Manufacturer
GE
Model Number
GWE19JGLWFWW
Description
Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
10.5MM X 8MM LOKRING |
|
|
5MM X 4MM LOKRING |
|
|
6MM X 2MM LOKRING |
|
|
6MM X 4MM LOKRING |
|
|
7MM X 5MM LOKRING |
|
|
8.5MM X 6MM LOKRING |
|
|
8MM X 7MM LOKRING |
|
|
8MM X 8MM LOKRING |
|
|
ACCESS COVER |
|
|
ARTICULATING MULLION ASM |
|
|
BLADE CONF FAN ASM |
|
|
BOARD LED LIGHT ASM |
|
|
BRACKET COND FAN (MTG) |
|
|
BRACKET COND FAN (REAR) |
|
|
BYPASS FILTER PLUG |
|
|
CAM CLOSURE WW |
|
|
CAPACITOR 12 UF |
|
|
CLIP COMPRESSOR MOUNT |
|
|
CLIP RETAINER MEI |
|
|
COMPRESSOR MEIZHI |
|
|
CONDENSER 10 PASS |
|
|
CONDENSER FAN & HOUSING |
|
|
CONNECTOR COVER |
|
|
COVER HINGE TOP LH WW |
|
|
COVER HINGE TOP RH WW |
|
|
COVER WATER LINE |
|
|
CUP FILL IM |
|
|
DAMPER ASM |
|
|
DEFROST HEATER & HARNESS |
|
|
DISPENSER INTERNAL ASM |
|
|
DOOR FOAM FF ASM LH WW |
|
|
DOOR FOAM FF ASM RH WW |
|
|
DOOR FOAM FZ ASM WW |
|
|
DUCT AIR TOWER FF ASM |
|
|
EVAP COVER & FAN |
|
|
EVAPORATOR |
|
|
EVAPORATOR COVER & FAN |
|
|
EVAPORATOR FAN BLADE |
|
|
FASTENER |
|
|
FOAM STRIP SE ADH |
|
|
FREEZER DOOR BRACKET LEFT |
|
|
FREEZER DOOR BRACKET RIGHT |
|
|
FREEZER DRAWER GASKET - WHITE |
|
|
FREEZER DRAWER RAIL HOLDER LEFT |
|
|
FREEZER DRAWER RAIL HOLDER RIGHT |
|
|
FREEZER ICE BUCKET |
|
|
FREEZER LOWER BASKET |
|
|
FREEZER UPPER BASKET |
|
|
FRESH FOOD AIR TOWER GRILL |
|
|
FRESH FOOD DOOR LIGHT SWITCH PAIR |
|
|
FULL-WIDTH DRAWER COVER WITH GLASS |
|
|
GASKET TOWER FF |
|
|
GEA BADGE FLAT CHROME |
|
|
GROMMET |
|
|
GROMMET AND TUBE IM ASM |
|
|
GROMMET EVAP FAN |
|
|
HARNESS BOARD INDIV |
|
|
HARNESS INTERFACE |
|
|
HARNESS SWITCH |
|
|
HINGE BUSHING BB |
|
|
HINGE BUSHING BB |
|
|
HINGE BUSHING BB |
|
|
HINGE CENTER |
|
|
HINGE TOP ASM LH WW |
|
|
HINGE TOP ASM RH WW |
|
|
ICEMAKER |
|
|
INTERFACE TOP ASM WHITE |
|
|
LED BOARD |
|
|
LIGHT SWITCH |
|
|
LOWER BASKET DIVIDER |
|
|
LOWER BASKET SLIDE |
|
|
LOWER DOOR BIN RH |
|
|
MAIN CONTROL BOARD |
|
|
MAIN CONTROL BOARD COVER |
|
|
MEAT PAN |
|
|
MEAT PAN DIVIDER |
|
|
MOBILITY BACK ASM |
|
|
MOTOR DC COND FAN |
|
|
MOTOR DC EVAP FAN |
|
|
OVERLOAD PTCR COMBO |
|
|
PCB NEXTGEN RFID |
|
|
PM MINI MANUAL AND WIRING |
|
|
PM QUICK OWNERS MANUAL |
|
|
POWER CORD |
|
|
QUICK SPACE SHELF |
|
|
R600 DRIER W/ RED CAP |
|
|
R600A CHARGE CAN 20 GRAMS |
|
|
R600A CHARGE CAN 35 GRAMS |
|
|
REFRIGERATOR DOOR GASKET - WHITE |
|
|
RFID COVER & FCC LABEL |
|
|
RING COMPRESSION |
|
|
SCR 1/4-20 RT FLAT 3/4 S |
|
|
SCR 10-14 PL FLT20 3/4 S |
|
|
SCR 10-16 B HXW 1/4 S |
|
|
SCR 10-32 TR 1/2 |
|
|
SCR 10-32 TT HXW 5/16 S |
|
|
SCR 12-24 HXT20 .90 S |
|
|
SCR 8-18 AB HXW 5/4 S |
|
|
SCR 8-18 AB IHW 5/8 S |
|
|
SCR 8-18 CA HX 1/2 S |
|
|
SCREW 10-32 GXTT FLP 595 |
|
|
SCREW 8-18 HI/LO 5/8 |
|
|
SCREW HINGE COVER |
|
|
SCREW LEVELING |
|
|
SHELF DOOR MODULE RH |
|
|
SHELF LEFT |
|
|
SHELF RIGHT |
|
|
SHIELD LIGHT |
|
|
SOUND DAMPER |
|
|
SPRING CLUSRE |
|
|
STAND OFF |
|
|
STEEL PIN HINGE |
|
|
STOP DOOR |
|
|
STRIKER TOP MULLION |
|
|
STUD MTG COMPR |
|
|
SUPPORT IM |
|
|
SUPPORT SHELF |
|
|
SWITCH ACTUATOR |
|
|
TANK COLD WATER |
|
|
TEMPERATUR SENSOR FF |
|
|
THERMOSTAT DEF |
|
|
TOP BUMPER DOOR WW |
|
|
TOP LED COVER |
|
|
TRACK CENTER ASM |
|
|
TROUGH DRAIN ASM |
|
|
TUBE DRAIN |
|
|
TUBE LEAD |
|
|
UPPER BASKET SLIDE LEFT |
|
|
UPPER BASKET SLIDE RIGHT |
|
|
VALVE ISOLATION ASM |
|
|
VEGETABLE DRAWER |
|
|
VEGETABLE DRAWER COVER WITH GLASS |
|
|
WHITE DOOR HANDLE |
|
|
WHITE FREEZER DOOR HANDLE |
|
|
XWFE FILTER COVER |
|
|
XWFE MANIFOLD & HOUSING |
|
|
XWFE RETAIL FILTER |
