Model Image
Manufacturer

GE

Model Number

JT5000SF6SS

Description

Electric Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB34T10134 WB34T10134 AIR DIVIDER
WB02X29479 WB02X29479 BADGE ASSEMBLY
WB27T11463 WB27T11463 BOARD FAN SE
WB07T10755 WB07T10755 BRACE VERTIC
WB07T10754 WB07T10754 BRACE VERTIC
WB07X35692 WB07X35692 BRACE VERTICAL LEFT
WB37T10026 WB37T10026 BRACKET UPPE
WB34T10150 WB34T10150 CHANNEL UPPE
WB02T10598 WB02T10598 COMPLETE FAN BLADE
WB18X35246 WB18X35246 CONDUIT WIRE ASM
WB01X0119 WB01X0119 CONTOURED WASHER
WB07T10745 WB07T10745 CONTROL PANEL
WB07X32471 WB07X32471 CONTROL PANEL MOUNTING BRACKET
WB37T10021 WB37T10021 CONVECTION COVER
WB44X21671 WB44X21671 CONVERSION ELEMENT
WB01T10079 WB01T10079 CONVERSION GASKET
WB35T10259 WB35T10259 CONVEX INSULATION
WB26X23813 WB26X23813 CONVEX MOTOR
WB56X43352 WB56X43352 COVER
WB34T10136 WB34T10136 COVER - UPPE
WB34X28390 WB34X28390 COVER HOUSING FRT
WB44T10126 WB44T10126 COVER TOP LE
WB34T10157 WB34T10157 COVER TOP RE
WB34T10164 WB34T10164 COVER TOP RIGHT
WB35T10273 WB35T10273 COVER WIRE R
WB03T10341 WB03T10341 DOOR BUMPER
WB34X31516 WB34X31516 DOOR INSULATION RETAINER
WB35X31513 WB35X31513 DOOR SIDE INSULATION
WH2X930 WH2X930 DRYER SCREW
WB37T10022 WB37T10022 DUCT CONVECT
WB26X31060 WB26X31060 FAN BLOWER
WB35X32825 WB35X32825 GASKET
WB35X21972 WB35X21972 GASKET BROIL
WB01T10128 WB01T10128 GROMMET
WB25T10102 WB25T10102 HALOGEN LAMP
WB25T10101 WB25T10101 HALOGEN LAMP
WB25X31221 WB25X31221 HALOGEN LAMP ASSEMBLY
WB25X31222 WB25X31222 HALOGEN LAMP ASSEMBLY
WB15X27281 WB15X27281 HANDLE
WB01X1259 WB01X1259 HEX NUT
WB1X1259 WB1X1259 HEX NUT
WB02X35585 WB02X35585 HEX NUT
WB55T10197 WB55T10197 HIDDEN COVER
WB49X21652 WB49X21652 HINGE BRACKET
WB10X30580 WB10X30580 HINGE DOOR LH
WB10X30579 WB10X30579 HINGE DOOR RH
WB27X20933 WB27X20933 HOUSING RJ45
31-10882 31-10882 INSTRUCTION INSTALL
WB35X33245 WB35X33245 INSULATION DOOR TOP 30-INCH
WB18X30704 WB18X30704 JUMPER
229C6291P003 229C6291P003 LABEL WIRE DIAGRAM
WB34X46746 WB34X46746 LINER SUPPORT
WB34T10151 WB34T10151 LOWER COVER
WB07X21187 WB07X21187 LOWER TRIM VENT
WB18X24030 WB18X24030 MAIN WIRE HARNESS
WB07T10740 WB07T10740 MOUNTING PAN
WB02T10608 WB02T10608 NUT HEX
WB18T10578 WB18T10578 OPTIONAL 6 F
WB27X29606 WB27X29606 OVEN CONTROL T012 WHITE LED
WB34T10142 WB34T10142 OVEN DEFLECTOR
WB35X21737 WB35X21737 OVEN INSULATION
WB35X34930 WB35X34930 OVEN INSULATION
WB34X31317 WB34X31317 OVEN LIGHT LENS
WB63X32818 WB63X32818 OVEN LINER
WB48X31582 WB48X31582 OVEN RACK
WB07T10786 WB07T10786 OVEN TRIM
31-10957 31-10957 PM INSTALL INSTRUCTIONS
31-17158 31-17158 PM MANUAL MINI & WD ASM
49-80722 49-80722 PM OWNERS MANUAL
WB24X46906 WB24X46906 RANGE HIGH-LIMIT THERMOSTAT
WB24T10147 WB24T10147 RANGE OVEN DOOR SWITCH
WB1K5072 WB1K5072 RANGE SCREW
WB1X1261 WB1X1261 RANGE SCREW
WB1M1 WB1M1 RANGE SCREW
WB1X119D WB1X119D RANGE WASHER, 12-PACK
WB34X21910 WB34X21910 REAR CHANNEL
WB55X10971 WB55X10971 REAR CHANNEL
WB01T10008 WB01T10008 SCR 10-32 TR
WB01K5072 WB01K5072 SCREW
WD02X10129 WD02X10129 SCREW
WB01X21742 WB01X21742 SCREW
WB01X32746 WB01X32746 SCREW
WB01T10130 WB01T10130 SCREW 7-19 1
WB01T10134 WB01T10134 SCREW 8-18 T
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB01T10132 WB01T10132 SCREW, #10-32
WB01X1174 WB01X1174 SCREW-NICKLE
WB21X10165 WB21X10165 SENSOR ASSEMBLY
WB56X33178 WB56X33178 STAINLESS STEEL OUTER DOOR ASS
WB02T10093 WB02T10093 STANDOFF PCB
WB17K10001 WB17K10001 TERMINAL BLOCK
WB34X32773 WB34X32773 TOP REAR COVER KIT
WB07T10732 WB07T10732 TRIM VERT SI
WB07T10805 WB07T10805 VENT TRIM
WB44X21667 WB44X21667 WALL OVEN BAKE ELEMENT
WB44T10128 WB44T10128 WALL OVEN BROIL ELEMENT
WB02T10603 WB02T10603 WALL OVEN DOOR HANDLE MOUNTING BRACKET
WB10X23814 WB10X23814 WALL OVEN DOOR LOCK ASSEMBLY
WB56X33188 WB56X33188 WALL OVEN DOOR OUTER PANEL ASSEMBLY (STAINLESS)
WB01T10127 WB01T10127 WALL OVEN LOCK NUT
WB27T11116 WB27T11116 WALL OVEN NOISE FILTER BOARD
WB01T10131 WB01T10131 WALL OVEN SCREW, #10-32 X 2-1/2-IN
WB02X32440 WB02X32440 WASHER CONTOURED
WB56X27480 WB56X27480 WINDOW PACK
