Model Image
Manufacturer

GE

Model Number

JGSP42DET2WW

Description

Gas Range Or Dual Fuel

Interactive Exploded View

Parts List

Part Number Description
WB1K5200 WB1K5200 340531
WB02X9014 WB02X9014 AIR SHUTTER
WB2X9014 WB2X9014 AIR SHUTTER
WB01X1124 WB01X1124 AIR SHUTTER SCREW
WB29K10024 WB29K10024 ASM BURNER CAP (12000)
WB29K10022 WB29K10022 ASM BURNER CAP (5000)
WB29K10023 WB29K10023 ASM BURNER CAP (9500)
WB34T10078 WB34T10078 BAFFLE BRO BURN-UPPER
WB02T10345 WB02T10345 BAFFLE BURNER
WB39T10012 WB39T10012 BASE RIVET ASM
WB26T10041 WB26T10041 BLOWER TANGENTIAL 60MM
WB64T10068 WB64T10068 BOTTOM BURN BOX
WB63T10101 WB63T10101 BOTTOM FALSE
WB53T10006 WB53T10006 BOX OVN BURN
WB02T10578 WB02T10578 BRACKET ANTITIP ASM
WB02T10341 WB02T10341 BRACKET BLOWER
WB02K10082 WB02K10082 BRACKET COOKTOP XL
WB02T10190 WB02T10190 BRACKET REGULATOR
WB02T10270 WB02T10270 BRACKET SWITCH
WB16T10046 WB16T10046 BURNER 12K
WB13T10035 WB13T10035 BURNER CAP LT FRT -SBK
WB16K10055 WB16K10055 BURNER MEDIUM (9500)
WB16T10022 WB16T10022 BURNER OVN BAKE ASM
WB16T10021 WB16T10021 BURNER OVN BROIL ASM
WB28K10222 WB28K10222 CAP BURNER ASM (15K)
WB02K10362 WB02K10362 CKT BRACKET MDM AND LGE
WB02K10361 WB02K10361 CKT BRACKET MEDIUM
WB02K10360 WB02K10360 CKT BRACKET SMALL
WB6X93 WB6X93 CLAMP
WB01K5209 WB01K5209 CLIP
WB1K5209 WB1K5209 CLIP
WB27T10833 WB27T10833 CONTROL OVEN (ERC3B)
WB02X10742 WB02X10742 CONTROL PANEL GASKET
WB02X9152 WB02X9152 COVER
WB02K5365 WB02K5365 COVER
WB2X9152 WB2X9152 COVER
WB2K5365 WB2K5365 COVER
WB02T10347 WB02T10347 COVER DUCT
WB31T10133 WB31T10133 COVER VENT
WB01T10022 WB01T10022 DOOR BUMPER
WB57T10344 WB57T10344 DOOR OTR ASM 30 (WH)
WB01T10026 WB01T10026 DOOR PAD
WB55T10180 WB55T10180 DRAWER BODY ASM
WB48T10013 WB48T10013 DRAWER SUPPORT FRT
WB01K10037 WB01K10037 ECONOMIC NUT
WB28T10091 WB28T10091 ELBOW
WB13K10014 WB13K10014 ELECTRODE TOP
WB07T10694 WB07T10694 EXTENSION REAR
WB07T10537 WB07T10537 EXTENSION SIDE
WB07T10536 WB07T10536 EXTENSION SIDE
WB27T11404 WB27T11404 FACEPLATE (SCR-WH)
WB02T10189 WB02T10189 FITTING BR ORIF
WB63T10083 WB63T10083 FRAME FRT LOWER
WB02X10744 WB02X10744 GASKET FACEPLATE
WB02T10320 WB02T10320 GASKET MAINTOP LH
WB02T10319 WB02T10319 GASKET MAINTOP RH
WB04T10050 WB04T10050 GASKET OVEN DOOR
WB04T10055 WB04T10055 GASKET VENT
WB31T10135 WB31T10135 GRATE CAST ASSEMBLY LEFT
WB31T10134 WB31T10134 GRATE CAST ASSEMBLY RIGHT
WB02T10461 WB02T10461 GRATE FOOT
WB02T10489 WB02T10489 GROMMET
WB15T10188 WB15T10188 HANDLE (WH)
WB18T10392 WB18T10392 HARNESS SWITCH
WB18T10521 WB18T10521 HARNESS WIRE CONTROL
WB18T10439 WB18T10439 HARNESS WIRE SPK MODULE
WB10T10075 WB10T10075 HINGE DOOR LT
WB10T10074 WB10T10074 HINGE DOOR RT
WB10T10097 WB10T10097 HINGE MAINTOP LEFT
WB10T10096 WB10T10096 HINGE MAINTOP RT
WB13T10045 WB13T10045 IGNITER ASM
WB36T10669 WB36T10669 INSERT PNL CNTL
31-10737 31-10737 INSTRUC INSTALL FRENCH
31-10738 31-10738 INSTRUC INSTALL SPANISH
31-10675 31-10675 INSTRUCTION INSTALL
31-10643 31-10643 INSTRUCTION LP
WB35T10090 WB35T10090 INSULATION BACK & BTM
WB35T10233 WB35T10233 INSULATION BBB HARNESS
WB35T10091 WB35T10091 INSULATION COMP SHLD
WB35K10025 WB35K10025 INSULATION OVEN DR SDE
WB35T10226 WB35T10226 INSULATION OVN DR SDE
WB35T10187 WB35T10187 INSULATION TOP
WB35T10089 WB35T10089 INSULATION TOP & SDS OTR
WB35T10164 WB35T10164 INSULATION VNT TBE
WB35K5112 WB35K5112 INSULATOR MODULE
WB27T11215 WB27T11215 KEYPANEL SUPT ASM (WH)
WB07T10681 WB07T10681 KIT BACKSPALSH (WH)
WB49T10014 WB49T10014 KIT CONVERSION ASM
WB03T10198 WB03T10198 KNOB GAS VLV (PRF)
WB49X29679 WB49X29679 LAMO HALOGEN
WB25T10096 WB25T10096 LAMP HALOGEN ASM
WB14T10069 WB14T10069 LATCH OVN
WB02X10521 WB02X10521 LEG LEVELER
WB25T10027 WB25T10027 LENS OVEN LAMP
WB55T10179 WB55T10179 LINING OVN DR ASM
WB01K5046 WB01K5046 LOCKWASHER
WB61T10164 WB61T10164 MAINTOP
WB28T10084 WB28T10084 MANIFOLD PIPE
31-14857 31-14857 MANUAL MINI & WD ASM
49-80600 49-80600 MANUAL USE & CARE
WB13T10046 WB13T10046 MODULE SPARK (4+0)
WB28T10206 WB28T10206 ORIFICE SPUD
WB28T10207 WB28T10207 ORIFICE SPUD
WB28T10196 WB28T10196 ORIFICE SPUD 130 NG
WB28T10197 WB28T10197 ORIFICE SPUD 145 NG
WB28T10198 WB28T10198 ORIFICE SPUD 65 LP
WB28T10199 WB28T10199 ORIFICE SPUD 85 LP
WB28T10200 WB28T10200 ORIFICE SPUD 90 LP
WB28T10195 WB28T10195 ORIFICE SPUD 95 NG
WB56X22160 WB56X22160 PACK WINDOW ASSEMBLY
WB02T10234 WB02T10234 PANEL ACCESS WIRE
WB36T11011 WB36T11011 PANEL CONTROL ASM (WH)
WB56T10268 WB56T10268 PANEL DRAWER
WB48T10095 WB48T10095 RACK OVEN
WB08K5039 WB08K5039 RANGE CORD
WB8K5039 WB8K5039 RANGE CORD
WB01K10112 WB01K10112 RANGE ELECTRODE CLIP
WB10T10083 WB10T10083 RECEIVER HINGE
WB19T10074 WB19T10074 REGULATOR CONVERT PRESS
WB02T10183 WB02T10183 RETAINER GLASS (WHT)
WB02T10342 WB02T10342 RETAINER INSLN BACK
WB02T10454 WB02T10454 RETAINER INSLN BTM
WB02T10371 WB02T10371 RETAINER INSLN OVN DR
WB02T10284 WB02T10284 RETAINER INSLN SDE
WB02T10344 WB02T10344 RETAINER INSLN TOP
WD02X10208 WD02X10208 SCR 1032 TT HXW 7/16 S
WH02X0941 WH02X0941 SCR 8-15 A HXW 7/8 S
WH02X1186 WH02X1186 SCR 8-18 AB IHW 5/8 S
WB01X0500 WB01X0500 SCR 8-18 B HXW 1/4 S
WB01X1178 WB01X1178 SCREW
WB01K5200 WB01K5200 SCREW
WB01X1428 WB01X1428 SCREW
WB01K0001 WB01K0001 SCREW
WB01K5028 WB01K5028 SCREW
WB01X1137 WB01X1137 SCREW
WB01M0001 WB01M0001 SCREW
WB1K5119 WB1K5119 SCREW
WB1X1178 WB1X1178 SCREW
WH2X1186 WH2X1186 SCREW
WB1M1 WB1M1 SCREW
WB1X536 WB1X536 SCREW
WH2X930 WH2X930 SCREW
WB01X5364 WB01X5364 SCREW (CR)
WB01T10048 WB01T10048 SCREW 10-16 SHLDR TYPE A
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10017 WB01T10017 SCREW 8-18 AB IHW 3/8 S NS
WB1X5364 WB1X5364 SCREW MTG
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB1X1137 WB1X1137 SCREW-10AB
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB1X1124 WB1X1124 SCREW-ADJUST
WB01X1118 WB01X1118 SCREW-NICKEL
WH2X941D WH2X941D SCREW-PKG 12
WB1X500D WB1X500D SCREW-PKG 12
WB01K5185 WB01K5185 SCREW-WHITE
WB1K5185 WB1K5185 SCREW-WHITE
WB21X22134 WB21X22134 SENSOR ASSEMBLY
WB34T10080 WB34T10080 SHIELD COMPRT
WB02T10188 WB02T10188 SHIELD ORIFICE
WB02T10034 WB02T10034 SIDE PANEL SUPPORT
WB16K10070 WB16K10070 SMALL BURNER V 5K
WB02T10452 WB02T10452 SPACER REINFORCEMENT
WB02T10453 WB02T10453 STUD COMPOSITE
WB02T10192 WB02T10192 SUPPORT FALSE BTM
WB26T10015 WB26T10015 SUPPORT OVN CAV
WB02X33180 WB02X33180 SUPPORT REAR
WB02T10411 WB02T10411 SUPPORT SIDE PANEL
WB24T10140 WB24T10140 SWITCH LIMIT (L1)
WB24T10160 WB24T10160 SWITCH SPDT HIGH AMP
WB07T10500 WB07T10500 TRIM ASM
WB07T10516 WB07T10516 TRIM FRT FRM (BK)
WB07T10523 WB07T10523 TRIM VERT SDE LEFT (WHITE)
WB07T10522 WB07T10522 TRIM VERT SDE RT (WH)
WB07T10636 WB07T10636 TRIM VERT SIDE LT (WH)
WB07T10635 WB07T10635 TRIM VERT SIDE RT (WHITE)
WB28T10205 WB28T10205 TUBE (7/16)
WB28T10093 WB28T10093 TUBE 3/8
WB28T10094 WB28T10094 TUBE 3/8
WB28T10095 WB28T10095 TUBE 3/8
WB28T10188 WB28T10188 TUBE BURNER ASM
WB28T10189 WB28T10189 TUBE BURNER ASM
WB28T10204 WB28T10204 TUBE BURNER ASM
WB28T10190 WB28T10190 TUBE BURNER ASM
WB28T10203 WB28T10203 TUBE OVEN VENT
WB06X0093 WB06X0093 VALVE CLAMP
WB21T10014 WB21T10014 VALVE CNTL
WB21X22072 WB21X22072 VALVE GAS LT RR
WB21X22079 WB21X22079 VALVE KIT
WB21X22071 WB21X22071 VALVE KIT
WB38T10023 WB38T10023 VENT CAP
WB16K10062 WB16K10062 VISION BURNER XL
WB1K5046 WB1K5046 WASHER
WB48T10068 WB48T10068 WEDGE DRAWER
WB63T10102 WB63T10102 WRAPPER OVN CAV ASM
WZ4X416 WZ4X416 WZ04X0408
