Manufacturer
Hitachi
Model Number
VM1700A
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 7069066 | 3PIN EXTENSION CABLE |
| VM-RF80A | ADAPTOR, RF |
| 4717904 | BOTTOM CASE |
| 5793752 | BRUSH |
| 4799841 | CAP, LENS |
| 0255134 | CAPACITOR |
| VM-CC70A | CAR CORD |
| CN-VM1700A | CARTON BOX |
| 4731829 | CASSETTE LID |
| KX10418 | CASSETTE UP UNIT |
| 5846287 | CONNECTOR |
| 5887043 | CONNECTOR |
| 1880356 | CONNECTOR |
| EV10502 | CORD, DC " USE ORIGINAL" |
| 4731852 | COVER, RCA PLUG |
| HZ6A-3 | DIODE HZ6A |
| UE10281 | EVF ASSY |
| 1640084 | EVF PWB ASSY |
| 4799871 | EYECUP, FOCUS RING |
| QD10221 | FRONT CASE |
| 4799862 | FRONT PIECE |
| CB-3700 | HARD CARRYING CASE |
| HD6433724BB6H | I.C. HD64337 |
| CK10561U | IC |
| 6952291 | LENS ASSY |
| 6820588 | LOADING BLOCK |
| GP10151 | LOADING MOTOR |
| 5436378 | LOWER CYLINDER |
| 1654295 | MAIN (SWS) PWB ASSEMBLY |
| 5886211 | MINI CONNECTOR |
| 5842026 | MINI CONNECTOR |
| 5846345 | MINI CONNECTOR |
| 5813841 | MINI CONNECTOR |
| 5666606 | MINI PLUG |
| 5666198 | MINI PLUG |
| 5661691 | MINI PLUG |
| 5666143 | MINI PLUG |
| 5668891 | MINI PLUG |
| 5666168 | MINI PLUG |
| 5666619 | MINI PLUG |
| 5666146 | MINI PLUG (7 PIN) |
| 4717951 | NECK BOTTOM |
| 4717941 | NECK UPPER |
| OG-VM2700A | OWNERS MANUAL |
| 5669169 | PLUG |
| 5666431 | PLUG |
| JP10354 | PWB ASSY |
| 4592536 | RING |
| 5621951 | S0901 |
| SM-TK6407 | SERVICE MANUAL |
| 4133069 | SHOULDER STRAP |
| 4717862 | SIDE CASE (L) |
| 4717811 | SIDE CASE (R) |
| TS10641 | SUPPLY SENSOR (TSS) PWB ASSY |
| 6186691 | TRIPOD ATTACHMENT |
| 4717882 | UPPER CASE |
| 5436278 | UPPER CYLINDER |
| KQ10161 | ZOOM LENS ASSY |
