GE

Model Number

JCT915BF1BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
WB1K5200 WB1K5200 340531
WB02K10048 WB02K10048 BASE RAIL
WB38T10019 WB38T10019 BOX VENT ASSEMBLY
WB02T10152 WB02T10152 BRACKET CAPACITOR MTR
WB26T10016 WB26T10016 CAPACITOR MOTOR
WB2K5126 WB2K5126 COND CLAMP
WB02K5126 WB02K5126 CONDUIT CLAMP
WB18T10271 WB18T10271 CONDUIT WIRE ASM
WB2K5365 WB2K5365 COVER
WB2X9152 WB2X9152 COVER ENAM WIPE
WB26T10053 WB26T10053 COVER FAN (CONVX)
WB34T10058 WB34T10058 COVER FAN HOUSING
WB2X8309 WB2X8309 COVER PROBE
WB34T10056 WB34T10056 COVER WIRE LWR
WB34T10057 WB34T10057 COVER WIRE TOP
WB34T10055 WB34T10055 COVER WIRE UPR RR
WB01T10022 WB01T10022 DOOR BUMPER
WB03T10156 WB03T10156 DOOR BUMPER
WB57T10259 WB57T10259 DOOR OTR ASSEMBLY 30 (BLK)
WB28T10074 WB28T10074 DUCT VNT INLET
WB44T10055 WB44T10055 ELEMENT BAKE
WB63T10034 WB63T10034 FALSE BOTTOM
WB26T10018 WB26T10018 FAN ASM - CONTROL
WB34T10043 WB34T10043 FAN SCREEN
WB63T10083 WB63T10083 FRAME FRT LOWER
WB41T10003 WB41T10003 GASKET OVN DR
WB57T10233 WB57T10233 GLASS OVN DR INR
WB01X1260 WB01X1260 GROUND WASHER
WB1X1260 WB1X1260 GRUND WASHER
WB15T10063 WB15T10063 HANDLE PROFILE 30 (BLK)
WB15T10067 WB15T10067 HANDLE PROFILE 30 (WHT)
WB10T10024 WB10T10024 HINGE DOOR LT
WB10T10023 WB10T10023 HINGE DOOR RT
WB26T10014 WB26T10014 HOUSING FAN
WB02T10289 WB02T10289 HUB BLADE ASSEMBLY
31-10549 31-10549 INSTRUCTION INSTALL
31-10522 31-10522 INSTRUCTION INSTALL
WB35T10073 WB35T10073 INSULATION (INR) LWR
WB35T10074 WB35T10074 INSULATION (OUT) LWR
WB35K10025 WB35K10025 INSULATION OVEN DR SDE
WB35T10080 WB35T10080 INSULATION OVN DR SDE
WB35X30052 WB35X30052 INSULATION OVN DR TOP
WB25T10026 WB25T10026 LAMP HALOGEN ASSEMBLY
WB49X29679 WB49X29679 LAMP HALOGEN UPR
WB14T10013 WB14T10013 LATCH OVN
WB25T10027 WB25T10027 LENS OVEN LAMP
WB24T10060 WB24T10060 LIMIT SWITCH-UPPER(LOCK)
WB55T10147 WB55T10147 LINER OVEN DR ASSEMBLY UPPER
WB01K5046 WB01K5046 LOCKWASHER
WB02K5306 WB02K5306 LOWER OVN INSLN RETAINER
31-14021 31-14021 MANUAL MINI & WD ASM
29-5031 29-5031 MANUAL USE & CARE
WB1X5572 WB1X5572 NUT
WB02T10017 WB02T10017 NUT
WB01X5572 WB01X5572 NUT MEAT PROBE
WB57T10260 WB57T10260 OUTER DR ASSEMBLY LWR
WB27T10398 WB27T10398 OVEN CONTROL (CLOCK)
WB02K5310 WB02K5310 OVEN DOOR GLASS RETAINER
WB56T10105 WB56T10105 PACK WINDOW ASM
WB56X22160 WB56X22160 PACK WINDOW ASSEMBLY
WB36T10557 WB36T10557 PANEL CNTL ASM
WB36T10554 WB36T10554 PANEL CNTL ASM
WB02T10147 WB02T10147 PLATE REINFORCEMEMT
WB02T10168 WB02T10168 PLUG FOAM
WB20T10024 WB20T10024 PROBE
WB02X8309 WB02X8309 PROBE COVER
WB26T10013 WB26T10013 PSC CONV MOTOR LOWER
WB48T10020 WB48T10020 RACK OVEN UPR
WB44T10053 WB44T10053 RANGE CONVECTION ELEMENT
WB10T10025 WB10T10025 RECEIVER HINGE
WB08T10018 WB08T10018 RECEPTACLE JACK
WB56T10373 WB56T10373 RETAINER GLASS OVEN DR
WB02X20948 WB02X20948 RETAINER INSLN BACK
WB56T10104 WB56T10104 RETAINER INSLN BACK LOW
WB02T10143 WB02T10143 RETAINER INSLN BTM
WB56T10147 WB56T10147 RETAINER INSLN OVN DR
WB02T10343 WB02T10343 RETAINER INSLN TOP CENTER
WB02T10172 WB02T10172 RETAINER OVN DR EXT
WB18T10331 WB18T10331 RIBBON CONNECTOR GLS TCH
WB48X5108 WB48X5108 ROAST RACK
WB01X1127 WB01X1127 SCREW
WB01X1253 WB01X1253 SCREW
WB01X1137 WB01X1137 SCREW
WB01K5116 WB01K5116 SCREW
WB01K5028 WB01K5028 SCREW
WB01K5029 WB01K5029 SCREW
WB01K5200 WB01K5200 SCREW
WB1K5116 WB1K5116 SCREW
WB1K5029 WB1K5029 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WB1X536 WB1X536 SCREW
WH2X930 WH2X930 SCREW
WB01T10058 WB01T10058 SCREW 10-16 AB HXW 750 S N
WB01T10048 WB01T10048 SCREW 10-16 SHLDR TYPE A
WB01T10066 WB01T10066 SCREW 10-16 X 1.000 HWH
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01X1261 WB01X1261 SCREW GROUND
WB1K5173 WB1K5173 SCREW ST 8-18 X 3/4 BLK
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB1X1130 WB1X1130 SCREW-10-32
WB1X1137 WB1X1137 SCREW-10AB
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB01X1180 WB01X1180 SCREW-BLACK
WB1K5157 WB1K5157 SCREW-BLK
WZ4X245D WZ4X245D SCREW-PKG 12
WB2K5306 WB2K5306 SD INSUL RET
WB23T10015 WB23T10015 SENSOR ASM
WB34T10067 WB34T10067 SHIELD BTM TRIM
WB26T10015 WB26T10015 SUPPORT OVEN CAVITY
WB24T10076 WB24T10076 SWITCH LIMIT BIMETAL
WB24T10147 WB24T10147 SWITCH SPDT HIGH AMP
WB07T10401 WB07T10401 TRIM BTM 30 OUTER (BLACK)
WB07T10388 WB07T10388 TRIM BTM CAB ASSEMBLY (BLK)
WB01K5173 WB01K5173 TRIM SCREW-BLK
WB07T10252 WB07T10252 TRIM VENT INR (BLACK) LWR
WB07T10251 WB07T10251 TRIM VERT SDE ASM LT
WB07T10250 WB07T10250 TRIM VERT SDE ASM RT
WB38X33650 WB38X33650 TUBE VENT
WB44T10043 WB44T10043 UNIT BROIL ASM (DLX)
WB48X10056 WB48X10056 UNIVERSAL RANGE BROILER PAN
WB01X5573 WB01X5573 WASHER
WB1K5117 WB1K5117 WASHER
WB1K5046 WB1K5046 WASHER
WB1X5573 WB1X5573 WASHER
WB01K5117 WB01K5117 WASHER .250 ID X .812 OD
WB1X681 WB1X681 WB01X0681
WB35T10090 WB35T10090 WB35K5116
WB63T10084 WB63T10084 WRAPPER OVEN CAV ASSEMBLY LO
WZ4X416 WZ4X416 WZ04X0408
