Manufacturer
GE
Model Number
GSS25IENXHDS
Description
Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
"CLIP, COND MNT" |
|
|
10MM X 8MM LOKRING |
|
|
5MM X 4MM LOKRING |
|
|
6MM X 2MM LOKRING |
|
|
6MM X 4MM LOKRING |
|
|
7MM X 5MM LOKRING |
|
|
8.5MM X 6MM LOKRING |
|
|
8MM X 7MM LOKRING |
|
|
8MM X 8MM LOKRING |
|
|
AUGER MOTOR |
|
|
AUGER MOTOR HARNESS |
|
|
BAFFLE COND AIR |
|
|
BASKET WIRE FZ |
|
|
BASKET WIRE FZ |
|
|
BLACK SLATE FREEZER DOOR |
|
|
BLACK SLATE GRILL RECESS |
|
|
BLACK STAINLESS DOOR HANDLE |
|
|
BLADE CONF FAN ASM |
|
|
BOARD LED LIGHT ASM |
|
|
BOTTOM BRACKET EVAP |
|
|
BRACKET COND FAN (MTG) |
|
|
BRACKET COND FAN (REAR) |
|
|
BRACKET CONDENSER BAR |
|
|
BRACKET FZ TOWER LOWER |
|
|
BRACKET FZ TOWER UPPER |
|
|
BUCKET AND AUGER ASM |
|
|
BUMPER |
|
|
BYPASS FILTER PLUG |
|
|
CABLE CLAMP |
|
|
CAM CLOSURE FF BLACK |
|
|
CAM CLOSURE FZ BLACK |
|
|
CAP CORNER OC |
|
|
CAP DUST |
|
|
CAPACITOR 12 UF |
|
|
CHILLER SHELF |
|
|
CLIP |
|
|
CLIP RETAINER MEI |
|
|
COMPARTMENT DAIRY |
|
|
COMPRESSOR |
|
|
CONDENSER & BRACKET |
|
|
CONDENSER FAN & HOUSING |
|
|
CONDENSER FOAM STRIP |
|
|
COVER ACCESS ASM |
|
|
COVER ASM FF INLET |
|
|
COVER AUGER MOTOR |
|
|
COVER BOTTOM PAN |
|
|
COVER EVAPORATOR FRONT |
|
|
COVER FF INLET |
|
|
COVER GASKET FF ASM |
|
|
COVER INLET DISCHARGE |
|
|
COVER LED |
|
|
COVER MIDDLE PAN |
|
|
COVER MOTOR BACK |
|
|
COVER PAN GLASS |
|
|
COVER TOP PAN ASM |
|
|
COVER WATER LINE |
|
|
CRANK DOOR RECESS |
|
|
CRUSHER SOLENOID |
|
|
CUP FILL IM |
|
|
DEFROST HEATER |
|
|
DISPENSER ICE FUNNEL |
|
|
DISPENSER PADDLE BLACK SLATE |
|
|
DIVERTER FF AIRFLOW |
|
|
DOOR DAIRY CLEAR |
|
|
DOOR RECESS ASM |
|
|
DRIVE AUGER DISP |
|
|
DUCT ASM FF TRANSITION |
|
|
EVAPORATOR |
|
|
EVAPORATOR FAN BLADE |
|
|
EVAPORATOR FAN PLENUM |
|
|
FAN ORIFICE |
|
|
FASTENER DOOR HANDLE |
|
|
FOAM & ALUMINUM |
|
|
FREEZER DOOR STOP BLACK |
|
|
FRESH FOOD DOOR STOP BLACK |
|
|
FRESH FOOD FIXED SHELF |
|
|
GASKET |
|
|
GASKET |
|
|
GASKET EVAP COVER |
|
|
GASKET PAN CRV FRONT |
|
|
GASKET PAN CRV REAR |
|
|
GASKET PLENUM |
|
|
GASKET PLENUM |
|
|
GE BADGE |
|
|
GLIDE BUCKET LH DISP |
|
|
GLIDE BUCKET RH DISP |
|
|
GRILLE AIR RETURN |
|
|
GRILLE BASE |
|
|
GRILLE SENSOR |
|
|
GROMMET |
|
|
GROMMET |
|
|
GROMMET AND TUBE ASM |
|
|
GROMMET BASE GRILL |
|
|
GROMMET EVAP FAN |
|
|
GROMMET EVAP FAN |
|
|
HANDLE |
|
|
HARNESS BOARD INDIV |
|
|
HARNESS CAB LOWER |
|
|
HARNESS RECESS DISP |
|
|
HINGE BTM & PIN ASSEMBLY |
|
|
HINGE BTM BLACK |
|
|
HINGE TOP & PIN ASM |
|
|
HINGE TOP & PIN ASM |
|
|
HOUSING SHIELD DISP BLACK |
|
|
HUMIDITY CONTROL |
|
|
ICEMAKER |
|
|
INSERT PLENUM |
|
|
INSUL TUBE FOAM |
|
|
INSULATION TANK FOAM |
|
|
INTERFACE DISPENSER ASM BLACK SLATE |
|
|
LEVER ASSEMBLY FF SIDE BLACK |
|
|
LEVER ASSEMBLY FZ BLACK |
|
|
MAIN CONTROL BOARD |
|
|
MAIN CONTROL BOARD COVER |
|
|
MOBILITY FRONT ASM |
|
|
MOBILITY WHEEL KIT |
|
|
MOTOR DC COND FAN |
|
|
MOTOR DC EVAP FAN ASM |
|
|
ORIFICE & FAN MOTOR |
|
|
OVERLOAD PTCR COMBO |
|
|
PAN BOTTOM ASM |
|
|
PAN MIDDLE ASM |
|
|
PAN TOP ASM |
|
|
PCB NEXTGEN RFID |
|
|
PIN HINGE BTM ADJ HOLLOW |
|
|
PIN SPIRAL |
|
|
PIN SPIRAL |
|
|
PLENUM EXTENSION FZ |
|
|
PM MINI MANUAL AND WIRING |
|
|
PM QUICK OWNERS MANUAL |
|
|
R600 DRIER W/ RED CAP |
|
|
R600A CHARGE CAN 20 GRAMS |
|
|
R600A CHARGE CAN 35 GRAMS |
|
|
REFRIGERATOR - FRESH FOOD DOOR BLACK SLA |
|
|
REFRIGERATOR DOOR LIGHT SWITCH |
|
|
RETAINER RECESS DOOR |
|
|
RFID COVER & FCC LABEL |
|
|
RING COMPRESSION |
|
|
SCR 1/4-14 AB IHW 3/4 S |
|
|
SCR 10-16 |
|
|
SCR 10-16 |
|
|
SCR 10-18 HI/LO HXW 1/2 |
|
|
SCR 10-32 B IHXW 1/2 |
|
|
SCR 10-32 TR 1/2 |
|
|
SCR 10-32 TT HXW 5/16 S |
|
|
SCR 12-24 TT OVT 1.000 S |
|
|
SCR 4-10 PL PNP 3/4 SS |
|
|
SCR 8-10 PL PNP 1/2 S |
|
|
SCR 8-18 AB IHW 5/8 S |
|
|
SCR 8-18 AB IHXW 9/16 S |
|
|
SCR 8-18 AB PNP 5/8 S |
|
|
SCR 8-18 DG TRT20 5/8 S |
|
|
SCR 8-32 T HXW 3/8 S |
|
|
SCR 8-32 T HXW 3/8 S |
|
|
SCR8-18 AB UFL 1 1/2 SS |
|
|
SCREW 10-32 GXTT FLP 595 |
|
|
SCREW MOBILITY |
|
|
SEPARATOR AIR HISIDE |
|
|
SET SCREW |
|
|
SHELF DOOR FZ BOTTOM |
|
|
SHELF DOOR FZ UPPER |
|
|
SHELF MODULE FF |
|
|
SHIELD ASSEMBLY TROUGH |
|
|
SHROUD CONDENSER |
|
|
SHUNT SENSOR |
|
|
SLIDE MIDDLE PAN COVER |
|
|
SLIDEOUT SHELF |
|
|
SOLENOID ASM |
|
|
SOUND DAMPER |
|
|
SOUND DAMPER |
|
|
SPRING CLOSURE |
|
|
SPRING RECESS DOOR |
|
|
SPRING SOLENOID LINKAGE |
|
|
SPRING TORSION |
|
|
STAND OFF |
|
|
STRIPPER IM |
|
|
STUD MTG COMPR |
|
|
SUPPORT SHELF |
|
|
SWITCH |
|
|
SWITCH LIGHT FZ |
|
|
SXS FREEZER SHELF |
|
|
SXS TOP FREEZER SHELF |
|
|
TEMPERATUR SENSOR FF |
|
|
THIMBLE DOOR |
|
|
THIMBLE DOOR |
|
|
THIMBLE DOOR BTM FZ BLAC |
|
|
TOWER AIR FZ LOWER |
|
|
TRIM DAIRY COMPARTMENT |
|
|
TUBE DRAIN |
|
|
TUBE LEAD |
|
|
TUBE PLASTIC |
|
|
TUBE PLASTIC |
|
|
UNION CONNECTOR |
|
|
VALVE ISOLATION ASM |
|
|
WATER TANK DISP ASM |
|
|
WATER VALVE DIODE HARNESS JUMPER KIT |
|
|
WHEEL MOBILITY |
|
|
WHEEL PAN COVER |
|
|
XWF MANIFOLD & TUBING |
|
|
XWFE FILTER COVER |
|
|
XWFE RETAIL FILTER |
