Model Image
Manufacturer

GE

Model Number

JBP65WC4WW

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
PM10X310 PM10X310 28 CERAMA BR
WB1K5200 WB1K5200 340531
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB02T10415 WB02T10415 ANTI-TIP BRACKET
WB2X7694 WB2X7694 BAIL
WB39T10001 WB39T10001 BASE RIVET ASSEMBLY
WB63T10050 WB63T10050 BODY SIDE ALMOND
WB63T10048 WB63T10048 BODY SIDE/WHITE
WB02T10132 WB02T10132 BRACE CHASSIS (RAD)
WB02T10133 WB02T10133 BRACE CHASSIS (RAD)
WB34X26004 WB34X26004 BRACE CHASSIS RADIANT LT
WB02T10463 WB02T10463 BRACE CHASSIS RADIANT RT
WB44T10009 WB44T10009 BROIL ELEMENT
WB01T10021 WB01T10021 BUMPER RANGETOP
WX10X302 WX10X302 CERAMA BRYTE COOKTOP SCRAPER
WB02X8323 WB02X8323 CLIP PUSHON
WB2X8323 WB2X8323 CLIP PUSHON
WB01X0119 WB01X0119 CONTOURED WASHER
WB34T10128 WB34T10128 COVER BACK
WB02T10532 WB02T10532 COVER CONTROL
WB34T10020 WB34T10020 COVER CONTROL
WB34T10011 WB34T10011 COVER RECEPTACLE
WB01T10022 WB01T10022 DOOR BUMPER
WB10T10006 WB10T10006 DOOR HINGE
WB55T10048 WB55T10048 DOOR LINER ASSEMBLY
WB35T10020 WB35T10020 DOOR LOCK INSULATIOIN
WB01T10026 WB01T10026 DOOR PAD
WB07T10220 WB07T10220 DOOR VENT TRIM (GE)
WB48T10068 WB48T10068 DRAWER GUIDE
WB30X44826 WB30X44826 ELEMENT HALIANT 6
WB30T10052 WB30T10052 ELEMENT HALIANT 6WARMER
WB34T10023 WB34T10023 ENCLOSURE RANGETOP
WB36T10220 WB36T10220 END CAP LT BLACK
WB36T10352 WB36T10352 END CAP LT/ALMOND
WB36T10233 WB36T10233 END CAP LT/WHITE
WB36T10235 WB36T10235 END CAP RT/ALMOND
WB36T10219 WB36T10219 END CAP RT/BLACK
WB36T10232 WB36T10232 END CAP RT/WHITE
WB27T10202 WB27T10202 FACEPLATE GRAPHICS AS
WB27T10123 WB27T10123 FACEPLATE GRAPHICS ASSEMBLY
WB27T10200 WB27T10200 FACEPLATE GRAPHICS ASSEMBLY
WB56T10063 WB56T10063 FRAME DOOR SIDE
WB56T10064 WB56T10064 FRAME DOOR SIDE
WB56T10290 WB56T10290 FRAME DOOR SIDE (WHITE)
WB55T10065 WB55T10065 FRAME WINDOW PACK ASM
WB63T10045 WB63T10045 FRONT FRAME
WB48T10013 WB48T10013 FRT DRAWER SUPPORT
WB02T10027 WB02T10027 GASKET OVEN LIGHT
WB04T10022 WB04T10022 GASKET OVN
WB64X0093 WB64X0093 GLASS CLEANER
WB56T10036 WB56T10036 GLASS DOOR OUTER
WB56T10035 WB56T10035 GLASS DOOR SM WN BL GE
WB56T10037 WB56T10037 GLASS DOOR SM WN WHT GE
WB62T10060 WB62T10060 GLASS MAINTOP KIT
WB62T10057 WB62T10057 GLASS MAINTOP KIT (AD)
WB62T10059 WB62T10059 GLASS MAINTOP KIT (WHITE)
WB02T10067 WB02T10067 GROUND STRAP
WB01X1260 WB01X1260 GROUND WASHER
WB1X1260 WB1X1260 GRUND WASHER
WB30T10045 WB30T10045 HALIANT ELEMENT 8
WB15X10047 WB15X10047 HANDLE DOOR (BLK)
WB15X10048 WB15X10048 HANDLE DOOR (WH)
WB15X10049 WB15X10049 HANDLE DOOR AL
WB18T10061 WB18T10061 HARNESS WIRE INF
WB18T10138 WB18T10138 HARNESS WIRE INFINITE
WB18T10137 WB18T10137 HARNESS WIRE MAIN
WB18T10139 WB18T10139 HARNESS WIRE MAINTOP
WB18T10143 WB18T10143 HARNESS WIRE WARMER
WB02T10022 WB02T10022 HEAT SHIELD
WB10T10005 WB10T10005 HINGE RECEIVER
WB25X5054 WB25X5054 INDICATOR LIGHT LENS
WB03T10072 WB03T10072 INF KNOB (BLK)
WB03T10074 WB03T10074 INF KNOB GE (ALMOND)
WB24T10029 WB24T10029 INF SW CNTL 1500W LF RR
WB24T10027 WB24T10027 INF SW CNTL 2100W RF LR
WB03T10076 WB03T10076 INFINITE KNOB GE (WH)
31-10414 31-10414 INSTALLATION INSTRUCTION
31-10463 31-10463 INSTRUCTION INSTALL
31-10301 31-10301 INSTRUCTION INSTALL
WB35T10085 WB35T10085 INSULATION DOOR
WB35T10113 WB35T10113 INSULATION OVN BACK/BTTM
WB03T10125 WB03T10125 KNOB CONTROL
WB03T10126 WB03T10126 KNOB CONTROL
WB03T10127 WB03T10127 KNOB CONTROL
WB03T10073 WB03T10073 KNOB GE T08 A
WB36X192 WB36X192 LAMP COV ASM
WB15X10068 WB15X10068 LATCH H AND LE
WB02X10521 WB02X10521 LEG LEVELER
WB25T10016 WB25T10016 LENS
WB02X7694 WB02X7694 LIGHT CAMERA LENS BAIL
WB27T10201 WB27T10201 LIGHT INDICATOR
WB27T10626 WB27T10626 LIGHT INDICATOR PILOT
WB24T10055 WB24T10055 LOGIC SWITCH
WB63T10047 WB63T10047 MAIN BACK
WB17T10003 WB17T10003 MAIN TERMINAL BLOCK
WB10T10002 WB10T10002 MAINTOP HINGE
WB02T10026 WB02T10026 MAINTOP STRIKE
31-13769 31-13769 MANUAL MINI & WD ASM
49-8998 49-8998 MANUAL USE & CARE
49-80091 49-80091 MANUAL USE & CARE
WB01X5968 WB01X5968 NUT
WB1X5968 WB1X5968 NUT 10-32
WB04T10086 WB04T10086 OVEN DOOR GASKET
WB02T10037 WB02T10037 OVEN LIGHT CUP
WB48T10011 WB48T10011 OVEN RACK
WB24T10043 WB24T10043 OVEN ROCKER SWITCH
WB35T10012 WB35T10012 OVEN TOP/SIDE INSULATION
WB56T10268 WB56T10268 PANEL DRAWER
WB08T10026 WB08T10026 PUSH-IN RECEPTICLE
WB36X0389 WB36X0389 RANGE OVEN BULB COVER
WB02X29562 WB02X29562 RANGETOP BUMPER
WB06K5036 WB06K5036 RAZOR BLADE SCRAPER
WB02T10031 WB02T10031 REAR DRAWER SUPPORT
WB56T10018 WB56T10018 RETAINER INSLN
WB24T10042 WB24T10042 ROCKER SWITCH OVEN
WH02X0941 WH02X0941 SCR 8-15 A HXW 7/8 S
WH02X10002 WH02X10002 SCR 8-18 AB IHWP 7/8 S
WB1X5904 WB1X5904 SCR 8-18 BA
WB01X5904 WB01X5904 SCR 8-18 BA POR 3/4 SN
WR01X10065 WR01X10065 SCR 8-18 BA POR 5/8 SS
WZ05X0132 WZ05X0132 SCR 8-32 T HXW 5/16 S
WB01M0013 WB01M0013 SCREW
WB01X1170 WB01X1170 SCREW
WB01X1137 WB01X1137 SCREW
WB01M0001 WB01M0001 SCREW
WB01K5028 WB01K5028 SCREW
WB01K5200 WB01K5200 SCREW
WD2X432 WD2X432 SCREW
WB1K5062 WB1K5062 SCREW
WB1X1262 WB1X1262 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WB1X536 WB1X536 SCREW
WH2X930 WH2X930 SCREW
WB01T10018 WB01T10018 SCREW 10-16 PL PNT 2 5 S
WB01T10056 WB01T10056 SCREW 10-32 IND HXW 437
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10016 WB01T10016 SCREW 8-18 AB HXW 5/8 S
WB01T10017 WB01T10017 SCREW 8-18 AB IHW 3/8 S NS
WB01T10019 WB01T10019 SCREW 8-18 AB TRT 7/16 SN
WB01T10037 WB01T10037 SCREW 8-18 BA TW 7/16 S
WD02X0432 WD02X0432 SCREW 8-18 X 5/16 BK
WB01T10013 WB01T10013 SCREW 8-19 HI/LO IHW 5/8 S
WB01X23501 WB01X23501 SCREW 8-32 TPT FLR 215 SN
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB01K5062 WB01K5062 SCREW ST8-18X.500TRBRNI
WB1X1137 WB1X1137 SCREW-10AB
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB01X1118 WB01X1118 SCREW-NICKEL
WH2X941D WH2X941D SCREW-PKG 12
WZ5X132D WZ5X132D SCREW-PKG 12
WZ4X245D WZ4X245D SCREW-PKG 12
WB04T10003 WB04T10003 SEAL
WB23X5340 WB23X5340 SENSOR ASM
WB21X22134 WB21X22134 SENSOR ASM
WB18T10055 WB18T10055 SENSOR WIRE HARNESS
WB02T10028 WB02T10028 SIDE INSULATION RETAINER
WB02T10034 WB02T10034 SIDE PANEL SUPPORT
WB02T10035 WB02T10035 SPACER
WB9X5119 WB9X5119 SPRG HTR MTG
WB09X5119 WB09X5119 SPRING HEATER MTG
WB55T10178 WB55T10178 STORAGE DRAWER LINING
WB02X8377 WB02X8377 STUD HEATER MOUNT
WB2X8377 WB2X8377 STUD HTR MT
WB02T10080 WB02T10080 SUPPORT ELEMENT
WB24T10058 WB24T10058 SWITCH INFINITE CNTL
WB24T10044 WB24T10044 SWITCH ROCKER OVEN
WB03T10071 WB03T10071 T08 A KNOB GE
WB03T10075 WB03T10075 T08 A KNOB GE
WB17T10002 WB17T10002 TERMINAL BOX
WB27T10231 WB27T10231 TO8 CONTROL
WB02T10029 WB02T10029 TOP INSULATION RETAINER
WB36T10346 WB36T10346 TRIM & BRACKET ASSEMBLY
WB07X32929 WB07X32929 TRIM DR BTM CHNL (WHT)
WB07X42948 WB07X42948 TRIM DR BTM CHNL (WHT)
WB7X7175 WB7X7175 TRIM LATCH
WB07X7175 WB07X7175 TRIM LATCH
WB07T10230 WB07T10230 TRIM VENT DOOR (GE)
WB38T10022 WB38T10022 TUBE VENT RADNT
WB44T10010 WB44T10010 UNIT ASM BAKE (2585W)
WB48X10056 WB48X10056 UNIVERSAL RANGE BROILER PAN
WB38X33648 WB38X33648 VENT TUBE
WB38T10012 WB38T10012 VENT TUBE ASSEMBLY
WB35T10017 WB35T10017 VENT TUBE INSULATION
WB01K5174 WB01K5174 WASHER
WB1K5174 WB1K5174 WASHER
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
WB63X20942 WB63X20942 WRAPPER OVEN CAVITY
