Model Number

AZ61H15EACM2

Description

Zoneline

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP85X10008 WP85X10008 AIR FILTER
WP65X10014 WP65X10014 BACK PLATE L
WJ07X10246 WJ07X10246 BADGE
WP76X10006 WP76X10006 BEARING ASM
WP03X10015 WP03X10015 BEARING HOLDER
WP65X10013 WP65X10013 BRACE
WP76X10041 WP76X10041 BULKHEAD K
WP03X10013 WP03X10013 CAB. ANGLE LH
WP03X10012 WP03X10012 CAB. ANGLE RH
WP03X10031 WP03X10031 CAPACITOR CLAMP
WP56X10024 WP56X10024 CAPILLARY TUBE
WP56X10023 WP56X10023 CAPILLARY TUBE
WP56X10022 WP56X10022 CAPILLARY TUBE
WP56X10021 WP56X10021 CAPILLARY TUBE
WP56X10020 WP56X10020 CAPILLARY TUBE
WP58X10002 WP58X10002 CHECK VALVE
WP73X10013 WP73X10013 CLOSS FAN
WP28X10020 WP28X10020 COIL
WP27X10071 WP27X10071 COMP. WIRING
WP98X10044 WP98X10044 COMPRESSOR
WJ01X10046 WJ01X10046 COMPRESSOR CUSHION
WP88X10091 WP88X10091 CONDENSER ASM
WJ79X10134 WJ79X10134 CONDENSER PLATE
WP76X10033 WP76X10033 CONDENSER SHROUD
WP03X10026 WP03X10026 CONNECTOR
WP07X10013 WP07X10013 CONTROL BASE ASM
WP71X10033 WP71X10033 CONTROL COVER W/LOGO
WP07X10008 WP07X10008 CONTROL SHEET
WP01X10038 WP01X10038 COVER
WP01X10037 WP01X10037 COVER
WP01X10039 WP01X10039 COVER RUBBER B
WP66X10007 WP66X10007 DAMPER ASSEMBLY
WP70X10031 WP70X10031 DAMPER LEVER
WP01X10058 WP01X10058 DAMPER LEVER COVER
WJ70X10026 WJ70X10026 DAMPER RUBBER
WP94X20644 WP94X20644 DC FAN MOTOR OUT DOOR
WP94X10306 WP94X10306 DC IN FAN MOTOR
WP66X10008 WP66X10008 DC IN MOTOR ANGLE
WP89X10023 WP89X10023 DRAIN TRAY
WJ58X10043 WJ58X10043 DRAINING VALVE
WP29X10015 WP29X10015 DRIVE PWB
WP87X21181 WP87X21181 EVAPORATOR ASM
WP03X10019 WP03X10019 FAN HOUSING COVER L
WP03X10020 WP03X10020 FAN HOUSING COVER R
WP71X10030 WP71X10030 FRONT PANEL
WP71X10029 WP71X10029 FRONT PANEL ASM
WP23X10031 WP23X10031 FUSE
WP23X10027 WP23X10027 FUSE
WP23X10026 WP23X10026 FUSE
WP23X10003 WP23X10003 FUSE (250V,4A)
WJ01X10003 WJ01X10003 GASKET WASHER
WP70X20721 WP70X20721 HEATER ASM
WP03X10016 WP03X10016 HOLDER
WP03X10017 WP03X10017 HOLDER ANG L TOP
WP56X10012 WP56X10012 LEAD TUBE
WP56X10011 WP56X10011 LEAD TUBE
WJ27X10001 WJ27X10001 LEAD WIRE
WP71X10031 WP71X10031 LOUVER
WP71X10032 WP71X10032 LOUVER ASM
WP71X10012 WP71X10012 LOUVER ASM
WP01X10001 WP01X10001 MAGNET
WP01X10002 WP01X10002 MAGNET SEAL
WP66X10009 WP66X10009 OUT DOOR MOTOR ANGLE
WP23X10035 WP23X10035 OVERLOAD PROTECTOR
31-61687 31-61687 PM MINI MANUAL
WJ73X10047 WJ73X10047 PROPELLER FAN
WP01X10059 WP01X10059 PROTECTOR COVER
WP27X10067 WP27X10067 PROTECTOR F
WP03X10030 WP03X10030 PROTECTOR HOLDER
WJ02X10001 WJ02X10001 PROTECTOR SPRING
WP02X10003 WP02X10003 PUSH NUT
WP29X10071 WP29X10071 PWB MAIN ASSEMBLY
WP58X10006 WP58X10006 REVERSE VALVE
WP01X10005 WP01X10005 RUBBER WASHER
WP20X10023 WP20X10023 RUNNING CAPACITOR
WP03X10023 WP03X10023 SPACER
WP03X10022 WP03X10022 SPACER
WP01X10015 WP01X10015 SPECIAL NUT
WJ01X10041 WJ01X10041 SPECIAL NUT
WJ01X10392 WJ01X10392 SPECIAL SCREW
WP01X10024 WP01X10024 SPECIAL SCREW
WP01X10021 WP01X10021 SPECIAL SCREW
WP02X10001 WP02X10001 SPRING
WJ01X10031 WJ01X10031 STUD BOLT
WP01X10036 WP01X10036 SUPPORTER
WP01X10026 WP01X10026 TAP TIGHT SCREW
WP29X10014 WP29X10014 TERMINAL BOARD
WP03X10021 WP03X10021 TERMINAL BOX COVER
WJ79X10013 WJ79X10013 TERMINAL COVER
WJ43X10003 WJ43X10003 TERMINAL GASKET
WP27X10065 WP27X10065 THERMISTOR
WJ03X10011 WJ03X10011 THERMISTOR HOLDER
WP01X10007 WP01X10007 THERMO CUSHION
WP27X10066 WP27X10066 THERMOSTAT
WP27X10069 WP27X10069 TRANSFORMER
WP26X10091 WP26X10091 TRIAC PWB ASM
49-7612-2 49-7612-2 USE & CARE
WP28X10021 WP28X10021 VARISTOR
WP03X10029 WP03X10029 WIRE HOLDER
WP56X10004 WP56X10004 WIRE NETTING 61
