Model Image
Manufacturer

GE

Model Number

CGS990SET4SS

Description

Gas Range Or Dual Fuel

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB16K10070 WB16K10070 000 BTUS GAS RANGE BURNER BASE; 5
WB29K10022 WB29K10022 000 BTUS GAS RANGE SMALL BURNER CAP; 5
WB29K10023 WB29K10023 500 BTUS GAS RANGE MEDIUM BURNER CAP; 9
WB28K10023 WB28K10023 89MM RANGE ORIFICE SPUD - NG TO LP
WB16K10055 WB16K10055 9 RANGE SURFACE BURNER BASE-MEDIUM 500
WB02K0003 WB02K0003 ANGLE SUPPORT
WB2K3 WB2K3 ANGLE SUPPRT
WB44K10034 WB44K10034 ASSEMBLY ELEMENT BROIL
WB63X25414 WB63X25414 BAKE DEFLECTOR COMPLEM
WB49K10036 WB49K10036 BAKE DEFLECTOR COMPLEMEN
WB49K10029 WB49K10029 BAKE DEFLECTOR UC
WB2X8351 WB2X8351 BLADE FAN
WB26K10019 WB26K10019 BLOWER SERVICE KIT
WB35X37967 WB35X37967 BOTTOM OVEN ASSEMBLY
WB63K10239 WB63K10239 BOTTOM RANGE
WB63K10208 WB63K10208 BRACE
WB02K10329 WB02K10329 BRACE OVEN TOP
WB02K10254 WB02K10254 BRACKET ANTI-TIP ASSEMBLY
WB02K10353 WB02K10353 BRACKET BACK COOKTOP
WB02K10313 WB02K10313 BRACKET CAVITY SUPPORT
WB02K10369 WB02K10369 BRACKET DOOR
WB02K10370 WB02K10370 BRACKET DOOR
WB02K10366 WB02K10366 BRACKET DUCT
WB02K10335 WB02K10335 BRACKET INNER DOOR
WB02K0041 WB02K0041 BRACKET OVEN CORNER
WB02X21734 WB02X21734 BRACKET PIPE
WB49K10028 WB49K10028 BROIL DEFLECTOR UC
WB02K10178 WB02K10178 BUMPER
WB2K15 WB2K15 BUMPER BLACK
WB02K0015 WB02K0015 BUMPER, BLACK
WB16K10074 WB16K10074 BURNER BAKE
WB16K10077 WB16K10077 BURNER BROIL UPPER
WB29K10045 WB29K10045 BURNER CAP CENTRAL
WB29K10044 WB29K10044 BURNER CAP OUTER
WB31K10218 WB31K10218 CENTER GRATE CAST
WB02K10361 WB02K10361 CKT BRACKET MDM AND LGE
WB02K10360 WB02K10360 CKT BRACKET SMALL
WB02K0036 WB02K0036 CLAMP CABLE
WB2K36 WB2K36 CLAMP CABLE
WB02K10367 WB02K10367 CLAMP HEAT ELEMENT
WB02T10111 WB02T10111 CLEANER-SS
WB02K0031 WB02K0031 CLIP CABLE
WB02X21679 WB02X21679 CLIP CABLE
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K10073 WB02K10073 CLIP CAPILLARY
WB02K0038 WB02K0038 CLIP WIRE
WB02X7066 WB02X7066 CLIP WIRE
WB02K10267 WB02K10267 CLIP WIRE
WB02K10068 WB02K10068 CLIP WIRE
WB27K10423 WB27K10423 CONTROL OVN (ERC3HP)
WB02K10363 WB02K10363 COOKTOP BURNER BRACKET - EXTRA LARGE
WB35X31383 WB35X31383 COOKTOP SIDE INSULATION
WB35X21685 WB35X21685 CORD FIBER GLASS
WB34X21731 WB34X21731 COVER BACK BOX
WB63K10063 WB63K10063 COVER BURNER BOX
WB63K10133 WB63K10133 COVER BURNER BOX
WB02K10337 WB02K10337 COVER CAP
WB02K10317 WB02K10317 COVER LATCH
WB34K10135 WB34K10135 COVER MOTOR
WB2X8309 WB2X8309 COVER PROBE
WB34K10133 WB34K10133 COVER SHUTER
WB37K10012 WB37K10012 COVER THERMOSTAT
WB37K10019 WB37K10019 COVER THERMOSTAT
WB02K0024 WB02K0024 COVER VALVE
WB57K10155 WB57K10155 CRYSTAL WINDOW
WB57K10156 WB57K10156 CRYSTAL WINDOW
WB57K10158 WB57K10158 CRYSTAL WINDOW
WB34K14 WB34K14 CVR IGNITOR
WB63X25413 WB63X25413 DEFLECTOR
WB35X37972 WB35X37972 DEFLECTOR OVEN KIT
WB63K10136 WB63K10136 DUCT AND BURNER BOX ASM
WB01K10037 WB01K10037 ECONOMIC NUT
WB28K10708 WB28K10708 ELBOW BAKE LOWER
WB28K10706 WB28K10706 ELBOW BAKE UPPER
WB28K10738 WB28K10738 ELBOW DUAL CAVITY
WB13T10080 WB13T10080 ELECTRODE TOP
WB18K10095 WB18K10095 ELECTRODES HARNESS H. V.
WB07K10426 WB07K10426 ENDCAP H AND LE
WB02X8351 WB02X8351 FAN BLADE
WB34K10132 WB34K10132 FAN COVER
WB26K10003 WB26K10003 FAN MOTOR CONVECT-2SPEED
WB01X1378 WB01X1378 FLAT WASHER-M4
WB02X28737 WB02X28737 FRAME FRONT BUMPER
WB63K10250 WB63K10250 FRAME FRONT UC
WB63K10251 WB63K10251 FRAME WELD ASSEMBLY
WB34X28741 WB34X28741 FRAME WINDOW ASSEMBLY
WB34X28740 WB34X28740 FRAME WINDOW ASSY
WB39K10040 WB39K10040 FULL EXT RACK-NICKEL PLATED-FREE STN GAS
WB28K10222 WB28K10222 GAS RANGE BURNER CAP - XL V2
WB03K10265 WB03K10265 GAS RANGE KNOB - STAINLESS STEEL
WB16K10062 WB16K10062 GAS RANGE XL BURNER
WB32K10046 WB32K10046 GASKET OVEN
WB32K10047 WB32K10047 GASKET OVEN
WB32K0001 WB32K0001 GASKET VENT
WB32K10045 WB32K10045 GASKET VENT
WB32K1 WB32K1 GASKET VENT
WB02T10589X WB02T10589X GE BADGE GRAY
WB57K10154 WB57K10154 GLASS AND PANEL DOOR ASSEMBLY
WB27K10369 WB27K10369 GLASS AND TOUCH BOARD ASSEMBLY
WB56X21280 WB56X21280 GLASS AND TRIM ASSEMBLY
WB31K10220 WB31K10220 GRIDDLE
WB2K8 WB2K8 GROMMET
WB56K10079 WB56K10079 GUARD INSULATION
WB56K10081 WB56K10081 GUARD INSULATION
WB53K10047 WB53K10047 GUARD TOP INSULATION
WB53K10048 WB53K10048 GUARD TOP INSULATION
WB18K10083 WB18K10083 HARNESS GROUND
WB18K10042 WB18K10042 HARNESS MODULE
WB18K10100 WB18K10100 HARNESS RF FILTER
WB18K10074 WB18K10074 HARNESS SWITCH
WB18T10386 WB18T10386 HARNESS WIRE GLASS TOUCH.
WB10K10027 WB10K10027 HINGE ASSEMBLY
WB10K10028 WB10K10028 HINGE ASSEMBLY
WB10K10023 WB10K10023 HINGE DOOR
WB10K10024 WB10K10024 HINGE DOOR
WB10K10025 WB10K10025 HINGE RECEIVER
WB10K10026 WB10K10026 HINGE RECEIVER
WB28K10712 WB28K10712 HOOD SPUD ORIFICE
WB28K10713 WB28K10713 HOOD SPUD ORIFICE
WB34K0014 WB34K0014 IGNITER COVER
WB02K10348 WB02K10348 INSULATION COVER LAMP
WB34X21726 WB34X21726 INSULATION DOOR
WB34X21727 WB34X21727 INSULATION DOOR
WB34X21728 WB34X21728 INSULATION DOOR
WB34X21729 WB34X21729 INSULATION DOOR
WB34X21730 WB34X21730 INSULATION DOOR
WB35X21691 WB35X21691 INSULATION DOOR
WB35K10201 WB35K10201 INSULATION OVEN BACK
WB35K10202 WB35K10202 INSULATION OVEN WRAP
WB35K10204 WB35K10204 INSULATION OVEN WRAP
WB35K10205 WB35K10205 INSULATION OVEN WRAP
WB02K10352 WB02K10352 INSULATION PRESSURE REGU
WB01T10086 WB01T10086 KEPS NUT 6-32
WB28K10800 WB28K10800 KIT CONVERSION LP
WB03K10308 WB03K10308 KNOB ASSEMBLY
WB02K10326 WB02K10326 L SUPPORT
WB25K10009 WB25K10009 LENS
WB25K10010 WB25K10010 LIGHT INDICATOR PILOT
WB18K10073 WB18K10073 LINE CORD
WB55K10081 WB55K10081 LINER DOOR ASSEMBLY
WB55K10080 WB55K10080 LINER DOOR WELD ASSEMBLY
31-10778 31-10778 LP INSTALL INSTRUCTIONS
WB28K10475 WB28K10475 LR ORIFICE HOLDER
WB02T10017 WB02T10017 NUT
WB01K0003 WB01K0003 NUT SPEED
WB1K3 WB1K3 NUT SPEED
WB28K10693 WB28K10693 ORIFICE SPUD
WB28K10694 WB28K10694 ORIFICE SPUD
WB28K10834 WB28K10834 ORIFICE SPUD
WB28K10842 WB28K10842 ORIFICE SPUD LP
WB16K10076 WB16K10076 OVAL BURNER ASSEMBLY
WB53K10051 WB53K10051 OVEN BACK
WB63K10238 WB63K10238 OVEN BACK UC
WB35K10200 WB35K10200 OVEN BOTTOM UC
WB49K10030 WB49K10030 OVEN DEFLECTOR
WB49K10031 WB49K10031 OVEN DEFLECTOR
WB48X20783 WB48X20783 OVEN RACK
WB53K10040 WB53K10040 OVEN SIDE
WB53K10041 WB53K10041 OVEN SIDE
WB53K10042 WB53K10042 OVEN SIDE UC
WB53K10043 WB53K10043 OVEN SIDE UC
WB53K10039 WB53K10039 OVEN TOP
WB53K10044 WB53K10044 OVEN TOP
WB02K0062 WB02K0062 PAD FELT (2"")
WB2K62 WB2K62 PAD FELT 2
WB36K10920 WB36K10920 PANEL MANIFOLD
WB63K10119 WB63K10119 PANEL SIDE BK
WB14K10004 WB14K10004 PIN LOCATOR
WB24K10068 WB24K10068 PLUNGER SWITCH
WB06K10007 WB06K10007 PM HELPFUL HINT
31-10781 31-10781 PM INSTALL INSTRUCTIONS
31-10869 31-10869 PM KIT INSTRUCTIONS
31-14982-2 31-14982-2 PM MINI MANUAL
49-85181 49-85181 PM OWNERS AND INSTALL
WB34X21733 WB34X21733 POST SIDE
WB19K10077 WB19K10077 PRESSURE REGULATOR
WB20T10024 WB20T10024 PROBE
WB02X8309 WB02X8309 PROBE COVER
WB16K10083 WB16K10083 RANGE 15K LP TUBE
WB63K10212 WB63K10212 RANGE BACK
WB34K10038 WB34K10038 RANGE BACK FAN COVER
WB30X28763 WB30X28763 RANGE BAKE BURNER
WB28K10215 WB28K10215 RANGE BURNER ORIFICE
WB02K10169 WB02K10169 RANGE CONTROL BRACKET
WB21K10161 WB21K10161 RANGE CONTROL VALVE
WB02K10168 WB02K10168 RANGE DEFLECTOR
WB21K10141 WB21K10141 RANGE DUAL VALVE
WB02K10023 WB02K10023 RANGE ELEMENT CLAMP
WB02K10034 WB02K10034 RANGE FAN SUPPORT
WB02K10167 WB02K10167 RANGE FLOW DEVIATOR
WB15K10112 WB15K10112 RANGE HANDLE - STAINLESS STEEL
WB01K10023 WB01K10023 RANGE HANDLE GROMMET
WB13K10043 WB13K10043 RANGE IGNITER GLOW BAR
WB13X25262 WB13X25262 RANGE IGNITER GLOWBAR
WB13X25263 WB13X25263 RANGE IGNITER GLOWBAR
WB1X1293 WB1X1293 RANGE IGNITER MOUNTING SCREW
WB02K10324 WB02K10324 RANGE INLET SUPPLY
WB35K10038 WB35K10038 RANGE INSULATOR FAN
WB03K10266 WB03K10266 RANGE KNOB - STAINLESS STEEL
WB03X23121 WB03X23121 RANGE KNOB - STAINLESS STEEL
WB02K10315 WB02K10315 RANGE LATCH - AUTOMATIC
WB02K10318 WB02K10318 RANGE LATCH ASSEMBLY - LOWER
WB02K10182 WB02K10182 RANGE LEVELING LEG
WB08K10018 WB08K10018 RANGE LIGHT COVER
WB02K10349 WB02K10349 RANGE LIGHT INSULATION
WB24K10046 WB24K10046 RANGE LIMIT SWITCH
WB28K10698 WB28K10698 RANGE MAIN DUAL VALVE TUBE
WB02K10249 WB02K10249 RANGE MANIFOLD PANEL SUPPORT
WB02K10250 WB02K10250 RANGE MANIFOLD PANEL SUPPORT
WB28K10686 WB28K10686 RANGE MANIFOLD PIPE
WB28K10684 WB28K10684 RANGE MANIFOLD SUPPLY TUBE
WB28K10687 WB28K10687 RANGE MANIFOLD TUBE
WB28K10871 WB28K10871 RANGE NG ORIFICE AND TUBE
WB28K10740 WB28K10740 RANGE ORIFICE HOLDER - FRONT LEFT
WB28K10741 WB28K10741 RANGE ORIFICE HOLDER - RIGHT REAR
WB2K41 WB2K41 RANGE OVEN BRACKET
WB08T10002 WB08T10002 RANGE OVEN LAMP ASSEMBLY
WB32K10044 WB32K10044 RANGE OVEN LIGHT GASKET
WB35K10100 WB35K10100 RANGE SIDE INSULATION
WB28K10699 WB28K10699 RANGE SIMMER DUAL VALVE TUBE
WB02K10270 WB02K10270 RANGE SPACER BASE
WB13X26360 WB13X26360 RANGE SPARK MODULE 6+0
WB04K10037 WB04K10037 RANGE SURFACE BURNER KNOB BEZEL
WB20K10027 WB20K10027 RANGE TEMPERATURE SENSOR
WB20K10036 WB20K10036 RANGE THERMOSTAT.
WB62X25403 WB62X25403 RANGE TOP
WB28K10785 WB28K10785 RANGE TOP BURNER ASSEMBLY
WB34K10096 WB34K10096 RANGE UPPER HALF DUCT
WB63K10283 WB63K10283 RANGETOP
WB10K10029 WB10K10029 RECEIVER HINGE
WB34K10134 WB34K10134 RECEPTABLE ASSEMBLY
WB13K10050 WB13K10050 RELAY
WB2X2030 WB2X2030 RETAINER
WB02K0030 WB02K0030 RETAINER-INSULATION VENT
WR1X1466 WR1X1466 SCR 8-32 T HXW 3/8 S
WZ5X158D WZ5X158D SCR 8-32 T HXW 3/8 S
WB1K45 WB1K45 SCR AND WSHR ASSEMBLY
WB01K0001 WB01K0001 SCREW
WB01K10091 WB01K10091 SCREW
WB1X536 WB1X536 SCREW
WB1X1261 WB1X1261 SCREW
WB1K5062 WB1K5062 SCREW
WB01K10070 WB01K10070 SCREW
WB01K10106 WB01K10106 SCREW
WB1K5119 WB1K5119 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5364 WB01X5364 SCREW (CR)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01K10116 WB01K10116 SCREW 10-16
WB01K10047 WB01K10047 SCREW 10-32 HXW 9/16 DWR
WB01K10009 WB01K10009 SCREW 10-32 MTG H AND LE
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01K10099 WB01K10099 SCREW 6-322
WB01K10067 WB01K10067 SCREW 8 HD 1/4-20
WB01K10065 WB01K10065 SCREW 8 HD 12-24
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K10002 WB01K10002 SCREW 8-32
WB01X1261 WB01X1261 SCREW GROUND
WB1X5364 WB1X5364 SCREW MTG
WB01K0050 WB01K0050 SCREW MTG IGNITER
WB1K8 WB1K8 SCREW THERMO
WB01K0008 WB01K0008 SCREW THERMOSTAT
WB01K10110 WB01K10110 SCREW TRILOBULAR
WB01K0045 WB01K0045 SCREW WASHER ASM
WB34K10136 WB34K10136 SHIELD BROIL
WB02K10371 WB02K10371 SHIELD HEAT DOOR
WB31K10219 WB31K10219 SIDE GRATE CAST
WB02K10320 WB02K10320 SPACER BASE
WB02K10345 WB02K10345 SPACER BASE
WB13K10044 WB13K10044 SPARK MODULE BRACKET
WB01K0002 WB01K0002 SPEEDNUT
WB1K2 WB1K2 SPEEDNUT
WB01K10093 WB01K10093 SPEEDNUT
WB63K10267 WB63K10267 SUPPORT BASE
WB63K10268 WB63K10268 SUPPORT BASE
WB02K10333 WB02K10333 SUPPORT H AND LE
WB02K10325 WB02K10325 SUPPORT VALVE SINGLE
WB24K10091 WB24K10091 SWITCH LIMIT BIMETAL
WB24K10090 WB24K10090 SWITCH THERMOSTAT
WB16X24999 WB16X24999 TRIPLE RING BURNER
WB28K10700 WB28K10700 TUBE BURNER SUPPLY BAKE
WB28K10795 WB28K10795 TUBE BURNER SUPPLY BROIL
WB28K10688 WB28K10688 TUBE MANIFOLD SUPPLY
WB28K10716 WB28K10716 TUBE MANIFOLD SUPPLY
WB28K10701 WB28K10701 TUBE VALVE SAFETY
WB28K10703 WB28K10703 TUBE VALVE SUPPLY
WB28K10796 WB28K10796 TUBE VALVE SUPPLY
WB21K10096 WB21K10096 VALVE BURNER 270
WB21K10097 WB21K10097 VALVE BURNER 270
WB21K10119 WB21K10119 VALVE BURNER 270
WB21K10080 WB21K10080 VALVE BURNER 270 HI-CAP
WB21K10160 WB21K10160 VALVE CONTROL ASSEMBLY
WB2K24 WB2K24 VALVE COVER
WB19K10072 WB19K10072 VALVE LOCKOUT
WB38K10037 WB38K10037 VENT ASSEMBLY
WB38K10030 WB38K10030 VENT BACKER
WB07K10395 WB07K10395 VENT TRIM
WB07K10396 WB07K10396 VENT TRIM INSULATION
Main Menu x
