Model Image
Manufacturer

GE

Model Number

CTX21GIXERWW

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WR84X0202 WR84X0202 21/22 COND KIT DL M MTG
40A15 40A15 40WATT 15AMP
WR02X4039 WR02X4039 ADHESIVE CLIP
WR01X1774 WR01X1774 AXLE WHEEL REAR
WR1X1774 WR1X1774 AXWHEEL REAR
WR17X3770 WR17X3770 BAFFLE ASSEMBLY LH
WR17X2227 WR17X2227 BAFFLE ASSEMBLY RH
WR02X8693 WR02X8693 BEAUTY BUTTON-WHT
WR60X220 WR60X220 BLADE COND F
WR60X0212 WR60X0212 BLADE COND FAN ASM
WR02X7768 WR02X7768 BRACKET CONTROL HSG
WR02X7664 WR02X7664 BRACKET EVAP FAN
WR02X7823 WR02X7823 BRACKET MULLION LH
WR02X7822 WR02X7822 BRACKET MULLION RH
WR2X7767 WR2X7767 BRKT CONTROL
WR2X7768 WR2X7768 BRKT CONTROL
WR02X7767 WR02X7767 BRKT CONTROL BACK
WR2X7664 WR2X7664 BRKT FAN
WR30X10154 WR30X10154 BUCKET ICE
WR1X5278 WR1X5278 CABLE CLAMP
WR2X4928 WR2X4928 CAP
WR02X7656 WR02X7656 CAP CORNER O.C. WH
WR2X7656 WR2X7656 CAP CORNR-WH
WR02X4928 WR02X4928 CAP HANDLE
WR02X7975 WR02X7975 CAP SHELF FRT
WR2X7975 WR2X7975 CAP SHF FRT
WR02X7792 WR02X7792 CAP TRIM HANDLE
WR02X7791 WR02X7791 CAP TRIM HANDLE
WR62X0079 WR62X0079 CAPACITOR
WR2X7791 WR2X7791 CAPTRIM HDLE
WR2X7792 WR2X7792 CAPTRIM HDLE
WR12X0471 WR12X0471 CHANNEL HANDLE
WR12X0579 WR12X0579 CHANNEL HANDLE
WR12X471 WR12X471 CHANNEL HDLE
WR12X579 WR12X579 CHANNEL HDLE
WR2X4039 WR2X4039 CLAMP
WR01X5278 WR01X5278 CLAMP CABLE
WR01X5223 WR01X5223 CLAMP HOSE
WR02X7272 WR02X7272 CLAMP RELAY COVER
WR02X8503 WR02X8503 CLAMP TUBE
WR2X4754 WR2X4754 CLAMP-FILL T
WR1X1360 WR1X1360 CLIP
WR2X8203 WR2X8203 CLIP
WR02X7646 WR02X7646 CLIP BASE GRILLE
WR02X8203 WR02X8203 CLIP COMPRESSOR MOUNT
WR02X9207 WR02X9207 CLIP COND
WR2X9207 WR2X9207 CLIP COND
WR02X9209 WR02X9209 CLIP COND (DL)
WR2X9209 WR2X9209 CLIP COND DL
WR2X9208 WR2X9208 CLIP COND UP
WR02X9208 WR02X9208 CLIP COND UPPER
WR2X9206 WR2X9206 CLIP DR PAN
WR2X4516 WR2X4516 CLIP DRAIN
WR02X9206 WR02X9206 CLIP DRAIN PAN
WR2X7646 WR2X7646 CLIP GRILLE
WR02X7140 WR02X7140 CLIP HANDLE
WR2X7140 WR2X7140 CLIP HANDLE
WR01X1360 WR01X1360 CLIP U
WR02X3198 WR02X3198 COMP. RING, EVAP. FAN
WR87X10224 WR87X10224 COMPRESSOR KIT EGYS60
WR84X202 WR84X202 COND ASM
WR14X0313 WR14X0313 COND TOP BAFFLE FOAM
WR09X0520 WR09X0520 CONTROL DEFROST
WR09X0559 WR09X0559 CONTROL TEMP
WR9X559 WR9X559 CONTROL TEMP
WR82X0320 WR82X0320 COVER ACCESS ASM
WR02X9290 WR02X9290 COVER ASM
WR17X2228 WR17X2228 COVER EVAP ASSEMBLY
WR17X3910 WR17X3910 COVER FF SUPPLY
WR17X3056 WR17X3056 COVER SUCT LINE
WR2X7271 WR2X7271 CVR RELAY
WR22X522 WR22X522 DAIRY DOOR
WR51X0465 WR51X0465 DEF HTR & FUSE KIT
WR51X465 WR51X465 DEF HTR KIT
WR9X520 WR9X520 DEFROST CTRL
WR19X5003 WR19X5003 DISH BUTTER
WR22X0522 WR22X0522 DOOR DAIRY
WR77X0602 WR77X0602 DOOR INNER FF
WR77X0603 WR77X0603 DOOR INNER FZ
WR78X8734 WR78X8734 DOOR OUTER FF ALMOND
WR78X8736 WR78X8736 DOOR OUTER FF WHITE
WR78X8737 WR78X8737 DOOR OUTER FZ WHITE
WR02X7628 WR02X7628 DOOR STOP
WR2X8504 WR2X8504 DRAIN GROMET
WR60X30349 WR60X30349 EVAP FAN MOTOR KIT
WR60X114 WR60X114 FAN BLADE
WR60X123 WR60X123 FAN BLADE
WR60X0123 WR60X0123 FAN BLADE EVAP MOTOR
WR60X187 WR60X187 FAN MOTOR
WR2X6087 WR2X6087 FILL TUBE
WR82X360 WR82X360 FOAM PLUG
WR82X0360 WR82X0360 FOAM PLUG S.L.
WR14X0352 WR14X0352 FOAM STRIP MULLION
WR17X2401 WR17X2401 FRONT LINER FZ
WR02X7640 WR02X7640 FUNNEL DRAIN
WR2X7640 WR2X7640 FUNNEL DRAIN
WR14X384 WR14X384 GASKET
WR14X313 WR14X313 GASKET COVER
WR24X0446 WR24X0446 GASKET DOOR FF WH
WR24X0445 WR24X0445 GASKET DOOR FZ WH
WR24X446 WR24X446 GASKET FF
WR24X445 WR24X445 GASKET FZ
WR14X0366 WR14X0366 GASKET SLIDE CTR VP
WR14X0348 WR14X0348 GASKET TROUGH
WR14X0384 WR14X0384 GASKET VEG PAN SLIDE
WR74X269 WR74X269 GRILL BASE
WR74X0219 WR74X0219 GRILLE BASE ASM WH
WR2X8629 WR2X8629 GRILLE I/S
WR02X8629 WR02X8629 GRILLE ICE SERV SNAP-IN
WR2X7391 WR2X7391 GROMMET
WR2X9001 WR2X9001 GROMMET
WR2X6261 WR2X6261 GROMMET
WR02X7238 WR02X7238 GROMMET COMP MTG
WR02X8504 WR02X8504 GROMMET DRAIN & TUBE
WR02X7391 WR02X7391 GROMMET EVAP FAN
WR02X6261 WR02X6261 GROMMET FZ SHELF
WR2X7238 WR2X7238 GROMMET MTG.
WR02X7773 WR02X7773 GROMMET WTR FILL
WR14X366 WR14X366 GSKT SLID VP
WR14X357 WR14X357 GSKT TROUGH
WR02X9168 WR02X9168 GUSSET
WR2X9168 WR2X9168 GUSSET
WR12X0463 WR12X0463 HANDLE DOOR
WR12X463 WR12X463 HANDLE DR GE
WR38X2165 WR38X2165 HANDLE VEG PAN
WR51X0356 WR51X0356 HEATER MULLION
WR13X648 WR13X648 HGE B/P ASM
WR13X0648 WR13X0648 HINGE BTM ASM WH
WR13X0714 WR13X0714 HINGE CENTER ASM WH
WR13X714 WR13X714 HINGE CTR WH
WR13X626 WR13X626 HINGE TOP
WR13X0626 WR13X0626 HINGE TOP ASM
WR17X3196 WR17X3196 HOUSING CONTROL
WR17X3760 WR17X3760 HSNG FAN CON *NLA*
WD1X1459 WD1X1459 HSNG INSUL
WR51X356 WR51X356 HTR MULLION
WR77X602 WR77X602 I.D.PANEL FF
WR77X603 WR77X603 I.D.PANEL FZ
WR30X0291 WR30X0291 ICE BUCKET
WR30X0318 WR30X0318 ICEMAKER KIT
WR12X950 WR12X950 INS DR HNDL
WR12X1004 WR12X1004 INSERT DOOR HANDLE
WR12X1006 WR12X1006 INSERT HANDLE FF ALMOND
WR12X1013 WR12X1013 INSERT/NP HANDLE FZ ALMOND
WR12X0950 WR12X0950 INSERT/NP HNDL FZ WH
WR17X3858 WR17X3858 INSUL DIVIDER
WR17X3495 WR17X3495 INSUL DIVIDER
WR02X7669 WR02X7669 INSUL ELECT
WR2X7669 WR2X7669 INSUL ELECT
WD01X1459 WD01X1459 INSULATOR HSNG TERM
WR01X1803 WR01X1803 KEY PIVOT
WR1X1733 WR1X1733 KEY PIVOT
WR55X24064 WR55X24064 KIT CAPACITOR 12 UF
WR2X8692 WR2X8692 KNOB TEMP CO
WR01X1815 WR01X1815 LEVELING NUT
WR1X1815 WR1X1815 LEVELING NUT
WR17X2234 WR17X2234 LINER BOTTOM FZ
WR17X2796 WR17X2796 LINER TOP FF
WR85X10005 WR85X10005 LOW SIDE ASM
WR85X0310 WR85X0310 LOW SIDE ASM
WR2X8842 WR2X8842 MBLTY FT ASM
WR30X10093 WR30X10093 MECH ICEMAKER ASM
WR1X1816 WR1X1816 MOBIL- SCREW
WR02X8842 WR02X8842 MOBILITY FRONT ASM
WR60X0233 WR60X0233 MOTOR COND FAN
WR60X0190 WR60X0190 MOTOR EVAP FAN
WR2X7823 WR2X7823 MULLION L H
WR2X7822 WR2X7822 MULLION RH
WR1X1935 WR1X1935 N/L/A 05/03/06
WR82X320 WR82X320 N/L/A 11/25/03
WR02X8363 WR02X8363 NOZZLE FOAM
WR2X8363 WR2X8363 NOZZLE FOAM
WR01X1715 WR01X1715 NUT
WR1X1715 WR1X1715 NUT
WR57X57 WR57X57 NUT
WR86X96 WR86X96 P/S DRYER KIT R134A
WR86X25269 WR86X25269 P/S DRYER KIT R134A
WR32X1141 WR32X1141 PAN 1/2
WR32X1022 WR32X1022 PAN MEAT
WR13X587 WR13X587 PIN HINGE
WR13X0587 WR13X0587 PIN HINGE CTR
WR17X3609 WR17X3609 PLENUM
WR17X2990 WR17X2990 PLENUM
WR2X8087 WR2X8087 PLUG BUT INS
WR02X7652 WR02X7652 PLUG BUTTON
WR02X7069 WR02X7069 PLUG BUTTON
WR2X7051 WR2X7051 PLUG BUTTON
WR2X7652 WR2X7652 PLUG BUTTON
WR2X7069 WR2X7069 PLUG BUTTON
WR2X7624 WR2X7624 PLUG BUTTON
WR02X7051 WR02X7051 PLUG BUTTON
WR02X8087 WR02X8087 PLUG BUTTON INSERT WH
WR02X7624 WR02X7624 PLUG BUTTON WH
WR01X21159 WR01X21159 PLUG DOOR
39-6402 39-6402 PM GUIDE OWNERS
WR01X1841 WR01X1841 POP RIVET
WR1X1841 WR1X1841 POP RIVET
WR23X0108 WR23X0108 POWER CORD
WR23X10300 WR23X10300 POWER CORD
WR87X0475 WR87X0475 PRODUCT SERVICE KIT
WR17X3744 WR17X3744 RAIL REAR
WR17X3288 WR17X3288 RAIL VEG PAN FRONT
WR17X2798 WR17X2798 RAIL VEG PAN REAR
WR38X1653 WR38X1653 REAR TRIM GLASS SHELF
WR38X1659 WR38X1659 REAR TRIM SNACK SHELF
WR23X315 WR23X315 RECEPTACLE
WR23X0315 WR23X0315 RECEPTACLE ICEMAKER
31-5025 31-5025 REF INSTALL INST
WR07X0195 WR07X0195 RELAY
WR07X10011 WR07X10011 RELAY PTCR
WR17X2237 WR17X2237 RETAINER STRIP H
WR17X2239 WR17X2239 RETAINER STRIP V
WR17X2238 WR17X2238 RETAINER STRIP V
WR01X1591 WR01X1591 SCR 1/4-14 X 3/4
WR01X1728 WR01X1728 SCR 10-16 1/2 PH
WR01X1726 WR01X1726 SCR 10-16 AB 3/4 SS
WZ04X0263 WZ04X0263 SCR 10-16 AB HXW 1/2
WR01X10590 WR01X10590 SCR 10-16 AB PNT20 1/2 S
WR01X1850 WR01X1850 SCR 7-19 HXW 1/2
WR01X1791 WR01X1791 SCR 8-15 SPEC
WR01X1804 WR01X1804 SCR 8-18 AB HXW 3/4 WH
WR01X1755 WR01X1755 SCR 8-18 AB SPECIAL PA S
WR01X10606 WR01X10606 SCR 8-18 CA HX 1/2 S
WR01X1763 WR01X1763 SCR 8-18 T WAFER 5/8
WR01X1565 WR01X1565 SCR 8-32 MA FL 21/32 S
WR1X1466 WR1X1466 SCR 8-32 T HXW 3/8 S
WZ5X158D WZ5X158D SCR 8-32 T HXW 3/8 S
WH02X0940 WH02X0940 SCR 8-32 TT FL 1/2 S
WR01X5475 WR01X5475 SCR 8/10-16 AB PA 5/8
WR01X1762 WR01X1762 SCREW
WD2X5166 WD2X5166 SCREW
WZ5X246 WZ5X246 SCREW
WR1X1850 WR1X1850 SCREW
WR1X1755 WR1X1755 SCREW
WH2X940 WH2X940 SCREW
WR1X1786 WR1X1786 SCREW
WR1X1591 WR1X1591 SCREW
WH02X0795 WH02X0795 SCREW 1/4-14 3/8 B HXW
WR1X2138 WR1X2138 SCREW 12-24
WR1X2136 WR1X2136 SCREW 12-24
WR01X2138 WR01X2138 SCREW 12-24 .7 WH
WR01X2136 WR01X2136 SCREW 12-24 .9 WH
WZ06X0133 WZ06X0133 SCREW BRKT. EVAP. FAN
WR01X1825 WR01X1825 SCREW COND HSG
WR01X1816 WR01X1816 SCREW MOBILITY
WZ6X133 WZ6X133 SCREW&WASHER
WZ04X0244 WZ04X0244 SCREW-FRONT
WR1X1791D WR1X1791D SCREW-PKG - 13 PACK
WZ4X244D WZ4X244D SCREW-PKG 12
WR1X1763D WR1X1763D SCREW-PKG 12
WR1X1565D WR1X1565D SCREW-PKG 12
WH2X795D WH2X795D SCREW-PKG 12
WR1X5475D WR1X5475D SCREW-PKG 12
WR1X1726D WR1X1726D SCREW-PKG 12
WR02X9303 WR02X9303 SHAFT KNOB DAMPER
WR2X9303 WR2X9303 SHAFT/KNOB
WR71X2312 WR71X2312 SHELF ASM FZ
WR71X2189 WR71X2189 SHELF CANT FULL
WR32X1511 WR32X1511 SHELF CANT GLASS FULL
WR32X1510 WR32X1510 SHELF CANT GLASS VP F
WR71X2183 WR71X2183 SHELF CANT SNACK FULL
WR71X10731 WR71X10731 SHELF FRONT NO GRAPHICS
WR02X8378 WR02X8378 SHIELD LIGHT
WR2X8378 WR2X8378 SHIELD LIGHT
WR02X7793 WR02X7793 SHIM HANDLE ASM
WR2X7793 WR2X7793 SHIM HDL ASM
WR02X8692 WR02X8692 SHIM HINGE TOP FZ
WR02X8344 WR02X8344 SLEEVE VINYL
WR2X8344 WR2X8344 SLEEVE VINYL
WR17X2768 WR17X2768 SLIDE COVER CENTER
WR72X0179 WR72X0179 SLIDE M PAN LH WH
WR72X0124 WR72X0124 SLIDE M PAN RH WH
WR72X273 WR72X273 SLIDE MP RH
WR72X287 WR72X287 SLIDE PAN
WR17X2770 WR17X2770 SLIDE VEG PAN LH
WR17X2769 WR17X2769 SLIDE VEG PAN RH
WR2X8202 WR2X8202 SOCKET ASM
WR02X8202 WR02X8202 SOCKET ASM WH
WR2X7018 WR2X7018 SPAC CT TRAC
WR02X7018 WR02X7018 SPACER TRACK
WR12X581 WR12X581 STIFFENER
WR12X582 WR12X582 STIFFENER
WR12X0582 WR12X0582 STIFFENER HANDLE
WR12X0581 WR12X0581 STIFFENER HANDLE
WR02X3736 WR02X3736 STR RELIEF
WR1X1779 WR1X1779 STUD MTGCOMP
WR02X10736 WR02X10736 SUPPORT TWIST VP
WR02X8695 WR02X8695 SUPPORT TWIST VP CVR
WR2X7973 WR2X7973 SUPT SHELF
WR23X309 WR23X309 SW POWER SAVER
WR23X10725 WR23X10725 SWITCH LIGHT
WR23X0193 WR23X0193 SWITCH LIGHT WH
WR23X0309 WR23X0309 SWITCH POWER SAVER
31-51017 31-51017 TECHNICAL DATA SHEET
WR50X0131 WR50X0131 THERMOSTAT DEF
WR50X10010 WR50X10010 THERMOSTAT DEFROST
WR02X10111 WR02X10111 THIMBLE DOOR PLASTIC
WR02X7627 WR02X7627 THIMBLE WH
WR72X96 WR72X96 TRACK SHELF
WR72X0096 WR72X0096 TRACK SHELF FF R/L
WR38X2161 WR38X2161 TRIM
WR17X3984 WR17X3984 TRIM FRAME VP
WR38X2167 WR38X2167 TRIM GLASS SHELF
WR38X2168 WR38X2168 TRIM GLASS SHELF SNAC
WR17X2243 WR17X2243 TROUGH DRAIN
WR02X6087 WR02X6087 TUBE WATER FILL
WR17X3759 WR17X3759 UNIMOUNT HS
WR1X1714 WR1X1714 WASHER
WR01X1797 WR01X1797 WASHER HINGE .495ID
WR01X1714 WR01X1714 WASHER,CUSION
WR1X1797D WR1X1797D WASHR-PKG 12
WR17X1948 WR17X1948 WATER LINE 1/4
WR57X0110 WR57X0110 WATER VALVE ASM
WR57X10033 WR57X10033 WATER VALVE WITH GUARD
WR2X3594 WR2X3594 WHEEL
WR02X3594 WR02X3594 WHEEL MOBILITY
WR14X347 WR14X347 WR14X347
WR17X4194 WR17X4194 WR17X4194
WR2X9009 WR2X9009 WR2X9009
WR38X2175 WR38X2175 WR38X2175
WZ4X416 WZ4X416 WZ04X0408
Main Menu x
