Model Image
Manufacturer

GE

Model Number

9119330193

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
40A15 40A15 40WATT 15AMP
WB31K5024 WB31K5024 6 INCH CHROME BURNER BOWL - EL
WB31K5025 WB31K5025 8 INCH CHROME BURNER BOWL - EL
WB2X7909 WB2X7909 ANTI-TIP RANGE KIT
WB37K5035 WB37K5035 BACKGUARD BODY
WB44K5012 WB44K5012 BAKE ELEMENT
WB2K5271 WB2K5271 BASE ASM
WB17X5095 WB17X5095 BLOCK TERMINAL POWER
WB2X9148 WB2X9148 BLOCK-FRONT
WB2X9146 WB2X9146 BLOCK-REAR
WB63K5066 WB63K5066 BODY SIDE ALMOND
WB63K5194 WB63K5194 BODY SIDE-TEXTURED
WB48X10056 WB48X10056 BROILER PAN&RACK LARGE 12-3/4
WB44X232 WB44X232 BROILUNT 240
WB2X9105 WB2X9105 CLIP
WB2X9404 WB2X9404 CLIP-KNOB
WB17X211 WB17X211 CLIP-TERM BK
WB11K5012 WB11K5012 CLOCK
WB2X9152 WB2X9152 COVER
WB2X9431 WB2X9431 COVER LOCK
WB34K5092 WB34K5092 DISCONNECT SHIELD
WB58X65 WB58X65 DRAWER
WB23M24 WB23M24 EL CTL 1500W
WB23M23 WB23M23 ELE CTL 2000
WB7X1649 WB7X1649 END CAP-RGHT
WB18M1 WB18M1 EYELET TERM
WB1X1138 WB1X1138 FIBER WASHER
WB63X353 WB63X353 FRONT FRAME
WB2X9373 WB2X9373 GASKET
WB36X767 WB36X767 GLASS-CLOCK
WB56X1886 WB56X1886 GLASS-OUTER-BLACK
WB1X1260 WB1X1260 GRUND WASHER
WB15X282 WB15X282 HANDLE DRWR
WB2X9434 WB2X9434 HANDLE-LATCH
WB1X1264 WB1X1264 HEX NUT
WB14X126 WB14X126 HINGE-LEFT
WB14X103 WB14X103 HINGE-LEFT
WB14X104 WB14X104 HINGE-RIGHT
WB14X127 WB14X127 HINGE-RIGHT
WB3K5069 WB3K5069 INF CTL KNOB
WB02T10077 WB02T10077 INSLN RETAINER-LO
WB2M38 WB2M38 INSUL RETNR
WB2X9430 WB2X9430 INSULATION
WB35K5113 WB35K5113 INSULATION-BACK & BTM
WB35K5027 WB35K5027 INSULATION-LOCK BOX
WB2X9129 WB2X9129 INSULATOR
WB3X787 WB3X787 KNOB CLOCK
WB14T10004 WB14T10004 LATCH ASM
WB2X9025 WB2X9025 LEG-LEVEL
WB25T10042 WB25T10042 LENS
WB2X9432 WB2X9432 LEVER-SWITCH
WB25T10040 WB25T10040 LIGHT INDICATOR
WB25T10039 WB25T10039 LIGHT INDICATOR
WB55T10018 WB55T10018 LINING OVEN DR ASSEMBLY
WB3K5154 WB3K5154 LOCK KNOB BL
WB18M64 WB18M64 LOCK SW HARN
WB63K5187 WB63K5187 MAIN BACK
WB62M17 WB62M17 MAIN TOP WH
WB18K5326 WB18K5326 MT WIRE HARNESS W/BLO
WB24X106 WB24X106 N/L/A 01/14/00
WB7X1648 WB7X1648 N/L/A 02/28/03
WB62M18 WB62M18 N/L/A 10/23/07
WB36K5170 WB36K5170 N/L/A 11/04/04
WB36K5169 WB36K5169 N/L/A 12/08/02
WB56K5066 WB56K5066 OV DR FRAME
WB35M2 WB35M2 OV DR INSUL
WB35K5026 WB35K5026 OV DR INSULATION
WB25M10 WB25M10 OV LAMP LENS
WB2X9384 WB2X9384 OVDR GL RET
WB2K5101 WB2K5101 OVDR INS RET
WB55K5036 WB55K5036 OVEN DOOR PLUG
WB48M4 WB48M4 OVEN RACK
WB20K5020 WB20K5020 OVEN THERMOSTAT
WB8K5042 WB8K5042 OVLAMP HLDR
WB56X1973 WB56X1973 PANEL ALMND
WB56X1959 WB56X1959 PANELDRWR WH
WB02T10054 WB02T10054 PLATE RANGE SERVICE M
WB2X9189 WB2X9189 PLUG BUT REC
WB2X9415 WB2X9415 RACEWAY
WB2K5316 WB2K5316 REINF PLATE
WB2X9433 WB2X9433 RETAINER
WB2X9084 WB2X9084 ROD-SUPPORT
WB01X32746 WB01X32746 SCR ST 8A8 X .625 TR NI
WB1K5122 WB1K5122 SCREW
WB1X1172 WB1X1172 SCREW
WB1M1 WB1M1 SCREW
WB1X1176 WB1X1176 SCREW
WB1X1261 WB1X1261 SCREW
WB1K5072 WB1K5072 SCREW
WB1X1258 WB1X1258 SCREW
WB1X1262 WB1X1262 SCREW
WB1X1149 WB1X1149 SCREW 10-16 X 3/8
WB1K5191 WB1K5191 SCREW FL ZNC 10-32
WB1X1130 WB1X1130 SCREW-10-32
WB1X1137 WB1X1137 SCREW-10AB
WB1X1132 WB1X1132 SCREW-6-32
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB1X1424D WB1X1424D SCREW-PKG 12
WB3K5081 WB3K5081 SELECT KNOB **NLA*
WB24K5060 WB24K5060 SELECTOR SWITCH
WB1X1177 WB1X1177 SPACER
WB2X9039 WB2X9039 SPACER-GLASS
WB2X9037 WB2X9037 SPACER-HNDL
WB9X251 WB9X251 SPRING
WB9X273 WB9X273 SPRING-DOOR
WB31X5021 WB31X5021 STAINLESS STEEL CENTER TRIM FO
WB2X9719 WB2X9719 SUPP-BROIL
WB7X1647 WB7X1647 SUPPORT
WB56M3 WB56M3 SUPPORT DRWR
WB30X254 WB30X254 SURF UNIT 6
WB30X253 WB30X253 SURF UNIT 8
WB24X415 WB24X415 SWITCH-LITE
WB17X210 WB17X210 TERM BLK
WB3K5080 WB3K5080 THERMOS KNOB **NLA*
WB19X10005 WB19X10005 TIMER
WB38K5018 WB38K5018 TUBE VENT ASSEMBLY
WB34M20 WB34M20 UP WIRE CVR
WB34K5093 WB34K5093 UPPER WIRE COVER
WB1M6 WB1M6 WASHER
WB1M22 WB1M22 WASHER
WB1X119D WB1X119D WASHR-PKG 12
WB1X1159D WB1X1159D WASHR-PKG 12
WB2X9416 WB2X9416 WB2X9416
WB63K5109 WB63K5109 WRAPPER OV CAV ASSEMBLY
