Model Image
Manufacturer

GE

Model Number

JGRS06BEJ1BB

Description

Gas Range Or Dual Fuel

Interactive Exploded View

Parts List

Part Number Description
WB02X9014 WB02X9014 AIR SHUTTER
WB2X9014 WB2X9014 AIR SHUTTER
WB01X1124 WB01X1124 AIR SHUTTER SCREW
WB2X7694 WB2X7694 BAIL
WB38K5036 WB38K5036 BARRIER
WB63K5099 WB63K5099 BODY SIDE
WB1X1156 WB1X1156 BOLT
WB49T10001 WB49T10001 BOTTOM BRO DRAWER
WB02X9634 WB02X9634 BOTTOM CHANNEL
WB63T10038 WB63T10038 BOTTOM MAIN
WB2K5406 WB2K5406 BRACKET
WB02T10250 WB02T10250 BRACKET CNTL MTG 24
311689 311689 BRACKET-IGN
WB09X0240 WB09X0240 BRO DRAWER SPRING
WB55T10014 WB55T10014 BROILER DOOR LINING
WB14K5018 WB14K5018 BROILER DRAWER HINGE-LT
WB14K5019 WB14K5019 BROILER DRAWER HINGE-RT
WB49T10003 WB49T10003 BROILER PAN GRID
WB02T10117 WB02T10117 BTM TRIM CLIP
WB63K5198 WB63K5198 CABINET TOP
WB35K5066 WB35K5066 CABINET TOP INSULATION
WB35K5130 WB35K5130 CABINET TOP INSULATION
WB2X9634 WB2X9634 CHANNEL
WB02X9573 WB02X9573 CLIP
WB01K5209 WB01K5209 CLIP
WB2X9020 WB2X9020 CLIP
WB1K5209 WB1K5209 CLIP
WB2X9573 WB2X9573 CLIP
WB02X9020 WB02X9020 CLIP CABLE NYLON
WB37K5041 WB37K5041 CONTROL HOUSING
WB37K5040 WB37K5040 CONTROL HOUSING TOP
WB27X27464 WB27X27464 CONTROL OVEN ERC3
WB02K5406 WB02K5406 CONTROL PANEL BRACKET
WB21K5009 WB21K5009 CONTROL VALVE
WB02X9152 WB02X9152 COVER
WB2X9152 WB2X9152 COVER
WB02K5164 WB02K5164 CUP LIGHT SUPPORT
WB35K5054 WB35K5054 DOOR INSULATION
WB14X0115 WB14X0115 DOOR LATCH-BURNER BOX BOTTOM
WB58T10003 WB58T10003 DRAWER BRO ASM W/RLRS
WB39M0003 WB39M0003 DRAWER GUIDE ASM-LT
WB39M0004 WB39M0004 DRAWER GUIDE ASM-RT
WB39M4 WB39M4 DRWR GD ASM
WB39M3 WB39M3 DRWR GD ASM
WB27T10589 WB27T10589 FACEPLATE GRAPHICS ASM
WB38T10003 WB38T10003 FLUE DEFLECT
WB04K5005 WB04K5005 FLUE GASKET
WB4K5005 WB4K5005 FLUE GASKET
WB56T10162 WB56T10162 FRAME OVN DR (BLK)
WB63T10017 WB63T10017 FRONT FRAME
WB04T10039 WB04T10039 GASKET OVN DR
WB36X0779 WB36X0779 GLASS DOOR-CENTER
WB15T10122 WB15T10122 GLASS OVN DR OTR 24(BLK)
WB02K5147 WB02K5147 GLASS SPACER
WB36X779 WB36X779 GLASS-CENTER
WB15T10121 WB15T10121 HANDLE GE 24 (BLK)
WB34K5249 WB34K5249 HEAT SHIELD
WB1X1153 WB1X1153 HEX NUT
WB10T10061 WB10T10061 HINGE OV DR LT
WB10T10060 WB10T10060 HINGE OV DR RT
WB02X9162 WB02X9162 IGNITER BRACKET-BAKE
WB02X9154 WB02X9154 IGNITER-BROIL/OVEN
WB2X9154 WB2X9154 IGNITR BR/OV
WB2K5168 WB2K5168 INS SIDE RET
31-10585 31-10585 INSTRUCTION INSTALL
WB02X9032 WB02X9032 INSULATION
WB2X9430 WB2X9430 INSULATION
WB02K5168 WB02K5168 INSULATION SIDE RETAINER
WB35K5059 WB35K5059 INSULATION TOP & SIDES
WB35K5065 WB35K5065 INSULATION-TOP/BACK
WB01X1117 WB01X1117 INVERTED NUT 3/8""
WB36X192 WB36X192 LAMP COV ASM
WB14X115 WB14X115 LATCH
WB02X9635 WB02X9635 LEVELING LEG
WB2X9635 WB2X9635 LEVELING LEG
WB2K5164 WB2K5164 LGHT CUP SUP
WB02X7694 WB02X7694 LIGHT CAMERA LENS BAIL
WB24T10067 WB24T10067 LIMIT SWITCH-LOWER
WB55T10145 WB55T10145 LINING OVEN DR ASSEMBLY LWR
WB56T10007 WB56T10007 LO FRT FRAME PNL-BLACK
WB15K5027 WB15K5027 LO FRT PANEL HANDLE-BLACK
WB56T10008 WB56T10008 LO FRT PANEL-BLACK
WB02K5364 WB02K5364 LOCK LEVER COVER
WB2K5364 WB2K5364 LOCK LVR CVR
WB63K5095 WB63K5095 MAIN BACK
31-14210 31-14210 MANUAL MINI & WD ASM
49-80230 49-80230 MANUAL USE & CARE
WB2X9096 WB2X9096 N/L/A 07/22/05
WB01X1153 WB01X1153 NUT
WB1X1117 WB1X1117 NUT-INVERTED
WB2K5165 WB2K5165 ORIF FIT PLT
WB02K5165 WB02K5165 ORIFICE FITTING PLATE
WB02K5166 WB02K5166 OV BTM INSUL RETAINER
WB34X38846 WB34X38846 OV BURN BAFFLE-UPPER
WB64K5036 WB64K5036 OV BURN BOX SIDE-LT
WB64K5035 WB64K5035 OV BURN BOX SIDE-RT
WB02K5159 WB02K5159 OV DR INS RETAINER
WB8X303 WB8X303 OV LAMP HLDR
WB08X0303 WB08X0303 OV LAMP HOLDER
WB2K5166 WB2K5166 OVBT INS RET
WB2K5159 WB2K5159 OVDR INS RET
WB63T10018 WB63T10018 OVEN BODY
WB63T10019 WB63T10019 OVEN BOTTOM
WB16K5014 WB16K5014 OVEN BURNER ASSEMBLY
WB02T10037 WB02T10037 OVEN LIGHT CUP
WB48X0218 WB48X0218 OVEN RACK
WB63T10016 WB63T10016 OVEN TOP COVER
WB56K10048 WB56K10048 OVERLAY PNL LWR (BLACK)
WB1X371D WB1X371D PACKAGE OF 12 CERAMIC WIRE NUT
WB49T10002 WB49T10002 PAN BRO
WB36T10756 WB36T10756 PANEL CNTL SWO (SCR-BLK)
WB2K5395 WB2K5395 PLATE REINFO
WB2X9587 WB2X9587 PLUG
WB02X9587 WB02X9587 PLUG BUTTON-ROUND
WB48T10094 WB48T10094 RACK OVEN
WB08K5039 WB08K5039 RANGE CORD
WB8K5039 WB8K5039 RANGE CORD
WB36X0389 WB36X0389 RANGE OVEN BULB COVER
WB2K5343 WB2K5343 REG SUPPORT
WB19T10079 WB19T10079 REGULATOR CONVERT PRESS
WB34K5181 WB34K5181 REGULATOR COVER
WB02K5343 WB02K5343 REGULATOR SUPPORT
WB02K5395 WB02K5395 REINFORCEMENT PLATE
WB02T10019 WB02T10019 RETAINER INSLN RR
WB01X1173 WB01X1173 RIVET
WB1X1173 WB1X1173 RIVET
WB02X9638 WB02X9638 ROLLER-DRAWER
WB01X32746 WB01X32746 SCR ST 8A8 X .625 TR NI
WB34T10066 WB34T10066 SCREEN FAN
WB01X1137 WB01X1137 SCREW
WB01X1127 WB01X1127 SCREW
WB01X1179 WB01X1179 SCREW
WB01X1141 WB01X1141 SCREW
WB01M0001 WB01M0001 SCREW
WB01K5028 WB01K5028 SCREW
WB01K5162 WB01K5162 SCREW
WB1X1334 WB1X1334 SCREW
WB1X1179 WB1X1179 SCREW
WB1X1293 WB1X1293 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WB1X536 WB1X536 SCREW
WB1K60 WB1K60 SCREW 8-18
WB01K0060 WB01K0060 SCREW 8-18 (BK) 1/2 S
WB1K5167 WB1K5167 SCREW 8-18 X 3/8
WB01K5167 WB01K5167 SCREW 8-18 X 3/8""
WB1K5191 WB1K5191 SCREW FL ZNC 10-32
WB01K5191 WB01K5191 SCREW FLAT ZINC 10-32
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB01X1293 WB01X1293 SCREW TC10-32X.250HEXNI
WB01X1424 WB01X1424 SCREW, TRANSFORMER
WB1X1137 WB1X1137 SCREW-10AB
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB1X1141 WB1X1141 SCREW-8-32
WB1X1124 WB1X1124 SCREW-ADJUST
WB01X1180 WB01X1180 SCREW-BLACK
WB1K5162 WB1K5162 SCREW-BLACK
WB1K5165 WB1K5165 SCREW-BLACK
WB01K5165 WB01K5165 SCREW-BLK
WB1K5157 WB1K5157 SCREW-BLK
WB01X1174 WB01X1174 SCREW-NICKLE
WB1X1424D WB1X1424D SCREW-PKG 12
WB21X5301 WB21X5301 SENSOR ASSEMBLY
WB01X1156 WB01X1156 SHOULDER BOLT
WB2K5147 WB2K5147 SPACER
WB02T10166 WB02T10166 SPACER FRT TRIM (BLK)
WB9X240 WB9X240 SPRING
WB09T10008 WB09T10008 SPRING OVEN DR LWR
WB07T10373 WB07T10373 TRIM FRT FRM LWR
WB28K5026 WB28K5026 TUBE ASM
WB34K5096 WB34K5096 VALVE COVER
WB34K5212 WB34K5212 VALVE WIRE COVER
WB38T10010 WB38T10010 VENT BOX
WB7K5108 WB7K5108 VENT TRIM EX
WB07K5108 WB07K5108 VENT TRIM EXTENSION
WB7K5477 WB7K5477 VENT TRIM-BL
WB07K5477 WB07K5477 VENT TRIM-BLACK
WB7K5278 WB7K5278 VERT SD TRIM
WB07K5278 WB07K5278 VERTICAL SIDE TRIM-BLK
WB01K5174 WB01K5174 WASHER
WB1X1256 WB1X1256 WASHER
WB1K5174 WB1K5174 WASHER
WB01X1256 WB01X1256 WASHER SPRING
WB1X681 WB1X681 WB01X0681
WB01X1181 WB01X1181 WIRE CONNECTOR
WB02X9665 WB02X9665 WIRE COVER
WB2X9665 WB2X9665 WIRE COVER
WB01X1413 WB01X1413 WOOD SCREW-BLK
