Model Image
Manufacturer

GE

Model Number

JB680DP1BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
PM10X310 PM10X310 28 CERAMA BR
WB1K5200 WB1K5200 340531
WB08T10023 WB08T10023 35W RANGE HALOGEN BULB
WB63T10147 WB63T10147 BACK MAIN
WB63X28540 WB63X28540 BASE RIVET ASM
WB63X25881 WB63X25881 BASE RIVET ASM
WB63T10145 WB63T10145 BODY OVEN WELD ASM
WB02T10463 WB02T10463 BRACE CHASSIS RADIANT RT
WB02T10415 WB02T10415 BRACKET ANTI-TIP ASM
WB02T10194 WB02T10194 BRACKET CAPACITOR
WB02T10471 WB02T10471 BRACKET CONV FAN
WB01X27696 WB01X27696 BRACKET OVN HDL VNT TRM
WB01X27695 WB01X27695 BRACKET OVN HDL VNT TRM
WB34X42027 WB34X42027 BRACKET OVN HDL VNT TRM
WB34X42670 WB34X42670 BRACKET OVN HDL VNT TRM
WB02T10464 WB02T10464 BRACKET RADIANT ELEMENT
WB02T10486 WB02T10486 BRACKET RADIANT ELEMENT
WB27T10662 WB27T10662 CAPACITOR MOTOR
WB02X45146 WB02X45146 CLIP CABLE
WB01X0119 WB01X0119 CONTOURED WASHER
WB27X45466 WB27X45466 CONTROL OVEN TO9 (ELEC)
WB24T10145 WB24T10145 CONTROL SURF ELEM
WB02K5365 WB02K5365 COVER
WB2K5365 WB2K5365 COVER
WB02T10532 WB02T10532 COVER CONTROL
WB26T10058 WB26T10058 COVER FAN CONV
WB34T10011 WB34T10011 COVER RECEPTACLE
WB01T10026 WB01T10026 DOOR PAD
WB55T10178 WB55T10178 DRAWER BODY ASM MECH
WB48T10013 WB48T10013 DRAWER SUPPORT FRT
WB30T10146 WB30T10146 ELEMENT HALIANT 12 IN
WB30T10131 WB30T10131 ELEMENT HALIANT 8 IN
WB30T10129 WB30T10129 ELEMENT RADIANT 6 IN
WB30T10124 WB30T10124 ELEMENT RADIANT 6 WARMER
WB34T10023 WB34T10023 ENCLOSURE RANGETOP
WB27T11179 WB27T11179 FACEPLATE GRAPHICBK/SS
WB27T11180 WB27T11180 FACEPLATE GRAPHICS (WH)
WB56T10287 WB56T10287 FRAME DOOR SIDE (BK)
WB56T10290 WB56T10290 FRAME DOOR SIDE (WH)
WB63T10096 WB63T10096 FRAME FRONT
WB64X0093 WB64X0093 GLASS CLEANER
WB56T10179 WB56T10179 GLASS OVN DR (BK)
WB56T10187 WB56T10187 GLASS OVN DR (WH)
WB02T10275 WB02T10275 GUARD INSLN SDE
WB25T10075 WB25T10075 HALOGEN LAMP ASM LWR
WB15T10176 WB15T10176 HANDLE (WH)
WB15T10161 WB15T10161 HANDLE - BLACK
WB35T10022 WB35T10022 HIDDEN BAKE INSULATION
WB10T10071 WB10T10071 HINGE DOOR
WB10T10068 WB10T10068 HINGE RECEIVER
WB02T10289 WB02T10289 HUB BLADE ASM
WB24T10168 WB24T10168 INFINITE SWITCH
31-10677 31-10677 INSTRUCTION INSTALL
31-10617 31-10617 INSTRUCTION INSTALL
WB35T10210 WB35T10210 INSULATION CONV
WB35T10077 WB35T10077 INSULATION DOOR
WB35T10114 WB35T10114 INSULATION DOOR
WB35T10209 WB35T10209 INSULATION OVN WRPR
WB03X26320 WB03X26320 KNOB INFINITE (BK)
WB03T10282 WB03T10282 KNOB INFINITE (WH)
WB14T10053 WB14T10053 LATCH & HANDLE ASM
WB14T10040 WB14T10040 LATCH AND HANDLE ASM
WB02X10521 WB02X10521 LEG LEVELER
WB25T10041 WB25T10041 LENS
WB27T10626 WB27T10626 LIGHT INDICATOR PILOT
WB55T10176 WB55T10176 LINER OVEN DOOR ASM
WB02T10026 WB02T10026 MAINTOP STRIKE
31-14842 31-14842 MANUAL MINI & WD ASM
49-80591 49-80591 MANUAL USE & CARE
WB26T10037 WB26T10037 MOTOR PSC CONV
WB17T10021 WB17T10021 MOUNT TERMINAL BLOCK
WB34T10128 WB34T10128 MULTIPLE SUPERCEDURES
WB02T10017 WB02T10017 NUT
WB25T10013 WB25T10013 OV LAMP LENS
WB35T10023 WB35T10023 OVEN BACK INSULATION
WB04T10086 WB04T10086 OVEN DOOR GASKET
WB48T10063 WB48T10063 OVEN RACK
WB24T10043 WB24T10043 OVEN ROCKER SWITCH
WB56T10105 WB56T10105 PACK WINDOW ASM
WB56X22160 WB56X22160 PACK WINDOW ASSEMBLY
WB56T10267 WB56T10267 PANEL DRAWER
WB56T10268 WB56T10268 PANEL DRAWER
WB56X28881 WB56X28881 PANEL SIDE (BK)
WB56X28884 WB56X28884 PANEL SIDE (WH)
WB10T10116 WB10T10116 PIN RANGETOP HINGE
WB36T11040 WB36T11040 PLATE END LT (BK)
WB36T11043 WB36T11043 PLATE END LT (WH)
WB36T11039 WB36T11039 PLATE END RT (BK)
WB36T11042 WB36T11042 PLATE END RT (WH)
WB34X26004 WB34X26004 RANGE RADIANT LEFT CHASSIS BRACE
WB62T10721 WB62T10721 RANGETOP GLASS ASM
WB62T10720 WB62T10720 RANGETOP GLASS ASM
WB02T10509 WB02T10509 REFECTOR PAN FOR BAKE ELEMENT
WB56T10178 WB56T10178 RETAINER OVN DR INSLN
WB24T10042 WB24T10042 ROCKER SWITCH OVEN
WB01T10103 WB01T10103 SCR 10-16 AB HXW .532
WB01T10072 WB01T10072 SCR 10-16 AB IHW .625 NI
WB01T10067 WB01T10067 SCR 10-16 PL PNT 2.5 S
WB02T10324 WB02T10324 SCR 6-20 GXB IHXW 3/8 NI
WH02X0941 WH02X0941 SCR 8-15 A HXW 7/8 S
WH02X1186 WH02X1186 SCR 8-18 AB IHW 5/8 S
WB1X5904 WB1X5904 SCR 8-18 BA
WB01X5904 WB01X5904 SCR 8-18 BA POR 3/4 SN
WB01K5156 WB01K5156 SCREW
WB01X1137 WB01X1137 SCREW
WB01M0001 WB01M0001 SCREW
WB01K5028 WB01K5028 SCREW
WZ04X0044 WZ04X0044 SCREW
WB01K5200 WB01K5200 SCREW
WD2X432 WD2X432 SCREW
WB1K5156 WB1K5156 SCREW
WH2X1186 WH2X1186 SCREW
WB1M1 WB1M1 SCREW
WB1X536 WB1X536 SCREW
WH2X930 WH2X930 SCREW
WB01X5364 WB01X5364 SCREW (CR)
WB01T10058 WB01T10058 SCREW 10-16 AB HXW 750 S N
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10016 WB01T10016 SCREW 8-18 AB HXW 5/8 S
WB01T10017 WB01T10017 SCREW 8-18 AB IHW 3/8 S NS
WD02X0432 WD02X0432 SCREW 8-18 X 5/16 BK
WB01X23501 WB01X23501 SCREW 8-32 TPT FLR 215 SN
WB01T10047 WB01T10047 SCREW 8-32 X 625 M HXW S
WB1X5364 WB1X5364 SCREW MTG
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB01X1425 WB01X1425 SCREW ST8ABX.250RD NI
WB1X1137 WB1X1137 SCREW-10AB
WH2X941D WH2X941D SCREW-PKG 12
WZ4X245D WZ4X245D SCREW-PKG 12
WZ4X44D WZ4X44D SCREW-PKG 12
WB1X1425 WB1X1425 SCW 8ABX.250
WB21X22134 WB21X22134 SENSOR ASSEMBLY
WB02T10391 WB02T10391 SHIELD HEAT BKGD
WB02T10034 WB02T10034 SIDE PANEL SUPPORT
WB49T10007 WB49T10007 SIDE REFLECTOR
WB02T10175 WB02T10175 SPACER
WB09X40389 WB09X40389 SPRING RADIANT ELEMENT
WB02X33180 WB02X33180 SUPPORT REAR
WB24T10058 WB24T10058 SWITCH INFINITE CONTROL
WB24T10165 WB24T10165 SWITCH ROCKER ELEM (BK)
WB24T10167 WB24T10167 SWITCH ROCKER ELEM (WH)
WB24T10147 WB24T10147 SWITCH SPDT HIGH AMP
WB17T10011 WB17T10011 TERMINAL BLOCK ASSEMBLY
WB36T11227 WB36T11227 TRIM & BRACKET ASM
WB36T11228 WB36T11228 TRIM & BRACKET ASM
WB07X32930 WB07X32930 TRIM DR BTM CHNL
WB07X42948 WB07X42948 TRIM DR BTM CHNL
WB07X42966 WB07X42966 TRIM DR BTM CHNL
WB07T10516 WB07T10516 TRIM FRT FRM (BK)
WB7X7175 WB7X7175 TRIM LATCH
WB07X7175 WB07X7175 TRIM LATCH
WB07X27233 WB07X27233 TRIM VENT DOOR
WB07X27236 WB07X27236 TRIM VENT DOOR
WB28T10217 WB28T10217 TUBE VNT RADIANT
WB44T10104 WB44T10104 UNIT ASM
WB44T10094 WB44T10094 UNIT BROIL ASM
WB38X33648 WB38X33648 VENT TUBE
WB38T10012 WB38T10012 VENT TUBE ASSEMBLY
WB35T10017 WB35T10017 VENT TUBE INSULATION
WB01T10112 WB01T10112 WASHER ALUM SHAPED
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
WB48T10068 WB48T10068 WEDGE DRAWER
