Manufacturer
HP
Model Number
Q1271A
Description
Hp Designjet 4500 Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
256MB MEMORY UPDATE - FOR DESIGNJET PRINTERS |
|
|
256MB, 184MHZ, SDRAM DIMM MEMORY MODULE |
|
|
3-INCH SPINDLE ADAPTORS - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
40GB HARD DISK DRIVE - INCLUDES HOLDER AND SCREWS |
|
|
42-INCH SPINDLE - DOES NOT INCLUDE THE BLUE HUB |
|
|
AEROSOL FAN ASSEMBLY |
|
|
AEROSOL FILTER - LOCATED BETWEEN THE AEROSOL FAN ASSEMBLY AND THE VACUUM FAN ASS |
|
|
BASKET ASSEMBLY - FOR DESIGNJET 4500 SERIES PRINTERS |
|
|
BLUE HUB - LOCATED AT THE TIP OF THE SPINDLE |
|
|
BRIGHT WHITE INKJET PAPER - 42.0CM (16.5IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 59.4CM (23.4IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 84.1CM (33.1IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
BRIGHT WHITE INKJET PAPER - 91.4CM (36IN) X 91.4M (300FT) ROLL |
|
|
BT ARM ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
BT ARM ENCODER AND PAPER LOAD LEVER SWITCH KIT - FOR THE DESIGNJET 4500 PRINTER |
|
|
CARRIAGE ASSEMBLY - FOR THE DESIGNJET 4000/4500 PRINTER SERIES - DOES NOT INCLUD |
|
|
CARRIAGE FLEX CABLE ASSEMBLY - BLACK PLASTIC PIECE THAT COVERS AND CONNECTS PRIN |
|
|
CARRIAGE PCA (CARRIAGE CONTROLLER BOARD) ASSEMBLY - INCLUDES CABLE - LOCATED ON |
|
|
CARRIAGE STOPPER - INCLUDES CARRIAGE STOPPER SCREW AND MEDIA-AXIS MOTOR BRACKET |
|
|
CARTRIDGE TRAYS - HOLDS THE INK CARTRIDGE ASSEMBLIES |
|
|
CASTOR AND FEET EXTENSION KIT - INCLUDES TWO FEET EXTENTION ASSEMBLIES AND FOUR |
|
|
CENTER PLATEN ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
CLEAR FILM (4 MIL) - 61CM (24IN) X 22.9M (75FT) ROLL |
|
|
CLEAR FILM (4 MIL) - 91.4CM (36IN) X 22.9M (75FT) ROLL |
|
|
COATED PAPER (98 GSM) - 106.7CM (42IN) X 45.7M (150FT) ROLL (EUROPE, ASIA/PACIFI |
|
|
COATED PAPER (98 GSM) - 61CM (24IN) X 45.7M (150FT) ROLL (USA, CANADA, AND LATIN |
|
|
COATED PAPER (98 GSM) - 91.4CM (36IN) X 45.7M (150FT) ROLL (USA, CANADA, AND LAT |
|
|
COATED PAPER (98 GSM) - 91.4CM (36IN) X 91.4M (300FT) ROLL (USA, CANADA, AND LAT |
|
|
COATED PAPER - 42.0CM (16.5IN) X 45.7M (150FT) ROLL |
|
|
COATED PAPER - 59.4CM (23.4IN) X 45.7M (150FT) ROLL |
|
|
COATED PAPER - 84.1CM (33.1IN) X 45.7M (150FT) ROLL |
|
|
COMPLETE PINCHWHEELS ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
COMPLETE STAND ASSEMBLY - INCLUDES THE RIGHTAND LEFT LEG ASSEMBLIES, THE LEG EXT |
|
|
CONTROL PANEL ASSEMBLY - INCLUDES CABLE AND FERRITE CORES |
|
|
CONTROL PANEL BEZEL - FITS OVER THE CONTROL PANEL ASSEMBLY |
|
|
CPU FAN ASSEMBLY |
|
|
CROSS-BRACE - BRACE THAT CONNECTS AND SUPPORTS THE TWO STAND LEGS - INCLUDES CRO |
|
|
CUTTER ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
DRAWER GUIDE AND BAR ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
DRAWER SWITCH SENSOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
DRIVE PINCHWHEEL LEVER - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
DRIVE ROLLER ENCODER KIT - INCLUDES ENCODER DISK AND ENCODER SENSOR |
|
|
DRIVE ROLLER GEAR (OVERDRIVE GEAR) KIT - INCLUDES ROLLER BRAKE ASSEMBLY |
|
|
DROP DETECTOR - SENSOR THAT DETECTS INK DROPS FROM THE PRINTHEADS |
|
|
EIO TO PCI INTERFACE CARD |
|
|
ELECTRONICS MODULE ASSEMBLY - 110-120VAC - MAIN PCA AND POWER SUPPLY NOT INCLUDE |
|
|
ELECTRONICS MODULE ASSEMBLY - 220-240VAC - MAIN PCA AND POWER SUPPLY NOT INCLUDE |
|
|
EMPTY ELECTRONICS MODULE ASSEMBLY |
|
|
ENCODER KIT - INCLUDES STRIP AND ENCODER SENSOR - FOR 42-INCH PLOTTERS |
|
|
FOOT ASSEMBLY - FOR THE DESIGNJET 4500 SERIES PRINTERS |
|
|
FOOT BRACE ASSEMBLY |
|
|
FRONT COVER SENSOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
FRONT PANEL WINDOW COVER SWITCH SENSOR |
|
|
FRONT PAPER PATH ASSEMBLY - DOES NOT INCLUDE THE MEDIA FEED MOTOR OR THE BT ARM |
|
|
FULL TRAY AND MEDIA SENSOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
GIGABIT ETHERNET PCI CARD |
|
|
HEAVYWEIGHT COATED PAPER - 106.7CM (42IN) X 30.5M (100FT) ROLL - FOR REGULAR OR |
|
|
HEAVYWEIGHT COATED PAPER - 61CM (24IN) X 30.5M (100FT) ROLL - FOR REGULAR OR UV |
|
|
HEAVYWEIGHT COATED PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL - FOR REGULAR OR U |
|
|
HP 90 3-INK BLACK CARTRIDGE MULTIPACK - 775ML |
|
|
HP 90 BLACK INK CARTRIDGE - 400ML |
|
|
HP 90 BLACK INK CARTRIDGE - 775ML |
|
|
HP 90 BLACK PRINTHEAD AND PRINTHEAD CLEANER - FOR HP DESIGNJET 4000/4000PS SERIE |
|
|
HP 90 BLACK PRINTHEAD CLEANER - FOR HP DESIGNJET 4000/4000PS SERIES PRINTERS |
|
|
HP 90 CYAN INK CARTRIDGE - 225ML |
|
|
HP 90 CYAN INK CARTRIDGE - 400 ML |
|
|
HP 90 CYAN PRINTHEAD AND PRINTHEAD CLEANER |
|
|
HP 90 MAGENTA INK CARTRIDGE - 225ML |
|
|
HP 90 MAGENTA INK CARTRIDGE - 400ML |
|
|
HP 90 MAGENTA PRINTHEAD AND PRINTHEAD CLEANER - FOR HP DESIGNJET 4000/4000PS SER |
|
|
HP 90 VALUE PACK BLACK INK CARTRIDGE AND PRINTHEAD - 400ML - INCLUDES PRINTHEAD |
|
|
HP 90 VALUE PACK CYAN INK CARTRIDGE AND PRINTHEAD- 400ML |
|
|
HP 90 VALUE PACK MAGENTA INK CARTRIDGE AND PRINTHEAD - 400ML - INCLUDES PRINTHEA |
|
|
HP 90 VALUE PACK YELLOW INK CARTRIDGE AND PRINTHEAD - 400ML - INCLUDES PRINTHEAD |
|
|
HP 90 YELLOW INK CARTRIDGE - 225ML |
|
|
HP 90 YELLOW INK CARTRIDGE - 400ML |
|
|
HP 90 YELLOW PRINTHEAD AND PRINTHEAD CLEANER |
|
|
HP HEAVYWEIGHT COATED PAPER - 106.7CM (42IN) X 68.6M (225FT) ROLL |
|
|
HP UNIVERSAL INKJET BOND PAPER - 91.4CM (36IN) X 152.4M (500FT) ROLL |
|
|
HP UNIVERSAL INSTANT-DRY GLOSS PHOTO PAPER - 106.7CM (42IN) X 30.5M (100FT) ROLL |
|
|
HP UNIVERSAL INSTANT-DRY GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HP UNIVERSAL INSTANT-DRY GLOSS PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL |
|
|
HP UNIVERSAL INSTANT-DRY SEMI-GLOSS PHOTO PAPER - 106.7CM (42IN) X 30.5M (100FT) |
|
|
HP UNIVERSAL INSTANT-DRY SEMI-GLOSS PHOTO PAPER - 91.4CM (36IN) X 30.5M (100FT) |
|
|
HP VELLUM PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
INK SUPPLY STATION ASSEMBLY - HOLDS THE INK CARTRIDGES AND PUMPS INK OUT TO THE |
|
|
INK SUPPLY STATION TO CARTRIDGE CABLE CONNECTOR |
|
|
INK SUPPLY TUBES - DOES NOT INCLUDE TRAILING CABLE ASSEMBLY |
|
|
INK SUPPLY TUBES CLIPS (FIVE USED) |
|
|
INK SYSTEM RETURN KIT (BOX AND INSTRUCTIONS) - FOR RETURNING PRINTHEADS, PRINTHE |
|
|
LEFT AND RIGHT DRAWER SLIDERS - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
LEFT AND RIGHT SIDE ARM CABLE |
|
|
LEFT BRACKET ASSEMBLY - CONNECTS THE INK SUPPLY STATION TO THE PRINTMECH |
|
|
LEFT CARTRIDGE ACCESS DOOR - PROVIDES ACCESS TO THE INK CARTRIDGES |
|
|
LEFT SIDE CONNECTOR COVER - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
LEFT SIDE LATERAL COVER - USED ON THE DESIGNJET 4500 STACKER ASSEMBLY |
|
|
LEFT SIDE SPINDLE SUPPORT - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
LEFT-SIDE COVER ASSEMBLY - HOUSES THE INK CARTRIDGES AND INK SUPPLY STATION - DO |
|
|
LEFT-SIDE SPITTOON ASSEMBLY - HOLDS EXPELLED INK FROM CARTRIDGE DURING REFRESH C |
|
|
LEG COVER - COVERS BOTH THE LEFT AND RIGHT LEG ASSEMBLIES |
|
|
LEGS ASSEMBLY - FOR THE DESIGNJET 4500 SERIES PRINTERS |
|
|
LINE AND COLOR SENSOR - LOCATED ABOVE CARRIAGE PCA |
|
|
LOCKING LEVERS - INCLUDES BOTH LEFT AND RIGHT LEVERS |
|
|
LOWER FRONT COVER - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
MAIN LOGIC PC BOARD - INCLUDES PROCESSOR AND HEATSINK |
|
|
MAIN MEDIA SENSOR - INCLUDES THE RETAINER - FOR THE DESIGNJET 4500 PRINTER SERIE |
|
|
MAIN PC BOARD - FOR THE DESIGNJET 4500 STACKER ASSEMBLY |
|
|
MEDIA DEFLECTOR WITH SENSOR (STACKER SWITCH) |
|
|
MEDIA DEFLECTORS KIT - INCLUDES TWO UNITS |
|
|
MEDIA FEED MOTOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
MEDIA-AXIS MOTOR - DRIVES THE DRIVE ROLLER ASSEMBLY - INCLUDES THE MEDIA ADVANCE |
|
|
MIDDLE-LEFT SPITTOON ASSEMBLY - HOLDS EXPELLED INK FROM CARTRIDGE DURING REFRESH |
|
|
MYLAR STRIP - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
NATURAL TRACING PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
NATURAL TRACING PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
OPAQUE POLYESTER FILM - 106.7CM (42IN) X 3.0M (10FT) ROLL (USA) |
|
|
OPAQUE WHITE GLOSSY FILM - 91.4CM (36IN) X 15.2M (50FT) ROLL (USA) |
|
|
OPAQUE WHITE GLOSSY POLYESTER FILM - 61CM (24IN) X 15.2M (50FT) ROLL (USA) |
|
|
OUTPUT PLATEN - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
PAPER CUTTER ASSEMBLY |
|
|
PAPER DRIVE ROLLER ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
PAPER LOAD LEVER - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
PHOTO PAPER RC MATTE - 91.4CM (36IN) X 30.5M (100FT) ROLL (USA) |
|
|
PINCHWHEEL (MEDIA) LEVER SENSOR |
|
|
PINCHWHEEL KIT - INCLUDES 5 PINCHWHEEL ASSEMBLIES |
|
|
PINCHWHEELS KIT - ONLY CONTAINS THE WHEELS |
|
|
POLYESTER MATTE FILM - 61CM (24IN) X 36.6M (120FT) ROLL |
|
|
POLYESTER MATTE FILM - 91.4CM (36IN) X 36.6M (120FT) ROLL |
|
|
POWER CORD (BLACK) - 18 AWG, THREE CONDUCTOR, 1.9M (75IN) LONG - HAS STRAIGHT (F |
|
|
POWER CORD (BLACK) - 18 AWG, THREE CONDUCTOR, 1.9M (75IN) LONG - HAS STRAIGHT (F |
|
|
POWER CORD (BLACK) - 3-WIRE, 18 AWG, 1.9M (75IN) LONG - HAS STRAIGHT (F) C13 REC |
|
|
POWER SUPPLY ASSEMBLY - FOR 200-240VAC OPERATION - FOR USE ON THE DESIGNJET 4500 |
|
|
POWER SUPPLY FUSE - FOR 110/220VAC OPERATION |
|
|
POWER SUPPLY FUSE - FOR 220/240VAC OPERATION |
|
|
PREVENTIVE MAINTENANCE KIT - INCLUDES THE COMPLETE CARRIAGE ASSEMBLY, INK SUPPLY |
|
|
PRINT CARTRIDGE DOOR LATCH |
|
|
PRINTER INTERCONNECT CABLE (CAN-BUS) |
|
|
PRINTMECH PC BOARD - CONTROLS THE FUNTION OF THE PRINT MECHANISM |
|
|
PROOFING PAPER RC SATIN - 91.4CM (36IN) X 30.5M (100FT) ROLL (USA) |
|
|
QUICK REFERENCE GUIDE HOLDER |
|
|
REAR PAPER PATH ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
REAR TUBE BRACKETS (TWO USED) - USED TO CONNECT THE INK SUPPLY TUBES TO THE CHAS |
|
|
REFERENCE SHAFT WHEEL - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
RETURN KIT - FOR RETURNING DEFECTIVE LARGE FORMAT PRINTER INK SYSTEMS - INCLUDES |
|
|
RIGHT SIDE CONNECTOR COVER - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
RIGHT SIDE PRINTHEAD CLEANER ACCESS DOOR - FOR THE DESIGNJET 4500PS PRINTER SERI |
|
|
RIGHT SIDE SPINDLE SUPPORT - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
RIGHT-SIDE COVER ASSEMBLY - DOES NOT INCLUDE PRINTHEAD CLEANER ACCESS DOOR |
|
|
ROLLER MEDIA SENSOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
ROLLFEED ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
SAFETY TEMPERATURE SENSOR - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
SCAN-AXIS MOTOR ASSEMBLY - FOR 42-INCH PLOTTERS |
|
|
SERVICE STATION ASSEMBLY - INCLUDES DROP DETECTOR |
|
|
SERVICE STATION CABLE - INCLUDES PRINTHEAD CLEANER DOOR SENSOR |
|
|
SETUP PRINT HEAD - INCLUDES FOUR PRINTHEADS |
|
|
TEMPERATURE SENSOR ASSEMBLY - FOR THE DESIGNJET 4500 PRINTER SERIES |
|
|
TOP COVER - LARGE BLACK PLASTIC COVER FOR MOST OF TOP AND REAR OF PLOTTER - FRON |
|
|
TOP COVER ASSEMBLY - INCLUDES THE FRONT COVER ASSEMBLY |
|
|
TRANSLUCENT BOND PAPER - 61CM (24IN) X 45.7M (150FT) ROLL |
|
|
TRANSLUCENT BOND PAPER - 91.4CM (36IN) X 45.7M (150FT) ROLL |
|
|
TRIM KIT - INCLUDES LEFT AND RIGHT SIDE TRIM ASSEMBLIES AND THE DRIVE PINCH LEVE |
|
|
UNIVERSAL HIGH-GLOSS PHOTO PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
VACUUM FAN ASSEMBLY |
|
|
VELLUM - 91.4CM (36IN) X 45.7M (150FT) ROLL |
