Model Image
Manufacturer

GE

Model Number

JGB620DEF3BB

Description

Gas Range Or Dual Fuel

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB16K10070 WB16K10070 000 BTUS GAS RANGE BURNER BASE; 5
WB29K10024 WB29K10024 000 BTUS GAS RANGE BURNER CAP-LARGE; 12
WB29K10022 WB29K10022 000 BTUS GAS RANGE SMALL BURNER CAP; 5
WB16T10046 WB16T10046 12 GAS COOKTOP LARGE BURNER 000 BTUS
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB29K10023 WB29K10023 500 BTUS GAS RANGE MEDIUM BURNER CAP; 9
WB28K10023 WB28K10023 89MM RANGE ORIFICE SPUD - NG TO LP
WB16K10055 WB16K10055 9 RANGE SURFACE BURNER BASE-MEDIUM 500
WB02K0027 WB02K0027 BAIL
WB2K27 WB2K27 BAIL
WB35X37973 WB35X37973 BOTTOM OVEN AND DEFLECTOR ASSEMBLY
WB02K0032 WB02K0032 BOTTOM OVEN BRACKT SUPPO
WB63K0015 WB63K0015 BRACE BOTTOM
WB02K10254 WB02K10254 BRACKET ANTI-TIP ASSEMBLY
WB63X24859 WB63X24859 BRACKET CAVITY
WB37X20193 WB37X20193 BRACKET COOK TOP
WB37X20196 WB37X20196 BRACKET COOK TOP
WB39K0020 WB39K0020 BRACKET MOUNTING DRAWER
WB02K0041 WB02K0041 BRACKET OVEN CORNER
WB02X24790 WB02X24790 BUMPER
WB02K10178 WB02K10178 BUMPER
WB16X20463 WB16X20463 BURNER BAKE
WB02K10362 WB02K10362 CKT BRACKET MDM AND LGE
WB02K10361 WB02K10361 CKT BRACKET MDM AND LGE
WB02K10360 WB02K10360 CKT BRACKET SMALL
WB01X24735 WB01X24735 CKT SCREW
WB02K0036 WB02K0036 CLAMP CABLE
WB2K36 WB2K36 CLAMP CABLE
WB02K0031 WB02K0031 CLIP CABLE
WB02X21679 WB02X21679 CLIP CABLE
WB02K10380 WB02K10380 CLIP INSULATION
WB02K0052 WB02K0052 CLIP RANGETOP
WB2K52 WB2K52 CLIP RNGETOP
WB02K0056 WB02K0056 CLIP WINDOW
WB2K56 WB2K56 CLIP WINDOW
WB02X7066 WB02X7066 CLIP WIRE
WB02K10267 WB02K10267 CLIP WIRE
WB01X0119 WB01X0119 CONTOURED WASHER
WB27X44729 WB27X44729 CONTROL OVEN TO9 (GAS)
WB34K0016 WB34K0016 COVER BACK
WB34X21575 WB34X21575 COVER BACK
WB34K16 WB34K16 COVER BACK
WB34K10129 WB34K10129 COVER BACK LOWER
WB34K10123 WB34K10123 COVER BACK UPPER
WB63K10040 WB63K10040 COVER TERMINAL
WB02K0024 WB02K0024 COVER VALVE
WB56X23809 WB56X23809 CRYSTAL WINDOW
WB49K10037 WB49K10037 DEFLECTOR OVEN
WB38K10022 WB38K10022 DIFFUSER VENT
WB02K10163 WB02K10163 DRAWER SUPPORT
WB01K10037 WB01K10037 ECONOMIC NUT
WB28X20295 WB28X20295 ELBOW 90 ASSEMBLY
WB18K10098 WB18K10098 ELECTRODES AND HARNESS HV
WB49K0044 WB49K0044 FLAME SPREADER
WB63X25196 WB63X25196 FRAME WELD ASSEMBLY
WB28K10803 WB28K10803 GAS RANGE FRONT ORIFICE HOLDER
WB31X20643 WB31X20643 GAS RANGE GRATE - BLACK
WB35X29668 WB35X29668 GASKET ASSEMBLY DOOR
WB32K0005 WB32K0005 GASKET OVEN LIGHT
WB32K2 WB32K2 GASKET OVEN SEAL LG
WB35X20455 WB35X20455 GASKET VENT
WB56X25503 WB56X25503 GLASS OVEN DOOR
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB02K0068 WB02K0068 GLIDER DRAWER
WB2K68 WB2K68 GLIDER DRWR
WB1K10 WB1K10 GROM HNDLE
WB2K8 WB2K8 GROMMET
WB01K0010 WB01K0010 GROMMET HANDLE
WB63K0016 WB63K0016 GUARD BOTTOM
WB56K12 WB56K12 GUARD INSUL
WB56K0012 WB56K0012 GUARD INSULATION
WB15T10213 WB15T10213 HANDLE (LE-BK)
WB18X31207 WB18X31207 HARNESS SWITCHES
WB10X21659 WB10X21659 HINGE DOOR
WB34K0004 WB34K0004 HINGE GUARD LEFT
WB34K0003 WB34K0003 HINGE GUARD RIGHT
WB34K4 WB34K4 HNGE GRD LFT
WB34K3 WB34K3 HNGE GRD RGT
WB8K1 WB8K1 HOUS RECEPTL
WB08K0001 WB08K0001 HOUSING RECEPTACLE
WB13K0021 WB13K0021 IGNITER-OVEN BAKE
WB35K10150 WB35K10150 INSULATION BOTTOM DOOR
WB35K10040 WB35K10040 INSULATION CONTROL
WB35X24786 WB35X24786 INSULATION OVEN WRAP
WB35K10149 WB35K10149 INSULATION SIDE DOOR
WB35X24787 WB35X24787 INSULATION VENT
WB28X20686 WB28X20686 KIT HIGH ALTITUDE ASSEMBLY
WB28X39143 WB28X39143 KIT LP CONVERSION ASSEMBLY
WB03X20319 WB03X20319 KNOB VALVE ASSEMBLY
WB10X33060 WB10X33060 LATCH ASSEMBLY
WB02K10140 WB02K10140 LATCH ASSEMBLY
WB18K0007 WB18K0007 LINE CORD
WB18K10036 WB18K10036 LINE CORD
WB56X24855 WB56X24855 LINER ASSEMBLY WELD DOOR
31-10911 31-10911 LP CONVERSION INST
WB36X20317 WB36X20317 MANIFOLD PANEL
WB28X20298 WB28X20298 MANIFOLD PIPE
WB34X20680 WB34X20680 MANIFOLD SUPPORT
WB28K10834 WB28K10834 ORIFICE SPUD
WB28K10032 WB28K10032 ORIFICE-LP LG 99MM
WB63X20289 WB63X20289 OVEN BACK
WB53K10035 WB53K10035 OVEN SIDE LEFT
WB53K10034 WB53K10034 OVEN SIDE RIGHT
WB53K10015 WB53K10015 OVEN TOP
WB02K0062 WB02K0062 PAD FELT (2"")
WB2K62 WB2K62 PAD FELT 2
WB55K10033 WB55K10033 PANEL ASSEMBLY WELD
WB56X20809 WB56X20809 PANEL BACKER
WB56X20396 WB56X20396 PANEL DRAWER
WB63K10203 WB63K10203 PANEL REAR BROIL
WB14K0005 WB14K0005 PIN HINGE
WB14K5 WB14K5 PIN HINGE
WB14K10004 WB14K10004 PIN LOCATOR
49-85224 49-85224 PM GAS QUICK GUIDE
31-10897 31-10897 PM INSTALL INSTRUCTIONS
31-17069 31-17069 PM MINI MANUAL
WB39K0016 WB39K0016 RAIL DRAWER
WB63X20207 WB63X20207 RANGE BACK
WB63K10187 WB63K10187 RANGE BOTTOM INNER GUARD
WB2K32 WB2K32 RANGE BRACKET SUPPORT
WB16K10086 WB16K10086 RANGE BROIL BURNER
WB28K10188 WB28K10188 RANGE BURNER SUPPLY TUBE, LEFT REAR, 9,5
WB28X24773 WB28X24773 RANGE BURNER TUBE SUPPLY
WB02K10150 WB02K10150 RANGE CONTROL BRACKET
WB07X20320 WB07X20320 RANGE CONTROL PANEL - BLACK
WB49K10025 WB49K10025 RANGE DEFLECTOR
WB58K10015 WB58K10015 RANGE DRAWER BODY
WB55K10068 WB55K10068 RANGE DRAWER LINER
WB39K20 WB39K20 RANGE DRAWER MOUNTING BRACKET
WB39K16 WB39K16 RANGE DRAWER RAIL
WB01K10112 WB01K10112 RANGE ELECTRODE CLIP
WB07X20197 WB07X20197 RANGE END SUPPORT - LEFT
WB07X20194 WB07X20194 RANGE END SUPPORT - RIGHT
WB28K10190 WB28K10190 RANGE FRONT ORIFICE HOLDER
WB10X20220 WB10X20220 RANGE HINGE RECEIVER
WB49X21392 WB49X21392 RANGE HINGE SERVICE KIT
WB02X24976 WB02X24976 RANGE IGNITER CLIP V2
WB1X1293 WB1X1293 RANGE IGNITER MOUNTING SCREW
WB34X24753 WB34X24753 RANGE IGNITOR COVER
WB02K10182 WB02K10182 RANGE LEVELING LEG
WB08K10018 WB08K10018 RANGE LIGHT COVER
WB34K10086 WB34K10086 RANGE LOWER HEAT SHIELD
WB35X20370 WB35X20370 RANGE OVEN BACK INSULATION
WB2K41 WB2K41 RANGE OVEN BRACKET
WB36X192 WB36X192 RANGE OVEN BULB COVER
WB32K5 WB32K5 RANGE OVEN GASKET
WB13K21 WB13K21 RANGE OVEN IGNITER
WB28X26089 WB28X26089 RANGE OVEN ORIFICE SPUD
WB48X20249 WB48X20249 RANGE OVEN RACK
WB63K16 WB63K16 RANGE PANEL
WB56X22008 WB56X22008 RANGE SIDE PANEL
WB02X20849 WB02X20849 RANGE SIDE SPACER
WB20K10027 WB20K10027 RANGE TEMPERATURE SENSOR
WB01K10080 WB01K10080 RANGE THERMOSTAT SCREW
WB62X20225 WB62X20225 RANGE TOP S.B.
WB02K10297 WB02K10297 RANGE VALVE BRACKET
WB63K15 WB63K15 RANGE VENT BRACE
WB28K10187 WB28K10187 REAR ORIFICE HOLDER
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB35K33 WB35K33 REFLECTOR
WB35K0022 WB35K0022 REFLECTOR 9.5 INCH
WB1K44 WB1K44 SCEW LATCH
WB1K45 WB1K45 SCR AND WSHR ASSEMBLY
WB01K0001 WB01K0001 SCREW
WB01K10091 WB01K10091 SCREW
WB1K5062 WB1K5062 SCREW
WB1X1261 WB1X1261 SCREW
WB1X5716 WB1X5716 SCREW
WB1X536 WB1X536 SCREW
WB1K5119 WB1K5119 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5716 WB01X5716 SCREW (BLK)
WB01X5364 WB01X5364 SCREW (CR)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01T10008 WB01T10008 SCREW 10-32 TR T
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K10012 WB01K10012 SCREW 8-22 PL 1HX 71
WB01K10002 WB01K10002 SCREW 8-32
WB01K0044 WB01K0044 SCREW DOOR LATCH
WB01X1261 WB01X1261 SCREW GROUND
WB1K53 WB1K53 SCREW HINGE
WB1X5364 WB1X5364 SCREW MTG
WB01K0053 WB01K0053 SCREW MTG HINGE (TORX)
WB01K0050 WB01K0050 SCREW MTG IGNITER
WB01K0045 WB01K0045 SCREW WASHER ASM
WB34X20303 WB34X20303 SHIELD BROIL
WB02K10156 WB02K10156 SPACER
WB16X20449 WB16X20449 SPACER BASE
WB16X20448 WB16X20448 SPACER BASE
WB13K10029 WB13K10029 SPARK MODULE 4+0
WB01K0002 WB01K0002 SPEEDNUT
WB1K2 WB1K2 SPEEDNUT
WB63X20216 WB63X20216 SUPPORT BASE
WB63X20215 WB63X20215 SUPPORT BASE
WB02K10276 WB02K10276 SUPPORT COOKTOP
WB07K10232 WB07K10232 TRIM BOTTOM ASSEMBLY
WB36X20227 WB36X20227 TRIM CONTROL
WB07X25502 WB07X25502 TRIM DOOR
WB34X24779 WB34X24779 TRIM FRONT FRAME
WB28X25363 WB28X25363 TUBE MANIFOLD SUPPLY ASSEMBLY
WB21X20300 WB21X20300 VALVE BURNER 270
WB21X20302 WB21X20302 VALVE BURNER 270
WB21X20293 WB21X20293 VALVE CONTROL ASSEMBLY NOR.D
WB2K24 WB2K24 VALVE COVER
WB34X20294 WB34X20294 VENT ASSEMBLY
WB07X24847 WB07X24847 VENT TRIM
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
WB34K10087 WB34K10087 WINDOW SPACER ASSEMBLY
