Model Image
Manufacturer

GE

Model Number

JBS160DM2BB

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB24T10022 WB24T10022 1250W RANGE SURFACE ELEMENT SWITCH
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB24T10025 WB24T10025 500W ELEC RNGE SRFCE BRNER CONTROL SWTCH2
WB31X46067 WB31X46067 6-INCH SURFACE BURNER WITH SENSOR
WB31X46066 WB31X46066 8-INCH SURFACE BURNER WITH SENSOR
WB02X29637 WB02X29637 BADGE ASSEMBLY
WB02K0027 WB02K0027 BAIL
WB2K27 WB2K27 BAIL
WB56X31458 WB56X31458 BLACK DRAWER PANEL
WB27X31509 WB27X31509 BLOCK TERMINAL ASSEMBLY
WB64K10009 WB64K10009 BOX COOKTOP
WB02X32405 WB02X32405 BRACKET ASSEMBLY ANTI-TIP
WB34X29134 WB34X29134 BRACKET BASE
WB37X20196 WB37X20196 BRACKET COOK TOP
WB37X20193 WB37X20193 BRACKET COOK TOP
WB02K10029 WB02K10029 BRACKET MTG TERMINAL
WB30X46986 WB30X46986 BROIL ELEMENT
WB25K0002 WB25K0002 CAMERA LENS
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K10073 WB02K10073 CLIP CAPILLARY
WB02K0050 WB02K0050 CLIP CRYSTAL
WB2K50 WB2K50 CLIP CRYSTAL
WB02K10133 WB02K10133 CLIP RECEPTICAL
WB01X0119 WB01X0119 CONTOURED WASHER
WB34X21585 WB34X21585 COVER BACK
WB56K5 WB56K5 CRYSTAL WIND
WB56K25 WB56K25 CRYSTAL WIND
WB56K0025 WB56K0025 CRYSTAL WINDOW
WB56K0005 WB56K0005 CRYSTAL WINDOW
WB34X21602 WB34X21602 DIVIDER WIRING
WB35K10114 WB35K10114 DOOR INSULATION
WB17T10006 WB17T10006 ELEC RANGE SURFACE BURNER TERMINAL BLOCK
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB63X21360 WB63X21360 FRAME WELD ASSEMBLY
WB35X29720 WB35X29720 GASKET DOOR ASSEMBLY
WB2K66 WB2K66 GD SUPT RGTP
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB02K10062 WB02K10062 GLIDER DRAWER LEFT
WB02K10061 WB02K10061 GLIDER DRAWER RIGHT
WB2K8 WB2K8 GROMMET
WB2X646 WB2X646 GROUND PLATE
WB56K10032 WB56K10032 GUARD INSULATION
WB34X21584 WB34X21584 GUARD TERMINAL
WB02K0066 WB02K0066 GUIDE SUPPORT RGTP
WB15T10213 WB15T10213 HANDLE (BLACK)
WB18X32878 WB18X32878 HARNESS MAIN
WB18X27488 WB18X27488 HARNESS SURFACE UNIT
WB18X48306 WB18X48306 HARNESS SURFACE UNIT
WB18X48307 WB18X48307 HARNESS SURFACE UNIT
WB10X21978 WB10X21978 HINGE DOOR
WB34K0004 WB34K0004 HINGE GUARD LEFT
WB34K0003 WB34K0003 HINGE GUARD RIGHT
WB34K4 WB34K4 HNGE GRD LFT
WB34K3 WB34K3 HNGE GRD RGT
WB8K1 WB8K1 HOUS RECEPTL
WB08K0001 WB08K0001 HOUSING RECEPTACLE
WB35K10107 WB35K10107 INSULATION OVEN BACK
WB35K10108 WB35K10108 INSULATION OVEN WRAP
WB03X21356 WB03X21356 KNOB VALVE
WB25T10041 WB25T10041 LENS
WB56X21217 WB56X21217 LINER ASSEMBLY WELD DOOR
WB01K0003 WB01K0003 NUT SPEED
WB1K3 WB1K3 NUT SPEED
WB63K10006 WB63K10006 OVEN BOTTOM
WB63K10021 WB63K10021 OVEN TOP
WB56X21214 WB56X21214 PANEL DOOR
WB56X29124 WB56X29124 PANEL SIDE
WB14K0005 WB14K0005 PIN HINGE
WB14K5 WB14K5 PIN HINGE
WB2K17 WB2K17 PIN LOCATOR
WB02K0017 WB02K0017 PIN LOCATOR FRONT
WB02K10075 WB02K10075 PLASTIC NAIL
WB02X0646 WB02X0646 PLATE-GROUND
49-88076 49-88076 PM GAS QUICK GUIDE
49-2000686 49-2000686 PM INSERT INSTRUCTIONS
31-10892 31-10892 PM INSTALL INSTRUCTIONS
31-2000872 31-2000872 PM MINI MANUAL AND WIRING
WB39K0016 WB39K0016 RAIL DRAWER
WB63K10273 WB63K10273 RANGE BACK
WB07X20288 WB07X20288 RANGE BARRIER DOOR
WB63K10233 WB63K10233 RANGE BASE SUPPORT
WB63K10241 WB63K10241 RANGE BOTTOM INSULATION GUARD
WB31T10014 WB31T10014 RANGE BURNER BOWL - BLACK PORCELAIN - 6-INCH
WB31T10015 WB31T10015 RANGE BURNER BOWL - BLACK PORCELAIN - 8-INCH
WB58K10015 WB58K10015 RANGE DRAWER BODY
WB02K10398 WB02K10398 RANGE DRAWER MOUNTING BRACKET
WB39K16 WB39K16 RANGE DRAWER RAIL
WB02K10158 WB02K10158 RANGE DRAWER SUPPORT
WB07X20197 WB07X20197 RANGE END SUPPORT - LEFT
WB07X20194 WB07X20194 RANGE END SUPPORT - RIGHT
WB10X20220 WB10X20220 RANGE HINGE RECEIVER
WB25K10002 WB25K10002 RANGE INDICATOR LIGHT
WB02X29030 WB02X29030 RANGE LEVELING LEG
WB02K10182 WB02K10182 RANGE LEVELING LEG
WB63K10007 WB63K10007 RANGE OVEN BACK
WB30X46987 WB30X46987 RANGE OVEN BAKE ELEMENT
WB36X192 WB36X192 RANGE OVEN BULB COVER
WB48X20249 WB48X20249 RANGE OVEN RACK
WB24X20458 WB24X20458 RANGE ROCKER SWITCH
WB02X21087 WB02X21087 RANGE THERMOSTAT CARTON COVER
WB03X21367 WB03X21367 RANGE THERMOSTAT KNOB - BLACK
WB62X21354 WB62X21354 RANGE TOP
WB04K10002 WB04K10002 RANGE VENT COVER
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB55K1 WB55K1 REFLECTOR
WB55K0001 WB55K0001 REFLECTOR LG
WB02K10026 WB02K10026 ROD SUPPORT
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB01K10091 WB01K10091 SCREW
WB1X536 WB1X536 SCREW
WB1X5716 WB1X5716 SCREW
WB1X1261 WB1X1261 SCREW
WB1K5062 WB1K5062 SCREW
WB01K10057 WB01K10057 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5716 WB01X5716 SCREW (BLK)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB02X32438 WB02X32438 SCREW 10-16 PL PNT 2.15S
WB01T10008 WB01T10008 SCREW 10-32 TR T
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K10012 WB01K10012 SCREW 8-22 PL 1HX 71
WB01X23501 WB01X23501 SCREW 8-32 TT FLP .270
WB01X1261 WB01X1261 SCREW GROUND
WB01K0053 WB01K0053 SCREW MTG HINGE (TORX)
WB63X23794 WB63X23794 SIDE OVEN LF
WB63X23795 WB63X23795 SIDE OVEN RT
WB02K10156 WB02K10156 SPACER
WB01K0002 WB01K0002 SPEEDNUT
WB1K2 WB1K2 SPEEDNUT
WB63K10232 WB63K10232 SUPPORT BASE
WB02K10028 WB02K10028 SUPPORT BROIL
WB24X21192 WB24X21192 THERMOSTAT ELECTRIC
WB36X21589 WB36X21589 TRIM CONTROL
WB38K10002 WB38K10002 TUBE-VENT
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
