Model Image
Manufacturer

GE

Model Number

P2B940SEJ3SS

Description

Dual Fuel Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB16X28654 WB16X28654 ASM. CAP, BURNER SMALL V2
WB36X24974 WB36X24974 BACKGUARD
WB34X25717 WB34X25717 BACKGUARD
WB16X20448 WB16X20448 BASE SPACER
WB16X20449 WB16X20449 BASE SPACER
WB27X31509 WB27X31509 BLOCK TERMINAL ASM
WB27X33353 WB27X33353 BOARD WIFI C
WB27X31514 WB27X31514 BOARD WIFI CAT MODULE
WB63K10041 WB63K10041 BOTTOM RANGE
WB63K0005 WB63K0005 BRACE BOTTOM
WB34X20456 WB34X20456 BRACE VENT
WB02X24939 WB02X24939 BRACKET
WB02X24940 WB02X24940 BRACKET
WB02K10052 WB02K10052 BRACKET MTG TERMINAL
WB02K0041 WB02K0041 BRACKET OVEN CORNER
WB02X22890 WB02X22890 BRACKET REGULATOR
WB28X20452 WB28X20452 BROILER SUPPORT
WB02K10171 WB02K10171 BUMPER
WB16X24722 WB16X24722 BURNER
WB16X24975 WB16X24975 BURNER AND P
WB29X24971 WB29X24971 BURNER ASSEMBLY
WB29X24972 WB29X24972 BURNER ASSEMBLY
WB21X25979 WB21X25979 BURNER VALVE
WB21X25002 WB21X25002 BURNER VALVE
WB02T10111 WB02T10111 CERAMA BRYTE STAINLESS STEEL BRIGHTENER
WB02K10023 WB02K10023 CLAMP-HEAT E
WB02X26569 WB02X26569 CLIP
WB02K0031 WB02K0031 CLIP CABLE
WB02K0052 WB02K0052 CLIP RANGETOP
WB02X7066 WB02X7066 CLIP WIRE
WB44X10051 WB44X10051 CONVECTION ELEMENT
WB21X20612 WB21X20612 COOKTOP BURNER VALVE
WB14K10003 WB14K10003 COOKTOP HINGE
WB28X24763 WB28X24763 COOKTOP HOLDER ORIFICE
WB28K10694 WB28K10694 COOKTOP ORIFICE SPUD
WB28K10693 WB28K10693 COOKTOP ORIFICE SPUD
WB28X24768 WB28X24768 COOKTOP ORIFICE SPUD
WB34X24745 WB34X24745 COVER
WB34K10140 WB34K10140 COVER
WB02K0004 WB02K0004 COVER ACCESS SPRING
WB34X24746 WB34X24746 COVER BACK L
WB34K10128 WB34K10128 COVER HEATIN
WB02K0024 WB02K0024 COVER VALVE
WB2K4 WB2K4 CVR ACC S
WB07X20288 WB07X20288 DOOR BARRIER
WB56X24827 WB56X24827 DOOR GLASS
WB34X24749 WB34X24749 DOOR GUARD
WB10X25550 WB10X25550 DOOR HINGE
WB10X24776 WB10X24776 DOOR HINGE
WB34X21570 WB34X21570 DOOR STIFFEN
WB02X24742 WB02X24742 DRAWER BRACKET
WB56X25101 WB56X25101 DRAWER LINER
WB56X25102 WB56X25102 DRAWER PANEL
WB04K10003 WB04K10003 DRAWER SEAL
WB28X24978 WB28X24978 DUAL OVAL OR
WB28X24977 WB28X24977 DUAL OVAL OR
WB18X26982 WB18X26982 ELECTRODE
WB13T10080 WB13T10080 ELECTRODE TO
WB07X29143 WB07X29143 END SUPPORT
WB07X29144 WB07X29144 END SUPPORT
WB02X8351 WB02X8351 FAN BLADE
WB34K10142 WB34K10142 FAN COVER
WB35K10013 WB35K10013 FAN INSULATION
WB35X20989 WB35X20989 FAN INSULATION
WB02K10170 WB02K10170 FAN SUPPORT
WB35X21685 WB35X21685 FIBER CORD
WB63K10048 WB63K10048 FIBER GLASS
WB01X1378 WB01X1378 FLAT WASHER-M4
WB02X28737 WB02X28737 FRAME FRONT BUMPER
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB63X27548 WB63X27548 FRAME WELD A
WB34X28742 WB34X28742 FRAME WINDOW ASSEMBLY
WB02T10589X WB02T10589X GE BADGE GRAY
WB31X24736 WB31X24736 GRATE ASM
WB2K8 WB2K8 GROMMET
WB2X646 WB2X646 GROUND PL
WB35X20420 WB35X20420 GUARD INSULATION
WB34K10054 WB34K10054 GUARD TERMINAL
WB02X24743 WB02X24743 HAND BRACKET
WB02X24744 WB02X24744 HAND BRACKET
WB18X24923 WB18X24923 HARNESS
WB18X24748 WB18X24748 HARNESS
WB18X25597 WB18X25597 HARNESS GROU
WB10X26564 WB10X26564 HINGE RECEIVER
WB28X24858 WB28X24858 HOLDER ORIFICE
WB28X24850 WB28X24850 HOLDER ORIFICE
WB02X20265 WB02X20265 HOUSING
WB02X24976 WB02X24976 IGNITER CLIP
WB16X24982 WB16X24982 INJECT TOP B
WB02X24728 WB02X24728 INJET
WB02X24727 WB02X24727 INJET
WB16X24983 WB16X24983 INJET
WB02X24725 WB02X24725 INJET, XL V2
WB34X24756 WB34X24756 INNER DOOR DEFLECTOR
WB35X24985 WB35X24985 INSULATION
WB35K10221 WB35K10221 INSULATION
WB35X21688 WB35X21688 INSULATION
WB35K10222 WB35K10222 INSULATION
WB35K10053 WB35K10053 INSULATION
WB35X21691 WB35X21691 INSULATION
WB35X21198 WB35X21198 INSULATION ASSEMBLY
WB02K10380 WB02K10380 INSULATION CLIP
WB35X24787 WB35X24787 INSULATION VENT TUBE
WB49X26120 WB49X26120 KIT COOKTOP BUMPER ASM
WB49X26562 WB49X26562 KIT DRAWER B
WB28X29255 WB28X29255 KIT HIGH ALT
WB28X29254 WB28X29254 KIT HIGH ALT
WB03X24990 WB03X24990 KNOB ASSEMBLY
WB10X24780 WB10X24780 LATCH
WB56X24760 WB56X24760 LINER DOOR W
WB01X26841 WB01X26841 LOCK WASHER
31-10994 31-10994 LP CONVERSION INST
WB49X25117 WB49X25117 LP CONVERSION KIT
WB36X32655 WB36X32655 MANIFOLD PANEL
WB28X25074 WB28X25074 MANIFOLD PIPE
WB34X20680 WB34X20680 MANIFOLD SUPPORT
WB28X24772 WB28X24772 MANIFOLD TUBE
WB08K10009 WB08K10009 MOTOR CAPACITOR
WB26X25118 WB26X25118 MOTOR PSC CO
WB02T10017 WB02T10017 NUT
WB01X1385 WB01X1385 NUT M4
WB2K41 WB2K41 ORIFICE BRACKET
WB35X23552 WB35X23552 OVEN
WB63X20437 WB63X20437 OVEN
WB63K10247 WB63K10247 OVEN
WB63K10249 WB63K10249 OVEN
WB63X20424 WB63X20424 OVEN
WB34K10038 WB34K10038 OVEN BACK CO
WB02X24790 WB02X24790 OVEN BUMPER
WB16X24721 WB16X24721 OVEN BURNER
WB16X24724 WB16X24724 OVEN BURNER
WB32K10044 WB32K10044 OVEN DOOR GASKET
WB32K10052 WB32K10052 OVEN DOOR GASKET
WB35X24786 WB35X24786 OVEN INSULATION
WB48X20990 WB48X20990 OVEN RACK
WB27X32207 WB27X32207 OVERLAY
WB56X22013 WB56X22013 PANEL
WB63X26606 WB63X26606 PANEL
WB63K10030 WB63K10030 PANEL REAR BROIL
WB63K0003 WB63K0003 PANEL SIDE BROIL LFT
WB63K0002 WB63K0002 PANEL SIDE BROIL RT
WB02X0646 WB02X0646 PLATE-GROUND
WB24X27550 WB24X27550 PLUNGER SWIT
49-85225 49-85225 PM GAS QUICK GUIDE
31-11000 31-11000 PM INSTALL INSTRUCTIONS
31-17181 31-17181 PM MINI MANUAL
49-85222 49-85222 PM ONLINE OWNERS MANUAL
31-11013 31-11013 PM WI FI INSTRUCTIONS
WB63K3 WB63K3 PNL SD BR
WB19K10018 WB19K10018 PRESSURE REGULATOR
WB20T10024 WB20T10024 PROBE THERMISTOR
WB02K10254 WB02K10254 RANGE ANTI-TIP BRACKET
WB63X20419 WB63X20419 RANGE BACK
WB30X46987 WB30X46987 RANGE BAKE ELEMENT
WB44K10011 WB44K10011 RANGE BAKE ELEMENT
WB63K5 WB63K5 RANGE BASE RAIL SUPPORT
WB30X46986 WB30X46986 RANGE BROIL ELEMENT
WB32K2 WB32K2 RANGE CONTROL PANEL FELT PAD
WB2X8351 WB2X8351 RANGE CONVECTION FAN BLADE
WB31X24998 WB31X24998 RANGE GRIDDLE
WB02X24941 WB02X24941 RANGE HOLDER
WB02X24942 WB02X24942 RANGE HOLDER
WB03X24991 WB03X24991 RANGE KNOB ASSEMBLY
WB02K10182 WB02K10182 RANGE LEVELING LEG
WB62X25085 WB62X25085 RANGE MAIN TOP
WB01K10037 WB01K10037 RANGE NUT
WB15X27280 WB15X27280 RANGE OVEN DOOR HANDLE ASSEMBLY
WB57K10174 WB57K10174 RANGE OVEN DOOR MIDDLE GLASS
WB48X21508 WB48X21508 RANGE OVEN RACK
WB1X5364 WB1X5364 RANGE SCREW
WB1K5119 WB1K5119 RANGE SCREW
WB01K10110 WB01K10110 RANGE SCREW
WB1X5754 WB1X5754 RANGE SCREW
WB1K5062 WB1K5062 RANGE SCREW
WB1X1261 WB1X1261 RANGE SCREW
WR01X10065 WR01X10065 RANGE SCREW
WB1X536 WB1X536 RANGE SCREW
WB1K78 WB1K78 RANGE SCREW
WB01K10091 WB01K10091 RANGE SCREW
WB1X5731D WB1X5731D RANGE SCREW, 12-PACK
WB13X26360 WB13X26360 RANGE SPARK MODULE
WB29K10023 WB29K10023 RANGE SURFACE BURNER CAP
WB28K10222 WB28K10222 RANGE SURFACE BURNER CAP
WB29K10045 WB29K10045 RANGE SURFACE BURNER CAP (BLACK)
WB29K10044 WB29K10044 RANGE SURFACE BURNER CAP, OUTER
WB31X24737 WB31X24737 RANGE SURFACE BURNER GRATE, CENTER
WB03X24988 WB03X24988 RANGE SURFACE BURNER KNOB
WB28K10107 WB28K10107 RANGE SURFACE BURNER ORIFICE
WB28K10834 WB28K10834 RANGE SURFACE BURNER ORIFICE
WB28K10023 WB28K10023 RANGE SURFACE BURNER ORIFICE
WB21X20470 WB21X20470 RANGE SURFACE BURNER VALVE
WB21X20472 WB21X20472 RANGE SURFACE BURNER VALVE
WB2K24 WB2K24 RANGE SURFACE BURNER VALVE GUARD
WB17T10011 WB17T10011 RANGE TERMINAL BLOCK
WB10X28563 WB10X28563 RECEIVER HINGE
WB34K10121 WB34K10121 RECEPTABLE A
WB1K44 WB1K44 SCEW LATC
WB01T10008 WB01T10008 SCR 10-32 TR
WB01K10067 WB01K10067 SCR 8 HD 1/4
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB01X5731 WB01X5731 SCREW
WB01K0021 WB01K0021 SCREW
WB01K0001 WB01K0001 SCREW
WB01X24735 WB01X24735 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5364 WB01X5364 SCREW (CR)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01X32512 WB01X32512 SCREW 10-24
WB01K0078 WB01K0078 SCREW 12-14, 5/8S
WB01X5754 WB01X5754 SCREW 8-18 ABT 1/2 S
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K0044 WB01K0044 SCREW DOOR LATCH
WB01X1261 WB01X1261 SCREW GROUND
WB01K10042 WB01K10042 SCREW, #8-18
WB24X25056 WB24X25056 SENSOR-UP OV
WB63K2 WB63K2 SIDE BROILER PANEL
WB39K10021 WB39K10021 SLIDE BEARING
WB39K10020 WB39K10020 SLIDE BEARING
WB38K10004 WB38K10004 SMOKE SUPPORT
WB02X20849 WB02X20849 SPACER
WB1K2 WB1K2 SPEED NUT
WB01K0002 WB01K0002 SPEEDNUT
WB63X20215 WB63X20215 SUPPORT BASE
WB63X20216 WB63X20216 SUPPORT BASE
WB35K10028 WB35K10028 SUPPORT CATALOG
WB18X27599 WB18X27599 SWITCH HARNESS
WB02K10029 WB02K10029 TERMINAL BRACKET
WB34K10029 WB34K10029 TERMINAL BUSHING
WB34X29145 WB34X29145 TOP COMPLEME
WB01K10072 WB01K10072 TRIM FRONT B
WB16X24999 WB16X24999 TRIPLE RING
WB28X25001 WB28X25001 TUBE DUAL VA
WB28X25000 WB28X25000 TUBE DUAL VA
WB38K10022 WB38K10022 VEN DIFFUSER
WB34X20294 WB34X20294 VENT ASSEMBLY
WB07X29141 WB07X29141 VENT COVER
WB08T10002 WB08T10002 WALL OVEN LIGHT ASSEMBLY
WB34K10141 WB34K10141 WINDOW FRAME
WB02X21679 WB02X21679 WIRE CLIP
WB02K10267 WB02K10267 WIRE CLIP
