Manufacturer
HP
Model Number
Q3932A
Description
Hp Color Laserjet Cp6015dn Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
128MB, 167MHZ, 200-PIN DDR DIMM MEMORY MODULE |
|
|
256MB, 167MHZ, 200-PIN DDR DIMM MEMORY MODULE |
|
|
500-SHEET PAPER INPUT TRAY CASSETTE - FOR USE WITH TRAY 2 |
|
|
512MB, 167MHZ, 200-PIN DDR DIMM MEMORY MODULE |
|
|
AIR FILTER KIT |
|
|
BLACK IMAGING DRUM - FOR THE COLOR LASERJET CP6015 SERIES |
|
|
CARTRIDGE INTERFACE ASSEMBLY |
|
|
CYAN IMAGING DRUM |
|
|
CYAN PRINT TONER CARTRIDGE - FOR THE COLOR LASERJET CP6015 SERIES |
|
|
DC CONTROLLER PC BOARD ASSEMBLY |
|
|
DUPLEX SWITCHBACK TRAY |
|
|
E-TYPE RETAINER RING |
|
|
FACE DOWN COVER - OUTPUT PAPER COVER ON TOP OF THE PRINTER - HOLDS THE PAPER AFT |
|
|
FEED ROLLER HIGH CAPACITY INPUT (HCI) - TRANSMIT THE PAPER FROM THE CASSETTE AND |
|
|
FORMATTER (MAIN LOGIC) BOARD - FOR HP COLOR LASERJET CP6015 SERIES |
|
|
FUSER ELECTRICAL CONNECTOR |
|
|
FUSING ASSEMBLY - FOR 220 VAC TO 240 VAC - BONDS TONER TO THE PAPER WITH HEAT |
|
|
LASER/SCANNER ASSEMBLY KIT |
|
|
M3 PAN-HEAD PHILLIPS SCREW WITH MACHINE THREADS - 8MM LONG |
|
|
M3 TRUSS HEAD (FLANGED) SCREW - 8MM LONG |
|
|
M3X4 MACHINED TRUSS-HEAD SCREW |
|
|
M3X6 SCREW WITH WASHER |
|
|
M4 PAN-HEAD PHILLIPS SCREW WITH SELF-TAPPING THREADS - 10MM LONG |
|
|
M4 X 12MM MACHINE SCREW WITH WASHER |
|
|
M4X8 MACHINED TRUSS-HEAD SCREW |
|
|
MACHINE SCREW - M3, 30MM LONG WITH SELF-TAPPING THREADS - TYPICALLY USED TO HOLD |
|
|
MACHINE SCREW WITH ATTACHED WASHER - M3, 10MM - USED TO HOLD PLASTIC TO METAL |
|
|
MAGENTA IMAGING DRUM |
|
|
MAGENTA PRINT TONER CARTRIDGE - FOR THE COLOR LASERJET CP6015 SERIES |
|
|
MAIN DRIVE ASSEMBLY - MOUNTS ON THE RIGHT SIDE OF THE PRINTER - METAL PLATE WITH |
|
|
PAPER PICK-UP RETARD ROLLER - USED FOR TRAY 1 |
|
|
PHOTO-INTERRUPTER SENSOR ASSEMBLY (DOES NOT INCLUDE THE SENSOR FLAG) |
|
|
REGISTRATION CABLE ASSEMBLY - INCLUDES 7P AND 3P CONNECTORS |
|
|
SCREW - M4 X 8MM LONG |
|
|
SECONDARY TRANSFER ASSEMBLY - LOCATED AT BOTTOM OF THE INTERMEDIATE TRANSFER BEL |
|
|
SNAP-IN CABLE CLAMP |
|
|
TONER CARTRIDGE DRIVE ASSEMBLY - METAL PLATE WITH GEARS ATTACHED - PROVIDES MOVE |
|
|
TONER CARTRIDGE DRIVE ASSEMBLY - METAL PLATE WITH GEARS ATTACHED - PROVIDES MOVE |
|
|
YELLOW IMAGING DRUM |
|
|
YELLOW PRINT TONER CARTRIDGE - FOR THE COLOR LASERJET CP6015 SERIES |
