY - USED TO CONNECT THE RIGHT COVER ASSEMBLY |
|
|
RIGHT COVER - DOES NOT INCLUDE THE RIGHT SIDE DOOR |
|
|
RIGHT SIDE CONNECTOR COVER - FOR DESIGNJET PRINTERS |
|
|
RIGHT SIDE CURING COVER |
|
|
RIGHT SIDE ROLLFEED MODULE ASSEMBLY |
|
|
SATA BRIDGE PCA |
|
|
SAUSALITO PCI PCA - MAIN CONTROLLER OF THE PRINTER, IT IS RESPONSIBLE FOR ALL TH |
|
|
SCAN-AXIS MOTOR ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
SCAN-AXIS MOTOR ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
SERVICE REPLACEABLE KIT AND TRAILING CABLE - CONTAINS VARIOUS COMPONENTS INCLUDI |
|
|
SERVICE STATION ASSEMBLY - INCLUDES SERICE STATION CABLE |
|
|
SERVICE STATION CABLE - INCLUDES PRINTHEAD CLEANER DOOR SENSOR |
|
|
SETUP PRINTHEAD KIT - FOR THE DESIGNJET Z6100 PRINTER SERIES |
|
|
SHUTTER BUMP (ACTUATOR) - FOR DESIGNJET PRINTERS |
|
|
SPITTOON ASSEMBLY - INCLUDES FUNNEL, TUBE AND END SECTION |
|
|
TAKE-UP REEL (TUR) DEFLECTOR SUPPORT ASSEMBLY |
|
|
TAKE-UP REEL (TUR) SPINDLE ASSEMBLY - INCLUDES THE TAKE-UP REEL TUBES - FOR 60-I |
|
|
TAKE-UP REEL (TUR) THUMBSCREW - LOCATED ON THE TAKE-UP REEL RECEIVER SENSOR HOUS |
|
|
TAKE-UP REEL LEFT HAND MODULE |
|
|
TAKE-UP REEL SHELF - FOR 60-INCH PLOTTERS |
|
|
TAKE-UP REEL SPINDLE HUBS |
|
|
TAKE-UP REEL TUBES ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
TAKE-UP REEL TUBES ASSEMBLY - FOR 60-INCH PLOTTERS |
|
|
TOP COVER - FOR 60-INCH PLOTTERS |
|
|
TOP COVER FAN CABLE - FOR 60-INCH PLOTTERS |
|
|
TOP COVER FAN GRILLE - LOCATED ON THE TOP COVER |
|
|
TOP FAN COVER |
|
|
TRANSPARENT WINDOW - LOCATED ON THE FRONT PANEL WINDOW COVER - FOR 42-INCH PLOTT |
|
|
UPPER INK SUPPLY STATION (ISS) - INCLUDES THE CARTRIDGE TRAYS |
|
|
WEB WIPER MOTOR ASSEMBLY - INCLUDES PLATE |
|
|
WINDOW HINGE BREAK - FOR DESIGNJET PLOTTERS |
|
|
WINDOW LOCK SENSOR |
|
|
WINDOW LOCK SENSOR CABLE - FOR 42-INCH PLOTTERS |
|
|
WINDOW LOCKS - LOCKS THE TRANSPARENT WINDOW IN PLACE |
