Model Image
Manufacturer

GE

Model Number

JGSS66EEL5ES

Description

Gas Range Or Dual Fuel

Interactive Exploded View

Parts List

Part Number Description
40A15 40A15 40A15
WB29K10023 WB29K10023 ASM BURNER CAP (9500)
WB16X28654 WB16X28654 ASM. CAP, BURNER SMALL V2
WB34X28912 WB34X28912 BACKGUARD COMPLEMENT
WB02X29637 WB02X29637 BADGE ASM
WB02K0027 WB02K0027 BAIL
WB07X28885 WB07X28885 BARRIER DOOR
WB63K10187 WB63K10187 BOTTOM INNER GUARD
WB35X37970 WB35X37970 BOTTOM OVEN AND DEFLECTOR ASM
WB02K0032 WB02K0032 BOTTOM OVEN BRACKT SUPPO
WB38K0002 WB38K0002 BRACE VENT
WB34X28665 WB34X28665 BRACKET
WB34X28238 WB34X28238 BRACKET
WB02K10254 WB02K10254 BRACKET ANTI-TIP ASM
WB02X24742 WB02X24742 BRACKET DRAWER
WB02K0041 WB02K0041 BRACKET OVEN CORNER
WB34X36828 WB34X36828 BRACKET SPARK MODULE
WB02X24790 WB02X24790 BUMPER
WB16X28250 WB16X28250 BURNER BAKE
WB16X28251 WB16X28251 BURNER BROIL
WB16X24724 WB16X24724 BURNER, MEDIUM V2
WB16X24721 WB16X24721 BURNER, SMALL V2
WB16X24722 WB16X24722 BURNER, XL V2
WB28K10222 WB28K10222 CAP BURNER XL
WB02K10360 WB02K10360 CKT BRACKET SMALL
WB01X24735 WB01X24735 CKT SCREW
WB02K0036 WB02K0036 CLAMP CABLE
WB02K0031 WB02K0031 CLIP CABLE
WB02K0056 WB02K0056 CLIP WINDOW
WB02K10267 WB02K10267 CLIP WIRE
WB02X24976 WB02X24976 CLIP, IGNITER V2
WB01X0119 WB01X0119 CONTOURED WASHER
WB27X44727 WB27X44727 CONTROL OVEN TO9 (GAS)
WB34K0016 WB34K0016 COVER BACK
WB34X21575 WB34X21575 COVER BACK
WB34X24753 WB34X24753 COVER IGNITOR
WB63K10040 WB63K10040 COVER TERMINAL
WB56X23809 WB56X23809 CRYSTAL WINDOW
WB16X28686 WB16X28686 CTR ORIFICE HOLDER
WB35X28981 WB35X28981 CTRL INSULATION HOUSING
WB62X28233 WB62X28233 DARK DORIAN GRAY RANGE TOP
WB07X29147 WB07X29147 DARK DORIAN GRAY TRIM DOOR
WB34X28689 WB34X28689 DEFLECTOR
WB34X28968 WB34X28968 DEFLECTOR INNER DOOR
WB58K10015 WB58K10015 DRAWER BODY
WB02K10163 WB02K10163 DRAWER SUPPORT
WB01K10037 WB01K10037 ECONOMIC NUT
WB28X28697 WB28X28697 ELBOW 90 ASM
WB18X33922 WB18X33922 ELECTRODE TOP & HARNESS HV
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB34X28749 WB34X28749 FRONT SUPPORT LH
WB34X28747 WB34X28747 FRONT SUPPORT RH
WB35X29668 WB35X29668 GASKET ASM DOOR
WB32K0005 WB32K0005 GASKET OVEN LIGHT
WB56X30061 WB56X30061 GLASS OVEN DOOR ASM
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB02X26847 WB02X26847 GLIDER DRAWER
WB31X28755 WB31X28755 GRATE ASM
WB31X24738 WB31X24738 GRIDDLE ALUMINUM
WB2K8 WB2K8 GROMMET
WB63K0016 WB63K0016 GUARD BOTTOM
WB56K0012 WB56K0012 GUARD INSULATION
WB18X27594 WB18X27594 HARNESS GROUND
WB18X28762 WB18X28762 HARNESS SWITCHES
WB10X21659 WB10X21659 HINGE DOOR
WB08K0001 WB08K0001 HOUSING RECEPTACLE
WB13X24755 WB13X24755 IGNITER GLOWBAR
WB13X25500 WB13X25500 IGNITER GLOWBAR
WB13X24741 WB13X24741 IGNITION MODULE
WB02X24727 WB02X24727 INJET, MEDIUM V2
WB02X24728 WB02X24728 INJET, SMALL V2
WB02X24725 WB02X24725 INJET, XL V2
WB35K10150 WB35K10150 INSULATION BOTTOM DOOR
WB35X21579 WB35X21579 INSULATION FRONT DOOR
WB35X20370 WB35X20370 INSULATION OVEN BACK
WB35K10149 WB35K10149 INSULATION SIDE DOOR
WB35X28971 WB35X28971 INSULATION SIDE DOOR
WB28X29255 WB28X29255 KIT LP HIGH ALTITUDE ASM
WB28X29254 WB28X29254 KIT NG HIGH ALTITUDE ASM
WB02K10182 WB02K10182 LEG LEVELER
WB28X28865 WB28X28865 LF ORIFICE HOLDER
WB18X28854 WB18X28854 LINE CORD
WB56X30421 WB56X30421 LINER ASM WELD DOOR
WB34K10086 WB34K10086 LOWER HEAT SHIELD
WB28X39149 WB28X39149 LP CONVERSION KIT
WB28X28142 WB28X28142 LR ORIFICE HOLDER
WB36X29269 WB36X29269 MANIFOLD PANEL LOWER
WB28X43248 WB28X43248 MANIFOLD PIPE ASM
WB28X43250 WB28X43250 MANIFOLD PIPE ASM
WB16K10076 WB16K10076 OVAL BURNER ASM
WB48X20249 WB48X20249 OVEN RACK
WB07X26701 WB07X26701 OVERLAY T09
WB55X30422 WB55X30422 PANEL ASM WELD
WB56X20809 WB56X20809 PANEL BACKER
WB36X28810 WB36X28810 PANEL COMPLEMENT
WB56X24821 WB56X24821 PANEL DRAWER
WB36X28858 WB36X28858 PANEL MANIFOLD SHIELD
WB36X28223 WB36X28223 PANEL MANIFOLD UPPER
WB63K10203 WB63K10203 PANEL REAR BROIL
WB56X28847 WB56X28847 PANEL SIDE
WB24X28840 WB24X28840 PLUNGER SWITCH DUAL
31-11060 31-11060 PM INSTALL INSTRUCTIONS
31-11084 31-11084 PM INSTALL INSTRUCTIONS
31-10781 31-10781 PM INSTALL INSTRUCTIONS
31-2001115 31-2001115 PM MINI MANUAL AND WIRING
49-2000316 49-2000316 PM OWNERS MANUAL
49-2001040 49-2001040 PM QUICK OWNERS MANUAL
WB39K0016 WB39K0016 RAIL DRAWER
WB63X28837 WB63X28837 RANGE BACK
WB10X20220 WB10X20220 RECEIVER HINGE
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB28X28144 WB28X28144 RF ORIFICE HOLDER
WB28X28147 WB28X28147 RR ORIFICE HOLDER
WB01K10067 WB01K10067 SCR 8 HD 1/4 - 20
WB01K10086 WB01K10086 SCR 8-18 AB TRP 3/8 SS
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB01K0033 WB01K0033 SCREW
WR01X10065 WR01X10065 SCREW
WB01K10091 WB01K10091 SCREW
WB01X31119 WB01X31119 SCREW #8-18
WB01K0042 WB01K0042 SCREW (BLK)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01X37565 WB01X37565 SCREW 10-32
WB01X37587 WB01X37587 SCREW 10-32 HSW 1/2
WB01T10008 WB01T10008 SCREW 10-32 TR T
WZ04X0345 WZ04X0345 SCREW 8-18X5/8 HXW
WB01X1261 WB01X1261 SCREW GROUND
WB01K0050 WB01K0050 SCREW MTG IGNITER
WB35X21708 WB35X21708 SEAL VALVE
WB24X25557 WB24X25557 SENSOR ASM
WB02K10156 WB02K10156 SPACER
WB16X20448 WB16X20448 SPACER BASE FRONT
WB16X20449 WB16X20449 SPACER BASE REAR
WB02X20849 WB02X20849 SPACER SIDE
WB15X35073 WB15X35073 STAINLESS STEEL HANDLE AND ENDCAP
WB03X42210 WB03X42210 STAINLESS STEEL KNOB BURNER
WB63X20216 WB63X20216 SUPPORT BASE LT
WB63X20215 WB63X20215 SUPPORT BASE RT
WB34X24779 WB34X24779 TRIM FRONT FRAME
WB07X28825 WB07X28825 TRIM KIT
WB28X28151 WB28X28151 TUBE BURNER BOX SUPPLY
WB28X24773 WB28X24773 TUBE BURNER SUPPLY
WB28X28158 WB28X28158 TUBE MANIFOLD SUPPLY
WB21X20612 WB21X20612 VALVE BURNER 270
WB21X20470 WB21X20470 VALVE BURNER 270
WB21X25979 WB21X25979 VALVE BURNER 270
WB21X20471 WB21X20471 VALVE BURNER 270
WB21X33225 WB21X33225 VALVE CONTROL ASM
WB07X28819 WB07X28819 VENT TRIM
WB07X28815 WB07X28815 VENT TRIM
WB34K10087 WB34K10087 WINDOW SPACER ASM
