Model Image
Manufacturer

GE

Model Number

JVM1850DM1CC

Description

Microwave

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB56X10712 WB56X10712 BASE BOTTOM
WB56X10690 WB56X10690 BASE PLATE.
WB26X10090 WB26X10090 BLADE-FAN
WB02X11297 WB02X11297 BRACKET BARRIER
WB06X10325 WB06X10325 BRACKET-MGT
WB06X10165 WB06X10165 BRACKET-V/T MOTOR
WB36X10213 WB36X10213 BULB HALOGEN (120V 20W)
WB25X10019 WB25X10019 BULB HALOGEN (120V 20W)
WB06X10126 WB06X10126 BUTTON-LOCK.
WB27X10170 WB27X10170 CAPACITOR- MOTOR
WB56X10714 WB56X10714 CASE OUTER
WB06X10290 WB06X10290 COVER-FRONT
WB36X10217 WB36X10217 COVER-GLASS
WB06X10130 WB06X10130 COVER-STIRRER
WB55X10855 WB55X10855 DOOR A
WB56X10715 WB56X10715 DOOR BQ
WB55X10856 WB55X10856 DOOR C
WB55X10444 WB55X10444 DOOR MAIN ASSEMBLY
WB26X10092 WB26X10092 DUCT REAR ASSEMBLY
WB26X10091 WB26X10091 DUCT-UPPER
WB24X799 WB24X799 EXPANDED PART
WB06X10332 WB06X10332 FILM-DOOR
WB06X10596 WB06X10596 FILTER-AIR
WB01X10065 WB01X10065 FLANGE NUT
WB07X11023 WB07X11023 GRILLE
WB06X10001 WB06X10001 GUIDE ROLLER ASSEMBLY
WB27X10867 WB27X10867 H.V. TRANSFORMER
WB15X10221 WB15X10221 HANDLE BQ
WB06X10060 WB06X10060 HINGE PIN
WB06X10521 WB06X10521 HOLDER-RACK
WB06X0549 WB06X0549 HOLDER-SENSOR
WB6X549 WB6X549 HOLDER-SENSR
49-40538 49-40538 INSTRUCTIONS INSTALL
49-40174-1 49-40174-1 LABEL-COOKING GUIDE
WB06X10676 WB06X10676 LATCH-BODY
WB06X10128 WB06X10128 LEVER-S/W
WB06X10295 WB06X10295 MICROWAVE AIR GUIDE ASSEMBLY
WB36X10003 WB36X10003 MICROWAVE BULB - 40W
WB27X10011 WB27X10011 MICROWAVE CAPACITOR
WB02X10733 WB02X10733 MICROWAVE CHARCOAL FILTER
WB07X11024 WB07X11024 MICROWAVE CONTROL PANEL - BISQUE
WB06X10129 WB06X10129 MICROWAVE DAMPER COVER
WB27X10597 WB27X10597 MICROWAVE DIODE
WB05X10005 WB05X10005 MICROWAVE DOOR LATCH
WB26X10037 WB26X10037 MICROWAVE FAN DRIVE MOTOR
WB06X10331 WB06X10331 MICROWAVE FAN MOTER
WB49X10063 WB49X10063 MICROWAVE GLASS TRAY
WB06X10447 WB06X10447 MICROWAVE HALOGEN BULB COVER
WB06X10436 WB06X10436 MICROWAVE HOOD DAMPER ASSEMBLY
WB06X10287 WB06X10287 MICROWAVE HVC BRACKET
WB02X11265 WB02X11265 MICROWAVE LIGHT BRACKET
WB36X10071 WB36X10071 MICROWAVE LIGHT LENS
WB27X10880 WB27X10880 MICROWAVE MAGNETRON
WB01X10180 WB01X10180 MICROWAVE MOUNTING FLAT BOLT
WB06X10122 WB06X10122 MICROWAVE POWER CORD BRACKET
WB08X10016 WB08X10016 MICROWAVE SOCKET LIGHT
WB05X10006 WB05X10006 MICROWAVE SPRING HOOK
WB06X10286 WB06X10286 MICROWAVE STIRRER/HOLDER
WB27X10166 WB27X10166 MICROWAVE THERMOSTAT
WB06X10124 WB06X10124 MICROWAVE TIP HOLDER
WB01X10071 WB01X10071 MICROWAVE TOP MOUNTING NUT
WB26X10208 WB26X10208 MICROWAVE TURNTABLE MOTOR
WB06X10144 WB06X10144 MICROWAVE TURNTABLE SHAFT
WB06X10446 WB06X10446 MICROWAVE UPPER DUCT BRACKET
31-40060 31-40060 MINI MANUAL
WB26X10191 WB26X10191 MOTOR VENTILATION
WB26X10089 WB26X10089 MOTOR-FAN
WB01X10181 WB01X10181 MOUNTING HARDWARE ASSEMBLY
WB56X10862 WB56X10862 MOUNTING PLATE W\MANUAL
WB02X11244 WB02X11244 NOISE FILTER
WB4X175 WB4X175 PCB SUPPORT
WB04X0175 WB04X0175 PCB SUPPORT.
WB18X10200 WB18X10200 POWER CORD ASSEMBLY
WB06X10464 WB06X10464 RANGE HOOD MOTOR COVER
WB27X10810 WB27X10810 RANGE THERMAL FUSE
WB27X10194 WB27X10194 RANGE THERMAL FUSE
49-40336 49-40336 REAR WALL TEMPLATE
WB36X10333 WB36X10333 SCREEN DOOR(B)
WB01X10084 WB01X10084 SCREW WASHER
WB27X10874 WB27X10874 SMART BOARD
WB08X10027 WB08X10027 SOCKET HAL/LAMP ASSEMBLY
WB06X10284 WB06X10284 SUPPORTER-CAVITY
WB24X830 WB24X830 SW-MONITOR
WB24X829 WB24X829 SW-SECONDARY
WB21X0535 WB21X0535 TCO -BOTTOM
49-40137-1 49-40137-1 TEMPLATE TOP
WB27X1127 WB27X1127 THERMO SW-TCO SENSE TEMP
49-40537 49-40537 USE & CARE
WB18X10340 WB18X10340 WIRE HARNESS - A
WB18X10057 WB18X10057 WIRE HARNESS -INCHS-INCH
WB48X10052 WB48X10052 WIRE RACK ASSEMBLY
