Model Image
Manufacturer

GE

Model Number

JBS160DM6BB

Description

30-inch Free-standing Electric Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB31T10014 WB31T10014 6-INCH BLACK PORCELAIN B
WB31X46067 WB31X46067 6-INCH SURFACE BURNER
WB31T10015 WB31T10015 8-INCH BLACK PORCELAIN B
WB31X46066 WB31X46066 8-INCH SURFACE BURNER
WB02X29637 WB02X29637 BADGE ASM
WB30X46987 WB30X46987 BAKE ELEMENT
WB07X20288 WB07X20288 BARRIER DOOR
WB56X31458 WB56X31458 BLACK DRAWER PANEL
WB15X35072 WB15X35072 BLACK HANDLE AND ENDCAP
WB56X46209 WB56X46209 BLACK PANEL SIDE
WB62X48586 WB62X48586 BLACK RANGE TOP
WB17T10006 WB17T10006 BLOCK INSULATOR
WB27X31509 WB27X31509 BLOCK TERMINAL ASM
WB63K10105 WB63K10105 BOTTOM OVEN
WB64K10009 WB64K10009 BOX COOKTOP
WB02X32405 WB02X32405 BRACKET ASM ANTI-TIP
WB34X29134 WB34X29134 BRACKET BASE
WB37X20193 WB37X20193 BRACKET COOK TOP
WB37X20196 WB37X20196 BRACKET COOK TOP
WB02K10398 WB02K10398 BRACKET MOUNTING DRAWER
WB02K10029 WB02K10029 BRACKET MTG TERMINAL
WB30X46986 WB30X46986 BROIL ELEMENT
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K0050 WB02K0050 CLIP CRYSTAL
WB02K10133 WB02K10133 CLIP RECEPTICAL
WB01X0119 WB01X0119 CONTOURED WASHER
WB34X21585 WB34X21585 COVER BACK
WB56K0025 WB56K0025 CRYSTAL WINDOW
WB56K0005 WB56K0005 CRYSTAL WINDOW
WB34X21602 WB34X21602 DIVIDER WIRING
WB35K10114 WB35K10114 DOOR INSULATION
WB58K10015 WB58K10015 DRAWER BODY
WB02K10158 WB02K10158 DRAWER SUPPORT
WB07X20197 WB07X20197 END SUPPORT LT
WB07X20194 WB07X20194 END SUPPORT RT
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB35X29720 WB35X29720 GASKET DOOR ASM
WB02K10062 WB02K10062 GLIDER DRAWER LEFT
WB02K10061 WB02K10061 GLIDER DRAWER RIGHT
WB2K8 WB2K8 GROMMET
WB56K10032 WB56K10032 GUARD INSULATION
WB63K10241 WB63K10241 GUARD INSULATION BOTTOM
WB34X21584 WB34X21584 GUARD TERMINAL
WB02K0066 WB02K0066 GUIDE SUPPORT RGTP
WB18X48306 WB18X48306 HARNESS SURFACE UNIT LR
WB18X27488 WB18X27488 HARNESS SURFACE UNIT RF
WB18X48307 WB18X48307 HARNESS SURFACE UNIT RR
WB10X21978 WB10X21978 HINGE DOOR
WB24T10025 WB24T10025 INF SW CONTROL (2500W)
WB24T10022 WB24T10022 INF SWITCH CONTROL 1250W
WB35K10107 WB35K10107 INSULATION OVEN BACK
WB03X21367 WB03X21367 KNOB THERMOSTAT ASM
WB03X21356 WB03X21356 KNOB VALVE
WB25X50906 WB25X50906 LAMP HALOGEN G9
WB25K10002 WB25K10002 LAMP PILOT
WB02K10182 WB02K10182 LEG LEVELER
WB02X29030 WB02X29030 LEG LEVELING
WB25K0002 WB25K0002 LENS
WB25X50907 WB25X50907 LENS OVEN
WB56X21217 WB56X21217 LINER ASM WELD DOOR
WB01K0003 WB01K0003 NUT SPEED
WB25X50908 WB25X50908 OVEN LAMP ASM
WB48X20249 WB48X20249 OVEN RACK
WB56X21214 WB56X21214 PANEL DOOR
WB14K0005 WB14K0005 PIN HINGE
WB02K0017 WB02K0017 PIN LOCATOR FRONT
WB02K10075 WB02K10075 PIN LOCATOR REAR
49-2000686 49-2000686 PM INSERT INSTRUCTIONS
31-2000872 31-2000872 PM MINI MANUAL AND WIRING
49-2001027 49-2001027 PM OWNERS MANUAL
49-2001036 49-2001036 PM QUICK OWNERS MANUAL
WB39K0016 WB39K0016 RAIL DRAWER
WB63K10273 WB63K10273 RANGE BACK
WB10X20220 WB10X20220 RECEIVER HINGE
WB55K0001 WB55K0001 REFLECTOR LG
WB02K10026 WB02K10026 ROD SUPPORT
WB02X32438 WB02X32438 SCR 10-16PL PNT 2.15S
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB01K10091 WB01K10091 SCREW
WB01X5716 WB01X5716 SCREW (BLK)
WB01K0042 WB01K0042 SCREW (BLK)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01T10008 WB01T10008 SCREW 10-32 TR T
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K10012 WB01K10012 SCREW 8-22 PL 1HX 71
WB01X23501 WB01X23501 SCREW 8-32 TPT FLR 215 S
WB01X1261 WB01X1261 SCREW GROUND
WB01K0053 WB01K0053 SCREW MTG HINGE (TORX)
WB02K10156 WB02K10156 SPACER
WB01K0002 WB01K0002 SPEEDNUT
WB63K10233 WB63K10233 SUPPORT BASE LEFT
WB63K10232 WB63K10232 SUPPORT BASE RIGHT
WB02K10028 WB02K10028 SUPPORT BROIL
WB24X20458 WB24X20458 SWITCH ROCKER SEALED
WB24X21192 WB24X21192 THERMOSTAT ELECTRIC
WB36X21589 WB36X21589 TRIM CONTROL
WB34X24779 WB34X24779 TRIM FRONT FRAME
WB38K10002 WB38K10002 TUBE-VENT
