Model Image
Manufacturer

GE

Model Number

GFMN100GL0WW

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
WE19M1437 WE19M1437 BACK HOUSING WHITE
WE14M75 WE14M75 BAFFLE
WE1M560 WE1M560 BAR GRAPH BUTTONS
WE25M40 WE25M40 BEARING KIT
WE1M300 WE1M300 BEARING RETAINER
WE1M1067 WE1M1067 BEARING SLIDE
WE1M504 WE1M504 BEARING-SLIDE WHITE
WE03X29897 WE03X29897 BELT DRIVE
WE09X27636 WE09X27636 BLOWER GASKET (EXHAUST)
WE16X20393 WE16X20393 BLOWER WHEEL
WE20M386 WE20M386 BOTTOM CHASSIS BASE
WE1M773 WE1M773 BRACKET & LEVEL LEG ASM
WE13X169 WE13X169 BRACKET COIL
WE13M48 WE13M48 BRACKET GAS VALVE
WE1M772 WE1M772 BRACKET LEVELLING LEG
WE14M104 WE14M104 BURNER ASM.
WE14M91 WE14M91 CHAMBER COMBUSTION 6
WE1X1091 WE1X1091 CLIP CORDSET
WE1M650 WE1M650 CONNECTOR MOTOR
WE26M341 WE26M341 CORD SET - GAS
WE20M327 WE20M327 COVER WH
WE11X29438 WE11X29438 DIFFUSER
WE11X29443 WE11X29443 DIFFUSER GAS
WE10M134 WE10M134 DOOR ASM- WH
WE9M19 WE9M19 DOOR GASKET
WE1M571 WE1M571 DOOR GUIDE
WE1M710 WE1M710 DOOR HINGE ASM - PLATED
WE1M579 WE1M579 DOOR HINGE COVER
WE1M893 WE1M893 DOOR OUTER RING WH
WE1M578 WE1M578 DOOR OUTER WINDOW
WE4M415 WE4M415 DOOR SWITCH
WE21X20566 WE21X20566 DRUM ASM
WE4X692 WE4X692 DUAL COIL
WE14M107 WE14M107 EXHAUST DUCT
WE1M587 WE1M587 EXHAUST PROTECTOR ASM
WE9M31 WE9M31 FELT CLEANING
WE09X27634 WE09X27634 FELT TRAP DUCT
WE18M24 WE18M24 FILTER ASM
WE4X448 WE4X448 FLAME DETECTOR
WE20M325 WE20M325 FRONT PANEL WHITE
WE1M564 WE1M564 FRONT SHEILD
WE14M114 WE14M114 GAS VALVE & PIPE ASM. NG
WE1M566 WE1M566 GASKET SEAL SIDE FRONT S
WE1M565 WE1M565 GASKET SEAL TOP FRONT SH
WE1M1015 WE1M1015 GROUND STRAP
WE5M47 WE5M47 HARNESS SENSORS
WE14M94 WE14M94 HOUSING BLOWER
WE03X20434 WE03X20434 IDLER ARM
WE04X25996 WE04X25996 IGNITER
WE4M398 WE4M398 INLET CONTROL THERMOSTAT
WE17X23463 WE17X23463 KIT AND MOTOR PULLEY
WE1M696 WE1M696 KNOB & FILM PROTECTOR
WE05X20431 WE05X20431 LAMP
WE1M1011 WE1M1011 LATCH DOOR
WE1X1076 WE1X1076 LEAK LIMITER
WE01X29357 WE01X29357 LEVELING LEG
WE19M1535 WE19M1535 LEXAN WINDOW SMALL
WE4X693 WE4X693 MAIN COIL
WE4M488 WE4M488 MAIN POWER BOARD ASM ELECT
WE4M489 WE4M489 MAIN POWER BOARD ASM GAS
WE1M864 WE1M864 MAIN POWER BOARD SUPPORT
WE13M41 WE13M41 MOTOR PLATE
WE1X921 WE1X921 MOTOR STRAP
WE13M39 WE13M39 MOTOR SUPPORT
WE2M213 WE2M213 NUT-STRIP DOOR GUIDE
WE1M461 WE1M461 O RING
WE1M561 WE1M561 OPTION BUTTONS
WE1X1148 WE1X1148 ORIFICE MAIN
WE20M301 WE20M301 PANEL REAR (6CU)
WE1X617 WE1X617 PIPE CLAMP
WR2X8693 WR2X8693 PLUG DR WHT
WE1M563 WE1M563 PLUS MINUS BUTTONS
WE1M557 WE1M557 POWER BUTTON
WE1M572 WE1M572 PRONGUED PLUG BUTTON
WE12X83 WE12X83 PULLEY IDLER
WE1M585 WE1M585 REAR PLATE
WE02X25454 WE02X25454 SCR 10-16 A TRQ2 1-1/4 S
WE1M584 WE1M584 SCR 10-16 B FLQ2 1-1/8 S
WR01X10317 WR01X10317 SCR 8-32 CA HXW 1/2
WE2M202 WE2M202 SCREW
WR2X9260 WR2X9260 SCREW
WE2M302 WE2M302 SCREW
WD2M101 WD2M101 SCREW
WE2M174 WE2M174 SCREW # 10
WE2M163 WE2M163 SCREW #10
WE2M196 WE2M196 SCREW #8
WE1M582 WE1M582 SCREW #8 X 5/8 SS DOOR H
WE1M583 WE1M583 SCREW #8-32 X 1/2 HINGE
WD02X10057 WD02X10057 SCREW 10-16X1/2 AB HXW S
WE2M210 WE2M210 SCREW BACK HOUSING
WE2M212 WE2M212 SCREW HINGE TO FRONT
WE2M225 WE2M225 SCREW WHITE #10-16 3/4
WE2X263D WE2X263D SCREW-PKG 12
WZ5X158D WZ5X158D SCREW-PKG 12
WE1M575 WE1M575 SENSOR RODS
WE20M382 WE20M382 SIDE PANEL WH
WE1M462 WE1M462 SLEEVE DRUM
WE5M62 WE5M62 SOCKET WITH HARNESS
WE1M894 WE1M894 START PAUSE BUTTON
WE13X200 WE13X200 STRAP MOTOR
WE1X1192 WE1X1192 STRIKE DOOR
WE1M569 WE1M569 STRIKE PLATE
WE1M570 WE1M570 STRIKE PLATE W/STRK HOLE
WD21X10261 WD21X10261 SWITCH INTERLOCK
WE4M300 WE4M300 T-STAT OUTLET BKUP ORG
WE04X20685 WE04X20685 THERMISTOR
WE4M137 WE4M137 THERMOSTAT HI-LIMIT
WE4M80 WE4M80 THERMOSTAT SAFETY
WE14M124 WE14M124 TOP BEARING ASM W/FELTS
WE11X29441 WE11X29441 TRANSITION DUCT
WE14M119 WE14M119 TRAP DUCT COMPLETE ASM
WE4M487 WE4M487 USER INTERFACE BOARD ASM
WE2M96 WE2M96 WE2X329
