Manufacturer
HP
Model Number
Q5981A
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1GB COMPACT FLASH MEMORY MODULE - FOR THE HP COLOR LASERJET 3600/3800/CP3505 SER |
|
|
31 TOOTH GEAR - GEAR LOCATED IN THE FUSER DRIVE ASSEMBLY ON TOP |
|
|
41 TOOTH GEAR - MECHANICALLY CONNECTS THE FOUR CARTRIDGE ENGAGING ROLLERS - TWO |
|
|
500 SHEET PAPER FEEDER PC BOARD - 500 SHEET PAPER FEEDER TRAY CONTROLLER PC BOAR |
|
|
500 SHEET PAPER INPUT TRAY |
|
|
500 SHEET TRAY AND FEEDER ASSEMBLY - PRINTER SITS ON TOP OF THIS ASSEMBLY |
|
|
500-SHEET PAPER INPUT TRAY FOR HP COLOR LASERJET 3000, 3600, 3800, CP3505 PRINTE |
|
|
58 TOOTH DRIVE GEAR - LOCATED BETWEEN THE TONER MOTOR AND IMAGE DRIVE ASSEMBLY - |
|
|
AIR DUCT - DEFLECTS AIR FROM FAN FM1 |
|
|
AIR DUCT - THIS DUCT GOES FROM FAN FM1 TO UNDER THE LOW VOLTAGE POWER SUPPLY |
|
|
ALIENTION FLAG - SENSES IF THE BLACK OR ALL THE COLOR CARTRIDGES ARE IN THE PROP |
|
|
BLACK TONER CARTRIDGE - FOR THE COLOR LASERJET 3600/3800/CP3505 SERIES PRINTERS |
|
|
CABLE CLAMP - USED TO ATTACH DRIVER BOARD RIBBON CABLE 1 AND 2 TO DC CONTROLLER |
|
|
CABLE GUARD - PROTECTS THE CABLES (NON-FLAT TYPE) FROM BEING PINCHED BETWEEN PC |
|
|
CABLE GUIDE - FUSER CABLE HOUSING - LOCATED IN UPPER LEFT SIDE OF PRINTER |
|
|
CAM GEAR - 48 TOOTH GEAR ASSOCIATED WITH THE CARTRIDGE FOR ENGAGING THE DEVELOPI |
|
|
CARTRIDGE GUIDE - LEFT SIDE GUIDE ASSEMBLY FOR TONER CARTRIDGES |
|
|
CARTRIDGE GUIDE - RIGHT SIDE GUIDE ASSEMBLY FOR TONER CARTRIDGES |
|
|
CASSETTE FEEDER CABLE - CONNECTS DRIVER PCA TO 500 SHEET PAPER FEEDER PCA |
|
|
CASSETTE GUIDE - RIGHT SIDE GUIDE FOR MEDIA CASSETTE |
|
|
CASSETTE SENSOR PCA - SENSES WHEN PAPER TRAY IS CORRECTLY INSTALLED |
|
|
CLUSTER GEAR - 17 TOOTH/41 TOOTH GEAR MOUNTED IN GEAR ASSEMBLY ON RIGHT SIDE OF |
|
|
CLUSTER GEAR - 19 TOOTH/30 TOOTH GEAR MOUNTED IN GEAR ASSEMBLY ON RIGHT SIDE OF |
|
|
COLOR LASERJET TRANSPARENCY FILM - A SIZE (8.5 X 11-INCHES) - 50 SHEETS |
|
|
COMPRESSION SPRING - PROVIDES PRESSURE FOR CLUTCH AND 18 TOOTH GEAR ON RIGHT SID |
|
|
CONTROL PANEL CABLE - CONNECTS CONTROL PANEL TO LOW VOLTAGE POWER SUPPLY |
|
|
CONTROL PANEL CABLE - FROM CONTROL PANEL TO HIGH VOLTAGE POWER SUPPLY (HVPS) |
|
|
CONTROL PANEL OVERLAY - FOR HP COLOR LASERJET 3600/3800/CP3505 SERIES (CZECH, HU |
|
|
CONTROL PANEL OVERLAY - FOR HP COLOR LASERJET 3600/3800/CP3505 SERIES (FINNISH, |
|
|
CONTROL PANEL OVERLAY - FOR HP COLOR LASERJET 3600/3800/CP3505 SERIES (FRENCH, |
|
|
CONTROL PANEL OVERLAY - FOR HP COLOR LASERJET 3600/3800/CP3505 SERIES (SPANISH, |
|
|
COOLING FAN - PROVIDES COOLING FOR PRINTER |
|
|
CYAN TONER CARTRIDGE - FOR THE COLOR LASERJET 3600 SERIES PRINTERS |
|
|
DC CONTROLLER BOARD - FOR COLOR LASERJET 3600 AND 3800 PRINTERS |
|
|
DC MOTOR - ELECTROSTATIC TRANSFER BELT DRIVE MOTOR - MOTOR M5 - SIMPLEX MODELS O |
|
|
DEVELOPER DISENGAGEMENT DRIVE ASSEMBLY |
|
|
DRAWER CONNECTOR HOLDER - THIS IS THE CONNECTOR HOLDER FOR TRAY 3, WHERE THE ELE |
|
|
DRAWER HOLDER - SHEET METAL PIECE THAT HOLDS THE CONNECTOR FOR THE FUSER - LEFT |
|
|
DRIVE GEAR - 18 TOOTH GEAR ON RIGHT SIDE OF PAPER PICKUP ASSEMBLY |
|
|
DRIVE MOTOR - PRINT CARTRIDGE DRIVE MOTOR ASSEMBLY |
|
|
DRIVE MOTOR - PRINT CARTRIDGE DRIVE MOTOR ASSEMBLY |
|
|
DRIVE PLATE CROSS MEMBER - CROSS MEMBER PLATE THAT ATTACHES TO DUPLEXER SEPARATI |
|
|
DRIVER CABLE - FROM DC CONTROLLER BOARD TO DRIVER BOARD |
|
|
DRIVER PC BOARD ASSEMBLY |
|
|
DRUM MOTOR CABLE - CONNECTS CARTRIDGE DRIVE MOTORS M6 AND M7 TO DRIVER PCA |
|
|
DRUM MOTOR CABLE - CONNECTS CARTRIDGE DRIVE MOTORS M8 AND M9 TO DRIVER PCA - FOR |
|
|
DUPLEX DOCKING CABLE - THIS CABLE GOES FROM THE TOP COVER AND DUPLEX MOTORS DOWN |
|
|
DUPLEXER PAPER GUIDE ASSEMBLY - HELPS DIVERT THE PAPER BACK INTO THE DUPLEX PATH |
|
|
DUPLEXER PAPER POSITION GUIDE - KEEPS THE SKEWING/CENTERING CORRECT FOR THE SECO |
|
|
E-LABEL OR MEMORY TAG CABLE |
|
|
ELECTROSTATIC TRANFER BELT (ETB) ASSEMBLY - INCLUDES THE ASSEMBLY STRUCTURE, ETB |
|
|
ELECTROSTATIC TRANSFER BELT (ETB) CABLE - CONNECTS DRIVER PC BOARD TO ETB |
|
|
ELECTROSTATIC TRANSFER BELT (ETB) HOLDER - RIGHT SIDE ETB SUPPORT |
|
|
FAN DUCT - DIVERTS AIR FROM FAN 1 NEAR THE BACK OF PRINTER - DUCT 2 |
|
|
FAN DUCT - DIVERTS AIR FROM FAN 1 TO FRONT OF PRINTER AND HELPS COOL THE LOW VOL |
|
|
FAN HOLDER - MOUNTING ASSEMBLY FOR MAIN COOLING FAN - LOCATED ON LOWER LEFT SIDE |
|
|
FLAT CABLE - RIBBON CABLE THAT CONNECTS THE DC CONTROLLER BOARD TO THE DRIVER BO |
|
|
FLAT CABLE - RIBBON CABLE THAT CONNECTS THE DC CONTROLLER BOARD TO THE DRIVER BO |
|
|
FLAT CABLE GUIDE - LOCATED ON THE BOTTOM OF THE PRINTER AND HELP GUIDE FLAT CABL |
|
|
FLAT CABLE GUIDE - LOCATED ON THE BOTTOM OF THE PRINTER AND HELP GUIDE FLAT CABL |
|
|
FORMATTER (MAIN LOGIC) BOARD - HP COLOR LASERJET 3000/3000N AND 3800/3800N SERIE |
|
|
FORMATTER (MAIN LOGIC) BOARD - HP COLOR LASERJET 3000/3000N AND 3800/3800N SERIE |
|
|
FRONT CASSETTE COVER - PLASTIC FRONT COVER FOR 500 SHEET PAPER TRAY |
|
|
FRONT COVER - FRONT COVER FOR 250 SHEET PAPER TRAY/CASSETTE |
|
|
FUSER CABLE - CONNECTS FUSER TO DC CONTROLLER AND LOW VOLTAGE POWER SUPPLY |
|
|
FUSER DRIVE CABLE - CONNECTS DRIVER BOARD TO FUSER DRIVE MOTOR (M1) AND FUSER PR |
|
|
FUSER DRIVE GEAR ASSEMBLY - INCLUDES FUSER DRIVE MOTOR - MOTOR M1 |
|
|
GEAR ASSEMBLY - MP/TRAY 1 PAPER PICKUP GEAR ASSEMBLY |
|
|
GEAR ASSEMBLY - SMALL GEAR ASSEMBLY THAT COMES OFF WHEN REMOVING PAPER PICKUP DR |
|
|
GEAR ASSEMBLY COVER - COVER FOR PAPER PICKUP GEAR ASSEMBLY ON RIGHT LOWER SIDE O |
|
|
GEAR BUSHING - LOCATED BETWEEN 29 TOOTH IMAGE DRIVE GEAR AND CHASSIS ON RIGHT SI |
|
|
GEAR BUSHING - LOCATED BETWEEN THE 48 TOOTH CAM GEAR AND THE METAL CHASSIS ON TH |
|
|
GROUNDING SPRING - PROVIDES GROUNDING FOR MAIN COOLING FAN - FAN FM1 |
|
|
GROUNDING SPRING ? PROVIDES CHASSIS GROUND FOR TONER CARTRIDGES - FOUR USED |
|
|
HIGH GLOSS LASERJET PAPER - HIGH GLOSS FINISH ON BOTH SIDES, 95 BRIGHTNESS - A S |
|
|
HIGH PERFORMANCE 20GB HARD DISK - PLUGS IN ONE OF THE EXTENDED INPUT/OUTPUT (EIO |
|
|
HIGH VOLTAGE POWER SUPPLY BOARD |
|
|
HIGH VOLTAGE TONER CONTACT ASSEMBLY - ELECTRICAL CONTACTS FOR ALL FOUR TONER CAR |
|
|
HP COLOR LASER SOFT-GLOSS PRESENTATION PAPER - A SIZE (8.5 X 11-INCHES) - 200 SH |
|
|
HP COLOR LASERJET BLACK PRINT CARTRIDGE WITH HP COLORSPHERE TONER |
|
|
HP COLOR LASERJET CYAN PRINT CARTRIDGE WITH HP COLORSPHERE TONER |
|
|
HP COLOR LASERJET MAGENTA PRINT CARTRIDGE WITH HP COLORSPHERE TONER |
|
|
HP COLOR LASERJET YELLOW PRINT CARTRIDGE WITH HP COLORSPHERE TONER |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ON 4-PIN USB CONNECTOR AND ONE RJ- |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ONE 4-PIN USB CONNECTOR AND ONE RJ |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ONE 4-PIN USB CONNECTOR AND ONE RJ |
|
|
HP JETDIRECT 380X EXTERNAL IEEE-802.11B (WI-FI) WIRELESS PRINT SERVER - CONNECTS |
|
|
HP JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BO |
|
|
HP JETDIRECT 625N INTERNAL ETHERNET PRINT SERVER - PROVIDES 10BASET, 100BASETX, |
|
|
HP JETDIRECT 635N IPV6/IPSEC PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE |
|
|
HP JETDIRECT EN3700 EXTERNAL PRINT SERVER - FAST ETHERNET INTERNET CONNECTOR FOR |
|
|
HP JETDIRECT EW2400 802.11G WIRELESS PRINT SERVER MODULE - INCLUDES POWER SUPPLY |
|
|
HP LASERJET TOUGH PAPER - A4 SIZE (21.0CM X 29.7CM) |
|
|
IMAGE DRIVE GEAR - 29 TOOTH IMAGE DRIVE GEAR - LOCATED INSIDE CHASSIS ON RIGHT S |
|
|
INTERLOCK SWITCH ASEMBLY - FRONT DOOR OPEN SWITCH - SW1 |
|
|
LEFT LATCH - LEFT SIDE PAPER GUIDE/LATCH DIRECTLY UNDER CONTROL PANEL |
|
|
LEFT REAR BRACKET - THIS IS THE SHEET METAL BOX THAT SUPPORTS THE LOW VOLTAGE PO |
|
|
LEFT REAR COVER - LEGAL PAPER SIZE CASSETTE COVER - LOCATED AT REAR/BOTTOM OF PR |
|
|
LEFT SIDE HINGE MOUNT - LEFT SIDE ETB GUIDE HINGE MOUNT |
|
|
LOW VOLTAGE POWER SUPPLY BOARD - 110 TO 127VAC INPUT |
|
|
LOW VOLTAGE POWER SUPPLY BOARD - FOR 220 TO 240 VAC INPUT |
|
|
MAGENTA TONER CARTRIDGE - FOR THE COLOR LASERJET 3600 SERIES PRINTERS |
|
|
MAIN DRIVE ASSEMBLY - MAIN GEAR ASSEMBLY ON RIGHT SIDE OF PRINTER - MOTORS M6 TH |
|
|
MEDIA SENSOR CABLE - CABLE BETWEEN TRAY 2 MEDIA TYPE SENSOR AND RELAY PCA |
|
|
MEDIA SENSOR CABLE - CONNECTS MEDIA TYPE WITH SENSOR - LOCATED ON THE 500-SHEET |
|
|
MP/TRAY 1 BLOCK - REPLACES MEDIA SENSOR IN PAPER PICKUP ASSEMBLY - USED ON COLOR |
|
|
MP/TRAY 1 EXTENSION - FLIP OUT PAPER SUPPORT EXTENSION FOR MP/TRAY 1 |
|
|
PAPER DELIVERY FLAG |
|
|
PAPER FULL CABLE - FROM DRIVER PCA TO CONNECTOR J821 |
|
|
PAPER GUIDE CROSSMEMBER COVER - USED AS A SUPPORT TO HELP GUIDE PAPER THROUGH TH |
|
|
PAPER PICK UP/FEED MOTOR - LOCATED ON LOWER RIGHT FRONT OF PRINTER - MOTOR M4 |
|
|
PAPER PICKUP DRIVE ASSEMBLY - GEAR ASSEMBLY LOCATED ON RIGHT SIDE OF PAPER PICKU |
|
|
PAPER REGISTRATION COVER - SMALL METAL COVER FOR PAPER REGISTRATION SENSOR LOCAT |
|
|
PAPER SENSOR CABLE - CABLE THAT CONNECTS TO THE FACE DOWN PAPER TRAY FULL SENSOR |
|
|
PAPER SENSOR CABLE - CABLE THAT CONNECTS TO THE FACE DOWN PAPER TRAY FULL SENSOR |
|
|
PAPER SENSOR CABLE - CONNECTS PAPER SENSOR IN FRONT SECTION OF 500 SHEET TRAY TO |
|
|
PAPER SEPARATION PAD HOLDER - ATTACHES TO FRONT CENTER OF 500 SHEET PAPER CASSET |
|
|
PARALLEL PORT CARD - 1284B PARALLEL CARD - COMPATIBLE OPERATING SYSTEMS WINDOWS |
|
|
PC BOARD COVER - PICKUP AND FEED DRIVER PCA COVER |
|
|
PC BOARD SHIELD - DRIVER PC BOARD SHIELD - BLACK PLASTIC PIECE THAT COVERS DRIVE |
|
|
PHOTO-INTERRUPTER SENSOR ASSEMBLY (DOES NOT INCLUDE THE SENSOR FLAG) |
|
|
POWER CONTROL CABLE - CONNECTS DC CONTROLLER BOARD TO LOW VOLTAGE POWER SUPPLY |
|
|
POWER CORD (BLACK) - 16 AWG, 2.5M (8.2FT) LONG - HAS STRAIGHT (F) C13 RECEPTACLE |
|
|
REAR COVER - EXTERNAL METAL REAR COVER OF PRINTER |
|
|
REAR FOOT - BLACK PLASTIC FOOT FOR REAR BASE OF PRINTER - TWO USED |
|
|
REAR UPPER COVER - SMALL UPPER COVER THAT THE INTERNAL SHEET METAL REAR COVER AT |
|
|
RELAY PC BOARD - INCLUDES RIBBON CABLE THAT CONNECTS TO DC CONTROLLER BOARD |
|
|
RIGHT REAR BASE ASSEMBLY - RIGHT SIDE GUIDE FOR PAPER TRAY - REAR BLACK PLASTIC |
|
|
RIGHT REAR COVER HINGE - LEGAL PAPER SIZE TRAY COVER HINGE - LOCATED AT RIGHT RE |
|
|
RIGHT ROD LINK - RIGHT SIDE DOOR ROD LINK |
|
|
RIGHT SIDE CABLE GUIDE - LOCATED BELOW UPPER RIGHT CABLE GUIDE |
|
|
RIGHT SIDE CABLE GUIDE - LOCATED IN THE BOTTOM RIGHT SIDE OF THE PRINTER - ROUND |
|
|
ROLLER BUSHING - LEFT SIDE BUSHING FOR FEED ROLLER INSIDE OF PAPER PICK UP ASSEM |
|
|
ROLLER BUSHING - RIGHT SIDE BUSHING FOR FEED ROLLER INSIDE OF PAPER PICK UP ASSE |
|
|
RUBBER FOOT - BLACK RUBBER FOOT FOR FRONT BASE OF PRINTER - TWO USED |
|
|
SCANNER CABLE - CABLE BETWEEN SCANNER MOTORS AND DC CONTROLLER PCA |
|
|
SCANNER CABLE - LONG FLAT SCANNER CABLE |
|
|
SCANNER CABLE - SHORT FLAT SCANNER CABLE |
|
|
SENSING LEVER - THIS DEVICE SENSES WHEN THE PACKAGING MATERIAL IS REMOVED FROM T |
|
|
SENSOR CABLE - SENSES WHEN THE ELECTROSTATIC TRANSFER BELT (ETB) IS LOCKED IN PL |
|
|
SENSOR COVER - SMALL METAL COVER FOR PAPER SENSOR LOCATED AT RIGHT REAR OF PAPER |
|
|
SEPARATION PAD ASSEMBLY (DOES NOT INCLUDE SPRING) - MOUNTS TOWARD THE FRONT OF T |
|
|
SEPARTATION PAD - MP/TRAY 1 SEPARATION PAD ASSEMBLY |
|
|
SHUTTER COVER - LEFT SIDE TONER CARTRIDGE SHUTTER COVER - FOUR USED |
|
|
SMALL REAR COVER - SMALL METAL COVER THAT ATTACHES WITH ONE SCREW TO LARGE METAL |
|
|
SOFT GLOSS COLOR LASERJET PAPER - A4 SIZE (21.0CM X 29.7CM) - 200 SHEETS PER PAC |
|
|
SOLENOID AND MOTOR CABLE - CONNECTS CST PICKUP AND MP TRAY PICKUP SOLENOIDS TO D |
|
|
SWITCH LINK ARM - CONNECTS THE ON/OFF SWITCH ON THE RIGHT SIDE DOOR TO THE ACTUA |
|
|
TEMPERATURE SENSOR - ALSO REFERRED TO AS ENVIRONMENT SENSOR |
|
|
TEMPERATURE SENSOR CABLE - CONNECTS ENVIRONMENT SENSOR TO DC CONTROLLER BOARD |
|
|
TENSION SPRING - PROVIDES TENSION FOR FRONT DROPDOWN MULTIPURPOSE PAPER INPUT TR |
|
|
TENSION SPRING - PROVIDES TENSION FOR RIGHT AND LEFT PAPER GUIDES DIRECTLY UNDER |
|
|
TENSION SPRING - PROVIDES TENSION FOR SENSING LEVER ON LEFT SIDE OF PRINTER |
|
|
TENSION SPRING - PROVIDES TENSION FOR THE FEED ROLLER BUSHING INSIDE OF PAPER PI |
|
|
TONER CARTRIDGE HOLDER - PLASTIC SUPPORT FOR RIGHT SIDE OF TONER CARTRIDGE - FOU |
|
|
TOP COVER ASSEMBLY - TOP PLASTIC COVER OF PRINTER THAT FUSER ACCESS DOOR MOUNTS |
|
|
TRAY HINGE LINK - LEFT SIDE LINK FOR DROP DOWN MULTIPURPOSE INPUT TRAY HINGE |
|
|
TRAY HINGE LINK - RIGHT SIDE LINK FOR DROP DOWN MULTIPURPOSE INPUT TRAY HINGE |
|
|
UNIVERSAL SERIAL BUS (USB) INTERFACE CABLE - TYPE 'A' CONNECTOR TO TYPE 'B' CONN |
|
|
UNIVERSAL SERIAL BUS (USB) INTERFACE CABLE - TYPE 'A' CONNECTOR TO TYPE 'B' CONN |
|
|
UPPER RIGHT CABLE GUIDE - LOCATED ON TOP OF THE MAIN DRIVE ASSEMBLY AND RUNS VER |
|
|
UPPER SUPPORT COVER - THIS IS BLACK PLASTIC UNDER THE SHEET METAL THAT IS UNDER |
|
|
YELLOW TONER CARTRIDGE - FOR THE COLOR LASERJET 3600 SERIES PRINTERS |
