Model Image
Manufacturer

GE

Model Number

CS980ST1SS

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
PM10X310 PM10X310 28 CERAMA BR
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB02K10374 WB02K10374 AUTOMATIC LATCH ASM
WB63K10167 WB63K10167 BACK DRAWER
WD34X11435 WD34X11435 BADGE
WB02K0027 WB02K0027 BAIL
WB2K27 WB2K27 BAIL
WB30X46987 WB30X46987 BAKE ELEMENT
WB07K10378 WB07K10378 BARRIER DOOR
WB07K10342 WB07K10342 BARRIER DOOR
WB2X8351 WB2X8351 BLADE FAN
WB26K10019 WB26K10019 BLOWER SERVICE KIT
WB26K10008 WB26K10008 BLOWER TANGENTIAL 60MM
WB35K10209 WB35K10209 BOTTOM OVEN
WB01K0005 WB01K0005 BOTTOM OVEN SCREW
WB63K10060 WB63K10060 BOTTOM RANGE
WB63K0005 WB63K0005 BRACE BOTTOM
WB63K5 WB63K5 BRACE BOTTOM
WB02K10253 WB02K10253 BRACE VENT
WB02K10256 WB02K10256 BRACKET ANTI-TIP ASM
WB02K10386 WB02K10386 BRACKET ASSEMBLY ANTI-TIP
WB02K10175 WB02K10175 BRACKET DOOR
WB63K10062 WB63K10062 BRACKET DRAWER
WB02K10350 WB02K10350 BRACKET GLASS
WB39K0020 WB39K0020 BRACKET MOUNTING DRAWER
WB02K10052 WB02K10052 BRACKET MTG TERMINAL
WB30X46986 WB30X46986 BROIL ELEMENT
WB02K10343 WB02K10343 BUMPER
WB02K10171 WB02K10171 BUMPER
WB2K15 WB2K15 BUMPER BLACK
WB02K10112 WB02K10112 BUMPER BLUE
WB02K10375 WB02K10375 BUMPER FRAME FRONT
WB02K0015 WB02K0015 BUMPER, BLACK
WB02K10172 WB02K10172 CAPACITOR HOLDER
WB08K10009 WB08K10009 CAPACITOR MOTOR
WB02K10110 WB02K10110 CATCH
WB02K0031 WB02K0031 CLIP CABLE
WB02X21679 WB02X21679 CLIP CABLE
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K10073 WB02K10073 CLIP CAPILLARY
WB02X7066 WB02X7066 CLIP WIRE
WB02K10068 WB02K10068 CLIP WIRE
WB01X0119 WB01X0119 CONTOURED WASHER
WB27K10386 WB27K10386 CONTROL OVN (ERC3HP)
WB27K10424 WB27K10424 CONTROL OVN (ERC3HP)
WB44X10051 WB44X10051 CONVECTION ELEMENT
WB02K10109 WB02K10109 COVER ACCESS SPRING LFT
WB02K10108 WB02K10108 COVER ACCESS SPRING RGT
WB55K10072 WB55K10072 COVER DRAWER
WB34K10128 WB34K10128 COVER HEATING ELEMENT
WB34K10099 WB34K10099 COVER MOTOR
WB56K0020 WB56K0020 CRYSTAL WINDOW
WB57K10174 WB57K10174 CRYSTAL WINDOW
WB49K10011 WB49K10011 DEFLECTOR BOTTOM
WB49K10012 WB49K10012 DEFLECTOR TOP
WB34K10096 WB34K10096 DUCT UPPER HALF
WB30T10145 WB30T10145 ELEMENT HALIANT
WB30T10068 WB30T10068 ELEMENT HALIANT (DUAL)
WB30T10130 WB30T10130 ELEMENT HALIANT 12 IN
WB30T10045 WB30T10045 ELEMENT HALIANT 8" 1900W
WB07K10426 WB07K10426 ENDCAP HANDLE
WB02X8351 WB02X8351 FAN BLADE
WB34K10038 WB34K10038 FAN COVER BACK
WB35K10013 WB35K10013 FAN INSULATION
WB02K10170 WB02K10170 FAN SUPPORT
WB58K10010 WB58K10010 FRAME DRAWER
WB34K10141 WB34K10141 FRAME WINDOW PACK ASM
WB04K10017 WB04K10017 GASKET DRAWER ASM
WB04K10018 WB04K10018 GASKET LOWER
WB32K10052 WB32K10052 GASKET OVEN ASM
WB32K0005 WB32K0005 GASKET OVEN LIGHT
WB32K0002 WB32K0002 GASKET OVEN SEAL LG
WB35K10019 WB35K10019 GASKET VENT
WB27K10312 WB27K10312 GLASS & TOUCH BOARD ASM
WB64X0093 WB64X0093 GLASS CLEANER
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB57K10175 WB57K10175 GLASS PANEL DOOR ASM
WB31K10229 WB31K10229 GRIDDLE ASM RADIANT
WB2K8 WB2K8 GROMMET
WB2X646 WB2X646 GROUND PLATE
WB53K10030 WB53K10030 GUARD TOP INSULATION
WB30X38928 WB30X38928 HALIANT ELEMENT 6" CERSP
WB15K10077 WB15K10077 HANDLE TUBE SS
WB18T10386 WB18T10386 HARNESS WIRE GLASS TOUCH
WB44K10015 WB44K10015 HEATING ELEMENT BOTTOM
WB44K10014 WB44K10014 HEATING ELEMENT TOP
WB10K10043 WB10K10043 HINGE DOOR
WB10K10042 WB10K10042 HINGE DOOR
WB10K10036 WB10K10036 HINGE DOOR LH
WB10K10037 WB10K10037 HINGE DOOR RH
WB8K1 WB8K1 HOUS RECEPTL
WB08K0001 WB08K0001 HOUSING RECEPTACLE
WB24K10059 WB24K10059 INFINITE SWITCH CENTER
WB24T10119 WB24T10119 INFINITE SWITCH CONTROL
WB35K10222 WB35K10222 INSULATION
WB35K10053 WB35K10053 INSULATION DRAWER FRONT
WB35K10054 WB35K10054 INSULATION DRAWER TOP
WB35K10055 WB35K10055 INSULATION FOIL
WB35K10168 WB35K10168 INSULATION OVEN BACK
WB35K10143 WB35K10143 INSULATION OVEN WRAP
WB35K10099 WB35K10099 INSULATION VENT
WB03K10267 WB03K10267 KNOB ASSEMBLY
WB03K10290 WB03K10290 KNOB ASSEMBLY CENTER
WB03K10289 WB03K10289 KNOB ASSEMBLY LF, RF
WB03K10288 WB03K10288 KNOB ASSEMBLY LR
WB03K10291 WB03K10291 KNOB ASSEMBLY RR
WB02K10182 WB02K10182 LEG LEVELER
WB25K10009 WB25K10009 LENS
WB25K10010 WB25K10010 LIGHT INDICATOR PILOT
WB55K10084 WB55K10084 LINER DOOR WELD ASSEMBLY
WB55K10024 WB55K10024 LINER DRAWER
WB18T10352 WB18T10352 LOCKOUT RELAY
WB02K10250 WB02K10250 MANIFOLD PANEL SUPPORT
WB02K10249 WB02K10249 MANIFOLD PANEL SUPPORT
WB25T10050 WB25T10050 MODULE INDICATOR LIGHT
WB26K10015 WB26K10015 MOTOR PSC CONV
WB02X8454 WB02X8454 NUT
WB2X8454 WB2X8454 NUT
WB1X5572 WB1X5572 NUT
WB01X5572 WB01X5572 NUT MEAT PROBE
WB01K0003 WB01K0003 NUT SPEED
WB1K3 WB1K3 NUT SPEED
WB63K10254 WB63K10254 OVEN BACK
WB48X21508 WB48X21508 OVEN RACK
WB53K10017 WB53K10017 OVEN TOP
WB2X1222 WB2X1222 PAD
WB02X1222 WB02X1222 PAD GLASS (FELT)
WB48K10033 WB48K10033 PAN DRAWER
WB36K10825 WB36K10825 PANEL MANF & TAPE ASM
WB63K10139 WB63K10139 PANEL REAR BROIL
WB63K10258 WB63K10258 PANEL SIDE
WB63K10056 WB63K10056 PANEL SIDE BROIL LFT
WB63K10055 WB63K10055 PANEL SIDE BROIL RGT
WB14K10004 WB14K10004 PIN LOCATOR
WB02X0646 WB02X0646 PLATE-GROUND
WB24K10068 WB24K10068 PLUNGER SWITCH
31-14994 31-14994 PM MINI MANUAL
49-85198 49-85198 PM OWNERS AND INSTALL
WB2X8309 WB2X8309 PR0BE COVER
WB02X8309 WB02X8309 PROBE COVER
WB20X5050 WB20X5050 PROBE THERMISTOR
WB20T10024 WB20T10024 PROBE THERMISTOR
WB48K10010 WB48K10010 RACK BAKING DRAWER
WB09T10002 WB09T10002 RADIANT ELEMENT SPRING
WB63K10173 WB63K10173 RANGE BACK
WB26K10018 WB26K10018 RANGE BLOWER - 60 MM
WB34K10137 WB34K10137 RANGE DOOR INSULATION GUARD
WB39K20 WB39K20 RANGE DRAWER MOUNTING BRACKET
WB34K10142 WB34K10142 RANGE FAN COVER
WB63K10257 WB63K10257 RANGE FRAME
WB15K10112 WB15K10112 RANGE HANDLE - STAINLESS STEEL
WB35K10221 WB35K10221 RANGE INSULATION
WB36X192 WB36X192 RANGE OVEN BULB COVER
WB32K2 WB32K2 RANGE OVEN DOOR GASKET
WB32K5 WB32K5 RANGE OVEN GASKET
WB34K30 WB34K30 RANGE RADIATION GUARD
WB62K10123 WB62K10123 RANGE TOP AND GLASS ASM
WB10K10029 WB10K10029 RECEIVER HINGE
WB34K10121 WB34K10121 RECEPTABLE ASM
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB13K10049 WB13K10049 RELAY GRIDDLE ASM
WB2X2030 WB2X2030 RETAINER
WB02K0030 WB02K0030 RETAINER-INSULATION VENT
WB1K44 WB1K44 SCEW LATCH
WB01K10042 WB01K10042 SCR 8-18 AB IHW 3/8 SN
WR01X10389 WR01X10389 SCR 8-18 AB PHR 1/2 S
WB01K10102 WB01K10102 SCR 818 1/4
WB01K0063 WB01K0063 SCREW
WB01K0084 WB01K0084 SCREW
WB01K10070 WB01K10070 SCREW
WB01K10091 WB01K10091 SCREW
WB01K10030 WB01K10030 SCREW
WB1K5062 WB1K5062 SCREW
WB1X1261 WB1X1261 SCREW
WB1X536 WB1X536 SCREW
WB1K84 WB1K84 SCREW & WASH
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5364 WB01X5364 SCREW (CR)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB1K63 WB1K63 SCREW 10-16 X 0.95 TYPE B
WB1K5 WB1K5 SCREW 8-18 X 1/2 -INCH
WZ04X0345 WZ04X0345 SCREW 8-18X5/8 HXW
WB01K0044 WB01K0044 SCREW DOOR LATCH
WB01X1261 WB01X1261 SCREW GROUND
WB1X5364 WB1X5364 SCREW MTG
WB1K8 WB1K8 SCREW THERMO
WB01K0008 WB01K0008 SCREW THERMOSTAT
WZ4X345D WZ4X345D SCREWS - 12 PACK
WB23X5340 WB23X5340 SENSOR-OVEN
WB04K10037 WB04K10037 SKIRT
WB39K10026 WB39K10026 SLIDE & BEARING ASM LFT
WB39K10025 WB39K10025 SLIDE & BEARING ASM RGT
WB39K10027 WB39K10027 SLIDE INTERNAL
WB02K10111 WB02K10111 STRIKE
WB63K10256 WB63K10256 SUPPORT BASE
WB63K10255 WB63K10255 SUPPORT BASE
WB02K10028 WB02K10028 SUPPORT BROIL
WB35K10028 WB35K10028 SUPPORT CATALYST
WB38K10004 WB38K10004 SUPPORT SMOKE ELIMINATOR
WB24K10092 WB24K10092 SWITCH CONTROL INFINITE
WB24K10046 WB24K10046 SWITCH LIMIT BIMETAL
WB17T10011 WB17T10011 TERMINAL BLOCK ASM
WB20K10017 WB20K10017 THERMOSTAT
WB63K10234 WB63K10234 TOP DRAWER
WB38K10017 WB38K10017 VENT ASSEMBLY
WB02K10346 WB02K10346 VENT MOTOR
WB07K10336 WB07K10336 VENT TRIM
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
WB56K20 WB56K20 WIND PACK LG
