Model Image
Manufacturer

GE

Model Number

CTX18LATERWH

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WR2X9222 WR2X9222 *NLA*BRKT CAP
WR01X1774 WR01X1774 AXLE WHEEL REAR
WR1X1774 WR1X1774 AXWHEEL REAR
WR17X3771 WR17X3771 BAFFLE ASSEMBLY LH
WR17X2268 WR17X2268 BAFFLE ASSEMBLY RH
WR02X8693 WR02X8693 BEAUTY BUTTON-WHT
WR60X220 WR60X220 BLADE COND F
WR60X0212 WR60X0212 BLADE COND FAN ASM
WR17X2417 WR17X2417 BRACE AND BUMPER ASSEMBLY
WR02X9222 WR02X9222 BRACKET CAPACITOR
WR02X7768 WR02X7768 BRACKET CONTROL HSG
WR02X7664 WR02X7664 BRACKET EVAP FAN
WR02X7823 WR02X7823 BRACKET MULLION LH
WR02X7822 WR02X7822 BRACKET MULLION RH
WR2X7767 WR2X7767 BRKT CONTROL
WR2X7768 WR2X7768 BRKT CONTROL
WR02X7767 WR02X7767 BRKT CONTROL BACK
WR2X7664 WR2X7664 BRKT FAN
WR2X7051 WR2X7051 BUTTON PLUG
WR1X5278 WR1X5278 CABLE CLAMP
WR2X8069 WR2X8069 CAP BTM CORN
WR02X8069 WR02X8069 CAP BTM CORNER
WR02X7656 WR02X7656 CAP CORNER O.C. WH
WR2X7656 WR2X7656 CAP CORNR-WH
WR02X8797 WR02X8797 CAP SHELF FRONT
WR2X8797 WR2X8797 CAP SHLD FRT
WR62X0079 WR62X0079 CAPACITOR
WR55X24064 WR55X24064 CAPACITOR
WR01X5278 WR01X5278 CLAMP CABLE
WR02X8503 WR02X8503 CLAMP TUBE
WR02X8203 WR02X8203 CLIP COMPRESSOR MOUNT
WR02X9207 WR02X9207 CLIP COND
WR2X9207 WR2X9207 CLIP COND
WR2X9208 WR2X9208 CLIP COND UP
WR02X9208 WR02X9208 CLIP COND UPPER
WR2X9206 WR2X9206 CLIP DR PAN
WR2X4516 WR2X4516 CLIP DRAIN
WR02X9206 WR02X9206 CLIP DRAIN PAN
WR02X7928 WR02X7928 CLIP RELAY COVER
WR2X7928 WR2X7928 CLIP RELY CV
WR87X10079 WR87X10079 COMP REPL
WR02X3198 WR02X3198 COMP. RING, EVAP. FAN
WR84X0205 WR84X0205 COND ASM FINAL RECIP
WR17X3760 WR17X3760 COND FAN HSG LEGS
WR14X0313 WR14X0313 COND TOP BAFFLE FOAM
WR84X194 WR84X194 CONDENSR ASM
WR02X4495 WR02X4495 CONNECTOR W/LEAD
WR09X0520 WR09X0520 CONTROL DEFROST
WR09X0517 WR09X0517 CONTROL TEMP
WR9X517 WR9X517 CONTROL TEMP
WR82X0321 WR82X0321 COVER ACCESS ASM
WR17X2269 WR17X2269 COVER EVAP ASSEMBLY
WR17X3649 WR17X3649 COVER FF SUPPLY
WR02X8444 WR02X8444 COVER PLUG I M
WR02X7929 WR02X7929 COVER RELAY
WR2X7929 WR2X7929 COVER RELAY
WR17X3056 WR17X3056 COVER SUCT LINE
WR13X585 WR13X585 CTR HINGE
39-6297 39-6297 CTX18 21 24 USE & CARE
WR51X464 WR51X464 DEF HTR KIT
WR9X520 WR9X520 DEFROST CTRL
WR19X5003 WR19X5003 DISH BUTTER
WR78X8727 WR78X8727 DOOR FOAM ASSEMBLY FZ
WR77X0609 WR77X0609 DOOR INNER FF
WR77X0610 WR77X0610 DOOR INNER FZ
WR78X8726 WR78X8726 DOOR OUTER FF WHITE
WR02X7628 WR02X7628 DOOR STOP
WR2X8504 WR2X8504 DRAIN GROMET
WR60X30349 WR60X30349 EVAP FAN MOTOR KIT
WR60X123 WR60X123 FAN BLADE
WR60X114 WR60X114 FAN BLADE
WR60X0123 WR60X0123 FAN BLADE EVAP MOTOR
WR60X187 WR60X187 FAN MOTOR
WR2X6087 WR2X6087 FILL TUBE
WR82X0318 WR82X0318 FOAM PLUG S L
WR82X318 WR82X318 FOAM PLUG SL
WR14X0356 WR14X0356 FOAM STRIP MULLION
WR24X449 WR24X449 FREEZER GASKET
WR71X2502 WR71X2502 FRONT DOOR SHELF
WR17X2385 WR17X2385 FRONT LINER FZ
WR02X7640 WR02X7640 FUNNEL DRAIN
WR2X7640 WR2X7640 FUNNEL DRAIN
WR24X0450 WR24X0450 GASKET DOOR FF
WR24X0449 WR24X0449 GASKET DOOR FZ WH
WR24X450 WR24X450 GASKET FF
WR14X0357 WR14X0357 GASKET TROUGH
WR2X8629 WR2X8629 GRILLE I/S
WR02X8629 WR02X8629 GRILLE ICE SERV SNAP-IN
WR2X7391 WR2X7391 GROMMET
WR2X9001 WR2X9001 GROMMET
WR2X6261 WR2X6261 GROMMET
WR02X7238 WR02X7238 GROMMET COMP MTG
WR02X8504 WR02X8504 GROMMET DRAIN & TUBE
WR02X7391 WR02X7391 GROMMET EVAP FAN
WR02X6261 WR02X6261 GROMMET FZ SHELF
WR2X7238 WR2X7238 GROMMET MTG.
WR02X7773 WR02X7773 GROMMET WTR FILL
WR14X357 WR14X357 GSKT TROUGH
WR02X9168 WR02X9168 GUSSET
WR2X9168 WR2X9168 GUSSET
WR12X991 WR12X991 HANDLE EXTR **NLA*
WR12X0991 WR12X0991 HANDLE EXTRUDED
WR51X0367 WR51X0367 HEATER & BRKT ASM
WR51X0358 WR51X0358 HEATER MULLION
WR13X651 WR13X651 HGE BTM ASM
WR87X0427 WR87X0427 HI SIDE ASM REPL.
WR13X0651 WR13X0651 HINGE BTM ASM BK
WR13X0585 WR13X0585 HINGE CENTER ASM
WR13X626 WR13X626 HINGE TOP
WR13X0626 WR13X0626 HINGE TOP ASM
WR17X3196 WR17X3196 HOUSING CONTROL
WB17X5064 WB17X5064 HOUSING SOCKET PKG 4 P1N
WB17X5079 WB17X5079 HOUSING SOCKET PKG 6 PIN
WD1X1459 WD1X1459 HSNG INSUL.
WR51X358 WR51X358 HTR MULLION
WR77X609 WR77X609 I.D.PANEL FF
WR77X610 WR77X610 I.D.PANEL FZ
WR02X7669 WR02X7669 INSUL ELECT
WR2X7669 WR2X7669 INSUL ELECT
WD01X1459 WD01X1459 INSULATOR HSNG TERM
WR01X1803 WR01X1803 KEY PIVOT
WR1X1733 WR1X1733 KEY PIVOT
WR2X8692 WR2X8692 KNOB TEMP CO
40A15 40A15 LAMP 40W 120V
WR01X1815 WR01X1815 LEVELING NUT
WR1X1815 WR1X1815 LEVELING NUT
WR17X2275 WR17X2275 LINER BOTTOM FZ
WR17X2774 WR17X2774 LINER TOP FF
WR17X10028 WR17X10028 LINER TOP FF
WR85X0284 WR85X0284 LOW SIDE ASM
WR85X10004 WR85X10004 LOW SIDE ASM
WR2X8842 WR2X8842 MBLTY FT ASM
WR1X1816 WR1X1816 MOBIL- SCREW
WR02X8842 WR02X8842 MOBILITY FRONT ASM
WR86X0086 WR86X0086 MONGRAM SERIES P/S
WR60X0187 WR60X0187 MOTOR COND FAN
WR60X0190 WR60X0190 MOTOR EVAP FAN
WR2X7823 WR2X7823 MULLION L H
WR2X7822 WR2X7822 MULLION RH
WR1X1935 WR1X1935 N/L/A 05/03/06
WR82X321 WR82X321 N/L/A 09/19/05
WR4X200 WR4X200 NAMEPLATE
WR04X0200 WR04X0200 NAMEPLATE DOOR
WR02X8363 WR02X8363 NOZZLE FOAM
WR2X8363 WR2X8363 NOZZLE FOAM
WR01X1715 WR01X1715 NUT
WR1X1715 WR1X1715 NUT
WR78X8517 WR78X8517 O.DOOR FF WH
WR08X0155 WR08X0155 OVERLOAD
WR8X155 WR8X155 OVERLOAD
WR32X1101 WR32X1101 PAN STORAGE
WR13X587 WR13X587 PIN HINGE
WR13X0587 WR13X0587 PIN HINGE CTR
WR17X3609 WR17X3609 PLENUM
WR17X2990 WR17X2990 PLENUM
WR2X8087 WR2X8087 PLUG BUT INS
WR02X7652 WR02X7652 PLUG BUTTON
WR02X7069 WR02X7069 PLUG BUTTON
WR02X7148 WR02X7148 PLUG BUTTON
WR2X7624 WR2X7624 PLUG BUTTON
WR2X7652 WR2X7652 PLUG BUTTON
WR2X7069 WR2X7069 PLUG BUTTON
WR02X11760 WR02X11760 PLUG BUTTON
WR2X8247 WR2X8247 PLUG BUTTON
WR02X7051 WR02X7051 PLUG BUTTON
WR02X8087 WR02X8087 PLUG BUTTON INSERT WH
WR02X8247 WR02X8247 PLUG BUTTON WATER FILL
WR02X7624 WR02X7624 PLUG BUTTON WH
WR2X8444 WR2X8444 PLUG COVER
WR01X21159 WR01X21159 PLUG DOOR
SR2953 SR2953 PM MINI MANUAL WIRING
WR01X1841 WR01X1841 POP RIVET
WR1X1841 WR1X1841 POP RIVET
WR23X0108 WR23X0108 POWER CORD
WR23X10300 WR23X10300 POWER CORD
WR86X25269 WR86X25269 R134 DRIER
WR17X3743 WR17X3743 RAIL REAR
WR23X315 WR23X315 RECEPTACLE
WR23X0315 WR23X0315 RECEPTACLE ICEMAKER
31-5025 31-5025 REF INSTALL INST
WR2X8203 WR2X8203 REFRIGERATOR CLIP
WR14X313 WR14X313 REFRIGERATOR GASKET COVER
WR2X8344 WR2X8344 REFRIGERATOR VINYL SLEEVE
WR07X0195 WR07X0195 RELAY
WR07X10011 WR07X10011 RELAY PTCR
WR17X2279 WR17X2279 RETAINER STRIP H
WR17X2280 WR17X2280 RETAINER STRIP V
WR17X2281 WR17X2281 RETAINER STRIP V
WR01X1591 WR01X1591 SCR 1/4-14 X 3/4
WR01X1728 WR01X1728 SCR 10-16 1/2 PH
WZ04X0263 WZ04X0263 SCR 10-16 AB HXW 1/2
WR01X10590 WR01X10590 SCR 10-16 AB PNT20 1/2 S
WR01X1850 WR01X1850 SCR 7-19 HXW 1/2
WR01X1791 WR01X1791 SCR 8-15 SPEC
WR01X1804 WR01X1804 SCR 8-18 AB HXW 3/4 WH
WZ05X0137 WZ05X0137 SCR 8-32 SPEC DRILL PT
WR1X1466 WR1X1466 SCR 8-32 T HXW 3/8 S
WZ5X158D WZ5X158D SCR 8-32 T HXW 3/8 S
WR01X5475 WR01X5475 SCR 8/10-16 AB PA 5/8
WR01X1762 WR01X1762 SCREW
WR01X1752 WR01X1752 SCREW
WZ04X0417 WZ04X0417 SCREW
WR1X1850 WR1X1850 SCREW
WR1X1752 WR1X1752 SCREW
WR1X1591 WR1X1591 SCREW
WR1X1750 WR1X1750 SCREW
WD2X5166 WD2X5166 SCREW
WR1X1753 WR1X1753 SCREW
WZ5X246 WZ5X246 SCREW
WR1X1786 WR1X1786 SCREW
WR01X10606 WR01X10606 SCREW
WH02X0795 WH02X0795 SCREW 1/4-14 3/8 B HXW
WR01X1754 WR01X1754 SCREW 12-24
WR01X1753 WR01X1753 SCREW 12-24
WR01X1822 WR01X1822 SCREW 12-24 .9 BK
WB01T10047 WB01T10047 SCREW 8-32 X 625 M HXW S
WZ06X0133 WZ06X0133 SCREW BRKT. EVAP. FAN
WR01X1825 WR01X1825 SCREW COND HSG
WR01X1816 WR01X1816 SCREW MOBILITY
WZ6X133 WZ6X133 SCREW&WASHER
WR1X1791D WR1X1791D SCREW-PKG - 13 PACK
WH2X795D WH2X795D SCREW-PKG 12
WR1X5475D WR1X5475D SCREW-PKG 12
WR1X1754D WR1X1754D SCREW-PKG 12
WR02X8694 WR02X8694 SHAFT / KNOB DAMPER
WR71X10731 WR71X10731 SHELF FRONT NO GRAPHICS
WR2X8694 WR2X8694 SHFT KNB DPR
WR02X8692 WR02X8692 SHIM HINGE TOP FZ
WR02X8344 WR02X8344 SLEEVE VINYL
WR02X7270 WR02X7270 SOCKET TERMINAL ASM
WR2X9391 WR2X9391 SOCKET&TERM
WR2X7018 WR2X7018 SPAC CT TRAC
WR02X7018 WR02X7018 SPACER TRACK
WR2X4495 WR2X4495 SPADE CONN
WR1X1779 WR1X1779 STUD MTGCOMP
WR2X7973 WR2X7973 SUPT SHELF
WR23X309 WR23X309 SW POWER SAVER
WR23X10725 WR23X10725 SWITCH LIGHT
WR23X0193 WR23X0193 SWITCH LIGHT WH
WR23X0309 WR23X0309 SWITCH POWER SAVER
WR50X0131 WR50X0131 THERMOSTAT DEF
WR50X10010 WR50X10010 THERMOSTAT DEFROST
WR02X10111 WR02X10111 THIMBLE DOOR PLASTIC
WR02X7627 WR02X7627 THIMBLE WH
WR72X0094 WR72X0094 TRACK CANT SHELF FF
WR72X94 WR72X94 TRACK SHELF
WR17X2283 WR17X2283 TROUGH DRAIN
WR02X6087 WR02X6087 TUBE WATER FILL
WR17X3759 WR17X3759 UNIMOUNT HS
WR71X1956 WR71X1956 UNKNOWN
WR1X1714 WR1X1714 WASHER
WR01X1797 WR01X1797 WASHER HINGE .495ID
WR01X1714 WR01X1714 WASHER,CUSION
WR1X1797D WR1X1797D WASHR-PKG 12
WR2X3594 WR2X3594 WHEEL
WR02X3594 WR02X3594 WHEEL MOBILITY
WR14X347 WR14X347 WR14X347
WR17X2773 WR17X2773 WR17X2773
WR17X4195 WR17X4195 WR17X4195
WR2X9009 WR2X9009 WR2X9009
WR78X7983 WR78X7983 WR78X8727
WZ4X416 WZ4X416 WZ04X0408
