GE

Model Number

JRP24BD2BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
WB1K5200 WB1K5200 340531
WB20T10008 WB20T10008 ATEA THERMOSTAT
WB2X7694 WB2X7694 BAIL
WB38K5058 WB38K5058 BARRIER VENT
WB1K5133 WB1K5133 BLB RET CLIP
WB63K5116 WB63K5116 BOTTOM CAB
WB02X9634 WB02X9634 BOTTOM CHANNEL
WB2K5406 WB2K5406 BRACKET
WB44K5009 WB44K5009 BROIL ELEMENT
WB02X9719 WB02X9719 BROIL ELEMENT SUPPORT
WB2K5173 WB2K5173 CAB TOP RET
WB37K5017 WB37K5017 CABINET BACK
WB35K5066 WB35K5066 CABINET TOP INSULATION
WD01X1444 WD01X1444 CAMERA LENS (RED)
WB2X9634 WB2X9634 CHANNEL
WB01K5209 WB01K5209 CLIP
WB1K5209 WB1K5209 CLIP
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K10073 WB02K10073 CLIP CAPILLARY
WB2K5126 WB2K5126 COND CLAMP
WB02K5126 WB02K5126 CONDUIT CLAMP
WB18X30615 WB18X30615 CONDUIT WIRE ASSEMBLY
WB18X32567 WB18X32567 CONDUIT WIRE ASSEMBLY
WB37K5041 WB37K5041 CONTROL HOUSING
WB37K5040 WB37K5040 CONTROL HOUSING TOP
WB27T10477 WB27T10477 CONTROL OVN ERC3B
WB02K5406 WB02K5406 CONTROL PANEL BRACKET
WB02X9152 WB02X9152 COVER
WB2X9152 WB2X9152 COVER
WB34K5068 WB34K5068 COVER LATCH OPNG
WB02X9642 WB02X9642 COVER PLATE
WB2X9642 WB2X9642 COVER PLATE
WB02K5164 WB02K5164 CUP LIGHT SUPPORT
WB55K5075 WB55K5075 DOOR FRAME-BLACK
WB35K5054 WB35K5054 DOOR INSULATION
WB34K5228 WB34K5228 DOOR LOCK PLAT
WB55T10009 WB55T10009 DOOR PLUG
WB32K5050 WB32K5050 DOOR SEAL
WB2K5172 WB2K5172 DR SPRG RET
WB18T10032 WB18T10032 DR SW WIRE HARNESS
WB44T10007 WB44T10007 ELEMENT BAKE
WB44K5013 WB44K5013 ELEMENT BAKE UPR
WB36T10065 WB36T10065 END CAP LT-B
WB36T10064 WB36T10064 END CAP RT-B
WB07K5121 WB07K5121 EXTENSION VENT TRIM
WB26K5072 WB26K5072 FAN
WB63T10013 WB63T10013 FRONT FRAME
WB36X0779 WB36X0779 GLASS DOOR-CENTER
WB2M1 WB2M1 GLASS RETNR
WB02K5147 WB02K5147 GLASS SPACER
WB36X779 WB36X779 GLASS-CENTER
WB57M0022 WB57M0022 GLASS-OVEN DOOR -INNER
WB57M22 WB57M22 GLS OV DR-IN
WB01X1260 WB01X1260 GROUND WASHER
WB1X1260 WB1X1260 GRUND WASHER
WB15K5087 WB15K5087 HANDLE ASSEMBLY (BLACK)
WB18K5645 WB18K5645 HARNESS WIRE LOCK MTR
WB18T10288 WB18T10288 HARNESS WIRE MAIN
WB34X26884 WB34X26884 HEAT REFLECTOR
WB34K5249 WB34K5249 HEAT SHIELD
WB14K5007 WB14K5007 HINGE OV DR LT
WB14K5006 WB14K5006 HINGE OV DR RT
WB07K5478 WB07K5478 I-BROW TRIM-BLK
WB7K5478 WB7K5478 I-BROW TRM-B
WB25X0092 WB25X0092 INDICATOR LIGHT
WB02K5173 WB02K5173 INS CABINET TOP RETAINER
WB02K5172 WB02K5172 INS DR SPRING RETAINER
WB02K5180 WB02K5180 INS OV SIDE RETAINER
WB35K5068 WB35K5068 INSULATION WRPR OTR
WB35K5067 WB35K5067 INSULATION-BACK BTM-LOW
WB35K5057 WB35K5057 INSULATION-BACK/BTM UPPER
WB35K5041 WB35K5041 INSULATION-INNER WRAP-LO
WB35K5048 WB35K5048 INSULATION-WRAPPER-INNER
WB24K5061 WB24K5061 JAMB SWITCH
WB03T10178 WB03T10178 KNOB THMST (BLK)
WB36X192 WB36X192 LAMP COV ASM
WD1X1444 WD1X1444 LENS
WB2K5164 WB2K5164 LGHT CUP SUP
WB02X7694 WB02X7694 LIGHT CAMERA LENS BAIL
WB25T10039 WB25T10039 LIGHT INDICATOR
WB24K5085 WB24K5085 LIMIT SWITCH
WB15K5016 WB15K5016 LOCK LEVER ASM
WB49T10020 WB49T10020 LOCK MOTOR
WB63K5113 WB63K5113 MAIN BACK
49-80105 49-80105 MANUAL USE & CARE
WB2K5132 WB2K5132 ODR STIF ASM
WB02K5171 WB02K5171 OV BTM INS RETAINER-UPP
WB34K5077 WB34K5077 OV DR BAFFLE
WB02K5131 WB02K5131 OV DR GLASS RETAINER
WB02M0001 WB02M0001 OV DR GLASS RETAINER
WB02K5159 WB02K5159 OV DR INS RETAINER
WB57K5093 WB57K5093 OV DR INTERMEDIATE GLASS
WB02K5132 WB02K5132 OV DR LINING STIFFENER
WB57K5256 WB57K5256 OV DR OUTER GLASS-BLK
WB8X303 WB8X303 OV LAMP HLDR
WB08X0303 WB08X0303 OV LAMP HOLDER
WB02K5174 WB02K5174 OV TOP INS RETAINER-LO
WB2K5174 WB2K5174 OV TOP RET L
WB2K5171 WB2K5171 OVBT INS RET
WB2K5131 WB2K5131 OVDR GL RET
WB2K5159 WB2K5159 OVDR INS RET
WB9K5018 WB9K5018 OVDR SPRING
WB63T10012 WB63T10012 OVEN BODY
WB32K5037 WB32K5037 OVEN DOOR GASKET
WB55T10010 WB55T10010 OVEN DOOR LI
WB55T10011 WB55T10011 OVEN DOOR LI
WB09K5018 WB09K5018 OVEN DOOR SPRING
WB09K5017 WB09K5017 OVEN DOOR SPRING
WB02T10037 WB02T10037 OVEN LIGHT CUP
WB48X0218 WB48X0218 OVEN RACK
WB2K5180 WB2K5180 OVSD INS RET
WB36T10474 WB36T10474 PANEL CNTL ASM W/OLY
WB1K5071 WB1K5071 PLASTC RIVET
WB01K5071 WB01K5071 PLASTIC RIVET
WB2K5395 WB2K5395 PLATE REINFO
WB2X9587 WB2X9587 PLUG
WB2X9189 WB2X9189 PLUG BUT REC
WB03K5043 WB03K5043 PLUG BUTTON
WB3K5043 WB3K5043 PLUG BUTTON
WB02X9189 WB02X9189 PLUG BUTTON-RECTANGULAR
WB02X9587 WB02X9587 PLUG BUTTON-ROUND
WB35K5055 WB35K5055 PLUG INSULATION
WB63M0007 WB63M0007 RACEWAY
WB63M7 WB63M7 RACEWAY
WB48T10094 WB48T10094 RACK OVEN
WB7X7183 WB7X7183 RANGE BLACK OVEN HANDLE END CAP
WB36X0389 WB36X0389 RANGE OVEN BULB COVER
WB02K5395 WB02K5395 REINFORCEMENT PLATE
WB01X1173 WB01X1173 RIVET
WB1X1173 WB1X1173 RIVET
WB01X0521 WB01X0521 SCR 8/32 TF FLR 5/16 S
WB34T10066 WB34T10066 SCREEN FAN
WZ04X0044 WZ04X0044 SCREW
WB01X1253 WB01X1253 SCREW
WB01X1137 WB01X1137 SCREW
WB01X1127 WB01X1127 SCREW
WB01K5073 WB01K5073 SCREW
WB01K5200 WB01K5200 SCREW
WB01M0001 WB01M0001 SCREW
WB01K5028 WB01K5028 SCREW
WB01K5162 WB01K5162 SCREW
WB1X1293 WB1X1293 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WB1X536 WB1X536 SCREW
WB1K60 WB1K60 SCREW 8-18
WB01K0060 WB01K0060 SCREW 8-18 (BK) 1/2 S
WB1K5167 WB1K5167 SCREW 8-18 X 3/8
WB01K5167 WB01K5167 SCREW 8-18 X 3/8""
WB1K5191 WB1K5191 SCREW FL ZNC 10-32
WB01K5191 WB01K5191 SCREW FLAT ZINC 10-32
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB01X1293 WB01X1293 SCREW TC10-32X.250HEXNI
WB1X1130 WB1X1130 SCREW-10-32
WB1X1137 WB1X1137 SCREW-10AB
WB1X1118 WB1X1118 SCREW-6-32T 6-20 X 3/8
WB01X1180 WB01X1180 SCREW-BLACK
WB1K5162 WB1K5162 SCREW-BLACK
WB1K5157 WB1K5157 SCREW-BLK
WZ4X44D WZ4X44D SCREW-PKG 12
WB02M0030 WB02M0030 SCROLL BRACKET
WB2M30 WB2M30 SCROLL BRCKT
WB2X9168 WB2X9168 SEAL
WB02X9168 WB02X9168 SEAL GLASS OV DR INNER
WB21X5301 WB21X5301 SENSOR ASSEMBLY
WB63K5112 WB63K5112 SIDE CABINET
WB6K5026 WB6K5026 SMOKE EL SCR
WB06K5026 WB06K5026 SMOKE ELIM SCREEN
WB2K5147 WB2K5147 SPACER
WB02T10164 WB02T10164 SPACER FRT TRIM (BLK)
WB09T10007 WB09T10007 SPRING OVEN DR UPPER
WB2X9719 WB2X9719 SUPP-BROIL
WB24K5046 WB24K5046 SWITCH LIMIT
WB63K5120 WB63K5120 TOP CABINET
WB2K5256 WB2K5256 TOP INS RET
WB02K5256 WB02K5256 TOP INSULATION RETNR-UPP
WB07T10415 WB07T10415 TRIM FRT FRM LWR
WB1K5177 WB1K5177 TRIM SCREW 10-16 X 3/4 BLK
WB01K5177 WB01K5177 TRIM SCREW-BLACK
WB07K5263 WB07K5263 TRIM SIDE (RT OR LT)BLK
WB7K5123 WB7K5123 TRIM-I-BROW
WB07K5123 WB07K5123 TRIM-I-BROW BLK-CENTER
WB01K5133 WB01K5133 TSTAT BULB RET CLIP
WB48X10056 WB48X10056 UNIVERSAL RANGE BROILER PAN
WB38K5051 WB38K5051 VENT BOX ASSEMBLY
WB7K5121 WB7K5121 VENT TRIM EX
WB07K5491 WB07K5491 VENT TRIM-BLACK
WB7K5491 WB7K5491 VENT TRM-BLK
WB7K5263 WB7K5263 VERT SD TRIM
WB01X1254 WB01X1254 WASHER
WB1X119D WB1X119D WASHR-PKG 12
WB1X681 WB1X681 WB01X0681
WB02X9665 WB02X9665 WIRE COVER
WB2X9665 WB2X9665 WIRE COVER
WB34K5099 WB34K5099 WIRE SHIELD
