Manufacturer

GE

Model Number

JTS3000EN1ES

Description

Single Electric Wall Oven

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB02X29479 WB02X29479 BADGE ASSEMBLY
WB17K10001 WB17K10001 BLOCK TERMINAL
WB27T11463 WB27T11463 BOARD FAN SENSOR
WB02X29179 WB02X29179 BOARD FRAME
WB27X31514 WB27X31514 BOARD WIFI CAT MODULE
WB27X33353 WB27X33353 BOARD WIFI CAT MODULE
WB07X35692 WB07X35692 BRACE VERTICAL LEFT
WB07T10755 WB07T10755 BRACE VERTICAL LEFT BLK
WB07T10754 WB07T10754 BRACE VERTICAL RIGHT BLK
WB37T10026 WB37T10026 BRACKET UPPER FAN MOUNT
WB03T10341 WB03T10341 BUMPER DOOR
WB55X10971 WB55X10971 CHANNEL REAR
WB34X21910 WB34X21910 CHANNEL REAR LEFT
WB34T10150 WB34T10150 CHANNEL UPPER AIR VENT
WB18X35246 WB18X35246 CONDUIT WIRE ASSEMBLY
WB27X33652 WB27X33652 CONTROL BOARD ASM
WB27X36806 WB27X36806 CONTROL BOARD ASM
WB07X32471 WB07X32471 CONTROL PANEL MOUNTING BRACKET
WB34T10136 WB34T10136 COVER - UPPER REAR DUCT
WB56X43352 WB56X43352 COVER BOTTOM AIR DUCT
WB55T10197 WB55T10197 COVER HIDDEN BAKE
WB34X28390 WB34X28390 COVER HOUSING FRT
WB34T10161 WB34T10161 COVER LATCH ACCESS
WB34T10151 WB34T10151 COVER LOWER RT AIR DUCT
WB44T10126 WB44T10126 COVER TOP LEFT EDGE
WB34T10157 WB34T10157 COVER TOP REAR
WB34T10164 WB34T10164 COVER TOP RIGHT EDGE
WB35T10273 WB35T10273 COVER WIRE REAR
WD02X10129 WD02X10129 DISHWASHER 6-19X1/4 TORX PAN HEAD SCREW
WB34T10134 WB34T10134 DIVIDER AIR CENTER
WB34X31516 WB34X31516 DOOR INSULATION RETAINER
WB02X32816 WB02X32816 DOOR LINER PLUG
WB35X31513 WB35X31513 DOOR SIDE INSULATION
WB44T10128 WB44T10128 ELEMENT BROIL ASSEMBLY
WB26X31060 WB26X31060 FAN BLOWER
WB35X21972 WB35X21972 GASKET BROIL ELEMENT
WB01T10128 WB01T10128 GROMMET
WB25X31221 WB25X31221 HALOGEN LAMP ASSEMBLY
WB01X1259 WB01X1259 HEX NUT
WB1X1259 WB1X1259 HEX NUT
WB44X21667 WB44X21667 HIDDEN BAKE ELEMENT KIT
WB49X21652 WB49X21652 HINGE BRACKET ASSEMBLY KIT
WB10X35066 WB10X35066 HINGE DOOR LEFT
WB10X35065 WB10X35065 HINGE DOOR RT
WB02X20265 WB02X20265 HOUSING TRANSCEIVER
31-10882 31-10882 INSTRUCTION INSTALL
WB35X33245 WB35X33245 INSULATION DOOR TOP 30-INCH
WB35X21737 WB35X21737 INSULATION DR TOP
WB18X30704 WB18X30704 JUMPER
WB25T10102 WB25T10102 LAMP HALOGEN BULB G9
WB10X28391 WB10X28391 LATCH ASSEMBLY
WB18X33365 WB18X33365 LATCH COM HARNESS WIRE
WB34X46746 WB34X46746 LINER SUPPORT
WB01T10127 WB01T10127 LOCK NUT
WB18X32833 WB18X32833 MAIN HARNESS WIRE
49-80597 49-80597 MANUAL U&C TIP SHEET
WB18T10578 WB18T10578 OPTIONAL 6 FT CONDUIT
WB35X32825 WB35X32825 OVEN DOOR GASKET
WB63X32569 WB63X32569 OVEN DOOR LINER ASSEMBLY
WB34X31317 WB34X31317 OVEN LIGHT LENS
WB48X31582 WB48X31582 OVEN RACK
31-10957 31-10957 PM INSTALL INSTRUCTIONS
31-11161 31-11161 PM INSTALL INSTRUCTIONS
31-2000262 31-2000262 PM MINI MANUAL AND WIRING
49-2000253 49-2000253 PM OWNERS MANUAL
31-11013 31-11013 PM WI FI INSTRUCTIONS
WB02X32826 WB02X32826 REINFORCEMENT SPACER ASSEMBLY
WB63T10169 WB63T10169 RETAINER INSULATION BACK
WB24X33028 WB24X33028 RJ45 BRACKET
WB01X21650 WB01X21650 SCR 8-18 AB TRT20NBS 5/8
WB01K5072 WB01K5072 SCREW
WH2X930 WH2X930 SCREW
WB01X21742 WB01X21742 SCREW
WB1X1261 WB1X1261 SCREW
WB1M1 WB1M1 SCREW
WB1K5072 WB1K5072 SCREW
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10130 WB01T10130 SCREW 7-19 1/4HEX 1/2IN
WB01X1261 WB01X1261 SCREW GROUND
WB01K5150 WB01K5150 SCREW ST10-16 X 7/16""
WB1K5165 WB1K5165 SCREW-BLACK
WB01K5165 WB01K5165 SCREW-BLK
WB21X10165 WB21X10165 SENSOR ASSEMBLY
WB56X32835 WB56X32835 SLATE OUTER DOOR ASSEMBLY
WB27X39829 WB27X39829 SLATE UI LCD CONTROL PANEL
WB15X32827 WB15X32827 STAINLESS STEEL HANDLE AND END CAP
WB24X46906 WB24X46906 SWITCH HIGH LIMIT
WB34X32773 WB34X32773 TOP REAR COVER KIT
WB07T10761 WB07T10761 TRIM BOTTOM CABINET-SMALL
WB07X21187 WB07X21187 TRIM VENT LWR
WB07T10732 WB07T10732 TRIM VERT SIDE (BLACK)
WB18X32824 WB18X32824 UI COM AND RJ45 HARNESS
WB27X32834 WB27X32834 UI CONTROL PANEL
WB07X32831 WB07X32831 UPPER VENT TRIM
WB56X27480 WB56X27480 WINDOW PACK ASSEMBLY
