Model Image
Manufacturer

GE

Model Number

JGP628WEC1WW

Description

Gas Range Or Dual Fuel

Interactive Exploded View

Parts List

Part Number Description
WB16T10030 WB16T10030 BASE BURNER MED
WB64T10025 WB64T10025 BOTTOM BURN BOX
WB2K5328 WB2K5328 BRKT HOLD DN
WB34T10026 WB34T10026 BURN BOX BOTTOM SHIELD
WB35T10054 WB35T10054 BURN BOX INSULATION
WB16T10031 WB16T10031 BURNER BASE SMALL
WB13T10023 WB13T10023 BURNER CAP BLK B MED
WB13T10024 WB13T10024 BURNER CAP BLK H SMALL
WB13T10025 WB13T10025 BURNER CAP LT FRT
WB03T10137 WB03T10137 BURNER CAP TAUPE H SMALL
WB13T10026 WB13T10026 BURNER CAP-GRAY- LR
WB13T10027 WB13T10027 BURNER CAP-GRAY-H SMALL
WB04T10011 WB04T10011 BURNER GASKET LT RR
WB16T10011 WB16T10011 BURNER GASKET RTR CENT
WB31X28386 WB31X28386 BURNER GRATE SINGLE-BLACK
WB31T10058 WB31T10058 BURNER GRATE SINGLE-GRAY
WB16K10036 WB16K10036 BURNER HEAD-SMALL
WB28T10031 WB28T10031 BURNER INJET LEFT FRT
WB28T10010 WB28T10010 BURNER INJET LTRR RT FT
WB02T10107 WB02T10107 BURNER SUPPORT BRACKET
WB02T10106 WB02T10106 BURNER SUPPORT BRACKET
WB28T10019 WB28T10019 BURNER TUBE LT FRT
WB28T10022 WB28T10022 BURNER TUBE RT RR
WB28T10021 WB28T10021 BURNER TUBE- RT FRT
WB28T10020 WB28T10020 BURNER TUBE-LT-RR
WB18T10179 WB18T10179 BURNER WIRE HARNESS
WB01K10112 WB01K10112 CLIP-ELECTRODE
WB32K5027 WB32K5027 CONTROL SEAL-GRAY
WB03T10138 WB03T10138 GAS VALVE KNOB
WB03T10136 WB03T10136 GAS VALVE KNOB
WB03T10139 WB03T10139 GAS VALVE KNOB BLACK
WB19T10010 WB19T10010 GAS VALVE LT FRT LT RR
WB19T10011 WB19T10011 GAS VALVE RT FRT
WB19T10009 WB19T10009 GAS VALVE RT RR CENT
WB06T10009 WB06T10009 GASKET
WB02X9008 WB02X9008 GASKET (VIEW 838)
WB2X9008 WB2X9008 GASKET SCREW
WB57T10128 WB57T10128 GLASS CONTROL PNL ASS
WB57T10135 WB57T10135 GLASS CONTROL PNL ASS
WB57T10129 WB57T10129 GLASS CONTROL PNL ASSEMBLY
WB4K5003 WB4K5003 GLUE GASKET
WB31T10052 WB31T10052 GRATE ASSEMBLY BISQUE
WB02T10461 WB02T10461 GRATE FOOT
WB16T10029 WB16T10029 HEAD BURNER B
WB02K5328 WB02K5328 HOLD DOWN BRACKET
WB13X27058 WB13X27058 IGNITER-TOP BURNERS
31-10455 31-10455 INSTALLATION INSTRUCTION
31-10444 31-10444 INSTALLATION INSTRUCTION
WB35T10053 WB35T10053 INSULATION GLASS TOP
WB35T10055 WB35T10055 INSULATION SDE
WB35T10056 WB35T10056 INSULATION SDE
WB62T10128 WB62T10128 MAINTOP ASSEMBLY BISQUE
WB62T10113 WB62T10113 MAINTOP ASSEMBLY WHITE
WB57T10157 WB57T10157 MAINTOP BLACK
WB02T10104 WB02T10104 MAINTOP SUPPORT
WB28T10038 WB28T10038 MANIFOLD INLET
WB28T10024 WB28T10024 MANIFOLD PIPE
49-80041 49-80041 MANUAL-USE & CARE
31-13840 31-13840 MINI MANUAL W/WIRE DIAG
WB02T10097 WB02T10097 MODULE BRACKET
WB35T10049 WB35T10049 MODULE INSULATION
WB28T10028 WB28T10028 ORIFICE SPUD ASSEMBLY
WB28K10288 WB28K10288 ORIFICE SPUD ASSEMBLY-LP
WB28T10017 WB28T10017 ORIFICE SPUD ASSEMBLY-LP
WB28T10014 WB28T10014 ORIFICE SPUD LT FRT
WB02T10244 WB02T10244 PAD FELT
WB19T10078 WB19T10078 PRESSURE REGULATOR
WB08K5040 WB08K5040 RANGE CORD
WB8K5040 WB8K5040 RANGE CORD
WB01X1121 WB01X1121 SCREW
WB01X1137 WB01X1137 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WH2X930 WH2X930 SCREW
WB01T10049 WB01T10049 SCREW 6-32 MCH FHT15 984
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB1X1137 WB1X1137 SCREW-10AB
WB1X1121 WB1X1121 SCREW-VLVE
WB13K25 WB13K25 SPARK MODULE
WB13K0025 WB13K0025 SPARK MODULE 4+0
WB2K5275 WB2K5275 STRAIN RELEF
WB02K5275 WB02K5275 STRAIN RELIEF-RT ANGLE
WB18T10178 WB18T10178 SWITCH HARNESS
WB1K5192 WB1K5192 TRIM SCREW
WB01K5192 WB01K5192 TRIM SCREW-CHROME
WB04K5003 WB04K5003 VALVE GASKET
