Model Image
Manufacturer

GE

Model Number

2661532211

Description

Washer/dryer Combo

Interactive Exploded View

Parts List

Part Number Description
WH01X10612 WH01X10612 1/4-20 TAPTITE HWH
WH43X10057 WH43X10057 ACTUATOR LID
WH43X10056 WH43X10056 AGITATOR
WE21M39 WE21M39 BAFFLE
WH45X10106 WH45X10106 BASKET ASM 27
WE1M504 WE1M504 BEARING-SLIDE WHITE
WE03X29897 WE03X29897 BELT DRIVE
WE09X27636 WE09X27636 BLOWER GASKET (EXHAUST)
WE16X20393 WE16X20393 BLOWER WHEEL
WH12X10586 WH12X10586 BOARD CONTROL ASM
WH16X10143 WH16X10143 BRACE FRONT UPPER
WH16X10153 WH16X10153 BRACKET SPRING
WH01X10627 WH01X10627 BUMPER LID
WH01X10625 WH01X10625 BUSHING HINGE
WH01X10637 WH01X10637 BUTTON SELECTOR
WE1M1014 WE1M1014 BUTTON START ASM
WH01X10598 WH01X10598 CLAMP
WH01X10599 WH01X10599 CLAMP
WH01X10649 WH01X10649 CLAMP
WH01X10603 WH01X10603 CLAMP TUB OUTLET
WH01X10601 WH01X10601 CLIP CAPACITOR
WH01X10623 WH01X10623 CLIP COVER
WH01X10604 WH01X10604 CLIP DRAINING HOSE
WE2M301 WE2M301 CLIP FRONT PANEL
WH01X10597 WH01X10597 CLIP GROUND
WH01X10592 WH01X10592 CLIP HOSE
WH01X10595 WH01X10595 CLIP LOCKING
WE1M1004 WE1M1004 COVER EXHAUST
WH44X10287 WH44X10287 COVER FSD
WE1M1009 WE1M1009 COVER FUSE TERMINAL
WE1M1000 WE1M1000 COVER HARNESS MAIN
WH44X10280 WH44X10280 COVER HOSE
WH44X10282 WH44X10282 COVER TOP
WH01X10630 WH01X10630 DAMPER PAD
WE10M151 WE10M151 DOOR ASM
WE1M1011 WE1M1011 DOOR LATCH
WE4M415 WE4M415 DOOR SWITCH
WH01X20436 WH01X20436 DRIVE 3L
WE21X28957 WE21X28957 DRUM ASM 27
WE14X27556 WE14X27556 DUCT EXHAUST
WH01X10605 WH01X10605 ELBOW OVER FLOW
WE19M1700 WE19M1700 ENCLOSURE BOARD
WH01X10619 WH01X10619 ENS. TORNILLO AGITADOR
WE1M997 WE1M997 FELT TRAP DUCT
WE18X25102 WE18X25102 FILTER LINT
WH16X10147 WH16X10147 FORK SUPPORT ASM
WH01X10621 WH01X10621 FUNNEL BLEACH
WH13X10051 WH13X10051 FUNNEL SHOWER HEAD
WE1M1002 WE1M1002 FUSE CCMR 30 AMP 120V
WE01X25135 WE01X25135 GASKET DOOR
WE1M999 WE1M999 GASKET EXHAUST
WH03X20508 WH03X20508 GROMMET MOTOR
WE01X30378 WE01X30378 HANDLE DOOR
WE26M361 WE26M361 HARNESS DOOR ASM
WH19X10084 WH19X10084 HARNESS EXTENSION ASM
WE26M368 WE26M368 HARNESS FUSE ASM
WH19X10085 WH19X10085 HARNESS MAIN
WE26M367 WE26M367 HARNESS MAIN ASM
WH19X10087 WH19X10087 HARNESS PRESSURE
WH19X10081 WH19X10081 HARNESS SELECTOR
WE26M362 WE26M362 HARNESS UI ASM
WE11M62 WE11M62 HEATER AND HOUSING ASM
WH01X10614 WH01X10614 HEX SCREW 5/16-18
WH01X10616 WH01X10616 HEX. PT SCREW K80 X 3.59
WH01M10001 WH01M10001 HEXSCREW832TRILOBULAR
WE1M1033 WE1M1033 HINGE
WH44X10290 WH44X10290 HINGE WASHER COVER LH
WH44X10289 WH44X10289 HINGE WASHER COVER RH
WE1M1003 WE1M1003 HOLDER FUSE
WH41X26574 WH41X26574 HOSE DRAIN ASM
WH41X10280 WH41X10280 HOSE DRAIN INLET
WE14M188 WE14M188 HOUSING BLOWER
WE12M50 WE12M50 IDLER ARM ASM
WH16X10157 WH16X10157 KIT BRACKET ASM
WE4M522 WE4M522 KNOB CONTROL ASM
WE4M523 WE4M523 KNOB ROTATORY ASM
WH01X10594 WH01X10594 LEG LEVELING
WH13X30373 WH13X30373 LID WASHER
WH44X10288 WH44X10288 LOCK LID
WH01X10626 WH01X10626 MAGNET
WH49X20495 WH49X20495 MOTOR
WE17X22217 WE17X22217 MOTOR
WE01X0921 WE01X0921 MOTOR BRACKET
WE03X27285 WE03X27285 MOTOR PLATE
WE13M39 WE13M39 MOTOR SUPPORT
WH01X10618 WH01X10618 NUT HUB
WH01X10611 WH01X10611 NUT PULLEY
WE02X20269 WE02X20269 NUT SPEED
WE20M474 WE20M474 PANEL ACCESS
WE19M1710 WE19M1710 PANEL CONTROL AND HT ASM
WE20M472 WE20M472 PANEL FRONT
WH42X10886 WH42X10886 PANEL FRONT ASM
WE20M173 WE20M173 PANEL TOP 27
WH01X10596 WH01X10596 PIN ALIGNMENT
WH08X10062 WH08X10062 PLUG SEAL
31-16656 31-16656 PM MINI MANUAL
49-90422 49-90422 PM SEARS KENMORE USE & C
WH16X10152 WH16X10152 PRESS HOSE CLAMP
WH12X10530 WH12X10530 PRESSURE SWITCH
WH23X10040 WH23X10040 PUMP DRAIN
WE4M416 WE4M416 PUSH TO START SWITCH
WH16X10151 WH16X10151 ROD ASSEMBLY FRONT
WH16X10150 WH16X10150 ROD ASSEMBLY REAR
WH12X10513 WH12X10513 RUN CAPACITOR
WE4M528 WE4M528 SAFETY LEFT TSTAT 24 E
WZ4X241D WZ4X241D SCR
WH02X0694 WH02X0694 SCR 10-12 A HX 1/2 S
WH01X10593 WH01X10593 SCR 12-14 B
WH01X10624 WH01X10624 SCR 6-20 B TRT 3/8 S
WH01X10631 WH01X10631 SCR 8-16 B FLP .525 S ZN
WE2M281 WE2M281 SCR 8-18 AB 1/2
WB01K10042 WB01K10042 SCR 8-18 AB IHW 3/8 SN
WE2M304 WE2M304 SCR 8-18 AB OVQ1 2 S ZN
WE2M305 WE2M305 SCR 8-18 AB TRQ2 5/8 S
WH01X10600 WH01X10600 SCR 8-18 B HXW 3/8 S ZN
WH01X10610 WH01X10610 SCR 915 TWIN HEL 3/4
WE1M280 WE1M280 SCREW
WH2X1211 WH2X1211 SCREW
WH2X1217 WH2X1217 SCREW
WE2M302 WE2M302 SCREW
WE2M223 WE2M223 SCREW
WR2X9260 WR2X9260 SCREW
WE2M202 WE2M202 SCREW
WD2M101 WD2M101 SCREW
WD02X10057 WD02X10057 SCREW
WE2M174 WE2M174 SCREW # 10
WE2M163 WE2M163 SCREW #10
WZ5X158D WZ5X158D SCREW 8-32X3/8 GRD SCR
WH08X24594 WH08X24594 SEAL TUB
WH01X10602 WH01X10602 SEAT BALL JOINT
WL49X20360 WL49X20360 SENSOR SPEED
WH01X10608 WH01X10608 SET SCREW PULLEY M. ASSEMBLY
WH01X10613 WH01X10613 SHIELD TUB
WH01X28559 WH01X28559 SHIFTER HUB
WE1M1067 WE1M1067 SLIDE DRUM - GREEN
WE03X37317 WE03X37317 SLIDE DRUM - GREEN
WH01X10620 WH01X10620 SOCKET ROD SUPPORT
WH01X10628 WH01X10628 SPRING COVER
WH01X10606 WH01X10606 SPRING SHIFTER
WH41X10282 WH41X10282 STOP - DRAIN HOSE
WE01X20423 WE01X20423 STRAIN RELIEF BRACKET
WH01X20442 WH01X20442 STRAP ASSEMBLY
WE13X0200 WE13X0200 STRAP MOTOR
WE1X1192 WE1X1192 STRIKE DOOR
WH02X10347 WH02X10347 STUD GROUNDING
WH16X20555 WH16X20555 SUPPORT BOARD
WE19M1696 WE19M1696 SUPPORT CONTROLS
WH12X20439 WH12X20439 SUPPORT SENSOR BOARD
WE03X27679 WE03X27679 SUPPORT TOP BEARING
WH16X10186 WH16X10186 SUPPORTS ASSEMBLY
WD21X10261 WD21X10261 SWITCH INTERLOCK
WH12X10509 WH12X10509 SWITCH SELECTOR
WH12X10510 WH12X10510 SWITCH SELECTOR
WE4M216 WE4M216 T'STAT OUTLET CTRL
WE4M525 WE4M525 TERM BLK & GRND STRAP
WH12X10512 WH12X10512 THERMISTOR ASM
WE4M181 WE4M181 THERMOSTAT BIAS CTR INLT
WE4M137 WE4M137 THERMOSTAT HI-LIMIT
WE04X22654 WE04X22654 TIMER
WH03X20271 WH03X20271 TOP BEARING
WH38X10018 WH38X10018 TRANSMISSION PULLEY
WE02X25500 WE02X25500 TRAP DUCT ASM 27
WH45X10149 WH45X10149 TUB 27
WH49X27616 WH49X27616 TUB COVER ASM 27
WH01X10617 WH01X10617 WASHER HUB
WH13X10052 WH13X10052 WATER VALVE
WE2X263D WE2X263D WE2X263D
