Manufacturer
GE
Model Number
JK3500DF1WW
Description
Electric Range
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
340531 |
|
|
6-19 X 1/4 TORX PAN HEAD |
|
|
BLOCK TERMINAL |
|
|
BOARD DAUGHTER RELAY 6 |
|
|
BOARD FAN SENSOR |
|
|
BOARD RJ45 CONNECTOR |
|
|
BOARD SENSOR |
|
|
BRACE VERT ASM (LT) |
|
|
BRACE VERTICAL LEFT BLK |
|
|
BRACE VERTICAL RIGHT BLK |
|
|
BRACKET FAN MOUNT LOWER |
|
|
BRACKET UPPER FAN MOUNT |
|
|
BUMPER DOOR |
|
|
CHANNEL AIR REAR LEFT |
|
|
CHANNEL LOWER AIR |
|
|
CHANNEL REAR |
|
|
CHANNEL UPPER AIR VENT |
|
|
CONDUIT WIRE ASM |
|
|
CONDUIT WIRE ASSEMBLY |
|
|
CONTOURED WASHER |
|
|
CONTROL BOARD T012 ELE |
|
|
CONTROL PANEL |
|
|
COOLING FAN |
|
|
COOLING FAN LOWER |
|
|
COVER - UPPER REAR DUCT |
|
|
COVER BOTTOM AIR DUCT |
|
|
COVER HIDDEN BAKE |
|
|
COVER LOWER REAR DUCT |
|
|
COVER TOP FRONT |
|
|
COVER TOP LEFT EDGE |
|
|
COVER TOP REAR |
|
|
COVER TOP RIGHT EDGE |
|
|
COVER WIRE REAR |
|
|
DEFLECTOR OVEN DOOR 27 |
|
|
DIVIDER AIR CENTER |
|
|
DIVIDER AIR DUCT RIGHT |
|
|
DOOR GLASS &TRIM WHITE |
|
|
DOOR GLASS &TRIM WHITE |
|
|
DOOR GLASS AND TRIM WH |
|
|
ELEMENT BAKE |
|
|
ELEMENT BROIL ASM |
|
|
EXTENSION REAR |
|
|
EXTENSION SIDE |
|
|
FOIL NSULATION BAKE |
|
|
GASKET OVEN DOOR |
|
|
GASKET OVEN DOOR |
|
|
GLASS OVEN WINDOW |
|
|
GROMMET |
|
|
HANDLE WHITE |
|
|
HARNESS WIRE LATCH COM |
|
|
HARNESS WIRE MAIN |
|
|
HEX NUT |
|
|
HINGE DOOR LEFT |
|
|
HINGE DOOR RIGHT |
|
|
HOUSING RJ45 ASM |
|
|
INSULATION BOTTOM TRIM |
|
|
INSULATION DOOR SIDES |
|
|
INSULATION DOOR SIDES |
|
|
INSULATION DOOR TOP |
|
|
INSULATION HIDDEN BAKE |
|
|
INSULATION TOP |
|
|
JUMPER |
|
|
LABEL WIRE DIAGRAM |
|
|
LAMP HALOGEN ASM |
|
|
LAMP HALOGEN BULB G9 |
|
|
LATCH ASSEMBLY |
|
|
LENS OVEN LIGHT |
|
|
LINER OVEN DOOR ASM |
|
|
LOCK NUT |
|
|
MOUNTING PANEL |
|
|
NUT HEX M4-.7 THREAD |
|
|
OVERLAY WHITE |
|
|
PM INSTALL INSTRUCTIONS |
|
|
PM INSTRUCTIONS INSTALL |
|
|
PM MANUAL MINI & WD ASM |
|
|
PM MANUAL USE & CARE |
|
|
RACK OVEN |
|
|
RETAINER INSLN BACK |
|
|
RETAINER INSLN OVEN DOOR |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW 10-32 TR T |
|
|
SCREW 1016 2 1/2 IN T20 |
|
|
SCREW 719 1/4HEX 1/2IN |
|
|
SCREW GROUND |
|
|
SCREW HANDLE SUPPORT |
|
|
SCREW ST10-16 X 7/16"" |
|
|
SCREW-BLACK |
|
|
SCREW-BLK |
|
|
SENSOR ASM |
|
|
SPACER HINGE |
|
|
SPACER OVEN WINDOW |
|
|
STANDOFF PCB |
|
|
SUPPORT DOOR LINER |
|
|
SUPPORT DOOR LINER |
|
|
SUPPORT HANDLE |
|
|
SWITCH HIGH LIMIT |
|
|
SWITCH LIMIT |
|
|
SWITCH SPDT HIGH AMP |
|
|
TRIM BOTTOM CABINET WH |
|
|
TRIM VENT LWR |
|
|
TRIM VENT MID |
|
|
TRIM VENT UPR |
|
|
TRIM VERTICAL SIDE WHITE |
|
|
WASHER CONTOURED |
|
|
WASHR-PKG 12 |
