Manufacturer
HP
Model Number
Q7831A
Description
Hp Laserjet M5035xs Mfp
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
128MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACRO |
|
|
14-TOOTH GEAR |
|
|
15-TOOTH GEAR |
|
|
25-TOOTH GEAR |
|
|
250-SHEET LOWER PAPER CASSETTE TRAY 3 ASSEMBLY |
|
|
250-SHEET UPPER PAPER CASSETTE TRAY 2 ASSEMBLY |
|
|
256MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACRO |
|
|
26-TOOTH GEAR - LOCATED ON THE GEAR PLATE - SNAPS IN TO THE 43-TOOTH GEAR |
|
|
32MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACROS |
|
|
33-TOOTH GEAR |
|
|
35-TOOTH GEAR |
|
|
40/99 TOOTH GEAR - HAVE 40-TOOTH ON THE INSIDE AND 99-TOOTH ON THE OUTSIDE - LOC |
|
|
43-TOOTH GEAR - LOCATED ON THE GEAR PLATE |
|
|
48MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACROS |
|
|
500 SHEET STAPLER STACKER PAPER ASSEMBLY |
|
|
500-SHEET OUTPUT BIN - FOR THE STAPLER/STACKER UNIT |
|
|
512MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACRO |
|
|
52/96 TOOTH GEAR - HAVE 52-TOOTH ON THE INSIDE AND 96-TOOTH ON THE OUTSIDE - LOC |
|
|
64MB, 100-PIN, DDR DIMM - USED TO ADD FLASH MEMORY-BASED ACCESSORY FONTS, MACROS |
|
|
73-TOOTH GEAR - LOCATED ON THE GEAR PLATE |
|
|
ADF DIVERTER ASSEMBLY - DIVERTS PAPER TO DUPLEXER ASSEMBLY, FACE UP TRAY OR FACE |
|
|
ADF FLAG SENSOR LS |
|
|
ADF FLOAT ASSEMBLY |
|
|
ADF FRONT COVER - LOCATED ON THE FORNT PART OF THE ADF UNIT ON TOP OF THE CONTRO |
|
|
ADF HINGE - FOR THE TOP COVER (DOCUMENT LID) ON THE SCANNER (TWO ARE REQUIRED) |
|
|
ADF INPUT PAPER TRAY ASSEMBLY - INCLUDES THE ADJUSTABLE WIDTH |
|
|
ADF JAM ACCESS COVER - LOCATED ON THE LEFT TOP SIDE OF THE PRINTER - TO REMOVE |
|
|
ADF MAINTENANCE KIT - INCLUDES THE ADF PAPER PICKUP ROLLER ASSEMBLY AND THE SEPA |
|
|
ADF PHOTO INTERRUPTER SENSOR WITH CONNECTOR |
|
|
ADF REAR END COVER - PROTECTS THE REAR SIDE OF THE ADF - LOCATED ON TOP OF THE S |
|
|
ADF REFLECTOR FOAM - WHITE PLASTIC SHEET WITH FOAM THAT REFLECTS THE LIGHT WILE |
|
|
AUTOMATIC DOCUMENT FEEDER (ADF) AND FLATBED SCANNER LID - INCLUDES THE LID, THE |
|
|
BACK END SENSOR ASSEMBLY - INCLUDES BLOCK SENSOR, GROUNDING SPRING, AND PUSH SWI |
|
|
BLACK TONER CARTRIDGE WITH SMART PRINTING TECHNOLOGY - PRINTS APPROXIMATELY 15,0 |
|
|
BOTTOM COVER - PROTECTS THE BOTTOM PART OF THE SCANNER ASSEMBLY - WHERE THE SCAN |
|
|
BUSHING - LOCATED BETWEEN THE 25-TOOTH AND 35-TOOTH GEARS ON THE TRANFER DRIVE S |
|
|
BUSHING - LOCATED ON THE GEAR PLATE NEXT TO THE CAM AND THE 133-TOOTH GEAR |
|
|
CARTRIDGE DOOR STOPPER - PROVIDED A PREDETERMINED POSITION FOR THE CARTRIDGE DOO |
|
|
CARTRIDGE DOOR STOPPER - PROVIDED A PREDETERMINED POSITION FOR THE CARTRIDGE DOO |
|
|
CARTRIDGE GUIDE - FRONT LEFT SIDE TONER CARTRIDGE GUIDE |
|
|
CARTRIDGE GUIDE - LOWER RIGHT SIDE TONER CARTRIDGE GUIDE |
|
|
CARTRIDGE GUIDE - UPPER RIGHT SIDE TONER CARTRIDGE GUIDE |
|
|
CASSETTE SUPPORT RAIL ASSEMBLY - LEFT SIDE TRAY 2 SUPPORT RAIL ASSEMBLY |
|
|
CASSETTE SUPPORT RAIL ASSEMBLY - RIGHT SIDE TRAY 2 SUPPORT RAIL ASSEMBLY |
|
|
CLEAN OUT ACCESS DOOR - LEFT SIDE DOOR THAT PROVIDES ACCESS TO PAPER JAMS |
|
|
COMPRESSION SPRING - ELECTRICAL CONTACT SPRING FOR TONER CARTRIDGE |
|
|
COMPRESSION SPRING - ELECTRICAL CONTACT SPRING FOR TONER CARTRIDGE |
|
|
COMPRESSION SPRING - ELECTRICAL CONTACT SPRING FOR TONER CARTRIDGE |
|
|
COMPRESSION SPRING - FUSER BIAS CONTACT FOR FUSER GROUNDING |
|
|
COMPRESSION SPRING - LOCATED NEXT TO THE ARM LOCK |
|
|
COMPRESSION SPRING - LOCATED ON THE FUSER SENSING LINK |
|
|
COMPRESSION SPRING - LOCATED ON THE GEAR PLATE AT THE END OF THE 43-TOOTH GEAR |
|
|
COMPRESSION SPRING - PROVIDES PRESSURE FOR GEAR PACK AT LEVER ARM THAT COUPLES T |
|
|
COMPRESSION SPRING - PROVIDES PRESSURE FOR MP/TRAY 1 SEPARATION PAD ASSEMBLY |
|
|
COMPRESSION SPRING - PROVIDES PRESSURE FOR TAG LINK |
|
|
CONTACT HOLDER - HOLDS FUSER BIAS CONTACTS |
|
|
CONTACT HOLDER COVER - FUSER BIAS CONTACT COVER |
|
|
CONTROL BOARD CABLE - CONNECTS AUTOMATIC DOCUMENT FEEDER (ADF) TO THE SCANNER |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (ARABIC) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (CHINESE) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (CROATIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (CZECH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (DANISH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (DUTCH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (ENGLISH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (FINLAND) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (FOR USE IN T |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (FRENCH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (GREEK) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (HEBREW) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (HUNGARIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (ITALIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (NORWEGIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (POLISH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (PORTUGUESE) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (ROMANIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (RUSSIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (SLOVAKIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (SLOVENIAN) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (SPANISH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (SWEDISH) |
|
|
CONTROL PANEL OVERLAY - SNAPS ON TOP OF THE CONTROL PANEL ASSEMBLY (TURKISH) |
|
|
COUPLING LEVER - LEVER ARM THAT COUPLES THE DRIVE GEAR TO THE TONER CARTRIDGE |
|
|
CROSS MEMBER AUXILIARY PLATE |
|
|
DELIVERY DRIVE ASSEMBLY |
|
|
DOOR OPEN DETECTION SWITCH (SW103) |
|
|
DOOR SWITCH - INDICATES WHEN FUSER DOOR IS OPEN |
|
|
DOOR SWITCH - INDICATES WHEN TONER CARTRIDGE DOOR IS OPEN |
|
|
DRIVE RELEASE LEVER |
|
|
DUPLEXER BLANK COVER - LOCATED NEXT TO THE LEFT UPPER COVER |
|
|
E-RING TYPE |
|
|
ELECTROMAGNETIC CLUTCH (CL2) |
|
|
FACE DOWN SIDE COVER - LOCATED BETWEEN THE FRONT COVER AND THE INNER FRONT COVER |
|
|
FAX CABLE |
|
|
FAX CARD CRADLE (BLACK) - HOLDS THE FAX CARD IN A SPECIFIC POSITION ON THE MOTHE |
|
|
FEED ROLLER HIGH CAPACITY INPUT (HCI) - TRANSMIT THE PAPER FROM THE CASSETTE AND |
|
|
FEED/SEPARATION ROLLER - HAS A BLUE GEAR ON ONE END AND BLUE RELEASE TAB ON THE |
|
|
FLEXIBLE FLAT CABLE - 21 PIN CONNECTOR |
|
|
FLEXIBLE FLAT CABLE - 23 PIN CONNECTOR |
|
|
FORMATTER (MAIN LOGIC) PC BOARD - FOR HP LASERJET M5025/M5035 SERIES ONLY |
|
|
FORMATTER BOARD CAGE ASSEMBLY - METAL SHIELD AND ENCLOSURE FOR THE FORMATTER BOA |
|
|
FORMATTER BOARD COVER - LOCATED ON THE BACK RIGHT SIDE OF THE PRINTER NEXT TO TH |
|
|
FORMATTER INSTRUCTION GUIDE |
|
|
FRONT COOLING FAN - MOUNTS ON THE FRONT PART OF THE PRINTER ON TOP OF THE TRAY 3 |
|
|
FRONT COVER - FACE DOWN PAPER DELIVERY COVER |
|
|
FRONT COVER - PLASTIC COVER ON TOP OF THE PAPER CASSETTE TRAY |
|
|
FRONT DUPLEXER GUIDE - GUIDE/SUPPORT FOR DUPLEXER ASSEMBLY |
|
|
FRONT PRESSURE RELEASE LOCK |
|
|
FRONT UPPER COVER - FOR THE 1X500 HIGH CAPACITY INPUT (HCI) TRAY |
|
|
FUSER PRESSURE RELEASE ASSEMBLY |
|
|
FUSER PRESSURE RELEASE ASSEMBLY - INCLUDES PRESSURE RELEASE FRAME, FRONT AND REA |
|
|
FUSER SHAFT SHUTTER |
|
|
FUSER SHUTTER LEVER |
|
|
FUSING ASSEMBLY - FOR 110 VAC - BONDS TONER TO PAPER WITH HEAT |
|
|
FUSING ASSEMBLY DRIVE MOTOR |
|
|
FUSING SHUTTER - FUSER SHUTTER DOOR - CLOSES WHEN CARTRIDGE ACCESS DOOR IS OPENE |
|
|
GEAR SUPPORT PLATE - HOLDS 133-TOOTH GEAR, 73-TOOTH GEAR, 96/52-TOOTH GEAR, 99/4 |
|
|
GROUNDING PLATE - PROVIDES GROUNDING FOR THE PHOTO INTERRUPTER |
|
|
GROUNDING SPRING - LOCATED ON THE REAR GUIDE ASSEMBLY |
|
|
GROUNDING SPRING - USED INSIDE THE PRINT ENGINE |
|
|
HARD DRIVE POWER SATA CABLE - PROVIDES POWER TO THE HARD DRIVE CONNECTS TO THE M |
|
|
HARD DRIVE SATA CABLE - CONNECTS THE HARD DRIVE WITH THE MOTHER BOARD - TRANSFER |
|
|
HP LASERJET MFP 110V PRINTER MAINTENANCE KIT |
|
|
INTERLOCK ASSEMBLY - INCLUDES INTERLOCK SWITCH HOLDER, AND FRON DOOR SWITCH CABL |
|
|
JOG GUIDE ASSEMBLY - MECHANICAL DEVICE THAT PREVENTS SHEETS FOR JOGGING WITH THE |
|
|
LASERJET 5200 SERIES DUPLEXER ASSEMBLY |
|
|
LEFT COVER - PLASTIC COVER THAT PROTECTS THE LEFT SIDE OF THE 1X500 HIGH CAPACIT |
|
|
LEFT DOOR ASSEMBLY - INCLUDES FLAPPER PAD, LEFT DOOR, FACEDOWN GUIDE, LEFT DOOR |
|
|
LEFT LOWER COVER ASSEMBLY |
|
|
LEFT RAIL - RAIL THAT THE CASSETTE TRAY MOUNTS TO - LOCATED ON THE 1X500 HIGH CA |
|
|
LEFT REAR COVER - RECTANGLE SHAPED PLASTIC COVER LOCATED ON THE LEFT REAR SIDE O |
|
|
LEFT UPPER COVER - SMALL RECTANGULAR COVER - LOCATED ON TOP OF THE LEFT LOWER CO |
|
|
LIFTER DRIVE ASSEMBLY - INCLUDES PHOTOSENSOR, GROUNDING PLATE, PUSH SWITCH, FRON |
|
|
LIFTER DRIVE ASSEMBLY - PROVIDES LIFT SUPPORT FOR HIGH CAPACITY INPUT PAPER TRAY |
|
|
LINK STOPPER - STOP FOR LEVER ARM THAT COUPLES THE DRIVE GEAR TO THE TONER CARTR |
|
|
LOOP SENSOR FLAG - TRACKS THE PAPER TENSION DURING ITS MOVEMENT IN THE PAPER PAT |
|
|
LOWER CASSETTE PAPER PICKUP ASSEMBLY |
|
|
LOWER DRIVE ASSEMBLY - INCLUDES LOWER DRIVE PLATE, 43/26 TOOTH GEAR, 14/14 TOOTH |
|
|
LOWER LEFT COVER - FOR THE HIGHT CAPACITY INPUT (HIC) FEEDER |
|
|
LOWER PAD RETURN CAM |
|
|
LOWER RIGHT COVER - FOR THE HIGHT CAPACITY INPUT (HIC) FEEDER |
|
|
LOWER SCANNER DUCT |
|
|
M3 PAN-HEAD PHILLIPS SCREW WITH WASHER - 6MM LONG |
|
|
M3 X 8MM LONG SELF THREADING SCREW WITH CAPTURED WASHER |
|
|
MAIN MOTOR - DRIVES GEARS IN MAIN DRIVE ASSEMBLY |
|
|
MAINTENANCE KIT (220 VAC) - INCLUDES SEPARATION PAD, PICK-UP ROLLERS, PICK-UP AN |
|
|
PAPER FEED ASSEMBLY - FOR THE STAPLER/STACKER UNIT |
|
|
PAPER FEED ASSEMBLY - INCLUDE PLATE, BUSHINGS, COVERS, SPRINGS, STATIC CHARGE EL |
|
|
PAPER FEED GUIDE CAP |
|
|
PAPER FEED PRINTED CIRCUIT ASSEMBLY (PCA) - LOCATED ON THE REAR PART OF THE HIGH |
|
|
PAPER PICK-UP ASSEMBLY - FOR THE 500-SHEET PAPER HIGHT CAPACITY INPUT (HIC) TRAY |
|
|
PAPER PICKUP ROLLER - MP/TRAY 1 PAPER PICKUP ROLLER |
|
|
PAPER PICKUP ROLLER ASSEMBLY - FOR THE LOWER CASSETTE PICKUP ASSEMBLY |
|
|
PAPER SENSOR - PAPER PRESENT SENSING |
|
|
PAPER SENSOR FLAG - LEADING EDGE PAPER SENSOR FLAG |
|
|
PCA MOTOR ASSEMBLY |
|
|
PHOTO-INTERRUPTER SENSOR ASSEMBLY (DOES NOT INCLUDE THE SENSOR FLAG) |
|
|
PICK-UP ROLLER - LOCATED ON THE ON THE PAPER PICK-UP PLATE ASSEMBLY |
|
|
PICK-UP ROLLER COVER - PLASTIC COVER THAT PROTECTS THE PAPER PICK-UP ROLLER AND |
|
|
PICKUP ROLLER ASSEMBLY - PICKS PAPER FROM PAPER INPUT TRAY - FOR TRAY 2 OR TRAY |
|
|
PICKUP ROLLER HIGH CAPACITY INPUT (HCI) - ATTACHED TO THE PICKUP ARM - PRESSES D |
|
|
PLASTIC SCREW COVERS WITH AN ADHESIVE BACK - COVERS SCREW HEADS THAT SECURE THE |
|
|
PULLEY ASSEMBLY - FOR TRANSMISSION TIMING BELT |
|
|
PUSHING LEVER - LOCATED ON THE LOWER SCANNER DUCT |
|
|
RAIL AND SLIDE SHEET ASSEMBLY |
|
|
REAR COOLING FAN - 2-WIRE, 92MM X 92MM X 25MM, 12VDC, 0.30A (BLACK) |
|
|
REAR COVER - COVERS THE BACK PART OF THE PRINTER - LOCATED NEXT TO THE FORMATTER |
|
|
REAR COVER - FOR THE HIGH CAPACITY INPUT (HCI) FEEDER |
|
|
REAR COVER ASSEMBLY - FOR THE STAPLER/STACKER MAIN BODY ASSEMBLY - INCLUDES THE |
|
|
REAR GEAR COVER - PROTECTS THE REAR PART OF THE GEAR PLATE |
|
|
REAR GUIDE FOR THE DUPLEXER ASSEMBLY |
|
|
REGISTRATION ROLLER ASSEMBLY - INCLUDES THE ROLLER, BUSHINGS, MOUNTING PLATE, TR |
|
|
RIGHT DOOR ASSEMBLY - FOR THE 3X500 HIGH CAPACITY INPUT (HCI) MAIN BODY |
|
|
RIGHT DOOR ASSEMBLY - FOR THE PRINT ENGINE - LOCATED BELOW THE CARTRIDGE ACCESS |
|
|
RIGHT DOOR STOPPER |
|
|
RIGHT FRONT COVER - FOR THE 500 SHEET HIGH CAPACITY INPUT (HCI) TRAY |
|
|
RIGHT GRIP COVER - RECTANGLE SHAPED COVER WITH TWO HANDLES TO PULL THE RIGHT DOO |
|
|
RIGHT LINK DOOR - RIGHT SIDE LINK FOR THE STOCK DOOR |
|
|
RIGHT LINK DOOR - UPPER RIGHT SIDE LINK FOR THE 1X500 HIGH CAPACITY INPUT (HIC) |
|
|
RIGHT RAIL - RAIL THAT THE CASSETTE TRAY MOUNTS TO - LOCATED ON THE 1X500 HIGH C |
|
|
RIGHT REAR COVER - PLASTIC COVER LOCATED ON THE RIGHT REAR SIDE OF THE PRINTER N |
|
|
RIGHT SIDE SCANNER COVER - LOCATED ON THE RIGHT SIDE PORTION OF THE TOP COVER |
|
|
RIGHT UPPER GEAR COVER - LOCATED NEXT TO THE RIGHT LOWER CARTRIDGE GIUDE |
|
|
ROLLER RAIL - ATTACHES TO THE LEFT CASSETTE RAIL |
|
|
RUBBER GUIDE - FOR THE SCANNER GLASS |
|
|
SCANNER CONTROLLER BOARD (SCB) MAIN COVER - PROTECTS THE SCANNER BORD ASSEMBLY - |
|
|
SCANNER CONTROLLER BOARD ASSEMBLY (SCB) (MAIN BAORD) - PROVIDES TIMING AND CONTR |
|
|
SCANNER DUCT PLATE |
|
|
SCANNER GLASS ASSEMBLY - GLASS PLATE ON WHICH THE DOCUMENTS ARE PLACED TO BE SCA |
|
|
SCANNER GLASS GUIDE - RECTANGLE SHAPED GUIDE THAT DETERMINES THE CORRECT POSITIO |
|
|
SCANNER GLASS GUIDE - RECTANGLE SHAPED GUIDE THAT DETERMINES THE CORRECT POSITIO |
|
|
SCANNER LID SENSOR ASSEMBLY |
|
|
SCANNER OPTICAL CARRIAGE ASSEMBLY - INCLUDES THE OPTICAL SCANNER AND LIGHT MOUNT |
|
|
SCANNER SLIDER ROD - SCANNER MODULE MOVES ALONG THIS ROD |
|
|
SENSOR ARM LOCK - DETECTS IF CARTRIDGE IS PRESENT SENSOR (SR9) |
|
|
SENSOR HOLDER - MEDIA LEADING EDGE SENSOR HOLDER |
|
|
SEPARATION BLOCK ASSEMBLY - INCLUDES SEPARATION ROLLER ASSEMBLY, SPRINGS, E-RING |
|
|
SEPARATION FLOOR ASSEMBLY FOR THE ADF - INCLUDES RIGHT AND LEFT SEPARATION MYLAR |
|
|
SEPARATION PAD FOR MULTIPURPOSE TRAY/TRAY 1 ASSEMBLY |
|
|
SHUTTER CAM - LOCATED ON THE LOWER SCANNER DUCT |
|
|
SHUTTER LEVER - CONNECTS TO LASER SHUTTER |
|
|
SLIDE CAM - LOCATED ON THE LOWER SCANNER DUCT |
|
|
SLIDE SPACER - LOCATED BETWEEN THE PUSHING LEVER AND THE SLIDE CAM ON THE LOWER |
|
|
SPACER RING - LOCATED ON THE LOWER SCANNER DUCT |
|
|
SPRING HOLDER - HOLD THE COMPRESSION SPRING LOCATED ON THE FUSER BIAS |
|
|
STABILIZING SCREW FOR THE 2,000-SHEET FEEDER - MOUNTS ON RIGHT SIDE OF THE 2,000 |
|
|
STAPLER ACCESS DOOR - RECTANGULAR SHAPED DOOR THAT PROVIDS ACCESS TO THE STAPLER |
|
|
STAPLER CARTIDGE COVER - LOCATED ON THE RIGHT SIDE OF THE STAPLER/STACKER MAIN A |
|
|
STAPLER LEFT COVER |
|
|
STAPLER/STACKER LEFT DOOR |
|
|
STAPLER/STACKER PRINTED CIRCUIT BOARD (PCA) ASSEMBLY |
|
|
STAPLING UNIT - STAPLER ASSEMBLY FOR THE STAPLER/STACKER UNIT - INCLUDES HOLDER, |
|
|
STATIONARY FRONT CASTER - MOUNTS ON THE BOTTOM FRAME OF THE 500-SHEET HIGH CAPAC |
|
|
STATIONARY REAR CASTER - MOUNTS ON THE BOTTOM FRAME OF THE 500-SHEET HIGH CAPACI |
|
|
STEPPING MOTOR - MAIN DRIVE MOTOR FOR THE PRINTER - MOTOR M1 |
|
|
STOP - BUSHING STOP FOR FUSER LEVER LOCATED ON HTE INSIDE UPPER FRONT PART OF T |
|
|
SUPPORT BUSHING - AXIAL SUPPORT FOR TOP SENSOR FLAG - TWO USED |
|
|
TAG HOLDER ASSEMBLY - INCLUDES CONNECTOR HOLDER TAG, HOLDER PLATE, COMPRESSION S |
|
|
TAG LINK - THIS IS AN ARM EXTENSION FOR A MECHANICAL MOVEMENT - IT ALLOWS THE PR |
|
|
TELEPHONE CABLE (2-WIRE) - RJ11 (M) CONNECTORS - 3M (10FT) LONG (USA, CANADA, ME |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (DENMARK) |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (GERMANY) |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (ISRAEL) |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (ITALY) |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (NETHERLANDS |
|
|
TELEPHONE CABLE - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG ON ONE END (SWEDEN) |
|
|
TELEPHONE CABLE WITH BILL TONE FILTER - 3.0M (9.8FT) LONG (BLACK) - RJ-11 PLUG O |
|
|
TENSION SPRING - LOCATED ON THE BACK OF THE JOG GUIDE ASSEMBLY - SPRINGS THAT HO |
|
|
TENSION SPRING - PROVIDES TENSION FOR FUSER RELEASE LEVER |
|
|
TENSION SPRING - PROVIDES TENSION FOR LEVER ARM THAT COUPLES THE DRIVE GEAR TO T |
|
|
TENSION SPRING - PROVIDES TENSION FOR MP/TRAY 1 SEPARATION PAD ASSEMBLY |
|
|
TENSION SPRING - PROVIDES TENSION FOR SHUTTER LEVER |
|
|
TENSION SPRING - PROVIDES TENSION TO THE FUSER RELEASE DRIVE LINK - LOCATED NEXT |
|
|
TENSION SPRING - PROVIDES TENSION TO THE FUSER SHUTTER LEVER |
|
|
TENSION SPRING - PROVIDES TENSION TO THE PADDLE - LOCATED ON LEFT CARTRIDGE GUID |
|
|
TOP COVER - ATTACHED TO THE FACE DOWN TOP COVER |
|
|
TOP COVER ASSEMBLY - COVERS THE SCANNER GLASS ASSEMBLY - DOES NOT INCLUDE LIFT-U |
|
|
TORSION SPRING - LOCATED ON THE FUSER SENSOR LINK |
|
|
TORSION SPRING - LOCATED ON THE LEFT CARTRIGE GUIDE - SPRING THAT IS USED FOR TH |
|
|
TORSION SPRING - LOCATED ON THE LOWER SCANNER DUCT |
|
|
TORSION SPRING - LOCATED ON THE SHUTTER CAM - PROVIDES TORSION TO THE SLIDE CAM |
|
|
TORSION SPRING - PROVIDES RADIAL TENSION FOR LOOP SENSOR FLAG LOCATED ON THE HIG |
|
|
TORSION SPRING - PROVIDES TENSION FOR TOP SENSOR FLAG |
|
|
TORSION SPRING - PROVIDES TORSION TO THE PADDLE OF THE LEFT CARTRIDGE GUIDE |
|
|
TRANSFER DRIVE SIDE PLATE - PLATE THAT HOLDS THE 33-TOOTH GEAR, 35-TOOTH GEAR, 2 |
|
|
TRANSFER ROLLER - TRANSFER CHARGE ROLLER (BLACK) |
|
|
TRANSMISSION MOTOR ASSEMBLY - LOCATED ON THE TRANSMISSION DRIVE ASSEMBLY - MAKES |
|
|
TRANSMISSION TIMING BELT - MAINTAIN CONSTANT SPEED DURING POWER TRANSMISSION |
|
|
TRAY - GOES BETWEEN THE FACE DOWN DELIVERY COVER AND THE TOP COVER |
|
|
TRAY HOLDER - LEFT FRONT PAPER CASSETTE HOLDER |
|
|
TRAY HOLDER - RIGHT FRONT PAPER CASSETTE HOLDER |
|
|
UPPER CASSETTE PAPER PICKUP ASSEMBLY |
|
|
UPPER RIGHT DOOR LINK STOPPER |
