Manufacturer
HP
Model Number
Q6719A
Description
Designjet Z3200 44-in Photo Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
3-INCH SPINDLE ADAPTOR KIT |
|
|
42-INCH TAKE-UP REEL SPINDLE ASSEMBLY |
|
|
BACK SIDE CHASSIS COVER - FOR 44-INCH DESIGNJET Z2100/Z3100/Z3200 PHOTO PRINTER |
|
|
CARRIAGE (SCAN-AXIS) BELT - FOR 44-INCH PRINTER SERIES |
|
|
CARRIAGE COVER - INCLUDES CARRIAGE LATCH |
|
|
CARRIAGE PC BOARD (PCA) - LOCATED BELOW THE CARRIAGE COVER - FOR THE DESIGNJET Z |
|
|
CARTRIDGE LATCH ASSEMBLY - HOLDS CARTRIDGES IN THE CARRIAGE |
|
|
CLEAN OUT ASSEMBLY - FOR 44-INCH PLOTTERS |
|
|
COLOR SENSOR ESP (SPECTROPHOTOMETER) - FOR THE DESIGNJET Z2100/Z3100/Z3200 PHOTO |
|
|
CROSS-BRACE - CONNECTS AND SUPPORTS THE TWO STAND LEGS - FOR 44-INCH PLOTTERS |
|
|
CUTTER ASSEMBLY - AUTO CUTTER FOR ROLLFEED PAPER |
|
|
DOUBLE SIDED ADHESIVE PAD |
|
|
DROP DETECTOR SENSOR ASSEMBLY |
|
|
ENCODER SENSOR ASSEMBLY |
|
|
ENCODER STRIP ASSEMBLY - INCLUDES ENCODER STRIP SPRING AND NUT - FOR 44-INCH PLO |
|
|
FLEX CONTACTS CLEANING TOOL |
|
|
FRONT COVER - FOR THE 24-INCH DESIGNJET Z3100/Z3200 PHOTO PRINTER SERIES |
|
|
FRONT PANEL ASSEMBLY - DESIGNJET Z3200 PHOTO PRINTER SERIES |
|
|
FRONT PANEL WINDOW COVER - FOR 44-INCH PLOTTERS |
|
|
FULL BLEED FOAM KIT - FOR 44-INCH PLOTTERS |
|
|
HARDWARE KIT FOR PRINTER STAND - INCLUDES SCREWDRIVER AND SCREWS - USED TO ASSEM |
|
|
HARNESS CABLES KIT - INCLUDES LEFT AND RIGHT INK SUPPLY SYSTEMS (ISS) AND THE PR |
|
|
HEAVYWEIGHT COATED PAPER - 91.4CM (36IN) X 30.5M (100FT) ROLL - FOR REGULAR OR U |
|
|
HP 70 BLUE AND GREEN PRINTHEAD |
|
|
HP 70 BLUE INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 CYAN INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 GLOSS ENHANCER INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 GRAY INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 GREEN INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 LIGHT CYAN INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 LIGHT GRAY INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 LIGHT MAGENTA INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 MAGENTA INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 MATTE BLACK INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 PHOTO BLACK INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 RED INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP 70 YELLOW INK CARTRIDGE - PRINT CARTRIDGE VOLUME 130ML |
|
|
HP AQUARELLA ART PAPER (240GSM) - 61CM (24IN) X 10.7M (35FT) ROLL |
|
|
HP ARTIST MATTE CANVAS - 106.7CM (42IN) X 15.2M (50FT) ROLL |
|
|
HP COLLECTOR SATIN CANVAS - 61CM (24IN) X 6.1M (20FT) ROLL |
|
|
HP HAHNEMUHLE TEXTURED FINE ART PAPER (310 GSM) - 106.7CM (42IN) X 10.7M (35FT) |
|
|
HP MATTE LITHO-REALISTIC PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
HP PREMIUM INSTANT-DRY GLOSS PHOTO PAPER - 61CM (24IN) X 22.9M (75FT) ROLL |
|
|
HP PROFESSIONAL MATTE CANVAS - 61CM (24IN) X 6.1M (20FT) ROLL |
|
|
HP SUPER HEAVYWEIGHT PLUS MATTE PAPER - 61CM (24IN) X 30.5M (100FT) ROLL |
|
|
INK SUPPLY STATION (ISS) ASSEMBLY - INSTALLED IN RIGHT SIDE OF PRINTER - FOR THE |
|
|
INK SUPPLY STATION (ISS) ASSEMBLY - INSTALLED ON THE LEFT SIDE OF PRINTER |
|
|
INK SUPPLY TUBES ASSEMBLY - FOR THE 44-INCH DESIGNJET Z3200 PHOTO PRINTER SERIES |
|
|
INK SYSTEM PURGERS - INCLUDES 100 UNITS |
|
|
INK SYSTEM PURGERS - INCLUDES SIX UNITS |
|
|
LEFT CARTRIDGE ACCESS DOOR - PROVIDES ACCESS TO THE PRINT CARTRIDGES |
|
|
LEFT CASE COVER - DOES NOT INCLUDE THE LEFT INK CARTRIDGE DOOR |
|
|
LEFT SIDE PANEL - FOR THE DESIGNJET Z2100/Z3100/Z3200 PHOTO PRINTER SERIES |
|
|
LEFT SIDE ROLL GUIDE ASSEMBLY - FOR 44-INCH PLOTTERS |
|
|
LEFT SIDE SPINDLE HOLDER |
|
|
LEFT-SIDE SPITTOON ASSEMBLY - HOLDS EXPELLED INK FROM CARTRIDGE DURING REFRESH C |
|
|
LEG ASSEMBLY - SIDE SUPPORT FOR THE PLOTTER - DOES NOT INCLUDE THE FOOT ASSEMBLY |
|
|
LEG COVER - SLIDES DOWN OUTSIDE OF STAND LEGS |
|
|
MAIN PCA - INCLUDES THE POWER SUPPLY UNIT AND THE ENGINE BOARD - FOR THE 44-INCH |
|
|
MEDIA BIN (GRAY) - INCLUDES BIN AND SUPPORT - MOUNTS TO THE PRINTER STAND LEGS - |
|
|
MEDIA DRIVER TOOL KIT - INCLUDES THE HANDLE FOR MEDIA DRIVER TOOL SUPPORT AND TH |
|
|
OUTPUT PLATEN ASSEMBLY - FOR 44-INCH PLOTTERS |
|
|
PEN TO PAPER SPACE (PPS) SOLENOID - FOR DESIGNJET PRINTERS |
|
|
PINCH ASSEMBLY - FOR THE DESIGNJET Z2100/Z3100/Z3200 PHOTO PRINTER SERIES |
|
|
PINCH LIFT ASSEMBLY - MOLDED PLASTIC PART - GUIDES THE PAPER DURING PAPER ADVANC |
|
|
PINCHWHEEL INSERTION TOOL |
|
|
PINCHWHEEL LIFTER SENSOR |
|
|
POWER SUPPLY UNIT (PSU) ASSEMBLY - FOR THE DESIGNJET Z3200 PHOTO PRINTER SERIES |
|
|
PREVENTIVE MAINTENANCE KIT - INCLUDES THE CARRIAGE ASSEMBLY WITH TRAILING CABLE, |
|
|
PREVENTIVE MAINTENANCE KIT - INCLUDES THE CUTTER ASSEMBLY |
|
|
PRINT MECHANISM PC BOARD - CONTROLS THE FUNTION OF THE PRINT MECHANISM - FOR THE |
|
|
PRINT ZONE OVERDRIVE ASSEMBLY - FOR 44-INCH PLOTTERS |
|
|
REAR TRAY ASSEMBLY - INCLUDES THE EXTENSION TRAY - FOR 44-INCH PLOTTERS |
|
|
REAR TRAY SUPPORTS - FOR DESIGNJET PRINTERS |
|
|
RIGHT CARTRIDGE ACCESS DOOR - PROVIDES ACCESS TO THE PRINT CARTRIDGES - FOR THE |
|
|
RIGHT SIDE COVER - DOES NOT INCLUDE THE RIGHT SIDE INK CARTRIDGE DOOR - FOR THE |
|
|
RIGHT SIDE SPINDLE HOLDER |
|
|
RUBBER PINCHWHEEL - FOR DESIGNJET PRINTERS |
|
|
SPANNER TOOL |
|
|
STARWHEEL ASSEMBLY - DOES NOT INCLUDE THE ACTUATOR - ENSURES PAPER HANDOVER FROM |
|
|
STARWHEEL LIFTER ASSEMBLY - FOR DESIGNJET PRINTERS |
|
|
TOOL KIT - INCLUDES PINCWHEEL ALIGNMENT TOOL, MEDIA DRIVER TOOL, SPANNER NUMBER |
|
|
TOP COVER ASSEMBLY - FOR 44-INCH DESIGNJET Z2100/Z3100/Z3200 PHOTO PRINTER SERI |
|
|
WINDOW POSITION SENSOR WITH SHIELD |
