Model Image
Manufacturer

GE

Model Number

ERT2018DARBB

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WR2X7226 WR2X7226 *NLA*CLIP COVER
WR01X10604 WR01X10604 AXLE WHEEL
WR17X10316 WR17X10316 BAFFLE ASSEMBLY LH
WR17X10314 WR17X10314 BAFFLE COND RH
WR17X10544 WR17X10544 BASEPLATE HIGH SIDE
WR60X10030 WR60X10030 BLADE COND FAN
WR02X7768 WR02X7768 BRACKET CONTROL HSG
WR02X7664 WR02X7664 BRACKET EVAP FAN
WR02X10100 WR02X10100 BRACKET EVAPORATOR FAN SM
WR02X7823 WR02X7823 BRACKET MULLION LH
WR02X7822 WR02X7822 BRACKET MULLION RH
WR2X7768 WR2X7768 BRKT CONTROL
WR2X7767 WR2X7767 BRKT CONTROL
WR02X7767 WR02X7767 BRKT CONTROL BACK
WR2X7664 WR2X7664 BRKT FAN
WR32X1560 WR32X1560 BUCKET UTILITY WHITE
WR2X7051 WR2X7051 BUTTON PLUG
WR1X5278 WR1X5278 CABLE CLAMP
WR02X8539 WR02X8539 CAP CORNER O.C. BK
WR02X10322 WR02X10322 CAP DUST
WR2X8539 WR2X8539 CAP OC BLACK
WR02X7975 WR02X7975 CAP SHELF FRT
WR2X7975 WR2X7975 CAP SHF FRT
WR02X9296 WR02X9296 CAP SHLF FRNT RH
WR2X9295 WR2X9295 CAP SHLF LH
WR2X9296 WR2X9296 CAP SHLF RH
WR01X5278 WR01X5278 CLAMP CABLE
WR02X7226 WR02X7226 CLAMP COVER
WR02X8503 WR02X8503 CLAMP TUBE
WR02X7646 WR02X7646 CLIP BASE GRILLE
WR02X8203 WR02X8203 CLIP COMPRESSOR MOUNT
WR02X9209 WR02X9209 CLIP COND (DL)
WR2X9209 WR2X9209 CLIP COND DL
WR2X4516 WR2X4516 CLIP DRAIN
WR2X7646 WR2X7646 CLIP GRILLE
WR02X9501 WR02X9501 CLIP TUBE
WR2X9501 WR2X9501 CLIP TUBE
WR02X3198 WR02X3198 COMP. RING, EVAP. FAN
WR84X10053 WR84X10053 COND ASSEMBLY FINAL RECIP
WR17X10425 WR17X10425 COND FAN HSG & BRACKET ASSEMBL
WR14X0313 WR14X0313 COND TOP BAFFLE FOAM
WR84X10052 WR84X10052 CONDENSER ASM S/L 3/16
WR09X0520 WR09X0520 CONTROL DEFROST
WR09X0559 WR09X0559 CONTROL TEMP
WR9X559 WR9X559 CONTROL TEMP
WR02X7834 WR02X7834 COVER
WR82X10044 WR82X10044 COVER ACCESS ASSEMBLY
WR17X2269 WR17X2269 COVER EVAP ASSEMBLY
WR17X3883 WR17X3883 COVER FF SUPPLY
WR02X8444 WR02X8444 COVER PLUG I M
WR2X7834 WR2X7834 COVER RELAY
WR02X10172 WR02X10172 COVER SCREW ALMOND
WR02X10171 WR02X10171 COVER SCREW BLACK
WR02X10170 WR02X10170 COVER SCREW WHITE
WR17X10543 WR17X10543 COVER SUCTION LINE
WR22X439 WR22X439 DAIRY DOOR
WR51X464 WR51X464 DEF HTR KIT
WR9X520 WR9X520 DEFROST CTRL
WR19X5003 WR19X5003 DISH BUTTER
WR02X9297 WR02X9297 DIVIDER SHELF
WR2X9297 WR2X9297 DIVIDER SHLF
WR78X8727 WR78X8727 DOOR FOAM ASSEMBLY FZ
WR77X0609 WR77X0609 DOOR INNER FF
WR77X0610 WR77X0610 DOOR INNER FZ
WR78X8724 WR78X8724 DOOR OUTER FF ALMOND
WR78X10085 WR78X10085 DOOR OUTER FF BLACK
WR78X8725 WR78X8725 DOOR OUTER FZ ALMOND
WR78X10086 WR78X10086 DOOR OUTER FZ BLACK
WR02X7628 WR02X7628 DOOR STOP
WR22X0518 WR22X0518 DOOR UTILITY
WR02X9295 WR02X9295 END CAP - L. H (WIDE)
WR60X30349 WR60X30349 EVAP FAN MOTOR KIT
WR60X123 WR60X123 FAN BLADE
WR60X114 WR60X114 FAN BLADE
WR60X0123 WR60X0123 FAN BLADE EVAP MOTOR
WR2X6087 WR2X6087 FILL TUBE
WR86X25269 WR86X25269 FILTER AND DRYER ASSEMBLY
WR82X360 WR82X360 FOAM PLUG
WR82X0360 WR82X0360 FOAM PLUG S.L.
WR14X0356 WR14X0356 FOAM STRIP MULLION
WR14X10008 WR14X10008 FOAM STRIP SE ADH
WR71X10732 WR71X10732 FRONT DOOR SHELF FZ
WR17X2385 WR17X2385 FRONT LINER FZ
WR14X384 WR14X384 GASKET
WR14X397 WR14X397 GASKET CVR
WR14X0371 WR14X0371 GASKET CVR PAN FRONT
WR14X0399 WR14X0399 GASKET CVR PAN REAR
WR24X0540 WR24X0540 GASKET DOOR FF BK
WR24X0539 WR24X0539 GASKET DOOR FZ BK
WR14X0366 WR14X0366 GASKET SLIDE CTR VP
WR14X0357 WR14X0357 GASKET TROUGH
WR14X0384 WR14X0384 GASKET VEG PAN SLIDE
WR24X540 WR24X540 GKT D. FF BL
WR24X539 WR24X539 GKT D. FZ BL
WR74X203 WR74X203 GRILLE B ASM
WR74X0203 WR74X0203 GRILLE BASE ASM
WR2X8629 WR2X8629 GRILLE I/S
WR02X8629 WR02X8629 GRILLE ICE SERV SNAP-IN
WR2X6261 WR2X6261 GROMMET
WR2X7391 WR2X7391 GROMMET
WR2X8474 WR2X8474 GROMMET
WR02X7238 WR02X7238 GROMMET COMP MTG
WR02X7391 WR02X7391 GROMMET EVAP FAN
WR02X6261 WR02X6261 GROMMET FZ SHELF
WR02X10098 WR02X10098 GROMMET MOTOR
WR2X7238 WR2X7238 GROMMET MTG.
WR02X9153 WR02X9153 GROMMET WATER FILL
WR14X366 WR14X366 GSKT SLID VP
WR14X357 WR14X357 GSKT TROUGH
WR02X9168 WR02X9168 GUSSET
WR2X9168 WR2X9168 GUSSET
WR12X10337 WR12X10337 HANDLE ASSEMBLY FZ
WR12X10124 WR12X10124 HANDLE DOOR ASSEMBLY FF A
WR12X10135 WR12X10135 HANDLE DOOR ASSEMBLY FF BLACK
WR12X10760 WR12X10760 HANDLE DOOR ASSEMBLY FF WHITE
WR38X10113 WR38X10113 HANDLE PAN
WR17X10175 WR17X10175 HANDLE VEG PAN
WR12X10334 WR12X10334 HANDLE/NP ASSEMBLY FZ BLACK
WR51X0358 WR51X0358 HEATER MULLION
WR13X651 WR13X651 HGE BTM ASM
WR13X0651 WR13X0651 HINGE BTM ASM BK
WR13X0726 WR13X0726 HINGE CENTER ASM BK
WR13X726 WR13X726 HINGE CTR BK
WR13X10003 WR13X10003 HINGE TOP PAINT ASSEMBLY
WR17X3196 WR17X3196 HOUSING CONTROL
WR51X358 WR51X358 HTR MULLION
WR77X609 WR77X609 I.D.PANEL FF
WR77X610 WR77X610 I.D.PANEL FZ
WR01X1803 WR01X1803 KEY PIVOT
WR1X1733 WR1X1733 KEY PIVOT
WR2X8692 WR2X8692 KNOB TEMP CO
40A15 40A15 LAMP 40W 120V
WR04X10071 WR04X10071 LENS NAMEPLATE BLACK
WR01X1815 WR01X1815 LEVELING NUT
WR1X1815 WR1X1815 LEVELING NUT
WR17X2275 WR17X2275 LINER BOTTOM FZ
WR17X10028 WR17X10028 LINER TOP FF
WR85X10004 WR85X10004 LOW SIDE ASM
WR2X8842 WR2X8842 MBLTY FT ASM
WR1X1816 WR1X1816 MOBIL- SCREW
WR02X8842 WR02X8842 MOBILITY FRONT ASM
WR60X10020 WR60X10020 MOTOR COND. FAN
WR60X0190 WR60X0190 MOTOR EVAP FAN
WR17X4201 WR17X4201 MULLION CROSSPIECE BL
WR17X4195 WR17X4195 MULLION CROSSPIECE WHITE
WR2X7823 WR2X7823 MULLION L H
WR2X7822 WR2X7822 MULLION RH
WR08X0169 WR08X0169 OVERLOAD
WR8X169 WR8X169 OVERLOAD
WR86X96 WR86X96 P/S DRYER KIT R134A
WR32X1590 WR32X1590 PAN ASSEMBLY VEG
WR32X1073 WR32X1073 PAN MEAT (4)
WR13X587 WR13X587 PIN HINGE
WR13X0587 WR13X0587 PIN HINGE CTR
WR12X10379 WR12X10379 PK HANDLE SMALL ASSEMBLY
WR12X10335 WR12X10335 PK HANDLE SMALL ASSEMBLY BLACK
WR17X3609 WR17X3609 PLENUM
WR17X2990 WR17X2990 PLENUM
WR02X7652 WR02X7652 PLUG BUTTON
WR02X7069 WR02X7069 PLUG BUTTON
WR02X7148 WR02X7148 PLUG BUTTON
WR2X8541 WR2X8541 PLUG BUTTON
WR2X7652 WR2X7652 PLUG BUTTON
WR2X7069 WR2X7069 PLUG BUTTON
WR02X11760 WR02X11760 PLUG BUTTON
WR2X8247 WR2X8247 PLUG BUTTON
WR02X7051 WR02X7051 PLUG BUTTON
WR02X8541 WR02X8541 PLUG BUTTON BK
WR12X10136 WR12X10136 PLUG BUTTON HANDLE BLACK
WR12X10129 WR12X10129 PLUG BUTTON HANDLE WH
WR02X8542 WR02X8542 PLUG BUTTON INSERT BK
WR02X8247 WR02X8247 PLUG BUTTON WATER FILL
WR2X8444 WR2X8444 PLUG COVER
WR02X21195 WR02X21195 PLUG DOOR REVERSABLE
WR02X8701 WR02X8701 PLUG DOOR RVSBL BK
WR2X8542 WR2X8542 PLUG INSERT
49-60013 49-60013 PM GUIDE OWNERS
31-51229 31-51229 PM MINI MANUAL WIRING
WR23X0108 WR23X0108 POWER CORD
WR23X10300 WR23X10300 POWER CORD
WR07X0277 WR07X0277 PTCR
WR07X10099 WR07X10099 PTCR
WR17X2779 WR17X2779 RAIL VEG PAN FRONT
WR17X3182 WR17X3182 RAIL VEG PAN REAR
WR23X315 WR23X315 RECEPTACLE
WR23X0315 WR23X0315 RECEPTACLE ICEMAKER
WR2X8203 WR2X8203 REFRIGERATOR CLIP
WR14X313 WR14X313 REFRIGERATOR GASKET COVER
WR2X8344 WR2X8344 REFRIGERATOR VINYL SLEEVE
WR17X2279 WR17X2279 RETAINER STRIP H
WR17X2281 WR17X2281 RETAINER STRIP V
WR17X2280 WR17X2280 RETAINER STRIP V
WR02X10323 WR02X10323 RING COMP COND FAN BLADE
WR01X1591 WR01X1591 SCR 1/4-14 X 3/4
WR01X1728 WR01X1728 SCR 10-16 1/2 PH
WR01X1726 WR01X1726 SCR 10-16 AB 3/4 SS
WZ04X0263 WZ04X0263 SCR 10-16 AB HXW 1/2
WR01X10590 WR01X10590 SCR 10-16 AB PNT20 1/2 S
WR01X1791 WR01X1791 SCR 8-15 SPEC
WR01X1804 WR01X1804 SCR 8-18 AB HXW 3/4 WH
WR01X1757 WR01X1757 SCR 8-18 HXW 1 1/4S
WR01X1763 WR01X1763 SCR 8-18 T WAFER 5/8
WR01X10626 WR01X10626 SCR HXW 11/4
WR01X1762 WR01X1762 SCREW
WR1X1752 WR1X1752 SCREW
WR1X1591 WR1X1591 SCREW
WZ5X246 WZ5X246 SCREW
WD2X5166 WD2X5166 SCREW
WR1X1786 WR1X1786 SCREW
WR01X10606 WR01X10606 SCREW
WR01X1821 WR01X1821 SCREW 12-24 .7 BK
WR01X1822 WR01X1822 SCREW 12-24 .9 BK
WR01X10060 WR01X10060 SCREW 12-24TT BHT 700 SC
WR01X10062 WR01X10062 SCREW 12-24TT BHT 900
WR01X10063 WR01X10063 SCREW 12-24TT BHT 900(AD)
WR01X10061 WR01X10061 SCREW 12-24TT BHT 900(WHITE)
WR01X10123 WR01X10123 SCREW 6-19 HI/LO HXW 1/2 S
WD02X0323 WD02X0323 SCREW 8-32 X 3/8 SPH
WR1X1821 WR1X1821 SCREW BLACK
WZ06X0133 WZ06X0133 SCREW BRKT. EVAP. FAN
WR01X1816 WR01X1816 SCREW MOBILITY
WZ6X133 WZ6X133 SCREW&WASHER
WZ04X0244 WZ04X0244 SCREW-FRONT
WR1X1791D WR1X1791D SCREW-PKG - 13 PACK
WZ4X244D WZ4X244D SCREW-PKG 12
WZ5X158D WZ5X158D SCREW-PKG 12
WR1X1763D WR1X1763D SCREW-PKG 12
WR1X1726D WR1X1726D SCREW-PKG 12
WD2X323D WD2X323D SCREW-PKG 12
WR2X9298 WR2X9298 SHAFT/KNOB
WR02X9298 WR02X9298 SHAFT/KNOB DAMPER
WR71X1955 WR71X1955 SHELF ASSEMBLY FZ
WR32X10050 WR32X10050 SHELF CANT GLASS
WR32X1588 WR32X1588 SHELF CANT SP ASSEMBLY
WR32X10117 WR32X10117 SHELF ENCAP SLIDEOUT
WR71X10093 WR71X10093 SHELF FRONT FF
WR30X300 WR30X300 SHELF ICE TR
WR30X0300 WR30X0300 SHELF ICE TRAY
WR02X8692 WR02X8692 SHIM HINGE TOP FZ
WR02X8344 WR02X8344 SLEEVE VINYL
WR17X4011 WR17X4011 SLIDE ASSEMBLY VP CVR
WR17X10234 WR17X10234 SLIDE CONTROL VP
WR17X2768 WR17X2768 SLIDE COVER CENTER
WR72X0274 WR72X0274 SLIDE MEAT PAN LH WH
WR72X0273 WR72X0273 SLIDE MEAT PAN RH WH
WR72X274 WR72X274 SLIDE MP LH
WR72X273 WR72X273 SLIDE MP RH
WR17X2770 WR17X2770 SLIDE VEG PAN LH
WR17X2769 WR17X2769 SLIDE VEG PAN RH
WR02X9391 WR02X9391 SOCKET & TERMINAL ASM
WR2X9391 WR2X9391 SOCKET AND TERM
WR2X7018 WR2X7018 SPAC CT TRAC
WR02X7018 WR02X7018 SPACER TRACK
WR01X2080 WR01X2080 STOP SHELF
WR1X2080 WR1X2080 STOP SHELF
WR1X1779 WR1X1779 STUD MTGCOMP
WR02X10736 WR02X10736 SUP VP CVR
WR17X10317 WR17X10317 SUPPORT HIGH SIDE
WR02X8695 WR02X8695 SUPPORT TWIST VP CVR
WR2X7973 WR2X7973 SUPT SHELF
WR23X309 WR23X309 SW POWER SAVER
WR23X10725 WR23X10725 SWITCH LIGHT
WR23X0193 WR23X0193 SWITCH LIGHT WH
WR23X0309 WR23X0309 SWITCH POWER SAVER
WR50X10010 WR50X10010 THERMOSTAT DEFROST
WR02X10111 WR02X10111 THIMBLE DOOR PLASTIC
WR72X0097 WR72X0097 TRACK CENTER FF
WR72X97 WR72X97 TRACK SHELF
WR72X96 WR72X96 TRACK SHELF
WR72X0096 WR72X0096 TRACK SHELF FF R/L
WR30X0311 WR30X0311 TRAY ICE
WR38X10114 WR38X10114 TRIM BRIGHT
WR17X10233 WR17X10233 TRIM FRAME VP
WR17X2283 WR17X2283 TROUGH DRAIN
WR02X10134 WR02X10134 TUBE DRAIN ASSEMBLY
WR02X6087 WR02X6087 TUBE WATER FILL
WR30X311 WR30X311 UNIVERSAL ICE TRAY
WR01X27364 WR01X27364 WASHER HINGE BROWN
WR02X10480 WR02X10480 WHEEL MOBILITY
WR14X347 WR14X347 WR14X347
WR14X363 WR14X363 WR14X363
WR17X2773 WR17X2773 WR17X2773
WR2X8363 WR2X8363 WR2X8363
WR2X9009 WR2X9009 WR2X9009
WR87X10224 WR87X10224 WR87X10034
WZ4X416 WZ4X416 WZ04X0408
