Manufacturer
GE
Model Number
JVM3160RF1SS
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
AIR BRACKET |
|
|
BASE PLATE |
|
|
BRACKET |
|
|
CAP (INTERIOR PARTS) |
|
|
CAPACITOR (OVEN CAVITY PARTS) |
|
|
CAVITY LAMP COVER |
|
|
CHARCOAL FILTER (OVEN CAVITY PARTS) |
|
|
CONTROL ASM, SS (CONTROLLER PARTS) |
|
|
CONTROL PANEL BRACKET (CONTROLLER PARTS) |
|
|
COUPLER (OVEN CAVITY PARTS) |
|
|
COVER CHOKE (DOOR PARTS) |
|
|
DAMPER |
|
|
DAMPER BRACKET (INTERIOR PARTS) |
|
|
DOOR ASM (DOOR PARTS) |
|
|
FAN (INTERIOR PARTS) |
|
|
FAN MOTOR |
|
|
FILTER NOISE (OVEN CAVITY PARTS) |
|
|
FUSE (OVEN CAVITY PARTS) |
|
|
GLASS LAMP |
|
|
GUIDE , FAN (INTERIOR PARTS) |
|
|
H.V.CAPACITOR (INTERIOR PARTS) |
|
|
H.V.TRANSFORMER (INTERIOR PARTS) |
|
|
HANDLE (DOOR PARTS) |
|
|
HANDLE SUPPORT (DOOR PARTS) |
|
|
HARNESS, MAIN (INTERIOR PARTS) |
|
|
HVDIODE (INTERIOR PARTS) |
|
|
INCANDESCENT LAMP, 30W (OVEN CAVITY PARTS) |
|
|
INCANDESCENT LAMP,40W (INTERIOR PARTS) |
|
|
INSTALLATI0N HARDWARE |
|
|
INSTALLATION INSTRUCTIONS |
|
|
INSTALLATION TEMPLATE |
|
|
LAMP COVER |
|
|
LAMP GLASS |
|
|
LATCH (DOOR PARTS) |
|
|
LATCH BOARD (OVEN CAVITY PARTS) |
|
|
LEVER SWITCH (OVEN CAVITY PARTS) |
|
|
MAGNETRON (OVEN CAVITY PARTS) |
|
|
MAIN BOARD (CONTROLLER PARTS) |
|
|
MEMBRANE SWITCH (CONTROLLER PARTS) |
|
|
MICRO SWITCH(ST AND ON) |
|
|
MICROWAVE GREASE FILTER |
|
|
MICROWAVE LATCH SPRING |
|
|
MICROWAVE MOTOR COVER VENT |
|
|
MICROWAVE SWITCH |
|
|
MINI MANUAL |
|
|
MOUNTING NUT BRACKET (INTERIOR PARTS) |
|
|
MOUNTING PLATE |
|
|
OUTER CASE |
|
|
PANEL-CONTROL MOUNTING |
|
|
POWER CORD ASM (INTERIOR PARTS) |
|
|
RANGE THERMOSTAT 70/40 |
|
|
ROTATING RING ASSEMBLY |
|
|
SCREW ST4*12 (OVEN CAVITY PARTS) |
|
|
SCREW ST4*12PWBHC (DOOR PARTS) |
|
|
SCREW ST4*20TBHC (INTERIOR PARTS) |
|
|
SCREW ST4*8PBHC (CONTROLLER PARTS) |
|
|
SOCKET LAMP |
|
|
SPACER |
|
|
SPRING LATCH |
|
|
SWITCH MICRO (OVEN CAVITY PARTS) |
|
|
THERMOSTAT, 110/0 (OVEN CAVITY PARTS) |
|
|
THERMOSTAT, 120/0 (INTERIOR PARTS) |
|
|
THERMOSTAT, 160/0 (OVEN CAVITY PARTS) |
|
|
TRAY |
|
|
TURN TABLE MOTOR |
|
|
USE AND CARE MANUAL |
|
|
VENT GRILLE (OVEN CAVITY PARTS) |
|
|
VENT MOTOR (OVEN CAVITY PARTS) |
|
|
WAVE GUIDE COVER (OVEN CAVITY PARTS) |
