Manufacturer
GE
Model Number
GTW490ACJ2WW
Description
4.4 Cu. Ft. Capacity Washer Gtw490acjww
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BACKSPLASH ASM |
|
|
BACKSPLASH FOAM SEAL |
|
|
BADGE GE |
|
|
BALL JOINT UPPER |
|
|
BASKET ASM |
|
|
BELLEVILLE WASHER |
|
|
BELT GUARD |
|
|
BLEACH CUP 2-INCH |
|
|
BRACKET PCB |
|
|
BUMPER LID |
|
|
BUTTON TREE |
|
|
CAPACITOR |
|
|
CLAMP |
|
|
CLIP ANT-SIP |
|
|
CLIP SPRING COVER |
|
|
CLUTCH |
|
|
CONTROL BOARD SHIELD |
|
|
CONTROL REAR PANEL |
|
|
DRAIN PUMP ASSEMBLY |
|
|
DRAIN PUMP SEAL |
|
|
DRIVE BELT |
|
|
DUAL HARNESS CONNECTOR BRACKET |
|
|
GREASE |
|
|
GROMMET SCR CLOSED |
|
|
HARNESS 2 VALVE |
|
|
HARNESS MAIN GREEN |
|
|
HARNESS WIRE TIE |
|
|
HINGE LID SCR 6-32 MCH FLP .285 SS |
|
|
HOSE DRAIN |
|
|
HOSE PRESSURE |
|
|
IMPELLER ASM |
|
|
IMPELLER CAP |
|
|
INNER DRAIN HOSE MOUNTING BRACKET |
|
|
INTERNAL DRAIN HOSE ASM |
|
|
KNOB MAIN ASM |
|
|
KNOB OPTIONS ASM |
|
|
LARGE LID BUSHING LEFT |
|
|
LARGE LID BUSHING RIGHT |
|
|
LARGE LID WHITE |
|
|
LEFT BACKSPLASH SUPPORT |
|
|
LEVELING LEG |
|
|
LID LOCK |
|
|
LID LOCK BEZEL |
|
|
LID LOCK HARNESS |
|
|
LID LOCK HARNESS CLIP |
|
|
MODE SHIFTER ASM |
|
|
MOTOR 1/2 HP |
|
|
MOTOR PULLEY |
|
|
NUT HUB |
|
|
NUT PULLEY |
|
|
OUTER CABINET BUMPER PAD |
|
|
PCBA 2015 LE TRIAC |
|
|
PCBA 2015 LE TRIAC |
|
|
PK HOSE INLET BAG ASM |
|
|
PLATFORM BEARING RETAINER & FA |
|
|
PLATFORM MOTOR SHIELD |
|
|
PM MANUAL USE AND CARE |
|
|
PM MINI MANUAL AND WIRING |
|
|
PM SHEET MINI MANUAL |
|
|
POWER CORD |
|
|
PULLEY TRANSMISSION |
|
|
PUSH MOUNT CABLE TIE |
|
|
PUSH MOUNT CABLE TIE |
|
|
RIGHT BACKSPLASH SUPPORT |
|
|
ROD AND SPRING ASM LEFT - BLACK |
|
|
ROD AND SPRING ASM RIGHT - WHITE |
|
|
SCR 1/4-20 TT HXT .485 S |
|
|
SCR 1/4-20, 2A SINULOC |
|
|
SCR 10-16 B HXW 3/8 S |
|
|
SCR 10-32 C HX 7/16 S |
|
|
SCR 10-32 GX 1.309 HWX S |
|
|
SCR 5/16-24 MCH HX 1 SINULOC |
|
|
SCR 8-16 PLASTITE HXW 5/8 |
|
|
SCR 8-18 AB 13/4 S HXW |
|
|
SCR 8-18 BS TRP 3/8 S |
|
|
SCREEN WASHER |
|
|
SCREW 10-32 GXTT FLP 595 S |
|
|
SCREW 8-18 B 1HW 1/2 SN |
|
|
SCREW 8-18 HI/LO 5/8 |
|
|
SCREW PLATFORM |
|
|
SELECTOR SWITCH ASM (4) |
|
|
SENSOR SPEED |
|
|
SPRING CLUTCH |
|
|
THERMISTOR ASSEMBLY |
|
|
THERMISTOR CLIP |
|
|
TOP COVER WHITE |
|
|
TRANSMISSION PULLEY |
|
|
TUB ASM |
|
|
TUB COVER |
|
|
VALVE INLET ASM |
|
|
WASHER FLAT |
|
|
WASHER HUB |
|
|
WASHER SPRING |
|
|
WATER INLET GASKET |
|
|
WIREFORM HINGE LID LEFT |
|
|
WIREFORM HINGE LID RIGHT |
