Model Image
Manufacturer

GE

Model Number

PB960EJ5ES

Description

Electric Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
PM10X310 PM10X310 GE 28 CERAMA BR
40A15 40A15 GE 40WATT 15AMP INC AND ESCENT BULB
WB1X500D WB1X500D GE APPLIANCE SCREW, #8-18 X 1/4-IN, 12-PACK
WB34X28565 WB34X28565 GE BACKGUARD SHIELD HEAT
WB02X29479 WB02X29479 GE BADGE ASSEMBLY
WB63X25990 WB63X25990 GE BASE DUAL CAVITY
WB02T10353 WB02T10353 GE BASE RAIL
WB02T10352 WB02T10352 GE BASE RAIL
WB34X26004 WB34X26004 GE BRACE
WB02T10463 WB02T10463 GE BRACE CHASSI
WB34X25221 WB34X25221 GE BRACKET OVN HDL VNT TRM
WB34X42670 WB34X42670 GE BRACKET OVN HDL VNT TRM
WB02X25142 WB02X25142 GE BRACKET RADIANT ELEMENT
WB02T10542 WB02T10542 GE BRACKET STRAIN RELIEF
WB02X25982 WB02X25982 GE CABLE CLIP
WB02T10533 WB02T10533 GE CAPACITOR BRACKET
WB34X30702 WB34X30702 GE CHASSIS BRACE RADIANT LH
WB34X30703 WB34X30703 GE CHASSIS BRACE RADIANT RH
WB34X20082 WB34X20082 GE COMPLETE FAN COVER
WB34X25565 WB34X25565 GE CONTROL COVER
WB07X32021 WB07X32021 GE CONTROL PANEL TRIM ASSEMBLY DS
WB01T10079 WB01T10079 GE CONVERSION GASKET
WB34X42993 WB34X42993 GE COVER
WB34X20970 WB34X20970 GE COVER PLATE
WB02T10575 WB02T10575 GE COVER WIRE M
WB34X25638 WB34X25638 GE DOOR BRACKET
WB01T10022 WB01T10022 GE DOOR BUMPER
WB56X21404 WB56X21404 GE DOOR FRAME
WB10X30491 WB10X30491 GE DOOR HINGE L
WB10X30492 WB10X30492 GE DOOR HINGE RT
WB02X25272 WB02X25272 GE DOOR SPACER
WH2X930 WH2X930 GE DRYER SCREW
WB38T10033 WB38T10033 GE ELIMINATOR S
WB07X29534 WB07X29534 GE END PLATE LH DG
WB07X29535 WB07X29535 GE END PLATE RH DG
WB63X20010 WB63X20010 GE FRAME
WB63X20864 WB63X20864 GE FRAME
WB04T10074 WB04T10074 GE GASKET OVN L
WB64X0093 WB64X0093 GE GLASS CLEANER
WB08T10045 WB08T10045 GE HALOGEN LAMP
WB25X33021 WB25X33021 GE HALOGEN LAMP ASSEMBLY
WB15X24967 WB15X24967 GE HANDLE
WB10X25237 WB10X25237 GE HARNESS LATCH
WB18X32668 WB18X32668 GE HARNESS WIRE COM
WB18X25097 WB18X25097 GE HARNESS WIRE COM
WB02X20855 WB02X20855 GE HEAT SHIELD
WB18X32735 WB18X32735 GE HIDDEN BAKE HARNESS WIRE
WB18X32736 WB18X32736 GE HIDDEN BAKE UPPER HARNESS WIRE
WB10T10105 WB10T10105 GE HINGE ASSEMBLY
WB10T10104 WB10T10104 GE HINGE ASSEMBLY
WB10T10101 WB10T10101 GE HINGE RECEIVER
WB10T10100 WB10T10100 GE HINGE RECEIVER
WB10X30495 WB10X30495 GE HINGE RECEIVER
WB34X20009 WB34X20009 GE HOLE COVER
WB25T10050 WB25T10050 GE INDICATOR MODULE
31-10781 31-10781 GE INSTALLATION INSTRUCTIONS
31-10816 31-10816 GE INSTALLATION INSTRUCTIONS
31-10661 31-10661 GE INSTRUCTION INSTALL
WB35X25049 WB35X25049 GE INSULATION
WB35T10170 WB35T10170 GE INSULATION
WB35X25048 WB35X25048 GE INSULATION
WB35T10180 WB35T10180 GE INSULATION B
WB35X25122 WB35X25122 GE INSULATION BACK
WB35X25301 WB35X25301 GE INSULATION BACK
WB35X25077 WB35X25077 GE INSULATION BOTTOM
WB35T10235 WB35T10235 GE INSULATION M
WB18X30704 WB18X30704 GE JUMPER
229C6464P001 229C6464P001 GE LABEL WIRE DIAGRAM
WB25X24909 WB25X24909 GE LAMP HALOGEN ASM
WB18X31286 WB18X31286 GE LATCH AND HARNESS ASM
WB10X25238 WB10X25238 GE LATCH ASSEMBLY
WB18X30720 WB18X30720 GE LEAD WIRE 14 GA GN
WB34X31226 WB34X31226 GE MAIN BACK COVER
WB02T10026 WB02T10026 GE MAIN TOP STRIP
WB18X32733 WB18X32733 GE MAINTOP HARNESS WIRE
WB18X30760 WB18X30760 GE MAINTOP HARNESS WIRE
49-80597 49-80597 GE MANUAL U&C TIP SHEET
WB02T10289 WB02T10289 GE MICROWAVE STIRRER FAN BLADE
WB26X24910 WB26X24910 GE MOTOR PSC CO
WB02T10017 WB02T10017 GE NUT
WB2X8454 WB2X8454 GE NUT
WB56X39773 WB56X39773 GE OUTER DOOR PANEL ASM LWR
WB27X33136 WB27X33136 GE OVEN CONTROL AND OVERLAY ASM WHITE LED
WB27X33126 WB27X33126 GE OVEN CONTROL AND OVERLAY ASM WHITE LED
WB56X21397 WB56X21397 GE OVEN DOOR FRAME
WB04T10077 WB04T10077 GE OVEN DOOR GASKET
WB04T10076 WB04T10076 GE OVEN DOOR GASKET
WB35X30050 WB35X30050 GE OVEN DOOR INSULATION
WB35X30052 WB35X30052 GE OVEN DOOR INSULATION
WB35X30051 WB35X30051 GE OVEN DOOR INSULATION SIDE
WB35X30053 WB35X30053 GE OVEN DOOR INSULATION SIDE
WB25T10013 WB25T10013 GE OVEN LAMP LENS
WB63X20854 WB63X20854 GE OVEN LINER
WB63X20852 WB63X20852 GE OVEN LINER
WB48T10042 WB48T10042 GE OVEN RACK
WB02X20947 WB02X20947 GE OVEN SUPPORT
WB56T10244 WB56T10244 GE OVEN UPPER WINDOW PACK ASSEMBLY
WB63T10162 WB63T10162 GE OVEN WRAPPER
WB49T10071 WB49T10071 GE PAN REFLECTOR
WB02T10477 WB02T10477 GE PCB STANDOFF
WB18X32732 WB18X32732 GE PLUNGER SWITCH HARNESS
WB18X29244 WB18X29244 GE PLUNGER SWITCH HARNESS
31-17220 31-17220 GE PM MANUAL MINI & WD ASM
49-80770 49-80770 GE PM QUICK GUIDE
WB02X20902 WB02X20902 GE RADIANT BRACKET
WB09X40389 WB09X40389 GE RADIANT SPRING
WB02T10578 WB02T10578 GE RANGE ANTI-TIP BRACKET
WB44T10082 WB44T10082 GE RANGE BAKE ELEMENT
WB27T10662 WB27T10662 GE RANGE CONVECTION FAN MOTOR START CAPACITOR
WB44X45488 WB44X45488 GE RANGE DRIP PAN
WB02X10521 WB02X10521 GE RANGE LEVELING LEG
WB56X22160 WB56X22160 GE RANGE OVEN DOOR INNER GLASS
WB24T10147 WB24T10147 GE RANGE OVEN DOOR SWITCH
WB48T10059 WB48T10059 GE RANGE OVEN RACK
WB21X22134 WB21X22134 GE RANGE OVEN TEMPERATURE SENSOR
WB10T10116 WB10T10116 GE RANGE PIN
WB30X20871 WB30X20871 GE RANGE RADIANT SURFACE ELEMENT
WB30T10132 WB30T10132 GE RANGE RADIANT SURFACE ELEMENT
WB30T10155 WB30T10155 GE RANGE RADIANT SURFACE ELEMENT
WB1M1 WB1M1 GE RANGE SCREW
WB1X536 WB1X536 GE RANGE SCREW
WB30T10145 WB30T10145 GE RANGE SURFACE ELEMENT
WB30T10135 WB30T10135 GE RANGE SURFACE ELEMENT
WB17T10011 WB17T10011 GE RANGE TERMINAL BLOCK
WB34X30165 WB34X30165 GE RANGE TOP ENCLOSURE
WB62X28649 WB62X28649 GE RANGE TOP GLASS ASSEMBLY
WB27X25594 WB27X25594 GE RELAY BOARD
WB18T10352 WB18T10352 GE RELAY SWITCH
WB56T10318 WB56T10318 GE RETAINER INSERT
WB27X30706 WB27X30706 GE RJ45 CONNECTOR AND HARNESS
WB01T10008 WB01T10008 GE SCR 10-32 TR
WB1X5904 WB1X5904 GE SCR 8-18
WZ4X416 WZ4X416 GE SCR 8-18 AB HXW 3/4 S
WB01X0500 WB01X0500 GE SCR 8-18 B HXW 1/4 S
WB01X5904 WB01X5904 GE SCR 8-18 BA POR 3/4 SN
WB01M0001 WB01M0001 GE SCREW
WB01K5028 WB01K5028 GE SCREW
WB01K5200 WB01K5200 GE SCREW
WB1K5200 WB1K5200 GE SCREW
WB01K5150 WB01K5150 GE SCREW ST10-16 X 7/16""
WZ4X245D WZ4X245D GE SCREW, #8-18
WB01X21650 WB01X21650 GE SCREW, #8-18
WB44X21400 WB44X21400 GE SHIELD BROIL
WB63X28679 WB63X28679 GE SIDE PANEL DG
WB02T10034 WB02T10034 GE SUPPORT
WB02T10564 WB02T10564 GE TERMINAL COVER
WB24T10105 WB24T10105 GE THERMAL CONTROL RUNAWAY
WB07T10621 WB07T10621 GE TRIM VERTICA
WB34X25232 WB34X25232 GE TUBE VNT ASM LWR
WB18X32734 WB18X32734 GE UI COM HARNESS WIRE
WB18X30748 WB18X30748 GE UI COM HARNESS WIRE
WB56X30627 WB56X30627 GE UPPER OUTER
WB38T10035 WB38T10035 GE VENT TUBE
WB38X33648 WB38X33648 GE VENT TUBE
WB02T10371 WB02T10371 GE WALL OVEN DOOR INSULATION RETAINER PANEL
WB08T10002 WB08T10002 GE WALL OVEN LIGHT ASSEMBLY
WB25T10002 WB25T10002 GE WALL OVEN LIGHT LENS
WB23T10015 WB23T10015 GE WALL OVEN TEMPERATURE SENSOR
WB00X6723 WB00X6723 GE WASHER
