Model Image
Manufacturer

GE

Model Number

DPXH46EA0WW

Description

Dryer Electric

Interactive Exploded View

Parts List

Part Number Description
WE02X10071 WE02X10071 8-18AB X0.44 SCREW QUAD
WE14X202 WE14X202 BAFFLE HEAT
WE14X0202 WE14X0202 BAFFLE-HEATER
WE01X1152 WE01X1152 BALL
WE1X1152 WE1X1152 BALL
WE3X70 WE3X70 BEARING
WE04X10063 WE04X10063 BEEPER
WE04X10027 WE04X10027 BLOCK TERM HEATER HSNG
WE04X0716 WE04X0716 BLOCK-TERMINAL
WE14X10025 WE14X10025 BLOWER HOUSING ASM
WE13X10017 WE13X10017 BRACKET - CONTROL BOARD
WE13X28680 WE13X28680 BRACKET BEARING
WE13X10018 WE13X10018 BRACKET CONTROL
WE13X10010 WE13X10010 BRACKET CORD
WE13X10006 WE13X10006 BRACKET MOTOR
WE13X10008 WE13X10008 BRACKET-BELT SWITCH
WE13X10005 WE13X10005 BRACKET-HINGE
WE2X358 WE2X358 CLIP
WE02X0358 WE02X0358 CLIP BALL
WE02X10013 WE02X10013 CLIP CABINET BTM
WE2X361 WE2X361 CLIP GUIDE
WE02X0361 WE02X0361 CLIP-GUIDE
WE02X10009 WE02X10009 CLIP-TOP FRONT/PANEL
WE02X10010 WE02X10010 CLIP-WIRING
WE04X10061 WE04X10061 CONTROL BOARD/SENSOR
WE20X10029 WE20X10029 CONTROL PANEL ASSEMBLY
WE20X10031 WE20X10031 CONTROL PANEL ASSEMBLY
WE20X10030 WE20X10030 CONTROL PANEL ASSEMBLY
WE18X10004 WE18X10004 COVER LINT TRAP
WE20X10005 WE20X10005 COVER TERM BLOCK
WE01X10023 WE01X10023 DOOR CATCH
WE10X10002 WE10X10002 DOOR OUTER WHITE
WE10X10008 WE10X10008 DOOR-INNER WHITE
WE10X10012 WE10X10012 DOOR-OUTER CC
WE10X10009 WE10X10009 DOOR-OUTER WH
WE21X10003 WE21X10003 DRUM-DRYER GALVANIZED BA
WE12X10009 WE12X10009 DRYER DRUM DRIVE BELT
WE4X757 WE4X757 DRYER THERMOSTAT
WE14X10102 WE14X10102 DUCT-AIR
WE09X0107 WE09X0107 GASKET DOOR
WE9X107 WE9X107 GASKET DOOR
WE03X10001 WE03X10001 GLIDE DRUM
WE03X0073 WE03X0073 GLIDE-DRUM
WE01X10089 WE01X10089 HANDLE-DOOR CC
WE01X10013 WE01X10013 HANDLE-DOOR WH
WE08X10025 WE08X10025 HARNESS-CONTROL
WE14X10015 WE14X10015 HEATER-HOUSING ASS'Y
WE01X10012 WE01X10012 HINGE-DOOR
WE01X10027 WE01X10027 IDLER SPRING
49-9963-2 49-9963-2 INSTALL/OWNERS GUIDE
WE04X10026 WE04X10026 INSULATOR HTR HSNG
WE25X10011 WE25X10011 KIT - AIR FLOW/THERMOSTAT
WE25X10001 WE25X10001 KIT REAR BEARING
WE01X10167 WE01X10167 KNOB-ROTARY WH
WE01X10168 WE01X10168 KNOB-TIMER WH
WE04X10058 WE04X10058 LAMP ASSEMBLY
WE02X10012 WE02X10012 LEVELING FOOT
WE18X10002 WE18X10002 LINT TRAP
WE01X10016 WE01X10016 LOCKFAN HOUSING
WE9X105 WE9X105 LOWER FELT
31-15415 31-15415 MINI MANUAL
WE17X10001 WE17X10001 MOTOR & PULLEY
WE01X10003 WE01X10003 MOTOR CLAMP
WE20X10009 WE20X10009 PANEL ACCESS
WE04X10098 WE04X10098 PANEL TOP CC
WE04X10011 WE04X10011 PANEL TOP WHITE
WE20X10033 WE20X10033 PANEL-FRONT STACK W/LIGHT
WE20X10016 WE20X10016 PANEL-FRONT STACK W/LIGHT
WE01X10088 WE01X10088 PLUG BISQUE
WE01X10090 WE01X10090 PLUG CC
WE01X10011 WE01X10011 PLUG WHITE
WE01X10010 WE01X10010 PLUG-DOME WHITE
WE01X10015 WE01X10015 RACK-DRYING
WH2X1150 WH2X1150 SCREW
WE02X10024 WE02X10024 SCREW
WE02X10007 WE02X10007 SCREW 10-14 X 1 00
WR2X9494 WR2X9494 SCREW 10-16 X 375
WE02X10002 WE02X10002 SCREW 10-16 X 625
WE02X10033 WE02X10033 SCREW 6-20 X 230
WE02X10011 WE02X10011 SCREW 8-18 X 375
WH01X10004 WH01X10004 SCREW 8-18AB X 375
WR02X9494 WR02X9494 SCREW 8-18B X 0.31
WH02X1150 WH02X1150 SCREW 8-32 X .250
WE02X10020 WE02X10020 SCREW GND 10-32T X 37
WE02X10014 WE02X10014 SCREW-
WE02X10005 WE02X10005 SCREW-BRACKET
WE02X10017 WE02X10017 SCREW-DOOR 10-16X 75
WH02X10009 WH02X10009 SCREW-LOCK 10-16X 50
WE09X0105 WE09X0105 SEAL BASKET LOWER
WE09X10003 WE09X10003 SEAL EXHAUST TUBE
WE09X10004 WE09X10004 SEAL-HEATER HOUSING
WE11X10002 WE11X10002 SHIELD-HEAT
WE01X10029 WE01X10029 SPACER-IDLER
WE25X10004 WE25X10004 STACKING KIT
WE01X1158 WE01X1158 STRIKE DOOR
WE1X1158 WE1X1158 STRIKE DOOR
WE13X10011 WE13X10011 SUPPORT SHAFT
WH12X10058 WH12X10058 SWITCH X-TRA RINSE/SPEED
WE04X10096 WE04X10096 SWITCH-BELT
WE04X10148 WE04X10148 SWITCH-DOOR W/DRUM LIGHT
WE04X10008 WE04X10008 SWITCH-START
WE04X10135 WE04X10135 TEMPERATURE SWITCH
WE4X716 WE4X716 TERM BLOCK
WE04X0774 WE04X0774 THERMAL LIMITER
WE04X10130 WE04X10130 THERMOSTAT-CONTROL
WE04X10060 WE04X10060 TIMER - DRYER
WE14X10007 WE14X10007 TUBE EXHAUST ASM
49-90380 49-90380 USE&CARE INST MANUAL
WE21X0069 WE21X0069 VANE
WE21X69 WE21X69 VANE DRUM
WE01X10218 WE01X10218 W/PULLEY IDLER ARM ASSEMBLY
