Model Image
Manufacturer

GE

Model Number

JT1000DF1BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
WB1K5200 WB1K5200 340531
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB17K10001 WB17K10001 BLOCK TERMINAL
WB07X35692 WB07X35692 BRACE VERTICAL LEFT
WB07T10755 WB07T10755 BRACE VERTICAL LEFT BLK
WB07T10754 WB07T10754 BRACE VERTICAL RIGHT BLK
WB37X20231 WB37X20231 BRACKET CONTROL PNL MTG
WB37T10026 WB37T10026 BRACKET UPPER FAN MOUNT
WB03T10341 WB03T10341 BUMPER DOOR
WB34T10133 WB34T10133 CHANNEL AIR REAR LEFT
WB55X10971 WB55X10971 CHANNEL REAR
WB34T10150 WB34T10150 CHANNEL UPPER AIR VENT
WB18T10567 WB18T10567 CONDUIT WIRE ASM
WB01X0119 WB01X0119 CONTOURED WASHER
WB27X45466 WB27X45466 CONTROL OVEN T09
WB07T10722 WB07T10722 CONTROL PANEL
WB26T10066 WB26T10066 COOLING FAN
WB34T10136 WB34T10136 COVER - UPPER REAR DUCT
WB56X43352 WB56X43352 COVER BOTTOM AIR DUCT
WB55T10197 WB55T10197 COVER HIDDEN BAKE
WB34X28390 WB34X28390 COVER HOUSING FRT
WB34T10151 WB34T10151 COVER LOWER RT AIR DUCT
WB44T10126 WB44T10126 COVER TOP LEFT EDGE
WB34T10157 WB34T10157 COVER TOP REAR
WB34T10164 WB34T10164 COVER TOP RIGHT EDGE
WB35T10273 WB35T10273 COVER WIRE REAR
WB34T10142 WB34T10142 DEFLECTOR OVEN DOOR
WB34T10134 WB34T10134 DIVIDER AIR CENTER
WB56X27492 WB56X27492 DOOR GLASS AND TRIM BL
WB56X33188 WB56X33188 DOOR GLASS AND TRIM BL
WB34X31516 WB34X31516 DOOR INSULATION RETAINER
WB44T10129 WB44T10129 ELEMENT BAKE
WB44T10128 WB44T10128 ELEMENT BROIL ASM
WB35T10256 WB35T10256 FOIL INSULATION BAKE
WB35X26196 WB35X26196 GASKET OVEN DOOR
WB35X32825 WB35X32825 GASKET OVEN DOOR
WB04T10021 WB04T10021 GASKET OVEN LIGHT
WB56T10351 WB56T10351 GLASS OVEN WINDOW
WB01T10128 WB01T10128 GROMMET
WB15T10206 WB15T10206 HANDLE BLACK
WB18T10569 WB18T10569 HARNESS WIRE MAIN
WB01X1259 WB01X1259 HEX NUT
WB1X1259 WB1X1259 HEX NUT
WB10T10139 WB10T10139 HINGE DOOR LEFT
WB10T10138 WB10T10138 HINGE DOOR RIGHT
WB35X21666 WB35X21666 INSULATION BAKE
WB35T10274 WB35T10274 INSULATION BOTTOM TRIM
WB35X21672 WB35X21672 INSULATION DOOR SIDES
WB35X34930 WB35X34930 INSULATION DOOR SIDES
WB35X21737 WB35X21737 INSULATION DOOR TOP
WB35X33245 WB35X33245 INSULATION DOOR TOP 30
WB35X10019 WB35X10019 INSULATION TOP
229C6155P001 229C6155P001 LABEL WIRE DIAGRAM
WB63X32818 WB63X32818 LINER OVEN DOOR ASM
WB01T10127 WB01T10127 LOCK NUT
WB18T10578 WB18T10578 OPTIONAL 6 FT CONDUIT
WB25T10002 WB25T10002 OVEN BULB LENS COVER-
WB08T10002 WB08T10002 OVEN LAMP HO
WB48X31582 WB48X31582 OVEN RACK
WB27T11458 WB27T11458 OVERLAY
31-10662 31-10662 PM INSTALL INSTRUCTIONS
31-10856 31-10856 PM INSTRUCTIONS INSTALL
31-17017 31-17017 PM MANUAL MINI & WD ASM
49-80677 49-80677 PM MANUAL USE & CARE
WB48X24064 WB48X24064 RACK OVEN
WB63T10169 WB63T10169 RETAINER INSULATION BACK
WB01K5200 WB01K5200 SCREW
WB01K5072 WB01K5072 SCREW
WB1K5072 WB1K5072 SCREW
WB1M1 WB1M1 SCREW
WB1X1261 WB1X1261 SCREW
WH2X930 WH2X930 SCREW
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10129 WB01T10129 SCREW 1016 2 1/2 IN T20
WB01T10130 WB01T10130 SCREW 719 1/4HEX 1/2IN
WB01X1261 WB01X1261 SCREW GROUND
WB01T10135 WB01T10135 SCREW HANDLE SUPPORT
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB1K5165 WB1K5165 SCREW-BLACK
WB01K5165 WB01K5165 SCREW-BLK
WB21X10165 WB21X10165 SENSOR ASM
WB06T10018 WB06T10018 SPACER HINGE
WB37T10030 WB37T10030 SPACER OVEN WINDOW
WB34X28482 WB34X28482 SUPPORT DOOR LINER
WB34X46746 WB34X46746 SUPPORT DOOR LINER
WB02T10603 WB02T10603 SUPPORT HANDLE
WB24X46906 WB24X46906 SWITCH HIGH LIMIT
WB24T10179 WB24T10179 SWITCH LIGHT
WB24T10118 WB24T10118 SWITCH LIMIT BIMETAL
WB34X32773 WB34X32773 TOP REAR COVER KIT
WB07T10761 WB07T10761 TRIM BOTTOM CABINET
WB07T10796 WB07T10796 TRIM VENT LWR
WB07T10797 WB07T10797 TRIM VENT UPR BK
WB07X11402 WB07X11402 TRIM VERT SIDE BK
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
