Model Image
Manufacturer

GE

Model Number

FUF17DHRBWW

Description

Freezer

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WR12X23534 WR12X23534 1/2-INCH PIN HINGE BOTTOM R
WR71X24038 WR71X24038 13.23-INCH X 27.88-INCH SHELF
WR71X24032 WR71X24032 15.23-INCH X 27.88-INCH SHELF
WR02X23535 WR02X23535 24-INCH INSULATION DRAIN TU
WR23X24025 WR23X24025 3 LED CLUSTE LIGHT BOARD
WR23X24024 WR23X24024 3 LED CLUSTER LENS
WR01X23544 WR01X23544 8-18 X .500 SCREW
WR17X12658 WR17X12658 BAFFLE AIR
WR02X23518 WR02X23518 BEARING HINGE CLOSER
WR02X23506 WR02X23506 BEARING,HINGE ,BLACK ,TO
WR21X24035 WR21X24035 BOTTOM BASKET
WR40X23512 WR40X23512 BOTTOM BREAKER
WR02X9496 WR02X9496 BRACKET FAN MOTOR
WR02X12686 WR02X12686 BRACKET FAN MOTOR MOUNT
WR40X24041 WR40X24041 BREAKER
WR2X6361 WR2X6361 BUMPER
WR62X23515 WR62X23515 CAPACITOR-RUN
WR02X12032 WR02X12032 CLIP CONTROLLER
WR01X10916 WR01X10916 CLIP PANEL MTG
WR01X10870 WR01X10870 CLIP SPRING
WR01X10931 WR01X10931 CLIP WIRE
WR09X26887 WR09X26887 COMPRESSOR CONTROLLER
WR84X5007 WR84X5007 CONDENSER EXT
WR55X27038 WR55X27038 CONTROL BOARD ASSEMBLY
WR09X24017 WR09X24017 CONTROL,ELECTRONIC
WR17X12665 WR17X12665 COVER-EVAPORATOR
WR02X12689 WR02X12689 COVER-HINGE
WR51X24019 WR51X24019 DEFROST HEATER
WR87X23519 WR87X23519 DGK57C COMPRESSOR
WR02X23542 WR02X23542 DOOR BASE PLUG-BUTTON
WR02X23543 WR02X23543 DOOR CLOSER RAMP
WR23X24022 WR23X24022 DOOR HARNESS
WR17X24031 WR17X24031 DOOR RACK
WR02X23525 WR02X23525 DOOR STOP
WR17X23526 WR17X23526 DRAIN
WR86X10005 WR86X10005 DRIER-FILTER
WR09X25916 WR09X25916 ELECTRONIC CONTROL
WR85X10033 WR85X10033 EVAPORATOR ASSEMBLY
WR60X24020 WR60X24020 FAN BLADE
WR24X29508 WR24X29508 FREEZER DOOR GASKET WHITE
WR77X24037 WR77X24037 FRZR PANEL-INNER DOOR
WR14X10293 WR14X10293 GASKET-EVAP COVER
WR12X23532 WR12X23532 GE HANDLE METAL
WR02X11444 WR02X11444 GLIDE-BASKET
WR74X28766 WR74X28766 GRILLE/KICKPLATE
WR2X9007 WR2X9007 GROMMET
WR86X10052 WR86X10052 HEAT EXCHANGER SUCT/CAP
WR12X10891 WR12X10891 HINGE-UPPER
WR17X5367 WR17X5367 HOSE-DRAIN 17 50-INCH
WR12X23533 WR12X23533 INSTALL KIT H AND LE
WR02X13242 WR02X13242 INSULATOREVAP STYROFOA
WR01X26468 WR01X26468 KEY
WR02X24034 WR02X24034 LEVELING LEG
WR02X23509 WR02X23509 LH LEG LEVELOR BRACKET
WR05X10038 WR05X10038 LOCK ASSEMBLY
WR23X24023 WR23X24023 MAIN HARNESS
WR60X10293 WR60X10293 MOTOR FAN 115 V
WR04X23538 WR04X23538 NAMEPLATE
WR78X24036 WR78X24036 OUTER DOOR PANEL- WHITE
WR14X27037 WR14X27037 PAN DRAIN
WR01X35245 WR01X35245 PH TRUSS HEAD SCREW 8-1
WR01X10031 WR01X10031 PLUG-DRAIN
WR23X23523 WR23X23523 POWER CORD
WR02X23510 WR02X23510 RH LEG LEVELOR BRACKET
WR01X10958 WR01X10958 SCREW 8-18AB X.470 QX
WR01X10997 WR01X10997 SCREW BOTTOM HINGE
WR01X10999 WR01X10999 SCREW COMP. MTG
WR02X12989 WR02X12989 SCREW DOOR STOP MTG FH
WR01X10798 WR01X10798 SCREW HEX WASHER HEAD 8
WR01X11042 WR01X11042 SCREW HOURGLASS
WR01X10888 WR01X10888 SCREW HWH 10-24 X 0.50
WR02X13481 WR02X13481 SCREW PH TRUSS HEAD 8-1
WR02X12764 WR02X12764 SCREW RWHD 8-32A X 0.50
WR01X10915 WR01X10915 SCREW, #8, 18X.63, SELF
WR01X23545 WR01X23545 SCREW-#8-32 X 3/8
WR01X10922 WR01X10922 SCREW-SET
WR14X23528 WR14X23528 SECONDARY GASKET
WR02X11446 WR02X11446 STOP-BASKET
WR02X11458 WR02X11458 STRAP-EVAP/HEATER ALUMIN
WR02X13243 WR02X13243 STYROFOA INSULATOR-EVAP
WR02X12991 WR02X12991 SUPPORT EVAPORATOR MTG
WR23X10303 WR23X10303 SWITCH LIGHT
WR40X23513 WR40X23513 TOP BREAKER
WR01X23855 WR01X23855 TOUCH-UP PAINT WHITE
WR02X27082 WR02X27082 TRIM-CABINET CORNER WHI
WR86X10064 WR86X10064 VALVE BREATHER
WR40X24040 WR40X24040 W/LOCK BREAKER
WR01X23517 WR01X23517 WIRE CLIP
