Model Image
Manufacturer

GE

Model Number

5TX62G9ST0WS

Description

Dryer Gas

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WE14X20683 WE14X20683 BAFFLE
WE1M300 WE1M300 BEARING RETAINER
WE03X37319 WE03X37319 BEARING SLIDE
WE03X37320 WE03X37320 BEARING SLIDE
WE03X25576 WE03X25576 BEARING TOP ASM
WE03X23956 WE03X23956 BEARING TOP SLIDES
WE03X29897 WE03X29897 BELT DRIVE
WE09X27636 WE09X27636 BLOWER GASKET (EXHAUST)
WH16X34317 WH16X34317 BLOWER WHEEL
WE01X25074 WE01X25074 BRACKET IDLER
WE14X25075 WE14X25075 BURNER ASM
WE04X24719 WE04X24719 BUTTON START ASM
WE4M318 WE4M318 BUZZER
WE01X32177 WE01X32177 CAP DOOR
WE2M96 WE2M96 CAP NUT
WE14M177 WE14M177 CHAMBER COMBUSTION
WE04X25159 WE04X25159 CHASSIS AND LEG ASM
WE22X35258 WE22X35258 CONTROL PANEL TL DRYER CROSLEY COMMERCIA
WE03X23883 WE03X23883 COVER BOTTOM
WE03X24721 WE03X24721 COVER TOP LOW DEPTH
WE11X25154 WE11X25154 DEFLECTOR FLAME
WE04X0448 WE04X0448 DETECTOR ASM
WE11X29438 WE11X29438 DIFFUSER
WE11X29443 WE11X29443 DIFFUSER GAS
WE14X21174 WE14X21174 DIFFUSER GAS ASM
WE01X31004 WE01X31004 DOOR DOOR LATCH
WE01X31005 WE01X31005 DOOR HINGE
WE01X30999 WE01X30999 DOOR STRIKE
WE04X28977 WE04X28977 DOOR SWITCH
WE21X23868 WE21X23868 DRUM ASM
WE01X35260 WE01X35260 DRYER CYCLE SELECT KNOB
WE10X31003 WE10X31003 DRYER DOOR
WE01X35261 WE01X35261 DRYER OPTIONS KNOB
WE01X23892 WE01X23892 EXHAUST DUCT
WE09X27635 WE09X27635 FELT TOP BEARING
WE09X27634 WE09X27634 FELT TRAP DUCT
WE03X23881 WE03X23881 FILTER LINT ASM
WE14X215 WE14X215 GAS VALVE ASM
WE13X20405 WE13X20405 GAS VALVE BRACKET
WE09X25276 WE09X25276 GASKET
WE1M825 WE1M825 GASKET (SEAL) 39 INCH
WE13X29439 WE13X29439 GROUND STRAP ASM
WE04X26138 WE04X26138 HIGH LIMIT THERMOSTAT
WE13X31117 WE13X31117 HOUSING BLOWER
WE03X20434 WE03X20434 IDLER ARM
WE03X27417 WE03X27417 IDLER ARM ASM
WE4M449 WE4M449 IGNITER ASM
WE04X25201 WE04X25201 INLET THERMOSTAT
WE15X25208 WE15X25208 JUMPER HARNESS BLACK TIM
WE15X25206 WE15X25206 JUMPER HARNESS RED START
WE01X25160 WE01X25160 KIT DRYING RACK
WE05X20431 WE05X20431 LAMP
WE01X29357 WE01X29357 LEVELING LEG
WE08X30998 WE08X30998 MAIN HARNESS GAS
WE17X24535 WE17X24535 MOTOR & BLOWER ASM
WE49X28295 WE49X28295 MOTOR AND PULLEY ASM
WE01X0921 WE01X0921 MOTOR BRACKET
WE13M39 WE13M39 MOTOR SUPPORT
WE1M461 WE1M461 O RING
WE20X24556 WE20X24556 PANEL BACK
WE20X25260 WE20X25260 PANEL FRONT
WE10X29822 WE10X29822 PANEL SIDE
WE13X29444 WE13X29444 PLATE BLOWER
WE10X30380 WE10X30380 PLATE DIFFUSER
WE03X23858 WE03X23858 PLATE MOTOR
WE1M934 WE1M934 PLUG BUTTON WHITE
31-16775 31-16775 PM INSTALLATION INSTRUCTION USA ELEC Y G
31-3000238 31-3000238 PM MINI MANUAL AND WIRING
49-3000333 49-3000333 PM QUICK OWNERS MANUAL
WE26M345 WE26M345 POWER CORD (120V GAS)
WE03X31620 WE03X31620 PULLEY
WE10X35437 WE10X35437 REAR PANEL
WE01X24720 WE01X24720 SCR 30 X 20 IA PP
WE2X21854 WE2X21854 SCREW
WE2M302 WE2M302 SCREW
WE2M202 WE2M202 SCREW
WE01X25535 WE01X25535 SCREW
WE01X25318 WE01X25318 SCREW
WE2M174 WE2M174 SCREW # 10
WE2M163 WE2M163 SCREW #10
WZ5X158D WZ5X158D SCREW 8-32X3/8 GRD SCR
WE00X181L WE00X181L SHAFT
WE3M33 WE3M33 SHAFT & BRACKET ASS'Y
WE01X23880 WE01X23880 SHIELD SWITCH
WE02X24214 WE02X24214 SHUTTER AIR
WE1M462 WE1M462 SLEEVE DRUM
WE01X26494 WE01X26494 SOCKET ASM
WE2M188 WE2M188 STABILIZING LEG ASM.
WE13X30697 WE13X30697 STRAP MOTOR
WE1M569 WE1M569 STRIKE PLATE
WD21X10261 WD21X10261 SWITCH INTERLOCK
WE4M416 WE4M416 SWITCH PTS
WE02X25283 WE02X25283 SWITCH ROTARY
WE04X26215 WE04X26215 THERMOSTAT
WE04X25199 WE04X25199 THERMOSTAT
WE04X25281 WE04X25281 TIMER
WE11X29441 WE11X29441 TRANSITION DUCT
WE01X33121 WE01X33121 TRAP DUCT
WE03X25275 WE03X25275 TRAP DUCT ASM
WE03X29452 WE03X29452 VALVE & BURNER ASM
WE03X23918 WE03X23918 VALVE AND PIPE ASM
WE03X23916 WE03X23916 VALVE AND PIPE ASM
WE01X26154 WE01X26154 WASHER
WE15X25279 WE15X25279 WIRE GROUP ASM
