Model Image
Manufacturer

GE

Model Number

JB655DKCWW

Description

Electric Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB30X24111 WB30X24111 GE "ELEMENT RADIANT 9"" DUAL"
WB34X28565 WB34X28565 GE BACKGUARD SHIELD HEAT
WB44X45494 WB44X45494 GE BAKE ELEMENT
WB34X31766 WB34X31766 GE BLACK CONVECTION FAN COVER
WB17X38438 WB17X38438 GE BLOCK TERMINAL ASM
WB07X42948 WB07X42948 GE BOTTOM TRIM CHANEL WHITE
WB02T10578 WB02T10578 GE BRACKET ANTI-TIP ASM
WB34X42027 WB34X42027 GE BRACKET DOOR TRIM RH
WB02X20940 WB02X20940 GE BRACKET RADIANT ELEMENT
WB02X20902 WB02X20902 GE BRACKET RADIANT ELEMENT
WB25X24023 WB25X24023 GE CAMERA LENS
WB02X25982 WB02X25982 GE CLIP CABLE
WB02T10118 WB02T10118 GE CLIP SEAM OVEN BODY
WB01X0119 WB01X0119 GE CONTOURED WASHER
WB27X45467 WB27X45467 GE CONTROL OVEN TO9
WB34X29564 WB34X29564 GE CONTROL PANEL BACK COVER
WB34X31189 WB34X31189 GE CONTROL PANEL BRACKET
WB07X31197 WB07X31197 GE CONTROL PANEL TRIM AND BRACKETS ASM WH
WB26X29574 WB26X29574 GE CONVECTION MOTOR
WB02X29181 WB02X29181 GE CONVECTION MOTOR BRACKET
WB02K5365 WB02K5365 GE COVER
WB07X42968 WB07X42968 GE DOOR GAP FILLER
WB34X42670 WB34X42670 GE DOOR HANDLE BRACKET LH
WB14T10093 WB14T10093 GE DOOR LATCH AND HANDLE ASM
WB07X7175 WB07X7175 GE DOOR LATCH TRIM
WB01T10026 WB01T10026 GE DOOR PAD
WB63X29070 WB63X29070 GE DRAWER BODY ASM
WB56X43435 WB56X43435 GE DRAWER PANEL-WHITE
WB48T10013 WB48T10013 GE DRAWER SUPPORT FRT
WB02X29072 WB02X29072 GE DRAWER WEDGE
WB30T10130 WB30T10130 GE ELEMENT HALIANT 12 IN
WB30T10145 WB30T10145 GE ELEMENT RADIANT 5.5 IN
WB07X27829 WB07X27829 GE END PLATE LT WH
WB07X27825 WB07X27825 GE END PLATE RT WH
WB07X46128 WB07X46128 GE FACEPLATE GRAPHICS WHITE
WB56T10290 WB56T10290 GE FRAME DOOR SIDE (WH)
WB04T10080 WB04T10080 GE GASKET CONV FAN
WB04T10086 WB04T10086 GE GASKET OVEN
WB64X0093 WB64X0093 GE GLASS CLEANER
WB56X26641 WB56X26641 GE GLASS OVN DR OTR (WH)
WB25X42688 WB25X42688 GE HALOGEN LAMP ASSEMBLY
WB15X42629 WB15X42629 GE HANDLE & ENDCAP ASM (WH)
WB10T10070 WB10T10070 GE HINGE DOOR
WB10X29566 WB10X29566 GE HINGE RECEIVER
WB02X26501 WB02X26501 GE HUB BLADE ASM
WB24T10022 WB24T10022 GE INF SWITCH CONTROL 1250W
31-10617 31-10617 GE INSTRUCTION INSTALL
WB35X39987 WB35X39987 GE INSULATION DOOR
WB35X38806 WB35X38806 GE INSULATION DOOR
WB35T10077 WB35T10077 GE INSULATION DOOR
WB35T10114 WB35T10114 GE INSULATION DOOR
WB35T10255 WB35T10255 GE INSULATION DOOR
WB35X38807 WB35X38807 GE INSULATION DOOR - SIDE
WB03X24952 WB03X24952 GE KNOB INFINITE (WH)
229C6522P002 229C6522P002 GE LABEL WIRE DIAGRAM
WB25T10102 WB25T10102 GE LAMP HALOGEN BULB G9
WB18X30705 WB18X30705 GE LEAD WIRE 14 GA GN
WB02X10521 WB02X10521 GE LEG LEVELER
WB27T10668 WB27T10668 GE LIGHT INDICATOR
WB25X20005 WB25X20005 GE LIGHT INDICATOR PILOT
WB55T10203 WB55T10203 GE LINER OVEN DOOR ASM (BK)
WB34X32059 WB34X32059 GE MAIN BACK COVER
WB18X42868 WB18X42868 GE MAINTOP HARNESS
WB02T10026 WB02T10026 GE MAINTOP STRIKE
WB02X35585 WB02X35585 GE NUT HEX
WB35X29571 WB35X29571 GE OVEN BACK INSULATION
WB35X29568 WB35X29568 GE OVEN BOTTOM INSULATION
WB24T10043 WB24T10043 GE OVEN ROCKER SWITCH
31-10781 31-10781 GE PM INSTALL INSTRUCTIONS
31-17231 31-17231 GE PM MANUAL MINI & WD ASM
49-2001000 49-2001000 GE PM OWNERS MANUAL
WB48T10063 WB48T10063 GE RACK OVEN
WB34X30165 WB34X30165 GE RANGETOP ENCLOSURE
WB62X25977 WB62X25977 GE RANGETOP GLASS ASM (WH)
WB02X33180 WB02X33180 GE REAR SUPPORT
WB56T10178 WB56T10178 GE RETAINER OVN DR INSLN
WB01T10103 WB01T10103 GE SCR 10-16 AB HXW .532
WB02X24268 WB02X24268 GE SCR 10-32 CA TRT15 3.06
WH02X0941 WH02X0941 GE SCR 8-15 A HXW 7/8 S
WB1X5904 WB1X5904 GE SCR 8-18 BA
WB01X5904 WB01X5904 GE SCR 8-18 BA POR 3/4 SN
WR01X10602 WR01X10602 GE SCR 8-32 AB IHWS 3/8 S
WB01X23501 WB01X23501 GE SCR 8-32 TT FLP .270
WB01K5200 WB01K5200 GE SCREW
WH2X930 WH2X930 GE SCREW
WB01M10002 WB01M10002 GE SCREW
WB1K5157 WB1K5157 GE SCREW
WB01T10008 WB01T10008 GE SCREW 10-32 TR T
WB01K0058 WB01K0058 GE SCREW 8-18 (WH) 1/2 S
WB01T10017 WB01T10017 GE SCREW 8-18 AB IHW 3/8 S
WB01K5150 WB01K5150 GE SCREW ST10-16 X 7/16""
WB21X22134 WB21X22134 GE SENSOR ASM
WB02T10034 WB02T10034 GE SIDE PANEL SUPPORT
WB56X28884 WB56X28884 GE SIDE PANEL WH
WB02X38986 WB02X38986 GE SPACER
WB09X40389 WB09X40389 GE SPRING RADIANT ELEMENT
WB24X25013 WB24X25013 GE SWITCH INFINITE CONTROL
WB24X40051 WB24X40051 GE SWITCH ROTARY
WB24T10147 WB24T10147 GE SWITCH SPDT HIGH AMP
WB34X29565 WB34X29565 GE TERMINAL BLOCK MOUNT
WB07X27236 WB07X27236 GE TRIM VENT DOOR (WH)
WB44X45498 WB44X45498 GE UNIT BROIL ASM
WB38X33648 WB38X33648 GE VENT TUBE
WB34X29573 WB34X29573 GE VENT TUBE
WB35T10017 WB35T10017 GE VENT TUBE INSULATION
WB30X42872 WB30X42872 GE WARMING ELEMENT 80W
WB56X22160 WB56X22160 GE WINDOW PACK ASM
WB34X29563 WB34X29563 GE WIRE COVER BACK
