Manufacturer
HP
Model Number
CK841A
Description
Hp Designjet T1120 Hd Multifunction Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
A2 SCAN COVER - FOR THE DESIGNJET T1100/T1120 HD-MFP PRINTER SERIES |
|
|
ARM ASSEMBLY - SUPPORTS KEYBOARD SHELF ASSEMBLY - DOES NOT INCLUDE BRACKET |
|
|
BASIC COATED PAPER - 61CM (24IN) X 45.7M (150FT) ROLL (USA AND ASIA/PACIFIC) |
|
|
BASIC COATED PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL (USA AND ASIA/PACIFIC) |
|
|
BASIC HEAVYWEIGHT PAPER - 61CM (24IN) X 30.5M (100FT) ROLL (USA AND ASIA/PACIFIC |
|
|
BASIC PHOTO SATIN PAPER - 61CM (24IN) X 30.5M (100FT) ROLL (USA AND ASIA/PACIFIC |
|
|
BRACKET - FOR DISPLAY PANEL |
|
|
BRIGHT WHITE INKJET PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 91.4CM (36IN) X 91.4M (300FT) ROLL |
|
|
CABLE HARNESS ASSEMBLY - FOR THE DESIGNJET T1100/T1120 HD-MFP PRINTER SERIES |
|
|
CALIBRATION SHEET - FOR THE DESIGNJET T1100 MFP, 4500MFP, 4500 SCANNER, 820 MFP |
|
|
CAMERA MOTOR ASSEMBLY |
|
|
CAMERA PC BOARD |
|
|
CLEAR FILM (4 MIL) - 61CM (24IN) X 22.9M (75FT) ROLL |
|
|
CLEAR FILM (4 MIL) - 91.4CM (36IN) X 22.9M (75FT) ROLL |
|
|
COATED PAPER (98 GSM) - 61CM (24IN) X 45.7M (150FT) ROLL (USA, CANADA, AND LATIN |
|
|
COATED PAPER (98 GSM) - 91.4CM (36IN) X 45.7M (150FT) ROLL (USA, CANADA, AND LAT |
|
|
COMPLETE CAMERA ASSEMBLY - DOES NOT INCLUDE THE MOTOR |
|
|
COMPLETE CAMERA ASSEMBLY - INCLUDES THE CAMERA MOTOR |
|
|
COPIER LEFT COVER PANEL |
|
|
COPIER TOP COVER PANEL |
|
|
CPU - PART OF THE PANEL PC |
|
|
CPU FAN - PART OF THE PANEL PC |
|
|
CROSS-BRACE - BRACE THAT CONNECTS AND SUPPORTS THE TWO STAND LEGS |
|
|
DOUBLE MATTE ERASEABLE FILM - 61CM (24IN) X 38.1M (125FT) ROLL (USA) |
|
|
DRIVE ROLLER ASSEMBLY |
|
|
DUSTCOVER - 40 INCHES - FOR THE DESIGNJET T1100/T1120 HD-MFP PRINTER SERIES |
|
|
DVD DRIVE - PART OF THE PANEL PC |
|
|
ELECTRO-LUMINESCENT STRIP |
|
|
ELEVATOR MOTOR ASSEMBLY - FOR THE DESIGNJET T1100 MFP PRINTER SERIES |
|
|
FAN ASSEMBLY |
|
|
FIREWIRE CONNECTOR COVER |
|
|
FLUORESCENT LAMP - TO ILLUMINATE DOCUMENTS FOR SCANNING |
|
|
FOOT ASSEMBLY - INCLUDES CASTORS - FOR THE DESIGNJET T1100 MFP/820 MFP PRINTER S |
|
|
FRONT PAPER GUIDE - WIDTH ADJUSTABLE SIDE WALL |
|
|
GUIDE PLATE ASSEMBLY - FOR MANUAL PAPER FEED |
|
|
HARD DISK DRIVE - PART OF THE PANEL PC |
|
|
HARDWARE KIT - INCLUDES VARIOUS SCREWS AND NUTS FOR THE STAND AND TOUCH SCREEN A |
|
|
HARNESS ASSEMBLY - FOR THE DESIGNJET T1100 MFP, 4500MFP, 4500 SCANNER, 820 MFP P |
|
|
HEAVYWEIGHT COATED PAPER - 106.7CM (42IN) X 30.5M (100FT) ROLL - FOR REGULAR OR |
|
|
HEAVYWEIGHT COATED PAPER - 61CM (24IN) X 30.5M (100FT) ROLL - FOR REGULAR OR UV |
|
|
HEAVYWEIGHT COATED PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL - FOR REGULAR OR U |
|
|
HIGH GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HIGH GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HIGH GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL (USA, CANADA, AND LATI |
|
|
HIGH GLOSS PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL (USA AND ASIA/PACIFI |
|
|
HIGH GLOSS WHITE FILM (4 MIL) - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HP 72 CYAN INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 GRAY INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 GRAY INK CARTRIDGE - PRINT CARTRIDGE VOLUME 69ML |
|
|
HP 72 MAGENTA INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 MAGENTA INK CARTRIDGE - PRINT CARTRIDGE VOLUME 69ML |
|
|
HP 72 MATTE BLACK INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 PHOTO BLACK INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 PHOTO BLACK INK CARTRIDGE - PRINT CARTRIDGE VOLUME 69ML |
|
|
HP 72 YELLOW INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 72 YELLOW INK CARTRIDGE - PRINT CARTRIDGE VOLUME 69ML |
|
|
HP HEAVYWEIGHT COATED PAPER - 106.7CM (42IN) X 68.6M (225FT) ROLL |
|
|
HP JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BO |
|
|
HP JETDIRECT 635N IPV6/IPSEC PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE |
|
|
HP PREMIUM INSTANT-DRY GLOSS PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) - 36 I |
|
|
HP SUPER HEAVYWEIGHT PLUS MATTE PAPER - 106.7CM (42IN) X 30.5M (100FT) ROLL |
|
|
HP SUPER HEAVYWEIGHT PLUS MATTE PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HP UNIVERSAL SEMI-GLOSS PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL |
|
|
IEEE 1394 (FIREWIRE) CABLE - 3.0M (9.8FT) LONG - FOR THE DESIGNJET T1100/T1120 H |
|
|
IEEE 1394 (FIREWIRE) CABLE - FOR THE SCANNER - 3.0M (9.8FT) LONG |
|
|
JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BOARD |
|
|
JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BOARD |
|
|
JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BOARD |
|
|
KEYBOARD - FOR DESIGNJET PRINTERS (CHINESE) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (FRENCH) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (GERMAN) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (ITALIAN) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (JAPANESE) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (PORTUGUESE) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (SPANISH) |
|
|
KEYBOARD - FOR DESIGNJET PRITNERS (TAIWANESE) |
|
|
KEYBOARD SHELF - SUPPORTS THE KEYBOARD |
|
|
KEYBOARD SHELF - SUPPORTS THE KEYBOARD - FOR THE DESIGNJET T1100 MFP/820 MFP PRI |
|
|
LAMP COVER - FLUORESCENT LAMP ACCESS COVER |
|
|
LCD CONTROLLER - PART OF THE PANEL PC |
|
|
LEG ASSEMBLY - SIDE SUPPORT FOR THE PLOTTER - DOES NOT INCLUDE THE FOOT ASSEMBLY |
|
|
MAIN ELELECTRONICS BOARD - FOR THE DESIGNJET T1100 MFP PRINTER SERIES |
|
|
MDA BOARD - LOCATED INSIDE THE GUIDE PLATE |
|
|
MEDIA DRIVE BELT - FOR THE DESIGNJET 820/4500 SCANNER SERIES |
|
|
MEDIA SENSOR CALIBRATION TOOLS - ADJUSTMENT TOOLS FOR ATAC SENSORS |
|
|
MOTHERBOARD - PART OF THE PANEL PC |
|
|
NATURAL TRACING PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
NATURAL TRACING PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
OPTICAL PATTERN - FOR THE DESIGNJET T1100 MFP, 4500MFP, 4500 SCANNER, 820 MFP PR |
|
|
OPTO INTERRUPTER MEDIA SENSOR |
|
|
PAPER ENTRY AND EXIT MEDIA SENSOR |
|
|
POLYESTER MATTE FILM - 61CM (24IN) X 36.6M (120FT) ROLL |
|
|
POLYESTER MATTE FILM - 91.4CM (36IN) X 36.6M (120FT) ROLL |
|
|
POWER SUPPLY UNIT - PART OF THE PANEL PC |
|
|
POWER SUPPLY/MOTOR DRIVER BOARD |
|
|
PPC POWER SWITCH BUTTON - FOR THE DESIGNJET T1100/T1120 HD-MFP PRINTER SERIES |
|
|
PRODUCTIVITY GLOSSY PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL |
|
|
PRODUCTIVITY PHOTO SEMI-GLOSS PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL |
|
|
RETURN KIT - FOR RETURNING DEFECTIVE LARGE FORMAT PRINTER INK SYSTEMS - INCLUDES |
|
|
RIGHT SIDE COVER ASSEMBLY - INCLUDES THE FRONT PANEL ASSEMBLY |
|
|
ROLLER SHIELD - INCLUDES 2 UNITS |
|
|
SCANNER GLASS PANE - GLASS PLATE THAT DOCUMENTS TO BE SCANNED LAY ON |
|
|
SCANNER POWER SUPPLY UNIT (PSU) - FOR THE DESIGNJET T1100 MFP, 4500MFP, 4500 SCA |
|
|
SDRAM MEMORY MODULE - PART OF THE PANEL PC |
|
|
SEMI-GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL (USA, CANADA, AND LATI |
|
|
SERVICE PATTERNS - INCLUDES THE FOCUS PATTERN AND THE CALIBRATION SHEET |
|
|
STEPPER MOTOR ASSEMBLY |
|
|
STITCHING WIRE |
|
|
STYLUS - FOR THE DESIGNJET T1100 MFP, 4500MFP, 4500 SCANNER, 820 MFP PRITNER SER |
|
|
SUPER HEAVYWEIGHT PAPER - 61CM (24IN) X 22.9M (75FT) ROLL (USA AND ASIA/PACIFIC) |
|
|
SYSTEM FAN - PART OF THE PANEL PC |
|
|
TOP BAR WITH GUIDE - FOR THE DESIGNJET T1100 MFP/820 MFP PRINTER SERIES |
|
|
TOP PROFILE ASSEMBLY - FOR THE DESIGNJET T1100 MFP PRINTER SERIES |
|
|
TOUCH SCREEN DRIVER PCA (INVERTER BOARD) |
|
|
TOUCHSCREEN LCD PANEL - THIS IS THE TOUCH ENABLED LCD DISPLAY ONLY |
|
|
TRANSLUCENT BOND PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
UNIVERSAL BOND PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL |
|
|
VACUUM FAN ASSEMBLY |
