Manufacturer
HP
Model Number
Q7517A
Description
Hp Color Laserjet 4730 Mfp
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
128MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACRO |
|
|
128MB, 200PIN, DIMM MEMORY MODULE |
|
|
18-TOOTH GEAR - ATTACHES TO PAPER FEED ASSEMBLY DRIVE MOTOR |
|
|
2 X 500 SHEET FEEDER LEFT FRONT CORNER COVER |
|
|
2 X 500 SHEET FEEDER LEFT LOWER CASTER COVER |
|
|
2 X 500 SHEET FEEDER LEFT LOWER COVER |
|
|
2 X 500 SHEET FEEDER LEFT SIDE COVER |
|
|
2 X 500 SHEET FEEDER RIGHT LOWER CASTER COVER |
|
|
2 X 500 SHEET FEEDER RIGHT LOWER COVER |
|
|
2 X 500 SHEET FEEDER RIGHT SIDE COVER |
|
|
2 X 500 SHEET FEEDER RIGHT SIDE LOWER COVER ASSEMBLY |
|
|
2 X 500 SHEET PAPER FEEDER CASSETTE SIZE CABLE |
|
|
2 X 500 SHEET PAPER FEEDER INTERFACE CABLE |
|
|
2 X 500 SHEET PAPER FEEDER LEFT REGISTRATION ADJUSTMENT ASSEMBLY |
|
|
2 X 500 SHEET PAPER FEEDER MOTOR ASSEMBLY |
|
|
2 X 500 SHEET PAPER FEEDER MOTOR CABLE |
|
|
2 X 500 SHEET PAPER FEEDER RIGHT SIDE SWITCH ASSEMBLY |
|
|
2 X 500 SHEET PAPER FEEDER SOLENOID CABLE - 2 X 500 PAPER DECK DRIVER PCB TO LOW |
|
|
2 X 500 SHEET PAPER FEEDER SOLENOID CABLE - 2X500 PAPER DECK DRIVER PCB TO PAPER |
|
|
2 X 500 SHEET PAPER TRAY ASSEMBLY - THIS IS THE COMPLETE ASSEMBLY |
|
|
256MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACRO |
|
|
256MB, 200 PIN, DIMM MEMORY MODULE |
|
|
29-TOOTH GEAR - CARTRIDGE DRIVE GEAR |
|
|
30-TOOTH GEAR - CARTRIDGE GEAR THAT DRIVES 29-TOOTH GEAR |
|
|
500-SHEET PAPER TRAY/CASSETTE - THIS IS ONLY THE TRAY, DOES NOT INCLUDE FEEDER O |
|
|
512MB, 200-PIN, SDRAM DIMM MEMORY MODULE |
|
|
ACCESS LATCH - ADF JAM ACCESSS LATCH |
|
|
ADF FRONT PLASTIC COVER |
|
|
ADF HINGE FLAP - ESD HINGE COVER FOR ADF ASSEMBLY |
|
|
ADF INPUT TRAY ASSEMBLY |
|
|
ADF JAM ACCESS COVER - TO REMOVE PAPER JAM FROM THE ADF |
|
|
ADF MAINTENANCE KIT - INCLUDES THE ADF PAPER PICK-UP ROLLER ASSEMBLY, SEPARATION |
|
|
ADF OUTPUT TRAY BOTTOM COVER |
|
|
ADF PAPER PICKUP ROLLER ASSEMBLY - INCLUDES THE PICKUP ROLLER, SEPARATION ROLLER |
|
|
ADF PAPER SEPERATION PAD ASSEMBLY - MOUNTS IN THE CENTER OF THE ADF SEPARATION P |
|
|
ADF PLASTIC COVER FOR LEFT SIDE |
|
|
ADF REAR PLASTIC COVER |
|
|
ADF SEPARATION PAD FRAME ASSEMBLY - INCLUDES THE FULL WIDTH SUPPORT STRUCTURE AN |
|
|
ADF WHITE PLASTIC SCANNER BACKGROUND PLATE - USED AS A WHITE BACKGROUND DURING F |
|
|
ADVANCED GLOSSY PAPER - 10.2CM (4IN) X 15.2CM (6IN) - 100 SHEETS |
|
|
ADVANCED GLOSSY PHOTO PAPER - 10.2CM (4IN) X 15.2CM (6IN) FINISHED SIZE - 10.2CM |
|
|
ADVANCED GLOSSY PHOTO PAPER - A SIZE (8.5 X 11-INCHES) - 100 SHEETS |
|
|
ADVANCED GLOSSY PHOTO PAPER - A SIZE (8.5 X 11-INCHES) - 25 SHEETS |
|
|
AUTOMATIC DOCUMENT FEEDER (ADF) ASSEMBLY - DOES NOT INCLUDE EXTERANL PLASTIC COV |
|
|
CABLE ASSEMBLY - GOES TO MP/TRAY 1 PICKUP UNIT, MP/TRAY 1 PICKUP UNIT TRAY SENSO |
|
|
CABLE GUIDE - COVER FOR THE FEED UNIT CABLE |
|
|
CABLE GUIDE - GUIDE FOR ELECTROSTATIC TRANSFER BELT (ETB) FAN TO DC CONTROLLER C |
|
|
CABLE HOLDER - BLACK PLACTIC COVER THAT PROTECTS FORMATTER TO SCANNER CABLE |
|
|
CABLE HOLDER - HOLDS THE FLAT CABLE FROM THE FORMATTER TO THE SCANNER ASSEMBLY |
|
|
CABLE HOLDER - LOCATED ON CENTER BACK OF RFI SHIELD |
|
|
CARTRIDGE GUIDE - LEFT SIDE GUIDE FOR TONER CARTRIGES - COVERS HIGH VOLTAGE CONT |
|
|
CARTRIDGE GUIDE ASSEMBLY - RIGHT LOWER SIDE |
|
|
CARTRIDGE GUIDE ASSEMBLY - RIGHT UPPER SIDE |
|
|
CASSETTE ROLLER KIT - INCLUDES TWO PICKUP/FEED ROLLERS AND ONE SEPARATION ROLLER |
|
|
COLOR LASERJET 4730MFP SERVICE MANUAL - ENGLISH ONLY |
|
|
COLOR LASERJET TRANSPARENCY FILM - A SIZE (8.5 X 11-INCHES) - 50 SHEETS |
|
|
COMPRESSION SPRING - CONTACT SPRING FOR TONER CARTRIDGE - FOUR USED |
|
|
COMPRESSION SPRING - HOLDS THE WHITE MYLAR BACKING PLATE FIRMLY AGAINST THE DOCU |
|
|
COMPRESSION SPRING - PROVIDES PRESSURE FOR SEPARATION GUIDE PIN |
|
|
COMPRESSION SPRING - PROVIDES TENSION FOR LEFT SIDE OF DELIVERY ROLLER |
|
|
CONTACT ASSEMBLY - HIGH VOLTAGE CONTACT FOR ATTRACTION ROLLER |
|
|
CONTROL PANEL CABLE ASSEMBLY |
|
|
CONTROL PANEL OVERLAY - CZECH |
|
|
CONTROL PANEL OVERLAY - DANISH |
|
|
CONTROL PANEL OVERLAY - DUTCH |
|
|
CONTROL PANEL OVERLAY - FINNISH |
|
|
CONTROL PANEL OVERLAY - FRENCH |
|
|
CONTROL PANEL OVERLAY - GERMAN |
|
|
CONTROL PANEL OVERLAY - GREEK |
|
|
CONTROL PANEL OVERLAY - HEBREW |
|
|
CONTROL PANEL OVERLAY - HUNGARIAN |
|
|
CONTROL PANEL OVERLAY - ITALIAN |
|
|
CONTROL PANEL OVERLAY - JAPANESE |
|
|
CONTROL PANEL OVERLAY - KOREAN |
|
|
CONTROL PANEL OVERLAY - NORWEGIAN |
|
|
CONTROL PANEL OVERLAY - POLISH |
|
|
CONTROL PANEL OVERLAY - PORTUGUESE |
|
|
CONTROL PANEL OVERLAY - RUSSIAN |
|
|
CONTROL PANEL OVERLAY - SIMPLIFIED CHINESE |
|
|
CONTROL PANEL OVERLAY - SPANISH |
|
|
CONTROL PANEL OVERLAY - SWEDISH |
|
|
CONTROL PANEL OVERLAY - THAI |
|
|
CONTROL PANEL OVERLAY - TRADITIONAL CHINESE |
|
|
CONTROL PANEL OVERLAY - TURKISH |
|
|
COOLING FAN - DUPLEXER UNIT COOLING FAN |
|
|
COOLING FAN - SUB POWER SUPPLY FAN - FAN FM2 |
|
|
COOLING FAN - USED ON CARTRIDGE AREA, FUSER AREA AND DELIVERY AREA COOLING FANS |
|
|
COVER SHIELD - LOCATED ON UPPER REAR OF PRINTER |
|
|
COVER SHIELD - RFI COVER SHIELD |
|
|
COVER SHIELD - RFI SHIELD FOR CABLE THAT RUNS BETWEEN FORMATTER PCA AND PAPER SC |
|
|
COVER SPRING - PROVIDES TENSION FOR LEFT SIDE PLASTIC COVER OF ADF ASSEMBLY - TW |
|
|
DELIVERY FAN ASSEMBLY - INCLUDES HOLDER AND DUCT ASSEMBLY - FAN #6 |
|
|
DELIVERY ROLLER - FOR 110-127 VAC DELIVERY ASSEMBLY |
|
|
DELIVERY ROLLER - FOR 220-240 VAC DELIVERY ASSEMBLY |
|
|
DISENGAGING DRIVE ASSEMBLY |
|
|
DOOR HINGE - LEFT SIDE DOOR HINGE FOR LOWER RIGHT ACCESS DOOR |
|
|
DOOR HINGE - RIGHT SIDE HINGE FOR LOWER RIGHT ACCESS DOOR |
|
|
DRIVE SENSOR CABLE - CABLE THAT CONNECTS TO DRIVE MOTORS ON RIGHT OF PRINTER |
|
|
DRUM MOTOR ASSEMBLY - PROVIDES POWER FOR ALL FOUR DRUMS - FOR MOTORS M1 THROUGH |
|
|
DUPLEXER FEED ASSEMBLY - MOUNTED ON THE ELECTROSTATIC TRANSFER BELT (ETB) |
|
|
ELECTROSTATIC TRANSFER BELT (ETB) ASSEMBLY - DOES NOT INCLUDE THE DUPLEX FEED AS |
|
|
ELECTROSTATIC TRANSFER BELT (ETB) LEVER ASSEMBLY - RIGHT TOP OF ETB CLIPS INTO T |
|
|
ELECTROSTATIC TRANSFER BELT (ETB) LEVER ASSEMBLY - TOP LEFT OF ETB ASSEMBLY CLIP |
|
|
FACE DOWN CENTER GUIDE - |
|
|
FAN CABLE - CONNECTS FAN DRIVER PCA TO ELECTROSTATIC TRANSFER BELT (ETB) COOLING |
|
|
FAN CABLE ASSEMBLY - CONNECTS FAN DRIVER BOARD TO FANS FM5, FM6 AND FM7 - ALSO C |
|
|
FAN CONNECTING CABLE - CONNECTS FANS FM2, FM4, AND FM7 TO THE DC CONTROLLER |
|
|
FAN DRIVER PC BOARD ASSEMBLY |
|
|
FAN DUCT - DUCT FOR SUB POWER SUPPLY FAN FM2 |
|
|
FAN DUCT - FOR FANS FM2 AND FM4 |
|
|
FAN HOLDER -FAN MOUNT ASSEMBLY FOR SUB POWER SUPPLY FAN FM2 |
|
|
FAN HOLDER FOR FUSER FAN - FAN FM1 |
|
|
FEED DRIVE BOARD ASSEMBLY - MOUNTS ON THE RIGHT SIDE OF THE 2X500-SHEET INPUT TR |
|
|
FEED UNIT CONNECT CABLE ASSEMBLY - CABLE FROM THE DC CONTROLLER TO THE PAPER FEE |
|
|
FLAG ACTIVATED PHOTOSENSOR - ONE USED TO INDICATE WHEN THE ADF ASSEMBLY IS OPEN |
|
|
FLAT CABLE - RIBBON CABLE THAT RUNS BETWEEN FORMATTER PCB AND PAPER SCANNER ON T |
|
|
FLAT CABLE CONNECTOR - RIBBON CABLE CONNECTOR FOR RIBBON CABLE THAT RUNS BETWEEN |
|
|
FLATBED SCANNER INVERTER PC BOARD - PROVIDES REGULATED VOLTAGE FOR THE SCANNING |
|
|
FORMATTER BOARD ASSEMBLY - FOR COLOR LASERJET 4730MFP |
|
|
FORMATTER BOARD POWER CABLE ASSEMBLY |
|
|
FROM ADF TO SCAN CONTROL BOARD CABLE |
|
|
FRONT COVER MOUNTING PLATE - UPPER MOUNTING PLATE FOR PRINTER FRONT COVER |
|
|
FRONT DOOR AJAR SWITCH - SWITCH SW1 |
|
|
FRONT INNER COVER ASSEMBLY |
|
|
FUSER DOOR ASSEMBLY |
|
|
FUSER DOOR LINK ASSEMBLY - FRONT SIDE |
|
|
FUSER DOOR LINK ASSEMBLY - REAR SIDE |
|
|
FUSER DRIVE CABLE ASSEMBLY - FROM LOW VOLATAGE POWER SUPPLY TO FUSING ASSEMBLY |
|
|
FUSER DRIVE MOTOR - PROVIDES ROTATIONAL POWER FOR FUSER ROLLER - MOTOR M5 |
|
|
FUSER FAN - PROVIDES COOLING FOR FUSER AREA - FAN FM1 |
|
|
FUSER MOTOR CABLE ASSEMBLY |
|
|
FUSER ROLLER DRIVE ASSEMBLY - INCLUDES BOTH MOTORS |
|
|
GEAR BUSHING - FITS BEHIND 30 TOOTH CARTRIDGE DRIVE GEAR |
|
|
GUIDE - COVER/GUIDE THAT GOES OVER TRAY 2 SEPARATION ROLLER |
|
|
GUIDE ASSEMBLY - CONNECTOR GUIDE ASSEMBLY FOR ELECTROSTATIC TRANSFER BELT (ETB) |
|
|
GUIDE COVER - LOWER GUIDE FOR TEST ENGINE BUTTON ROD |
|
|
GUIDE COVER - UPPER GUIDE FOR TEST ENGINE BUTTON ROD |
|
|
GUIDE PIN - FRONT MOUNT FOR GUIDE |
|
|
HIGH VOLTAGE POWER SUPPLY PC BOARD |
|
|
HIGH VOLTAGE TERMINAL BLOCK - HIGH VOLTAGE CONTACT FOR TONER CARTRIDGE - FOUR US |
|
|
HINGE ASSEMBLY - ADF LEFT SIDE HINGE ASSEMBLY |
|
|
HINGE ASSEMBLY - ADF RIGHT SIDE HINGE ASSEMBLY |
|
|
HP 512MB 100 PIN DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACR |
|
|
HP COLOR LASER SOFT-GLOSS PRESENTATION PAPER - A SIZE (8.5 X 11-INCHES) - 200 SH |
|
|
HP COLOR LASERJET YELLOW PRINT CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ON 4-PIN USB CONNECTOR AND ONE RJ- |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ONE 4-PIN USB CONNECTOR AND ONE RJ |
|
|
HP JETDIRECT 175X EXTERNAL PRINT SERVER - HAS ONE 4-PIN USB CONNECTOR AND ONE RJ |
|
|
HP JETDIRECT 380X EXTERNAL IEEE-802.11B (WI-FI) WIRELESS PRINT SERVER - CONNECTS |
|
|
HP JETDIRECT 620N INTERNAL PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE BO |
|
|
HP JETDIRECT 625N INTERNAL ETHERNET PRINT SERVER - PROVIDES 10BASET, 100BASETX, |
|
|
HP JETDIRECT 635N IPV6/IPSEC PRINT SERVER - 10BASET AND 100BASETX LAN INTERFACE |
|
|
HP JETDIRECT EN3700 EXTERNAL PRINT SERVER - FAST ETHERNET INTERNET CONNECTOR FOR |
|
|
HP JETDIRECT EW2400 802.11G WIRELESS PRINT SERVER MODULE - INCLUDES POWER SUPPLY |
|
|
HP LASERJET 4345 MFP ADF MYLAR SHEETS - PACKAGE OF THREE SHEETS |
|
|
HUMIDITY SENSOR ASSEMBLY - LOCATED AT BOTTOM OF LEFT SIDE ETB FAN DUCT |
|
|
IEEE 1284 BI-TRONICS PARALLEL CABLE - DB-25 (M) CONNECTOR (TYPE A) TO 36-PIN HIG |
|
|
IMAGE TRANSFER KIT - ELECTROSTATIC TRANSFER BELT (ETB) ASSEMBLY WITH CLEANING CL |
|
|
INNER FRONT COVER (BLACK) - FRONT COVER THAT PROTECTS THE METAL FRAME BELOW THE |
|
|
INNER REAR COVER - |
|
|
INNER TOP COVER - |
|
|
INNER TOP REAR COVER - |
|
|
INTERMEDIATE PAPER TRANSFER UNIT (IPTU) STEPPER MOTOR - TWO USED |
|
|
JAM ACCESS COVER - TOP ACCESS COVER FOR ADF ASSEMBLY |
|
|
KICKER ASSEMBLY - PLASTIC PIECE THAT WRAPS AROUND THE LIFTER MOTOR |
|
|
LASERJET PRINTER TRANSPARENCY FILM - A4 SIZE (21.0CM X 29.7CM) - 50 SHEETS |
|
|
LEFT CASSETTE RAIL ASSEMBLY - LEFT RAIL ASSEMBLY FOR 500 SHEET PAPER TRAY |
|
|
LEFT ELECTROSTATIC TRANSFER BELT (ETB) CAP - LOWER LEFT SIDE OF ELECTROSTATIC T |
|
|
LEFT SIDE ARM COVER |
|
|
LEFT SIDE CARTRIDGE PRESSURE LEVER - HOLDS CARTRIDGE AGAINST HIGH VOLTAGE CONTAC |
|
|
LEFT SIDE PRINTER COVER ASSEMBLY - LEFT SIDE PLASTIC COVER FOR PRINTER |
|
|
LOCK COVER - FLATBED SCANNER CARRIAGE LOCK COVER - TOP LEFT SIDE OF FLATBED SCAN |
|
|
LOCK LEVER - LEVER THAT LOCKS INTO PLATE THAT SECURES THE MP PAPER PICKUP ASSEMB |
|
|
LOCK PLATE - PLATE THAT MP PAPER PICKUP ASSEMBLY LEVER LOCKS INTO - TWO USED |
|
|
LOCK TAB - WHITE PLASTIC TAB ON TOP OF DUPLEXER THAT LOCKS UNIT IN PLACE - TWO U |
|
|
LOW VOLTAGE POWER SUPPLY BOARD - 110 VAC |
|
|
LOW VOLTAGE POWER SUPPLY BOARD - 220 VAC |
|
|
LOWER COVER - COVERS LOWER RIGHT CORNER OF ELECTROSTATIC TRANSFER BELT (ETB) ARE |
|
|
LOWER PAPER PICKUP ASSEMBLY FOR LOWER HALF OF 2 X 500 SHEET PAPER TRAY ASSEMBLY |
|
|
LOWER PAPER PICKUP DRIVE ASSEMBLY - LOCATED IN 2 X 500-SHEET PAPER TRAY ASSEMBLY |
|
|
M3 PAN-HEAD PHILLIPS SCREW WITH PLASTITE THREADS - 8MM LONG |
|
|
M3 TRUSS HEAD (FLANGED) SCREW - 8MM LONG |
|
|
M4 PAN-HEAD PHILLIPS SCREW WITH MACHINE THREADS - 10MM LONG |
|
|
MAIN CABLE ASSEMBLY |
|
|
MAIN DRIVE ASSEMBLY - GEAR DRIVE ASSEMBLY FOR DRUM MOTORS |
|
|
MEMORY BOARD PCA |
|
|
MEMORY CONTACT CABLE - CONNECTS TO E-LABEL SENSORS |
|
|
MFP POWER CABLE ASSEMBLY |
|
|
MOUNT ASSEMBLY - HIGH VOLTAGE TERMINAL MOUNT FOR TONER CARTRIDGE - FOUR USED |
|
|
MP TRAY ROLLER KIT - CONTAINS TRAY 1/MP TRAY PICKUP ROLLER AND TRAY 2 SEPARATION |
|
|
MULTIPURPOSE PAPER INPUT TRAY ASSEMBLY - TRAY 1 - HOLDS UP TO 100 SHEETS OF PAPE |
|
|
MULTIPURPOSE/TRAY 1 PAPER INPUT PICKUP ASSEMBLY - INCLUDES ALL ROLLERS AND SEPER |
|
|
MULTIPURPOSE/TRAY 1 SEPARATION PAD ASSEMBLY |
|
|
MYLAR HOLDER ASSEMBLY - THIS IS THE COVER (HOLDER) THAT HOLDS THE CLEAR MYLAR SH |
|
|
PAPER DELIVERY COVER ASSEMBLY |
|
|
PAPER FEED ASSEMBLY - INCLUDES METAL PLATE, PICKUP DRIVE SOLENOID, DRIVE GEARS A |
|
|
PAPER GUIDE - ADF CLEAR PLASTIC PAPER GUIDE |
|
|
PAPER GUIDE - FACE DOWN FRONT PAPER OUTPUT GUIDE |
|
|
PAPER GUIDE - FACE DOWN REAR PAPER OUTPUT GUIDE |
|
|
PAPER LEVEL SENSOR FLAG - PAPER SENSOR FLAG IN DELIVERY ASSEMBLY |
|
|
PAPER OUTPUT TRAY - FACE DOWN OUTPUT TRAY ON LEFT SIDE OF PRINTER |
|
|
PAPER PICKUP DRIVE ASSEMBLY - FOR TRAY 1 AND TRAY 2 |
|
|
PAPER PICKUP DRIVE ASSEMBLY SOLENOID |
|
|
PAPER PICKUP MOTOR ASSEMBLY - DRIVES PICKUP AND FEED ROLLERS - INCLUDES MOTOR M9 |
|
|
PAPER PICKUP ROLLER - GRAY SPONGY RUBBER ROLLER ON A WHITE CYLINDER AND 24-TOOTH |
|
|
PAPER SENSOR CABLE ASSEMBLY |
|
|
PAPER STOP - ADF OUTPUT TRAY PAPER STOP |
|
|
PARALLEL PORT CARD - 1284B PARALLEL CARD - COMPATIBLE OPERATING SYSTEMS WINDOWS |
|
|
PHOTO-INTERRUPTER SENSOR ASSEMBLY (DOES NOT INCLUDE THE SENSOR FLAG) |
|
|
PICKUP CABLE ASSEMBLY |
|
|
PICKUP ROLLER COVER - 'C' SHAPED PLASTIC COVER THAT SURROUNDS THE PAPER PICKUP R |
|
|
POWER CABLE ASSEMBLY - CABLE THAT RUNS BETWEEN THE LOW VOLTAGE POWER SUPPLY AND |
|
|
POWER SAVE CABLE ASSEMBLY - CONNECTS SUB POWER SUPPLY TO THE LOW VOLTAGE POWER S |
|
|
POWER SUPPLY SWITCH ASSEMBLY - USER POWER BUTTON ASSEMBLY |
|
|
PRESSURE PLATE - WHEN THIS PLATE IS PUSHED, IT ROTATES A GEAR, WHICH THEN MOVES |
|
|
PRINTER HARD DRIVE ASSEMBLY |
|
|
RAIL ASSEMBLY - RAIL THAT THE MP TRAY PAPER PICKUP ASSEMBLY MOUNTS TO - TWO USED |
|
|
REAR COVER FOR 2 X 500 SHEET PAPER FEEDER ASSEMBLY |
|
|
REAR OF PRINTER COVER ASSEMBLY |
|
|
REAR PLATE ASSEMBLY - METAL SUPPORT FOR LASER/SCANNER ASSEMBLIES |
|
|
REPLACEMENT STAPLE CARTRIDGE - CONTAINS 5000 STAPLES |
|
|
RIGHT CASSETTE RAIL ASSEMBLY - RIGHT RAIL ASSEMBLY FOR 500 SHEET PAPER TRAY |
|
|
RIGHT ELECTROSTATIC TRANSFER BELT (ETB) CAP - LOWER RIGHT SIDE OF ELECTROSTATIC |
|
|
RIGHT FRONT COVER FOR 2 X 500 SHEET PAPER FEEDER ASSEMBLY |
|
|
RIGHT SIDE ARM COVER |
|
|
RIGHT SIDE PRINTER COVER ASSEMBLY - INCLUDES ELECTROSTATIC TRANSFER BELT (ETB) F |
|
|
SCANNER ASSEMBLY - COMPLETE FLATBED SCANNER ASSEMBLY |
|
|
SCANNER ASSEMBLY FAN FILTER COVER |
|
|
SCANNER CARRIAGE DRIVE BELT ASSEMBLY - INCLUDES THE BELT, IDLER GEAR, GEAR HOLDE |
|
|
SCANNER CARRIAGE LOCK ASSEMBLY - INCLUDES THE BRACKECT, THE TWO SLIDER/LOCK PIEC |
|
|
SCANNER CONTROL BOARD (SCB) - PROVIDES TIMING AND CONTROL FOR THE FLATBED SCANNE |
|
|
SCANNER FAN FILTER - SMALL RECTANGULAR FOAM FILTER |
|
|
SCANNER FLATBED UNIT ASSEMBLY |
|
|
SCANNER FLATBED UNIT LEFT LOWER PLASTIC COVER |
|
|
SCANNER FLATBED UNIT REAR PLASTIC COVER |
|
|
SCANNER MOTOR BELT - SMALL BELT BETWEEN THE SCANNER MOTOR AND THE DOUBLE DRIVE G |
|
|
SCANNER OPEN SENSOR ASSEMBLY - INCLUDES THE HOUSING, SPRING-LOADED PLUNGER, AND |
|
|
SCANNER RETAINING ASSEMBLY - BAR ON LEFT SIDE OF LASER/SCANNER ASSEMBLIES THAT H |
|
|
SCANNER RETAINING ASSEMBLY - BAR ON RIGHT SIDE OF LASER/SCANNER ASSEMBLIES THAT |
|
|
SCANNER RIGHT COVER ASSEMBLY |
|
|
SCANNER SUPPORT ROD - PLASTIC ROD ON BACK OF SCANNER BANK |
|
|
SCANNER SUPPORT SPRING - PROVIDES TENSION FOR SCANNER SUPPORT ROD - FOUR USED |
|
|
SCANNER TOP COVER FLATBED FLANGE |
|
|
SCREW - USED TO SECURE FLATBED SCANNER SLIDE RAIL |
|
|
SENSOR CABLE - BETWEEN DC CONTROLLER BOARD AND DISENGAGING DRIVE SENSOR |
|
|
SENSOR CABLE - FROM DC CONTROLLER BOARD TO SENSORS SR1, SR2 AND SR3 |
|
|
SENSOR LEVER - TRAY 2 TOP OF STACK SENSOR |
|
|
SENSOR MICROSWITCH - SENSES WHEN MP/TRAY 1 PAPER PICKUP UNIT IS INSTALLED |
|
|
SEPARATION PAD SUPPORT - SUPPORT THAT THE TRAY 2 SEPARATION PAD MOUNTS TO |
|
|
SHEET METAL COVER - RIGHT FRONT INNER LOWER COVER |
|
|
SMALL MOUNTING PLATE FOR PRINTER FRONT COVER - ATTACHES ON LOWER RIGHT FRONT |
|
|
SOFT GLOSS COLOR LASERJET PAPER - A4 SIZE (21.0CM X 29.7CM) - 200 SHEETS PER PAC |
|
|
SOLENOID COVER - COVER ON LEFT SIDE OF DUPLEXER ASSEMBLY |
|
|
SPRING LOADED PIN - REAR SPRING LOADED PIN FOR SEPARATION GUIDE |
|
|
STEPPER MOTOR - DISENGAGING MOTOR - MOTOR M8 |
|
|
SUB POWER SUPPLY BOARD - PROVIDES POWER TO THE ADF AND THE IMAGE SCANNER |
|
|
SWITCHING ARM - ATTACHES TO THE SWITCHING ARM GUIDE |
|
|
SWITCHING ARM - METAL ROD THAT PROVIDES MECHANICAL LINK FROM OUTSIDE POWER BUTTO |
|
|
SWITCHING ARM GUIDE - PLASTIC SUPPORT FOR METAL ROD THAT GOES BETWEEN LOW VOLTAG |
|
|
SWITCHING ARM GUIDE - PLASTIC SUPPORT FOR METAL ROD THAT GOES BETWEEN OUTSIDE PO |
|
|
SWITCHING ARM LINK - PLASTIC PIVOT FOR METAL RODS THAT MECHANICALLY CONNECT OUTS |
|
|
TENSION SPRING - PROVIDES TENSION FOR BAR ON LEFT SIDE OF CARTRIDGE ELECTRICAL C |
|
|
TENSION SPRING - PROVIDES TENSION FOR ETB RIGHT SIDE LOWER PRESSURE PLATE |
|
|
TENSION SPRING - PROVIDES TENSION FOR LEFT SIDE CARTRIDGE LEVER - FOUR USED |
|
|
TENSION SPRING - PROVIDES TENSION FOR LIFTER DRIVE ASSEMBLY |
|
|
TEST PRINT BUTTON ASSEMBLY - LOCATED ON THE DC CONTROLLER BOARD |
|
|
TEST PRINT ROD - TEST ENGINE BUTTON ROD - MECHANICAL CONNECTION FOR ENGINE TEST |
|
|
TONER CARTRIDGE - BLACK TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES |
|
|
TONER CARTRIDGE - BLACK TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES |
|
|
TONER CARTRIDGE - CYAN TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES B |
|
|
TONER CARTRIDGE - CYAN TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES B |
|
|
TONER CARTRIDGE - MAGENTA TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGE |
|
|
TONER CARTRIDGE - MAGENTA TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGE |
|
|
TONER CARTRIDGE - YELLOW TONER CARTRIDGE - WILL PRINT APPROXIMATELY 12,000 PAGES |
|
|
TONER CLEANING CLOTH - SPECIALLY TREATED CLOTH FOR ABSORBING TONER (1 PER PACKAG |
|
|
TONER SENSOR PC BOARD - SMALL VERTICAL BOARD ON RIGHT SIDE OF TONER CARTRIDGES |
|
|
TORSION SPRING - PROVIDES TENSION FOR LEVER THAT SECURES THE MP PAPER PICKUP ASS |
|
|
TRAY 1 PICKUP ROLLER - D-SHAPED ROLLER LOCATED UNDER THE ENVELOPE COVER |
|
|
TRAY 1/MP TRAY COVER - COVER ON THE FRONT OF THE MP TRAY PICKUP ASSEMBLY |
|
|
TRAY 2 PAPER SIZE TRAY SENSING ASSEMBLY - WHITE PLASTIC TRAY SIZE SENSING FINGER |
|
|
TUBAXIAL FAN - SCANNER MOTOR COOLING FAN |
|
|
UNIVERSAL SERIAL BUS (USB) INTERFACE CABLE (BLACK) - TYPE 'A' CONNECTOR TO TYPE |
|
|
UPPER PAPER DELIVERY COVER - |
|
|
UPPER PAPER PICKUP ASSEMBLY - USED IN 2 X 500 SHEET PAPER FEEDER |
|
|
UPPER PAPER PICKUP ASSEMBLY DOOR SWITCH CABLE |
|
|
UPPER PAPER PICKUP ASSEMBLY PAPER FEED JAM SENSOR CABLE |
|
|
UPPER PAPER PICKUP ASSEMBLY PAPER FEED SENSOR UNIT - INCLUDES FLAG, SENSOR AND C |
|
|
UPPER PAPER PICKUP ASSEMBLY PAPER JAM SENSOR FLAG |
|
|
UPPER PAPER PICKUP DRIVE ASSEMBLY - LOCATED IN 2 X 500-SHEET PAPER TRAY ASSEMBLY |
|
|
UPPER RIGHT SIDE ACCESS DOOR ASSEMBLY - LOCATED ABOVE MP/TRAY 1 ASSEMBLY |
|
|
WHITE BACKING PLATE ASSEMBLY - USED AS A WHITE BACKGROUND FOR SCANNING DOCUMENTS |
