Model Image
Manufacturer

GE

Model Number

JSP42DN4BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
PM10X310 PM10X310 GE 28 CERAMA BR
WB1K5200 WB1K5200 GE 340531
40A15 40A15 GE 40WATT 15AMP INC AND ESCENT BULB
WB44T10069 WB44T10069 GE BAKE ELEMENT
WB63X28540 WB63X28540 GE BASE RIVET ASM
WB63X25881 WB63X25881 GE BASE RIVET ASM
WB26T10039 WB26T10039 GE BLOWER ASM
WB38T10019 WB38T10019 GE BOX VENT ASSEMBLY
WB02T10242 WB02T10242 GE BRACKET
WB02T10578 WB02T10578 GE BRACKET ANTITIP ASM
WB44T10071 WB44T10071 GE BROIL ELEMENT
WB61K10010 WB61K10010 GE BURNER BOX BOTTOM
WB01K5209 WB01K5209 GE CLIP
WB1K5209 WB1K5209 GE CLIP
WB02X10742 WB02X10742 GE CONTROL PANEL GASKET
WB02X9152 WB02X9152 GE COVER
WB02K5365 WB02K5365 GE COVER
WB2X9152 WB2X9152 GE COVER
WB2K5365 WB2K5365 GE COVER
WB34K10049 WB34K10049 GE COVER WIRE REAR
WB34T10054 WB34T10054 GE COVER WIRE RR LWR
WB02T10047 WB02T10047 GE CRYSTAL MOUNT
WB02T10046 WB02T10046 GE CRYSTAL RETAINER
WB01T10022 WB01T10022 GE DOOR BUMPER
WB57T10346 WB57T10346 GE DOOR OTR ASM 30 (BK)
WB57T10345 WB57T10345 GE DOOR OTR ASM 30 (BQ)
WB57T10344 WB57T10344 GE DOOR OTR ASM 30 (WH)
WB01T10026 WB01T10026 GE DOOR PAD
WB55T10180 WB55T10180 GE DRAWER BODY ASM
WB48T10013 WB48T10013 GE DRAWER SUPPORT FRT
WB30T10129 WB30T10129 GE ELEMENT RADIANT 6 IN
WB30T10132 WB30T10132 GE ELEMENT RADIANT 8 IN
WB30T10133 WB30T10133 GE ELEMENT RADIANT 9 DUAL
WB07K10155 WB07K10155 GE EXTENSION REAR
WB07T10498 WB07T10498 GE EXTENSION SIDE LT
WB07T10497 WB07T10497 GE EXTENSION SIDE RT
WB27K10306 WB27K10306 GE FACEPLATE (SCR-BK)
WB27K10307 WB27K10307 GE FACEPLATE (SCR-BQ)
WB27K10308 WB27K10308 GE FACEPLATE (SCR-WH)
WR02X10562 WR02X10562 GE FASTENER PUSH
WB63T10083 WB63T10083 GE FRAME FRT LOWER
WB02X10744 WB02X10744 GE GASKET FACEPLATE
WB02T10320 WB02T10320 GE GASKET MAINTOP LH
WB02T10319 WB02T10319 GE GASKET MAINTOP RH
WB04T10050 WB04T10050 GE GASKET OVEN DOOR
WB64X0093 WB64X0093 GE GLASS CLEANER
WB15T10187 WB15T10187 GE HANDLE (BK)
WB15T10186 WB15T10186 GE HANDLE (BQ)
WB15T10188 WB15T10188 GE HANDLE (WH)
WB18T10522 WB18T10522 GE HARNESS WIRE MAINTOP
WB10X30494 WB10X30494 GE HINGE DOOR LEFT
WB10X24381 WB10X24381 GE HINGE DOOR LT
WB10X20965 WB10X20965 GE HINGE DOOR RT
WB24T10026 WB24T10026 GE INF SWITCH CONTROL (2000W)
WB24T10012 WB24T10012 GE INF SWITCH CONTROL (WM)
WB36T10568 WB36T10568 GE INSERT CNTL PNL
31-10673 31-10673 GE INSTRUCTION INSTALL
WB35T10074 WB35T10074 GE INSULATION (OUT) LWR
WB35T10090 WB35T10090 GE INSULATION BACK & BTM
WB35K10025 WB35K10025 GE INSULATION OVEN DR SDE
WB35T10226 WB35T10226 GE INSULATION OVN DR SDE
WB35T10126 WB35T10126 GE INSULATION TOP
WB27T11076 WB27T11076 GE KEYPANEL SUPT ASM (BK)
WB27T11077 WB27T11077 GE KEYPANEL SUPT ASM (BQ)
WB27T11078 WB27T11078 GE KEYPANEL SUPT ASM (WH)
WB07T10681 WB07T10681 GE KIT BACKSPALSH (WH)
WB07T10682 WB07T10682 GE KIT BACKSPLASH (BQ)
WB03X26320 WB03X26320 GE KNOB INFINITE (BK)
WB03T10285 WB03T10285 GE KNOB INFINITE (BQ)
WB03T10282 WB03T10282 GE KNOB INFINITE (WH)
WB14T10069 WB14T10069 GE LATCH OVN
WB02X10521 WB02X10521 GE LEG LEVELER
WB25T10022 WB25T10022 GE LENS SNAP-IN
WB25T10056 WB25T10056 GE LIGHT INDICATOR
WB24T10060 WB24T10060 GE LIMIT SWITCH-UPPER(LOCK)
WB55T10179 WB55T10179 GE LINING OVN DR ASM
WB01K5046 WB01K5046 GE LOCKWASHER
WB62T10726 WB62T10726 GE MAINTOP GLASS ASM (BK)
WB62T10727 WB62T10727 GE MAINTOP GLASS ASM (BQ)
WB62T10728 WB62T10728 GE MAINTOP GLASS ASM (WH)
49-80602 49-80602 GE MANUAL USE & CARE
WB18T10349 WB18T10349 GE MODULE INDICATOR LIGHT
WB17T10021 WB17T10021 GE MOUNT TERMINAL BLOCK
WB25T10002 WB25T10002 GE OVEN BULB LENS COVER-
WB27T10416 WB27T10416 GE OVEN CONTROL (ERC3B)
WB57K5230 WB57K5230 GE OVEN DOOR GLASS-INNER
WB08T10002 WB08T10002 GE OVEN LAMP HO
WB56X22160 WB56X22160 GE PACK WINDOW ASSEMBLY
WB36T10668 WB36T10668 GE PANEL CNTL ASM
WB36T10667 WB36T10667 GE PANEL CNTL ASM
WB36T10666 WB36T10666 GE PANEL CNTL ASM
WB56T10267 WB56T10267 GE PANEL DRAWER
WB56T10270 WB56T10270 GE PANEL DRAWER
WB56T10268 WB56T10268 GE PANEL DRAWER
31-10781 31-10781 GE PM INSTALL INSTRUCTIONS
31-10780 31-10780 GE PM INSTRUCTIONS INSTALL
31-14957 31-14957 GE PM MANUAL MINI & WD ASM
WB48T10095 WB48T10095 GE RACK OVEN
WB07T10680 WB07T10680 GE RANGE OVEN BACKSPLASH KIT (BLACK)
WB07T10631 WB07T10631 GE RANGE SIDE TRIM - RIGHT - BLACK
WB10T10083 WB10T10083 GE RECEIVER HINGE
WB56T10321 WB56T10321 GE RETAINER GLASS OVN DR
WB56T10320 WB56T10320 GE RETAINER GLASS OVN DR
WB02X20948 WB02X20948 GE RETAINER INSLN BACK
WB02T10372 WB02T10372 GE RETAINER INSLN BTM
WB02T10371 WB02T10371 GE RETAINER INSLN OVN DR
WB02T10284 WB02T10284 GE RETAINER INSLN SDE
WB02T10343 WB02T10343 GE RETAINER INSLN TOP
WB02T10324 WB02T10324 GE SCR 6-20 GXB IHXW 3/8 NI
WH02X0941 WH02X0941 GE SCR 8-15 A HXW 7/8 S
WH02X1186 WH02X1186 GE SCR 8-18 AB IHW 5/8 S
WB01X0500 WB01X0500 GE SCR 8-18 B HXW 1/4 S
WB01X1178 WB01X1178 GE SCREW
WB01M0001 WB01M0001 GE SCREW
WB01X1137 WB01X1137 GE SCREW
WB01K5029 WB01K5029 GE SCREW
WB01K5200 WB01K5200 GE SCREW
WB01X0537 WB01X0537 GE SCREW
WB01K5028 WB01K5028 GE SCREW
WB1X1178 WB1X1178 GE SCREW
WB1X537 WB1X537 GE SCREW
WB1K5029 WB1K5029 GE SCREW
WH2X1186 WH2X1186 GE SCREW
WB1M1 WB1M1 GE SCREW
WB1X536 WB1X536 GE SCREW
WH2X930 WH2X930 GE SCREW
WB01X5364 WB01X5364 GE SCREW (CR)
WB01T10008 WB01T10008 GE SCREW 10-32 TR T
WB01T10017 WB01T10017 GE SCREW 8-18 AB IHW 3/8 S NS
WB1K5062 WB1K5062 GE SCREW 8-18 AB TRP 500 BQT
WB01T10053 WB01T10053 GE SCREW 8-32 TPT FLR 270
WB1X5364 WB1X5364 GE SCREW MTG
WB01K5150 WB01K5150 GE SCREW ST10-16 X 7/16""
WB01K5062 WB01K5062 GE SCREW ST8-18X.500TRBRNI
WB1X1137 WB1X1137 GE SCREW-10AB
WH2X941D WH2X941D GE SCREW-PKG 12
WB1X500D WB1X500D GE SCREW-PKG 12
WB23T10015 WB23T10015 GE SENSOR ASM
WB34T10059 WB34T10059 GE SHIELD VENT ASM
WB02T10034 WB02T10034 GE SIDE PANEL SUPPORT
WB02T10452 WB02T10452 GE SPACER REINFORCEMENT
WB09X40389 WB09X40389 GE SPRING RADIANT ELEMENT
WB02T10453 WB02T10453 GE STUD COMPOSITE
WB26T10015 WB26T10015 GE SUPPORT OVN CAV
WB02X33180 WB02X33180 GE SUPPORT REAR
WB02T10411 WB02T10411 GE SUPPORT SIDE PANEL
WB2K5238 WB2K5238 GE SW BRACKET
WB02K5238 WB02K5238 GE SWITCH BRACKET
WB24T10134 WB24T10134 GE SWITCH INF CNTL
WB24T10079 WB24T10079 GE SWITCH LIMIT
WB24T10160 WB24T10160 GE SWITCH SPDT HIGH AMP
WB17T10011 WB17T10011 GE TERMINAL BLOCK ASSEMBLY
WB07T10496 WB07T10496 GE TRIM ASM
WB07T10516 WB07T10516 GE TRIM FRT FRM (BK)
WB07T10521 WB07T10521 GE TRIM VERT SDE LT (BK)
WB07T10520 WB07T10520 GE TRIM VERT SDE RT (BK)
WB07T10524 WB07T10524 GE TRIM VERT SDE RT (BQ)
WB07T10522 WB07T10522 GE TRIM VERT SDE RT (WH)
WB07T10632 WB07T10632 GE TRIM VERT SIDE LT (BK)
WB07T10634 WB07T10634 GE TRIM VERT SIDE LT (BQ)
WB07T10636 WB07T10636 GE TRIM VERT SIDE LT (WH)
WB07T10633 WB07T10633 GE TRIM VERT SIDE RT (BQ)
WB38X33650 WB38X33650 GE TUBE VENT
WB28T10075 WB28T10075 GE VENT INLET DUCT
WB01K5174 WB01K5174 GE WASHER
WB1K5174 WB1K5174 GE WASHER
WB1K5046 WB1K5046 GE WASHER
WB48T10068 WB48T10068 GE WEDGE DRAWER
WB63T10085 WB63T10085 GE WRAPPER OVEN CAV
