Model Image
Manufacturer

GE

Model Number

JK29*08

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
WB49X0195 WB49X0195 AIR CHANNEL
WB02X2273 WB02X2273 ARM LH
WB2X2273 WB2X2273 ARM LH
WB02X2272 WB02X2272 ARM RH
WB2X2272 WB2X2272 ARM RH **NLA*
WB49X0265 WB49X0265 BACK INNER
WB44X0160 WB44X0160 BAKE UNIT
WB44X200 WB44X200 BAKE UNIT 240V L O
WB02X2033 WB02X2033 BARRIER
WB02X2114 WB02X2114 BARRIER
WB2X2033 WB2X2033 BARRIER **NLA*
WB02X2007 WB02X2007 BARRIER - TIMER
WB02X1986 WB02X1986 BARRIER FIBRE
WB2X2001 WB2X2001 BLADE FAN
WB02X2001 WB02X2001 BLADE FAN, UPPER
WB55X302 WB55X302 BOTTOM
WB02X1981 WB02X1981 BRACE DOOR LATCH
WB02X2119 WB02X2119 BRACKET
WB02X2056 WB02X2056 BRACKET
WB02X2259 WB02X2259 BRACKET
WB02X1801 WB02X1801 BRACKET
WB02X2826 WB02X2826 BRACKET - CAPILLARY TUBE
WB02X2846 WB02X2846 BRACKET FAN
WB02X2941 WB02X2941 BRACKET GASKET (08 UP)
WB02X2407 WB02X2407 BRACKET MEAT THERMO
WB02X2082 WB02X2082 BRACKET TRIM
WB02X1457 WB02X1457 BRACKET TRIM
WB02X2035 WB02X2035 BRKT. MOUNTING
WB02X2409 WB02X2409 BRKT. MT. BOARD
WB49X0088 WB49X0088 BROIL PAN
WB48X0035 WB48X0035 BROIL PAN RACK
WB2X1452 WB2X1452 BROIL SUPPT
WB44X173 WB44X173 BROIL UNIT
WB44X0168 WB44X0168 BROIL UNIT-208-V
WB44X0173 WB44X0173 BROIL UNIT-236-V
WB48X10056 WB48X10056 BROILER PAN&RACK LARGE 12-3/4
WB08X0163 WB08X0163 BUZZER
WB49X0223 WB49X0223 CAP TERMINAL GUARD
WB49X0270 WB49X0270 CASE TOP
WB2X2037 WB2X2037 CHANNEL **NLA*
WB59X0163 WB59X0163 CHANNEL BOTTOM
WB59X0167 WB59X0167 CHANNEL BOTTOM
WB02X2037 WB02X2037 CHANNEL DOOR LATCH - LOWER LA
WB02X2073 WB02X2073 CHANNEL DOOR LATCH - UPPER LA
WB02X1796 WB02X1796 CHANNEL GASKET LONG
WB02X1797 WB02X1797 CHANNEL GASKET SHORT
WB02X2401 WB02X2401 CHANNEL SIDE
WB02X2009 WB02X2009 CHNL. SHORT BTM. (02-03)
WB24X0151 WB24X0151 CIRCUIT BOARD P-7
WB02X1406 WB02X1406 CLAMP
WB2X1422 WB2X1422 CLAMP
WB02X2843 WB02X2843 CLAMP CONDUIT
WB02X1422 WB02X1422 CLAMP HARNESS
WB02X2006 WB02X2006 CLAMP HARNESS
WB01X0440 WB01X0440 CLIP
WB2X1862 WB2X1862 CLIP
WB2X1132 WB2X1132 CLIP
WB2X1867 WB2X1867 CLIP
WB2X2256 WB2X2256 CLIP **NLA*
WB02X1867 WB02X1867 CLIP ANTI-WOBBLE
WB02X1132 WB02X1132 CLIP CAP TUBE UPPER OVEN
WB02X2275 WB02X2275 CLIP CRYSTAL
WB02X0574 WB02X0574 CLIP INSULATOR
WB2X1659D WB2X1659D CLIP-PKG 12
WB2X574D WB2X574D CLIP-PKG 12
WB1X439D WB1X439D CLIP-PKG 12 **NLA*
WB24X125 WB24X125 COIL{{{N/L/A}}}
WR02X3198 WR02X3198 COMP. RING, EVAP. FAN
WB01X0119 WB01X0119 CONTOURED WASHER
WB07X0634 WB07X0634 CONTROL TRIM
WB02X1165 WB02X1165 COVER
WB49X0276 WB49X0276 COVER FAN
WB02X2845 WB02X2845 COVER LIGHT
WB02X1925 WB02X1925 COVER ROTO OPENING
WB02X0818 WB02X0818 COVER VENT
WB36X0277 WB36X0277 CRYSTAL
WB36X0236 WB36X0236 CRYSTAL
WB36X567 WB36X567 CRYSTAL KIT **NLA*
WB2X2845 WB2X2845 CVR LIGHT **NLA*
WB02X1973 WB02X1973 DEFLECTOR
WB2X1973 WB2X1973 DEFLECTOR
WB09X0101 WB09X0101 DOOR SPRING
WB07X0598 WB07X0598 ESCUTCHEON
WB55X305 WB55X305 EXT SIDE LH
WB55X0304 WB55X0304 EXT. SIDE - RH
WB49X0266 WB49X0266 EXTENSION SIDE
WB55X0305 WB55X0305 EXTENSION SIDE LH
WB02X2282 WB02X2282 FAN BLADE
WB2X2911 WB2X2911 FAN BLADE
WR60X114 WR60X114 FAN BLADE
WB26X0017 WB26X0017 FAN MOTOR
WB26X0035 WB26X0035 FAN MOTOR LOWER
WB56X1023 WB56X1023 FRAME ASM.
WB02X2848 WB02X2848 GASKET
WB02X2257 WB02X2257 GASKET
WB2X1815 WB2X1815 GASKET
WB2X1623 WB2X1623 GASKET
WB02X2076 WB02X2076 GASKET (02-03)
WB02X1543 WB02X1543 GASKET - BROIL
WB02X3138 WB02X3138 GASKET DOOR
WB02X1815 WB02X1815 GASKET ELIM. BTM.
WB02X2095 WB02X2095 GASKET FOIL
WB02X2849 WB02X2849 GASKET SUPPORT
WB02X2071 WB02X2071 GASKET, THICK
WB02X2280 WB02X2280 GASKET, THIN
WB02X1623 WB02X1623 GASKET, VENT
WB2X3138 WB2X3138 GASKET-DOOR
WB07X0697 WB07X0697 GRILL
WB07X0635 WB07X0635 GRILLE
WB7X635 WB7X635 GRILLE
WB55X0302 WB55X0302 GUARD BOTTOM
WB55X0223 WB55X0223 GUARD INSULATION
WB49X0268 WB49X0268 GUARD TERMINAL
WB02X2844 WB02X2844 GUARD THERMOSTAT
WB59X0165 WB59X0165 GUARD WIRE
WB02X2402 WB02X2402 GUARD WIRE
WB49X0269 WB49X0269 GUARDIAN
WB2X1460 WB2X1460 GUIDE
WB02X2251 WB02X2251 GUIDE & SPRING ASM RH
WB02X2252 WB02X2252 GUIDE L. SPRING ASM LH
WB02X1460 WB02X1460 GUIDE LEVER LOWER OVEN
WB02X2861 WB02X2861 GUSSET
WB15X0098 WB15X0098 HANDLE
WB15X0121 WB15X0121 HANDLE
WB15X80 WB15X80 HANDLE
WZ04X0209 WZ04X0209 HANDLE SCREW
WB15X0080 WB15X0080 HANDLE-BLADE
WB1X443 WB1X443 HEX NUT
WB01X0239 WB01X0239 HEX NUT PAL
WB10X0123 WB10X0123 HINGE LEVER LH
WB10X0122 WB10X0122 HINGE LEVER RH
WB2X6195 WB2X6195 HINGE PIN
WB10X121 WB10X121 HINGE SPT LH
WB10X120 WB10X120 HINGE SPT RH
WB2X1116 WB2X1116 HINGE STUD **NLA*
WB2X3466 WB2X3466 HOUS.LAMP
WB02X1608 WB02X1608 INDICATOR LAMP
WB59X0166 WB59X0166 INS. GUARD LH
WB02X2120 WB02X2120 INSTRUMENT BRACKET
WB2X8100 WB2X8100 INSUL-BACK
WB55X0204 WB55X0204 INSUL. GUARD RH
WB02X2116 WB02X2116 INSULATION
WB02X2270 WB02X2270 INSULATION
WB02X2267 WB02X2267 INSULATION
WB02X2013 WB02X2013 INSULATOR CERAMIC (2)
WB03X0268 WB03X0268 KNOB
WB03X0218 WB03X0218 KNOB - TIMER
WB03X0314 WB03X0314 KNOB CONTROL
WB03X0316 WB03X0316 KNOB CONTROL UPPER
WB02X2118 WB02X2118 KNOB RETAINER
WB03X0315 WB03X0315 KNOB SW. - UPPER
WB03X0317 WB03X0317 KNOB SWITCH UPPER
WB3X459 WB3X459 KNOB TIMER
WB02X1609 WB02X1609 LAMP CLEAN
WB36X192 WB36X192 LAMP COV ASM
WB36X0192 WB36X0192 LAMP COVER ASM
WB02X1977 WB02X1977 LAMP HOUSING
WB14X5035 WB14X5035 LATCH
WB02X2032 WB02X2032 LEVER LOCK
WB55X0342 WB55X0342 LINER - LOCK COVER A
WB55X0327 WB55X0327 LINER - LOCK CVR. ASM.(0
WB55X0229 WB55X0229 LINER - LOCK CVR.ASM.(02
WB55X0230 WB55X0230 LINER SMALL (02)
WB55X0326 WB55X0326 LINER SMALL (03-UP)
WB09X0127 WB09X0127 LINK
WB02X2250 WB02X2250 LINK
WB02X2072 WB02X2072 LOCK BAR - UPPER DOOR LATCH
WB2X2032 WB2X2032 LOCK LEVER
WB24X0131 WB24X0131 LOCK SWITCH
WB02X2036 WB02X2036 LOCKING BAR
WB2X2036 WB2X2036 LOCKING BAR **NLA*
WB09X0088 WB09X0088 LOCKWASHER
WB20X0050 WB20X0050 MEAT PROBE (09-UP)
WB20X0038 WB20X0038 METER
WB44X0162 WB44X0162 MULLION UNIT
WB15X121 WB15X121 N.L.A. HANDLE
WB2X1799 WB2X1799 N.L.A.PIN
WB19X114 WB19X114 N/L/A 02/10/99
WB2X818 WB2X818 N/L/A 02/11/02
WB2X2248 WB2X2248 N/L/A 02/12/09
WB2X2257 WB2X2257 N/L/A 03/16/99
WB24X108 WB24X108 N/L/A 03/24/04
WB3X385 WB3X385 N/L/A 04/26/94
WB26X5052 WB26X5052 N/L/A 05/26/06
WB3X381 WB3X381 N/L/A 05/30/97
WB21X180 WB21X180 N/L/A 07/15/04
WB2X3322 WB2X3322 N/L/A 08/13/02
WZ4X219D WZ4X219D N/L/A 09/25/03
WB2X1795 WB2X1795 N/L/A 10/04/06
WB24X134 WB24X134 N/L/A 10/07/03
WB24X160 WB24X160 N/L/A 10/27/95
WB10X156 WB10X156 N/L/A 11/03/97
WB2X3295 WB2X3295 N/L/A 11/28/05
WB24X130 WB24X130 N/L/A 12/18/02
WB2X3468 WB2X3468 NEON LAMP
WB2X1608 WB2X1608 NEON LAMP
WB2X2616 WB2X2616 NLA PART
WB01X0443 WB01X0443 NUT
WB9X88 WB9X88 OVEN HOOK
PM3X122 PM3X122 OVEN KNOB
WB53X0155 WB53X0155 OVEN LINER (06)
WB53X0197 WB53X0197 OVEN LINER (07 UP)
WB21X158 WB21X158 OVEN SENSOR
WB02X2825 WB02X2825 OVEN SENSOR GASKET
WB24X0160 WB24X0160 OVEN TEMPERATURE SWITCH
WB56X0776 WB56X0776 PANEL - AVOCADO
WB56X0778 WB56X0778 PANEL - BRUSHED CHROME
WB56X0777 WB56X0777 PANEL - DK. COPPER
WB56X0849 WB56X0849 PANEL - HARVEST
WB56X0772 WB56X0772 PANEL - WHITE
WB49X0275 WB49X0275 PARTITION FAN
WB02X1799 WB02X1799 PIN
WB02X1081 WB02X1081 PIN HINGE
WB02X1115 WB02X1115 PIN IN LEVER
WB02X1822 WB02X1822 PIVOT STUD
WB02X2842 WB02X2842 PLATE ADAPTER
WB2X1959 WB2X1959 PLUG **NLA*
WB02X1957 WB02X1957 PLUG BUTTON - LARGE
WB02X1959 WB02X1959 PLUG BUTTON - SMALL
WB20X0041 WB20X0041 PROBE MEAT
WB1X523 WB1X523 PUSH RIVET **NLA*
WB48X82 WB48X82 RACK
WB48X0082 WB48X0082 RACK OVEN
WB48X83 WB48X83 RACK REV **NLA*
WB02X2028 WB02X2028 RACK SLIDE
WB02X1994 WB02X1994 RACK SLIDE FASTENER
WB48X0083 WB48X0083 RACK-REVERSIBLE
WB20X0032 WB20X0032 RECEPTACLE
WB8X191 WB8X191 RECEPTACLE
WB20X55 WB20X55 RECEPTACLE
WB08X0159 WB08X0159 RECEPTACLE 75 W. LAMP
WB20X0049 WB20X0049 RECEPTACLE MEAT MTR. (09
WB49X0124 WB49X0124 REFLECTOR BOIL
WB02X2276 WB02X2276 REFLECTOR FOIL
WB21X0180 WB21X0180 RELAY, H.W.
WB2X1800 WB2X1800 RETAIN RING
WB2X1082 WB2X1082 RETAINER
WB02X1800 WB02X1800 RETAINER RING
WB24X0153 WB24X0153 RHEOSTAT
WB24X190 WB24X190 RHEOSTAT
WB02X1082 WB02X1082 RING RETAINING
WB01X0523 WB01X0523 RIVET PUSH MTG. GASKET
WZ09X0014 WZ09X0014 RIVET-MT. BOLT
WB02X1462 WB02X1462 ROLLER
WB2X1462 WB2X1462 ROLLER
WB26X0021 WB26X0021 ROTISSERIE MOTOR
WZ02X0492 WZ02X0492 SCR 10-24X1/2 TT TRR S
WZ04X0279 WZ04X0279 SCR 6-20 AB HXW 1/4 S
WZ04X0218 WZ04X0218 SCR 6-20 AB PH 3/8 S
WZ04X0289 WZ04X0289 SCR 8-18 AB HX 1/4 S
WZ04X0291 WZ04X0291 SCR 8-18 AB HXW 3/8 S
WZ04X0249 WZ04X0249 SCR 8-18 AB OVR 3/4 S
WZ04X0245 WZ04X0245 SCR 8-18 AB PHR 5/8 S
WZ06X0082 WZ06X0082 SCR 8-18 B HXW 3/8 S
WB01X0422 WB01X0422 SCR 8-18 T IHW 1/2 S
WZ05X0132 WZ05X0132 SCR 8-32 T HXW 5/16 S
WZ04X0237 WZ04X0237 SCREW
WB01X0524 WB01X0524 SCREW
WZ02X0513 WZ02X0513 SCREW
WB1X524 WB1X524 SCREW
WB1X272 WB1X272 SCREW
WB01X0438 WB01X0438 SCREW & WASHER ASM
WZ04X0294 WZ04X0294 SCREW 8--18X1/2 HEX-WASH
WZ04X0280 WZ04X0280 SCREW 8-18 HXW
WZ02X0503 WZ02X0503 SCREW 8-32 , 13-32
WZ05X0128 WZ05X0128 SCREW BOTTOM
WZ04X0304 WZ04X0304 SCREW DUCT
WB1X428 WB1X428 SCREW LEVER
WZ04X0278 WZ04X0278 SCREW MT. BRACKET
WZ04X0327 WZ04X0327 SCREW MT. BRKT. (04-UP)
WZ04X0282 WZ04X0282 SCREW MT. BRKT. TO TOP
WZ04X0222 WZ04X0222 SCREW MT. BRKT. TO TRIM
WZ02X0500 WZ02X0500 SCREW MT. COIL
WZ04X0292 WZ04X0292 SCREW MT. COVER
WZ04X0256 WZ04X0256 SCREW MT. GUIDE L.L.H. -
WZ05X0179 WZ05X0179 SCREW MT. HANDLE
WZ05X0131 WZ05X0131 SCREW MT. MOTOR
WB04X0231 WB04X0231 SCREW MT. STOP
WB01X0351 WB01X0351 SCREW MT. SUPPORT
WZ05X0152 WZ05X0152 SCREW MT. SWITCH
WZ02X0495 WZ02X0495 SCREW MT. SWITCH
WZ04X0231 WZ04X0231 SCREW MTG. GUIDE
WB01X0272 WB01X0272 SCREW THUMB
WB01X0428 WB01X0428 SCREW-BEARING
WZ4X360D WZ4X360D SCREW-PKG 12
WZ2X464D WZ2X464D SCREW-PKG 12
WB1X500D WB1X500D SCREW-PKG 12
WZ4X345D WZ4X345D SCREW-PKG 12
WZ4X237D WZ4X237D SCREW-PKG 12
WZ4X218D WZ4X218D SCREW-PKG 12
WZ5X132D WZ5X132D SCREW-PKG 12
WZ2X252D WZ2X252D SCREW-PKG 12
WZ4X230D WZ4X230D SCREW-PKG 12
WZ4X245D WZ4X245D SCREW-PKG 12
WZ5X120D WZ5X120D SCREW-PKG 12
WZ2X492D WZ2X492D SCREW-PKG 12
WZ4X338D WZ4X338D SCREW-PKG 12
WB1X438D WB1X438D SCREW-PKG 12
WZ4X284D WZ4X284D SCREW-PKG 12
WZ6X86D WZ6X86D SCREW-PKG 12 **NLA*
WB02X2274 WB02X2274 SEAL DOOR
WB21X0158 WB21X0158 SENSOR, OVEN
WB55X0218 WB55X0218 SHIELD
WB07X0519 WB07X0519 SHIELD
WB55X0303 WB55X0303 SHIELD AIR
WB2X2972 WB2X2972 SHIELD KIT
WB02X2847 WB02X2847 SHIELD WIRE
WB59X0164 WB59X0164 SIDE INNER
WB02X1167 WB02X1167 SKEWER ASM
WB2X1167 WB2X1167 SKEWER ASM
WB2X2794 WB2X2794 SLEEVE
WB02X2794 WB02X2794 SLEEVE ROLLER
WB02X2255 WB02X2255 SLIDE
WB2X2028 WB2X2028 SLIDE ASM **NLA*
WB02X2256 WB02X2256 SLIDE CLIP
WB29X0035 WB29X0035 SMOKE ELIMINATOR
WB24X0125 WB24X0125 SOLENOID COIL AM.
WB02X2012 WB02X2012 SPACER
WB02X2104 WB02X2104 SPACER
WB55X0227 WB55X0227 SPACER INSULATION
WB02X1659 WB02X1659 SPEEDNUT
WB02X1119 WB02X1119 SPEEDNUT
WB01X0439 WB01X0439 SPEEDNUT BRACKET
WB01X0455 WB01X0455 SPEEDNUT, CLAMP
WB2X1166 WB2X1166 SPIT SHAFT **NLA*
WB02X1166 WB02X1166 SPITBLADE
WB09X0099 WB09X0099 SPRING
WB2X2249 WB2X2249 SPRING
WB2X1983 WB2X1983 SPRING
WB02X1983 WB02X1983 SPRING HINGE LEVER
WB02X1117 WB02X1117 SPRING IN LEVER
WB02X2249 WB02X2249 SPRING TOGGLE
WB02X2269 WB02X2269 STOP INSULATION
WB09X0089 WB09X0089 STRIKE SPRING
WB02X1116 WB02X1116 STUD IN LEVER
WB02X1452 WB02X1452 SUPPORT BROIL
WB02X2827 WB02X2827 SUPPORT CAPILLARY BULB
WB10X0121 WB10X0121 SUPPORT HINGE LH
WB10X0120 WB10X0120 SUPPORT HINGE RH
WB48X0062 WB48X0062 SUPPORT SPIT
WB48X62 WB48X62 SUPT SPIT
WB2X2034 WB2X2034 SW ACTUATOR
WB24X131 WB24X131 SWITCH
WB22X53 WB22X53 SWITCH
WB24K2 WB24K2 SWITCH
WB22X55 WB22X55 SWITCH
WB02X2034 WB02X2034 SWITCH ACTUATOR
WB24X0130 WB24X0130 SWITCH DOOR LATCH (SLIDE)
WB24X0108 WB24X0108 SWITCH DOOR LATCH RELEASE
WB24X0105 WB24X0105 SWITCH, OVEN LIGHT
WB22X0055 WB22X0055 SWITCH, OVEN U.O.
WB22X0053 WB22X0053 SWITCH, OVEN U.O.
WB17X125 WB17X125 TERM BLOCK
WB17X0125 WB17X0125 TERMINAL BLOCK DIST.
WB24X0134 WB24X0134 THERMOSTAT, DUAL
WB19X0083 WB19X0083 TIMER
WB02X2079 WB02X2079 TIMER BRACKET
WB02X2248 WB02X2248 TOGGLE
WB20X44 WB20X44 TRANSFORMER
WB20X0044 WB20X0044 TRANSFORMER FOR OVEN CONTROL
WB07X0693 WB07X0693 TRIM
WB7X636 WB7X636 TRIM
WB7X273 WB7X273 TRIM **NLA*
WB02X1838 WB02X1838 TRIM - SWITCH
WB07X0636 WB07X0636 TRIM BOTTOM
WB2X1457 WB2X1457 TRIM BRACKET **NLA*
WB02X0996 WB02X0996 TRIM CLIP
WB02X2271 WB02X2271 TRIM CLIP(ALL BC MODELS)
WB07X0729 WB07X0729 TRIM MIDDLE
WB07X0273 WB07X0273 TRIM PLATE
WB2X3429 WB2X3429 TRIM SWI PKG
WB07X0695 WB07X0695 TRIM WINDOW
WB07X0696 WB07X0696 TRIM(ALL BC MODELS)
WB38X0064 WB38X0064 VENT
WB02X2408 WB02X2408 VENT COVER
WZ2X513D WZ2X513D W SCREW-PKG 12 **NLA*
WZ10X0017 WZ10X0017 WASHER
WZ10X0016 WZ10X0016 WASHER
WB02X1835 WB02X1835 WASHER
WB01X0445 WB01X0445 WASHER
WB02X1847 WB02X1847 WASHER MT. COVER
WZ10X17D WZ10X17D WASHR PKG 12
WB1X119D WB1X119D WASHR-PKG 12
WZ10X16D WZ10X16D WASHR-PKG 12
WB24X162 WB24X162 WB24X162
WB36X0270 WB36X0270 WINDOW
WB36X270 WB36X270 WINDOW
Main Menu x
