Manufacturer
Hitachi
Model Number
51F710
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| AT03844M | 10.0OHM 1/2W RDS50 CARBON FILM RESISTOR [R732] |
| AT03857M | 100OHM 1/2W RDS50 CARBON FILM RESISTOR [R626] |
| AT03886M | 15KOHM 1/2W RDS50 CARBON FILM RESISTOR [RP47] |
| AT03871M | 1KOHM 1/2W RDS50 CARBON FILM RESISTOR [RA40] |
| AT03848M | 22.0OHM 1/2W RDS50 CARBON FILM RESISTOR [RP16] |
| AT03862M | 220OHM 1/2W RDS50 CARBON FILM RESISTOR [R723] |
| AT03864M | 330OHM 1/2W RDS50 CARBON FILM RESISTOR [RZ85] |
| AT03892M | 39KOHM 1/2W RDS50 CARBON FILM RESISTOR [RH28] |
| AT03881M | 5.6KOHM 1/2W RDS50 CARBON FILM RESISTOR [R706] |
| AT03882M | 6.8KOHM 1/2W RDS50 CARBON FILM RESISTOR [R707] |
| AT03869M | 820OHM 1/2W RDS50 CARBON FILM RESISTOR [R737] |
| AT03896M | 82KOHM 1/2W RDS50 CARBON FILM RESISTOR [RP38] |
| CK50001U | AN15865A [I501] |
| CP08091 | ANALOG MONOLITHIC IC (TA8258H) [IA02] |
| CP04232 | ANALOG MONOLITHIC IC BA033T [IY01] |
| CP02411 | ANALOG MONOLITHIC IC KIA7805PI [IK01] |
| CK37051R | ANALOG MONOLITHIC IC(BD4729G) [I003] |
| CK35441R | ANALOG MONOLITHIC IC(MM1501) [IV07] |
| QD38063 | BACK COVER 51" [#010] |
| UE23423 | BLUE CRT |
| QD38511 | CABINET ASSEMBLY |
| 0893232R | CAP 1608CHIP 100000PFZF25V TAPE [C002] |
| 0893239R | CAP 1608CHIP 10000PFZF 50V TAPE [C416] |
| 0893208R | CAP 1608CHIP 1000PFKB 50V TAPE [C014] |
| 0893126R | CAP 1608CHIP 100PFJCH 50V TAPE [C067] |
| 0893127R | CAP 1608CHIP 120PFJCH 50V TAPE [CV51] |
| 0893114R | CAP 1608CHIP 12PFJCH 50V TAPE [C4C2] |
| 0893128R | CAP 1608CHIP 150PFJCH 50V TAPE [C065] |
| 0893115R | CAP 1608CHIP 15PFJCH 50V TAPE [CV11] |
| 0893129R | CAP 1608CHIP 180PFJCH 50V TAPE [CV49] |
| 0893197R | CAP 1608CHIP 22000PFKB 25V TAPE [CA15] |
| 0893118R | CAP 1608CHIP 27PFJCH 50V TAPE [CV09] |
| 0893121R | CAP 1608CHIP 39PFJCH 50V TAPE [CV23] |
| 0893217R | CAP 1608CHIP 4700PFKB 50V TAPE [CA13] |
| 0893135R | CAP 1608CHIP 470PFJCH 50V TAPE [CV58] |
| 0893205R | CAP 1608CHIP 560PFKB 50V TAPE [C020] |
| 0893111R | CAP 1608CHIP 8PFCCH 50V TAPE [CV14] |
| 0893222R | CAP 1608CHIP10000PFKB 50V TAPE [C044] |
| 0893027 | CAP 2125 CHIP 100000PF-K B 25V TAPE [CA03] |
| 0244505R | CAP-CERAMIC 0.0022UF-K 500V [C707] |
| AA00934R | CAP. CERAMIC 2012 (2.2UF 10V) [CW05] |
| AJ00132R | CAP. CERAMIC CK45-R3DD681K-VR [CP42] |
| 0800328R | CAP. ELECTRO. 100UF-M 35V [CA43] |
| 0244501R | CAP.-CERAMIC 1000PF-K 500V [CP30] |
| 0890078 | CAP.-CERAMIC 220PF-K 50V [CH02] |
| 0890081R | CAP.-CERAMIC 330PF 50V [C709] |
| 0243509R | CAP.-CERAMIC 470PF-K 500V [C708] |
| 0890084R | CAP.-CERAMIC 560PF-K 50V [C728] |
| 0243511R | CAP.-CERAMIC 680PF-K 500V TAPE [CP50] |
| 0800279R | CAP.-ELECTORO. 1.0UF-M(SMG) 50V [C026] |
| 0800282R | CAP.-ELECTORO. 2.2UF-M(SMG) 50V [C034] |
| AL00032R | CAP.-ELECTORO. 47UF-M 250V [CP37] |
| 0800361N | CAP.-ELECTRO 1000UF 16V [CP36] |
| 0800337R | CAP.-ELECTRO 220UF 35V (SMG TY PE) [CP13] |
| 0284634R | CAP.-ELECTRO 4.7UF-SME(BP) 50V [C715] |
| 0800359R | CAP.-ELECTRO. 1000UF-M 10V [CA22] |
| 0800358R | CAP.-ELECTRO. 1000UF-M 6.3V [CY19] |
| 0800326R | CAP.-ELECTRO. 100UF-M 16V [C001] |
| 0800329R | CAP.-ELECTRO. 100UF-M(SMG) 50V [C725] |
| 0800294R | CAP.-ELECTRO. 10UF-M(SMG) 50V [C019] |
| 0284638R | CAP.-ELECTRO. 10UF-SME(BP) 16V [CF04] |
| 0800303R | CAP.-ELECTRO. 22UF-M 50V [C048] |
| 0800299R | CAP.-ELECTRO. 22UF-M(SMG) 16V [CP49] |
| 0800284R | CAP.-ELECTRO. 3.3UF-M(SMG) 50V [CP09] |
| 0800347N | CAP.-ELECTRO. 330UF-M(SMG) 50V [C604] |
| 0800288R | CAP.-ELECTRO. 4.7UF-M(SMG) 50V [C524] |
| 0800318R | CAP.-ELECTRO. 47UF-M 25V [C610] |
| 0800319R | CAP.-ELECTRO. 47UF-M 35V [CP46] |
| 0800317R | CAP.-ELECTRO. 47UF-M(SMG) 16V [C602] |
| 0800352R | CAP.-ELECTRO.470UF 10V [C430] |
| 0800353R | CAP.-ELECTRO.470UF-M 16V [CN02] |
| 0880198R | CAP.-PLOY. 0.22UF-J 50V [C612] |
| 0880035R | CAP.-POLY 2200PF-50V [C734] |
| 0880031R | CAP.-POLY.1000PF-K 50V [CP14] |
| 0880033R | CAP.-POLYESTER 0.0015UF-KEB50V [CH07] |
| 0299969F | CAP.-POLYESTER 0.001UF-JPF160V [CP41] |
| 0880039 | CAP.-POLYESTER 0.0047UF-KEB50V [CH15] |
| 0880044 | CAP.-POLYESTER 0.01UF-KEB 50V [CA51] |
| 0880051R | CAP.-POLYESTER 0.033UF-KEB 50V [CN03] |
| 0279692R | CAP.-POLYESTER 0.068UF 100V [CH14] |
| 0880194R | CAP.-POLYESTER 0.1UF-J 50V [C613] |
| 0880203R | CAP.-POLYESTER 0.47UF-J 50V [CH99] |
| 0880207R | CAP.-POLYESTER 1.0UF-J 50V [C608] |
| AL01153S | CAP.ELECTR. 1000UF-M 35V [CP32] |
| 0800355N | CAP.ELECTRO. 470UF-M 35V [C726] |
| AL01143S | CAP.ELECTROLYTIC 2200UF-M(YXF)25V [C607] |
| 0893213R | CAP1608CHIP 2200PFKB 50V TAPE [C009] |
| QX00961 | CASTERS |
| AA01141R | CERAMIC CAPACITOR(0.1UF 16V) [C011] |
| AA01121R | CERAMIC CAPACITOR(0.47UF 10V) [CY27] |
| AA01136R | CERAMIC CAPACITOR(0.47UF 6.3V) [C501] |
| AA01111R | CERAMIC CAPACITOR(1.0UF 6.3V) [C062] |
| AA01101R | CERAMIC CAPACITOR(1UF 10V-F) [C081] |
| AA00964R | CERAMIC CAPACITOR(2.2UF 6.3V) [CV33] |
| 0893186R | CERAMIC CAPACITOR(33000PF 16V) [CA12] |
| AA00966R | CERAMIC CAPACITOR(4.7UF 6.3V) [C433] |
| 0893188R | CERAMIC CAPACITOR(47000PF 16V) [C523] |
| AQ00164R | CHIP RESITOR 1/16W 75OHM TAPE [R406] |
| EV00558 | COD VM0284-192-C-NON PB [E999] |
| BH00228R | COIL 332K-1T7608A [L703] |
| BH00691R | COIL 33UH [LV06] |
| BH00692R | COIL 39UH [LV05] |
| BH01341M | COIL FERRITE BEADS 0.8UH [LK01] |
| 2125821N | COIL LHL08 560UH [LH01] |
| PH34193 | CONTROL DOOR_F VERSION D [#024] |
| PH34184 | CONTROL PANEL F VERSION_D [#014] |
| BP01311R | CSTLS16M0X [X002] |
| CH02851M | D1NS4 [DP02] |
| CH02881U | D4SBL20U [DP34] |
| CH02871U | D4SBS4 [DP32] |
| CS00834 | DCU ASSY [UKDG] |
| PH34123 | DECO PANEL 51" (R) F [#211] |
| PH34124 | DECO RAIL 51F_LEFT_D [#212] |
| QL24513 | DECORATION PLATE AV DP43 [#082] |
| QL24863 | DECORATION PLATE DIGITAL DP43 [#092] |
| CK07631R | DIGITAL MONOLITHIC IC (TC90A45F) [IV04] |
| 2348031M | DIO-MTZ-J2.7ATA [D405] |
| CH02001M | DIODE 1SR139-400 [D603] |
| CH02011M | DIODE 1SR153-400 [D605] |
| 2344041M | DIODE 1SS254TA/1SS270TA [D010] |
| 2337341M | DIODE 1SS270A (TP) [DA09] |
| CH00031M | DIODE AU02V1(280V) [DH13] |
| 2342061 | DIODE D3SB(A)60. [DP01] |
| 2339551M | DIODE ED14(V1) SI 5MA 45V [DK16] |
| CH00041M | DIODE ES1FV1 (1500V) [D711] |
| 2348002M | DIODE MTZ-J2.0BT [D713] |
| 2348282M | DIODE MTZ-J30B TAPE [DP36] |
| 2348081M | DIODE MTZ-J4.3ATA [DN05] |
| 2348091M | DIODE MTZ-J4.7A TAPE [DH04] |
| 2348093M | DIODE MTZ-J4.7C TAPE [DH01] |
| 2348143M | DIODE MTZ-J7.5CTA [DP39] |
| 2359312S | DIODE RU3C LF-C4 (1000V 1.5A ) [DH07] |
| 2337951S | DIODE RU4Z(LF015-302) [DP31] |
| CC10521R | DIODE [DA07] |
| CC00003R | DIODE.CHIP 1SS355 [D411] |
| CC00971R | DIODE.CHIP DAN202KT146 [D407] |
| UE23125 | DP43 CHASSIS ASY [#031] |
| JT24515R | DP43 CONVER AMP PWB ASY [A025] |
| JT24505 | DP43 CPT CONTROL PWB ASY [A011] |
| JT24566 | DP43 HDMI PWB ASY [A025] |
| JT24485 | DP43 POW DEF PWB ASY |
| JT24475R | DP43 SIGNAL PWB ASY |
| JT24525R | DP43 TUNER PWB ASY [A035] |
| BZ03061 | DRIVE TRANS.-DJ81 [T702] |
| FQ00021 | DRY BATTERY(R6P-AA) [E203] |
| BY01664 | DY-V80-7SS(0.65)LH [E12B] |
| BT02143 | EE22 DYNAMIC FOCUS TRANSFORMER [TF01] |
| CP08461U | EK1115 [IP03] |
| 2125824N | FILT.COIL(LHL08 1000UH) [LH06] |
| 2125811N | FILT.COIL(LHL08 100UH) [L603] |
| 2125797N | FILT.COIL(LHL08 10UH) [L407] |
| 2125803N | FILT.COIL(LHL08 27UH) [LP30] |
| 2125806N | FILT.COIL(LHL08 47UH) [LK06] |
| BH00697R | FILTER COIL 100UH [L001] |
| 2123781R | FILTER COIL 100UH(EL0607) [L402] |
| CS00627R | FLEX CONVERTER [UY01] |
| AZ00165 | FOCUS PACK [UFPK] |
| NT04071 | FRAME ASSY 51F510 |
| FN00472 | FUSE 51MS 040 L 125V 4A [FP01] |
| 3487429 | HITACHI BADGE 55 2004 (F) |
| KQ03082K | HSB LENS SASS B [N200B] |
| KQ03081K | HSB LENS SASS RG [N200G] |
| CP04234 | IC BA09T [IH02] |
| CK50121R | IC CD4053BPWR [I005] |
| CP08261U | IC H11A817B-300W [IP02] |
| CZ00761U | IC LA7846N [I601] |
| CP07091 | IC M62501P [IH01] |
| CK39301R | IC MM1096AFFE [I002] |
| CK38621R | IC NJM1160M-TE1 [IA01] |
| CP05011R | IC PST994D-T [IK02] |
| CP05163F | IC SI-3090F [I403] |
| CK50111R | IC SN74HCT245PWR [I009] |
| CK07924U | IC TA1270BF [IV08] |
| CK38711U | IC TA1360AFG(HIT) [IY04] |
| CK38701U | IC UPD64084GC-8EA-A [IV02] |
| PH34232 | IR LENS F/G [#213] |
| ES00581 | JACK LAF5120-0403F [J401] |
| ES00351 | JACK LAP5120-0101F US9P Y/C3P [J402] |
| EY01543 | JACK PJX-YKF42-8057N [J002] |
| 2123107M | LAL02 AXIAL COIL 22UH-K [LV10] |
| BA00894R | LBC2518 CHIP COIL 100UH [L405] |
| BA00892R | LBC2518 CHIP COIL 47UH [L008] |
| CH02673R | LED SM3517F6T (GREEN ) [DP40] |
| CK50611U | M306V7MJ-050FP [I004] |
| CP08451U | MCZ3001DB [IP01] |
| AT01532S | METAL FILM RESISTOR(0.12OHM 1/2W ) [R731] |
| AT03171S | METAL OX. 0.22OHM 1W [RP11] |
| AT03184S | METAL OX. 0.68OHM 1W [R629] |
| AT03588S | METAL OX. 1.0KOHM 3W [R738] |
|
|
METAL OX. 1.2OHM 1W [R619] |
| AT03215S | METAL OX. 10.0OHM 1W [RH34] |
| AT03242S | METAL OX. 100OHM 1W [R625] |
| AT03562S | METAL OX. 100OHM 3W [R729] |
|
|
METAL OX. 220OHM 2W [R739] |
| AT03422S | METAL OX. 560OHM 2W [R748] |
| AT03213S | METAL OX. 8.2OHM 1W [RF09] |
| KS07996 | MIRROR |
| CK35442R | MM1503XNRE [IV06] |
| CK39881U | MM1630AQ [I402] |
| CK39891R | MM1631XJBE [I401] |
| CK37191R | MONO IC SI-3018LSA-TL [IY03] |
| CK37216R | MONO IC TK11133CSCL [I013] |
| BP01241 | OSCILLATOR 3.58 49U [XV02] |
| PC06001 | POWER BUTTON F/G [#034] |
| UE23152 | POWER DEFLECTION BOARD |
| HA01313 | POWER UNIT DP4X_24W [U901] |
| AZ00899M | PROTECTOR 0491007.NRT1- [EP01] |
| UE23421 | PRT ASSY RED |
| 0196104R | RES 1608 CHIP 1/16W 30KJ TAPE [RW60] |
| 0196079R | RES.-1608CHIP 1/16W 3.0K-J TAPE [RW69] |
| 0196056R | RES.-1608CHIP 1/16W 360-J TAPE [RW70] |
| 0700041 | RES.-CARBON FLM 1/16W 1.0K-JB [R632] |
| 0700043M | RES.-CARBON FLM 1/16W 1.5K-JB [RH01] |
| 0700044M | RES.-CARBON FLM 1/16W 1.8K-JB [RK22] |
| 0700027M | RES.-CARBON FLM 1/16W 100-JB [R637] |
| 0700067M | RES.-CARBON FLM 1/16W 100K-JB [RN12] |
| 0700054 | RES.-CARBON FLM 1/16W 10K-JB [R630] |
| 0700055M | RES.-CARBON FLM 1/16W 12K-JB [RH02] |
| 0700029 | RES.-CARBON FLM 1/16W 150-JB [RP14] |
| 0700057M | RES.-CARBON FLM 1/16W 18K-JB [RN05] |
| 0700045M | RES.-CARBON FLM 1/16W 2.2K-JB [R601] |
| 0700046 | RES.-CARBON FLM 1/16W 2.7K-JB [RK01] |
| 0700032M | RES.-CARBON FLM 1/16W 220-JB [R615] |
| 0700033Q | RES.-CARBON FLM 1/16W 270-JB [R735] |
| 0700059M | RES.-CARBON FLM 1/16W 27K-JB [R631] |
| 0700047 | RES.-CARBON FLM 1/16W 3.3K-JB [R602] |
| 0700034M | RES.-CARBON FLM 1/16W 330-JB [R609] |
| 0700061M | RES.-CARBON FLM 1/16W 33K-JB [RH18] |
| 0700062M | RES.-CARBON FLM 1/16W 39K-JB [RH04] |
| 0700009M | RES.-CARBON FLM 1/16W 4.7-J [RP07] |
| 0700036M | RES.-CARBON FLM 1/16W 470-JB [RK03] |
| 0700063M | RES.-CARBON FLM 1/16W 47K-JB [R759] |
| 0700064 | RES.-CARBON FLM 1/16W 56K-JB [R708] |
| 0700052M | RES.-CARBON FLM 1/16W 6.8K-JB [RH06] |
| 0700025M | RES.-CARBON FLM 1/16W 68-J [RP15] |
| 0700065M | RES.-CARBON FLM 1/16W 68K-JB [R724] |
| 0700053M | RES.-CARBON FLM 1/16W 8.2K-JB [R606] |
| 0188095M | RES.-CARBON FLM 1/2W 2.2-J [R622] |
| 0100121M | RES.-CARBON FLM 1/8W 220K-JB [RH32] |
| 0100053M | RES.-CARBON FLM 1/8W 330-JB [R613] |
| 0100033M | RES.-CARBON FLM 1/8W 47-JB [RH13] |
| 0100085M | RES.-CARBON FLM 1/8W 6.8K-JB [R725] |
| 0119633M | RES.-MTL FLM 1/8W 12K-FB [RH25] |
| 0119617M | RES.-MTL FLM 1/8W 2.7K-FB [RP18] |
| 0119653M | RES.-MTL FLM 1/8W 82K-FB [RH19] |
| 0119693M | RES.-MTL FLM 1W 0.39-JB [RP34] |
| AQ00194R | RES.CHIP 1/16W 1.0K OHM TAPE [RA01] |
| 0790037R | RES.CHIP 1/16W 1.0K OHM [R021] |
| 0790077R | RES.CHIP 1/16W 1.0M OHM [R062] |
| AQ00196R | RES.CHIP 1/16W 1.2K OHM TAPE [RV89] |
| 0790038R | RES.CHIP 1/16W 1.2K OHM [R088] |
| 0790039R | RES.CHIP 1/16W 1.5K OHM [RV93] |
| AQ00201R | RES.CHIP 1/16W 1.8K OHM TAPE [RY38] |
| 0790041R | RES.CHIP 1/16W 1.8K OHM [R2J2] |
| 0790011R | RES.CHIP 1/16W 10 OHM [RV47] |
| 0790024R | RES.CHIP 1/16W 100 OHM [R051] |
| 0790064 | RES.CHIP 1/16W 100K OHM [R028] |
| 0790051R | RES.CHIP 1/16W 10K OHM [R034] |
| 0790025R | RES.CHIP 1/16W 120 OHM [RZE4] |
| 0790052R | RES.CHIP 1/16W 12K OHM [R196] |
| 0790053R | RES.CHIP 1/16W 15K OHM [R405] |
| 0790054R | RES.CHIP 1/16W 18K OHM [RW01] |
| AQ00202R | RES.CHIP 1/16W 2.0K OHM TAPE [RY47] |
| AQ00203R | RES.CHIP 1/16W 2.2K OHM TAPE [RA23] |
| 0790042R | RES.CHIP 1/16W 2.2K OHM [R061] |
| AQ00205R | RES.CHIP 1/16W 2.7K OHM TAPE [RV88] |
| 0790043R | RES.CHIP 1/16W 2.7K OHM [RV26] |
| 0790028R | RES.CHIP 1/16W 220 OHM [R032] |
| 0790068R | RES.CHIP 1/16W 220K OHM [RV66] |
| 0790055R | RES.CHIP 1/16W 22K OHM [R159] |
| 0790029R | RES.CHIP 1/16W 270 OHM [RZ40] |
| 0790069R | RES.CHIP 1/16W 270K OHM [R052] |
| 0790056R | RES.CHIP 1/16W 27K OHM [RV81] |
| 0790044R | RES.CHIP 1/16W 3.3K OHM [R141] |
| 0790045R | RES.CHIP 1/16W 3.9K OHM [RW41] |
| AQ00181R | RES.CHIP 1/16W 330 OHM TAPE [RA05] |
| 0790031R | RES.CHIP 1/16W 330 OHM [RY05] |
| 0790057R | RES.CHIP 1/16W 33K OHM [R152] |
| 0790032R | RES.CHIP 1/16W 390 OHM [R214] |
| 0790058R | RES.CHIP 1/16W 39K OHM [RA07] |
| 0790046R | RES.CHIP 1/16W 4.7K OHM [R031] |
| AQ00185R | RES.CHIP 1/16W 470 OHM TAPE [RV08] |
| 0790033R | RES.CHIP 1/16W 470 OHM [R064] |
| 0790059R | RES.CHIP 1/16W 47K OHM [R068] |
| 0790047R | RES.CHIP 1/16W 5.6K OHM [R050] |
| AQ00214R | RES.CHIP 1/16W 5.6K OHM [RV63] |
| AQ00186R | RES.CHIP 1/16W 510 OHM TAPE [R459] |
| 0790021R | RES.CHIP 1/16W 56 OHM [RY07] |
| AQ00187R | RES.CHIP 1/16W 560 OHM TAPE [R468] |
| 0790034R | RES.CHIP 1/16W 560 OHM [RV60] |
| 0790061R | RES.CHIP 1/16W 56K OHM [RV39] |
| AQ00163R | RES.CHIP 1/16W 68 OHM TAPE [R456] |
| 0790035R | RES.CHIP 1/16W 680 OHM [R4M6] |
| 0790062R | RES.CHIP 1/16W 68K OHM [RA38] |
| AQ00191R | RES.CHIP 1/16W 750 OHM TAPE [RV16] |
| AQ00244R | RES.CHIP 1/16W 75K OHM TAPE [R523] |
| 0790049R | RES.CHIP 1/16W 8.2K OHM [RW00] |
| AQ00192R | RES.CHIP 1/16W 820 OHM TAPE [RV32] |
| 0790036R | RES.CHIP 1/16W 820 OHM [RV44] |
| 0790063R | RES.CHIP 1/16W 82K OHM [R483] |
| 0113766M | RESISTOR CARBON FILM SRD1/2P-B 4.7K-J [RH21] |
| CH02891U | S1WBA40L [DP33] |
| KR03302 | SCREEN ASSY |
| CK34991R | SN74ACT14PWR TSSO [I503] |
| GK01301 | SP-12CM C120RB514-10 [U402] |
|
|
SPARK GAP 2.5KV [GF01] |
| PH34102 | SPEAKER GRILLE ASSY 51F510 [#510] |
| FE10332R | SWITCH (TYPE SWP01N01TKSH0636BT) [SK01] |
| BT02252 | SWITCHING TRANSFORMER ST-1914F [TP01] |
| 2324321M | TRANSISTOR 2SC2610-05 [Q703] |
| 2326811 | TRANSISTOR 2SC3468 (E/F) [QH03] |
| AW00208 | TRIMMER RESISTOR 100KOHM 1/2W [RH17] |
| 2320637M | TRS. 2SA673 (C 26TZ/D 26TZ) SI 80MHZ 400MW [Q604] |
| CF02281R | TRS. 2SA821S [QP05] |
| 2326216 | TRS. 2SC3116 (S/T) [Q709] |
| 2312171 | TRS. 2SC3852 [QK01] |
| CF00821F | TRS. 2SC4686A 1200V [QF01] |
| CF03031F | TRS. 2SC6012000LT [Q777] |
| 2312172F | TRS. 2SD2375-P/Q(LT) [QP04] |
| CF01583F | TRS. 2SK2771-01R-F168R [QH01] |
| CF03021F | TRS. F13F50VX3 [QP01] |
| CF02771R | TRS. KTA1270 [QK02] |
| CF02781R | TRS. KTC200YAT [QH02] |
| CF01421R | TRS. KTC3198 (GR) TAPE [Q706] |
| CA00461R | TRS.CHIP 2SD2114K 20V TAPE [Q409] |
| 2328102 | TRS.FN-521 [Q701] |
| KR02074 | ULTRA SHEILD / PROTECTIVE SCREEN |
| EW08241 | USB A(M) TO USB A(F) CABLE ASS'Y [EUSB] |
| 2168771 | VFL-CSB503F30 [XV04] |
| 2348212M | ZENER DIODE MTZ-J15B [D001] |
| 2348193M | ZENER DIODE MTZJ-12C TA [D705] |
| 2334315M | ZENER DIODE RD33E TAPE (B4) [D611] |
|
|
ZENER DIODE RD36E TAPE (B3) SI 500MW 36V [D610] |
| 2335042M | ZENER HZ-22 (2L TP) SI 200MA 400MW [DH15] |
| 2331815M | ZENER HZ7-B2 [DK35] |
| 2339801M | ZENER HZS-2 TAPE (B1) SI 400MW 2.0V [DY06] |
| 2348142M | ZENER MTZ-J7.5BTA [D717] |
| 2348103M | ZENER MTZJ-5.1C TA [D601] |
| 2348123M | ZENER MTZJ-6.2C TA [D025] |
| 2348163M | ZENER MTZJ-9.1C TA [D023] |
| 2334243M | ZENER RD16E (B2 T2/TP/TA) SI 10MA 16.51V [DH08] |
| 2334304 | ZENER RD30E (B3 T2/TP/TA) SI 5MA 30.51V [DH14] |
| 2334305M | ZENER RD30E (B4 T2/TP/TA) SI 5MA 30.51V [D606] |
